17 PCE BEARING RACE
AND SEAL DRIVER KIT
User Manual
07901

01
Thank you for purchasing a BlueSpot product, you can find further information
on our range at www.BlueSpot.uk.com. Please ensure that you are using the
product correctly and that all guidance and cautions are followed in accordance
with the instructions. Please retain these instructions for future reference.
General Information
Please make sure that you read these instructions carefully in order to avoid injury when
using the bearing race and seal driver kit. Follow all health and safety rules and regulations.
If in doubt and available please contact a more knowledgeable source.
DO NOT use if damaged.
• Maintain tool in good and clean condition for best and safest performance.
• Keep the work area clean, uncluttered and ensure there is adequate lighting.
• Maintain correct balance and footing. Ensure the floor is not slippery and wear
non-slip shoes.
• Keep children and unauthorised persons away from the work area.
• If any of the parts within the bearing race and seal driver kit are damaged do not use.
• ALWAYS ensure you have read the instructions fully and feel confident in how to use
the tool before beginning.
• ALWAYS dress appropriately – clothing should be close fitted and long hair tied back.
Jewellery should be removed.
• ALWAYS wear the correct eye protection when operating.
• ALWAYS strike the driver directly on the centre of the head.
• NEVER hit the tool at an angle or off centre.This can be dangerous and cause damage
to property or injury.
• NEVER strike the side of the driver body.
• ALWAYS ensure you are aware of the limitations of the driver you are using. If you do
not know the limitations check with the driver manufacturer before using and
familiarise yourself.
• ALWAYS check for damaged or worn parts before beginning. If damage is found,
replace before beginning. Damaged parts may be dangerous and could cause injury.
• ALWAYS check the driver before use to check for any damage. If damage is found,
replace before beginning. Damaged parts may be dangerous and could cause injury.
• NEVER use any parts of the bearing race and seal driver kit to perform a task that they
Safe use
were not designed for. Do not overload or misuse the tool.
• NEVER operate the tool if you are under the influence of drugs or alcohol as this
is dangerous.
• When you have completed the task intended always ensure the kit is stored away in its
original box and that is out of reach of children.

Please make sure that you read these instructions carefully in order to avoid injury when
using the bearing race and seal driver kit. Follow all health and safety rules and regulations.
If in doubt and available please contact a more knowledgeable source.
DO NOT use if damaged.
• Maintain tool in good and clean condition for best and safest performance.
• Keep the work area clean, uncluttered and ensure there is adequate lighting.
• Maintain correct balance and footing. Ensure the floor is not slippery and wear
non-slip shoes.
• Keep children and unauthorised persons away from the work area.
• If any of the parts within the bearing race and seal driver kit are damaged do not use.
• ALWAYS ensure you have read the instructions fully and feel confident in how to use
the tool before beginning.
• ALWAYS dress appropriately – clothing should be close fitted and long hair tied back.
Jewellery should be removed.
• ALWAYS wear the correct eye protection when operating.
• ALWAYS strike the driver directly on the centre of the head.
• NEVER hit the tool at an angle or off centre.This can be dangerous and cause damage
to property or injury.
• NEVER strike the side of the driver body.
• ALWAYS ensure you are aware of the limitations of the driver you are using. If you do
not know the limitations check with the driver manufacturer before using and
familiarise yourself.
• ALWAYS check for damaged or worn parts before beginning. If damage is found,
replace before beginning. Damaged parts may be dangerous and could cause injury.
• ALWAYS check the driver before use to check for any damage. If damage is found,
replace before beginning. Damaged parts may be dangerous and could cause injury.
• NEVER use any parts of the bearing race and seal driver kit to perform a task that they
02
Safe use (continued)
were not designed for. Do not overload or misuse the tool.
• NEVER operate the tool if you are under the influence of drugs or alcohol as this
is dangerous.
• When you have completed the task intended always ensure the kit is stored away in its
original box and that is out of reach of children.
Introduction
The BlueSpot 17 PCE Bearing Race and Seal Driver Kit is suitable for the installation of
straight races and seals into brake disc hubs without damage to the bearing or axle
housing.The collars will fit most standard wheel bearing sizes, including 4x4 vehicles and
are made from machined aluminium.The kit comes in a handy carrying case for quick and
easy storage.There are three driver sizes are used with a small hammer to insert the new
straight race into the brake disc hub.The adaptor should sit snugly within the race with
minimal movement to avoid any damage to the axle housing.The seal can then be installed
once the bearing placed within the race with the same sized adaptor and hammer.
Contains: 3 PCE Drivers 11.3mm, 14mm & 16.2mm I/D 10mm O/D 12mm, I/D 12mm
O/D 14mm, I/D 14mm O/D 16mm, I/D 15mm O/D 17mm, I/D 16mm O/D 18mm, I/D
18mm O/D 20mm, I/D 20mm O/D 22mm, I/D 22mm O/D 24mm, I/D 25mm O/D 27mm,
I/D 28mm O/D 30mm, I/D 30mm O/D 34mm, I/D 32mm O/D 36mm, I/D 35mm O/D
40mm, I/D 38mm O/D 42mm.
Operation
Choose the correct adaptor before beginning by choosing the one that is slightly smaller
than the diameter or the seal/bearing.
1. Select the correct adaptor and attach it securely on the handle/mandrel.
2. Align the adaptor against the seal/bearing assembly.
3. Place the adaptor against the seal/bearing race.
4. With your hammer tap the driver handle to force it into place.

03
ContactDistance to Spot SizeDisposal
To clean just use a dry cloth to wipe over the tool parts.
Cleaning & Maintenance
ContactDistance to Spot SizeDisposal
ALWAYS ensure the tools are stored out of reach of children.
Store the tool in a secure, dry place.
Storage
ContactDistance to Spot SizeDisposal
Cleaning & Maintenance
Notes
ContactDistance to Spot SizeDisposal
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and
packaging should be sorted, taken to a recycling centre and disposed of in a manner which is
compatible with the environment. When the product becomes completely unserviceable and
requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Environmental Protection
Always check and adhere to national regulations when disposing of any tools that are no longer
functional and cannot be repaired.
• Contact your local waste disposal authority for information on how to correctly
dispose of tools.
Disposal
