OPERATING AND MAINTENANCE INSTRUCTIONS MANUAL
RG1200 Roll Grooving Tool
WARNING
Original Instructions
WARNING
Failure to follow instructions and warnings could result in death,
serious personal injury, property damage, and/or product damage.
• Before operating or servicing any grooving tools, read all
instructions in this manual and all warning labels on the tool.
• Wear safety glasses, hardhat, foot protection, and hearing
protection while working around this tool.
• Save this operating and maintenance manual in a place
accessible to all operators of the tool.
If you need additional copies of any literature, or if you have questions concerning the safe
and proper operation of this tool, contact Victaulic, P.O. Box 31, Easton, PA 18044-0031,
Phone: 1-800-PICK VIC, E-Mail: pick[email protected].
REV_D
TM-RG1200

TABLE OF CONTENTS
Hazard Identification ................. 4
Operator Safety Instructions ............ 4
Introduction ....................... 6
Receiving The Tool ...................6
Container Contents ...................6
Returning The Tool ...................6
Tool Nomenclature................... 7
Tool Dimensions and Specifications ...... 8
Pre-Operation Checks and Adjustments .... 9
Grooving Rolls .......................9
Pipe Preparation .....................9
Tool Setup ........................10
Pipe Vise Setup .....................10
Groove-in-Place Setup ................10
Power Drive Setup ...................11
Grooving Operation ..................12
Manual Grooving ....................12
Powered Grooving ...................14
Roll Changing ......................15
Upper Roll Changing .................15
Lower Roll Changing .................16
Maintenance .......................17
Lubrication ........................17
Shear Pin Replacement ...............18
Parts Ordering Information .............18
Troubleshooting.....................19
Roll Groove Specifications ............ 20
EC Declaration of Incorporation .........21
3
REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual

HAZARD IDENTIFICATION
Definitions for identifying the various hazard
levels are provided below.
This safety alert symbol indicates
important safety messages. When
you see this symbol, be alert to the
possibility of personal injury.
Carefully read and fully understand the message
that follows.
DANGER
• The use of the word “DANGER” identifies
an immediate hazard with a likelihood
of death or serious personal injury if
instructions, including recommended
precautions, are not followed.
WARNING
• The use of the word “WARNING”
identifies the presence of hazards
or unsafe practices that could result
in death or serious personal injury if
instructions, including recommended
precautions, are not followed.
CAUTION
• The use of the word “CAUTION”
identifies possible hazards or unsafe
practices that could result in personal
injury and product or property damage
if instructions, including recommended
precautions, are not followed.
NOTICE
• The use of the word “NOTICE” identifies
special instructions that are important
but not related to hazards.
OPERATOR SAFETY
INSTRUCTIONS
The RG1200 Roll Grooving Tool is designed
for the sole purpose of grooving pipe. These
instructions must be read and understood by
each operator PRIOR to working with the
grooving tool. These instructions describe safe
operation of the tool, including set up and
maintenance. Each operator must become
familiar with the tool’s operations, applications,
and limitations. Particular care should be given
to reading and understanding the dangers,
warnings, and cautions described throughout
these operating instructions.
Operators shall follow all appropriate OSHA
guidelines and training. Use of this tool requires
dexterity and mechanical skills, as well as sound
safety habits. Although this tool is designed and
manufactured for safe, dependable operation,
it is difficult to anticipate all combinations of
circumstances that could result in an accident.
The following instructions are recommended
for safe operation of this tool. The operator
is cautioned to always practice “safety first”
during each phase of use, including set up and
maintenance. It is the responsibility of the lessee
or user of this tool to ensure that all operators
read this manual and fully understand the
operation of this tool.
Make this manual readily available in a clean,
dry area. Additional copies are available upon
request through Victaulic, or can be downloaded
at victaulic.com.
4REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual

DANGER
1. Avoid using the tool in potentially
dangerous environments. Do not expose
the tool to rain, and do not use the tool in
damp or wet locations. Keep the work area
well lit. Allow sufficient space to operate
the tool properly.
WARNING
1. Prevent back injury. Always follow OSHA
guidelines for safe lifting techniques when
handling tool components.
2. Wear proper apparel. Do not wear loose
clothing, jewelry, or anything that can
become entangled in moving parts.
3. Wear protective items when working with
tools. Always wear safety glasses, hardhat,
foot protection, and hearing protection.
4. Keep hands and tools away from power
drive chuck during grooving operation.
Rotation of the power drive can pinch or
entangle fingers and hands.
5. Do not reach inside pipe ends during tool
operation. Pipe edges can be sharp and
can snag hands and shirt sleeves.
7. Do not over-reach. Maintain proper
balance at all times. Verify that all controls
are easily accessible to the operator.
8. Do not make any modifications to the
tool. Do not remove any safety guarding
or any components that would affect tool
performance.
CAUTION
1. The RG1200 tool is designed ONLY for
grooving pipe sizes, materials, and wall
thicknesses as designated.
2. Inspect the equipment. Before using
the tool, check moveable parts for
obstructions. Ensure that tool components
are installed and adjusted in accordance
with setup instructions.
3. Stay alert. Do not operate the tool if you
are drowsy from medication or fatigue.
4. Keep visitors, trainees, and observers
away from the work area. All visitors should
be kept a safe distance from equipment
at all times, and should be offered the
opportunity to review this manual.
5. Keep work areas clean. Keep the
work area around the tool clear of any
obstructions that could limit movement of
the operator. Clean up any spills.
6. Secure the work, machine, and
accessories. Verify that the tool is stable.
Refer to the “Tool Setup” section.
7. Support the work. Support pipe lengths
with a pipe stand or vise.
8. Do not force the tool. Do not force the tool
or accessories to perform any functions
beyond the capabilities described in these
instructions. Do not overload the tool.
9. Maintain tool with care. Keep the
tool clean to ensure proper and safe
performance. Follow the instructions for
matching and lubricating tool components,
if applicable.
10. Use only Victaulic replacement parts
and accessories. Use of any other parts
may result in a voided warranty, improper
operation, and hazardous situations. Refer
to the “Parts Ordering Information” section.
11. Do not remove any labels from the tool.
Replace any damaged or worn labels.
5
REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual

INTRODUCTION
NOTICE
• Drawings and/or pictures in this manual
may be exaggerated for clarity.
• The tool, along with this operating
and maintenance instructions manual,
contains trademarks, copyrights, and/or
patented features that are the exclusive
property of Victaulic.
The Victaulic RG1200 Roll Grooving Tool is a
portable tool that can be used in conjunction
with a power drive for grooving pipe to be
compatible with Victaulic grooved piping
products. The standard RG1200 tool is
equipped to groove 2–6 inch/60.3–168.3 mm
Schedule 40 and 2–3 inch/60.3–88.9 mm
Schedule 80 carbon steel pipe to Victaulic’s
proprietary OGS-200 groove specifications. Do
NOT use the RG1200 on stainless pipe.
CAUTION
• This tool must be used ONLY for grooving
pipe with specifications that fall within
the designated parameters.
• Verify that the upper and lower grooving
rolls are a matched set.
Failure to follow these instructions could
damage the tool and cause product failure,
resulting in property damage or personal
injury.
RECEIVING THE TOOL
RG1200 tools are packed individually in canvas
tool bags. Save the original packaging for return
shipment of rental tools.
Upon receipt of the tool, ensure that all
necessary parts are included. If any parts
are missing, contact Victaulic.
CONTAINER CONTENTS
Qty. Description
1RG1200 Roll Grooving Tool
1Adjustable Ratchet with Swivel Handle
127 mm Deep Socket
1Roll Set for 2–3 inch/60.3–88.9 mm pipe
1Roll Set for 4–6 inch/114.3–168.3 mm pipe
1Power Drive Adapter
2Support Arm
2Hex Key (3 mm and 8 mm)
1Go/No-Go Groove Diameter Tape
1Groove Confirmation Gauge Set
10 Shear Pin
1Shear Pin Punch
2 Operating and Maintenance Instructions Manual
RETURNING THE TOOL
Prepare tool for shipment as received. Contact
Victaulic with questions.
6REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual

TOOL NOMENCLATURE
NOTICE
• Drawings and/or pictures in this manual may be exaggerated for clarity.
• The tool, along with this operating and maintenance instructions manual, contains
trademarks, copyrights, and/or patented features that are the exclusive property of
Victaulic.
Groove
Diameter
Adjustment
Nut
Carrying Handle
Lower Roll
Upper Roll
Shaft
Upper Roll
Assembly
Hand
Drive
Nut
Drive
Shaft
Upper Roll
Support
Arm Port
7
REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual

TOOL DIMENSIONS AND SPECIFICATIONS
5.17 in/
131.3 mm
8.75 in/
222.3 mm
5.80 in/
147.3 mm
1.34 in/
34.0 mm
10.35 in/
263.0 mm
4.88 in/
124.0 mm
10.35 in/
263.0 mm
3.27 in/
83.0 mm
2.05 in/
52.0 mm
Tool weight is 27.7 pounds/12.6 kilograms. Tool weight includes the tool housing only.
Tool sound pressure for manual use is below 70 dB(A). Tool sound pressure for powered use is
93 dB(A), while tool sound power is 99 dB(A). Sound measurements are taken with a Ridgid™
Model 300 power drive.
NOTE: Noise measurements are dependent on the power drive, and will vary based on
configuration. Always check the power drive manufacturer’s documentation for details.
™Ridgid is a registered trademark of Ridgid Tool Company
8REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual

PRE-OPERATION CHECKS AND
ADJUSTMENTS
Every Victaulic roll grooving tool is checked,
adjusted, and tested at the factory prior to
shipment. However, before operating the tool,
the following checks and adjustments should be
made to verify proper tool operation. In addition,
the tool should be inspected for any damage
that may have occurred during shipping and
handling.
DANGER
• Before making any tool
adjustments, disconnect
the power cord from the
electrical source.
Accidental startup of the tool
could result in serious personal
injury.
GROOVING ROLLS
Verify that the proper roll set is installed on the
tool for the pipe size to be grooved. Roll sets are
marked with the pipe size and part number. If
the proper roll set is not installed on the tool,
refer to the “Roll Changing” section.
CAUTION
• Verify that the upper and lower grooving
rolls are a matched set.
Failure to follow these instructions could
damage the tool and cause product failure,
resulting in property damage or personal
injury.
PIPE PREPARATION
For proper tool operation and production of
grooves that are within Victaulic specifications,
the following guidelines must be followed.
1. Victaulic recommends square-cut pipe with
grooved-end pipe products. Roll grooving
beveled-end pipe may result in unacceptable
flare, leaks, or joint failure.
2. Raised internal and external weld beads,
seams, and burrs must be ground flush with
the pipe surface, 2 inches/50 mm back from
the pipe ends.
3. All coarse scale, dirt, and other foreign
material must be removed from the interior
and exterior surfaces of the pipe ends.
CAUTION
• For maximum grooving roll life, remove
foreign material from the interior and
exterior surfaces of the pipe ends.
Foreign material may interfere with or
damage grooving rolls, resulting in leaks
and property damage.
9
REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual

TOOL SETUP
RG1200 tools can be used to groove pipe that
is supported by several different methods. Refer
to the setup instructions listed in this section for
different grooving options.
PIPE VISE SETUP
1. When grooving pipe that is supported with a
pipe vise, select a location for the tool and pipe
vise by taking into consideration the following
factors:
a. Adequate space to handle pipe lengths
b. A firm and level surface for the pipe vise
c. Anchoring requirements for the pipe vise
2. Mount a chain-type pipe vise onto a stand or
workbench. The pipe vise should be mounted
flush with, or slightly overhanging, the edge
of the stand or workbench. When the tool is
mounted on the pipe, the tool must be able
to rotate freely around the pipe without being
obstructed by the stand or workbench.
3. Secure a length of pipe in the pipe vise.
Pipe position and pipe vise anchoring must be
capable of handling the weight of the tool
(27.7 pounds/12.6 kilograms), plus the manual
effort required to operate the tool (approximately
75 ft-lbs/101.7 N•m of torque).
Position the pipe to overhang the pipe vise by
approximately 8 inches/203.2 mm, so that the
tool can rotate freely.
4. Mount the tool on the pipe, then turn the
groove diameter adjustment nut clockwise to
lower the upper roll until the tool rests snugly on
the pipe.
GROOVE-IN-PLACE SETUP
DANGER
• Depressurize and drain
the piping system before
attempting to adjust or
disassemble any Victaulic
piping products.
• Pipe hangers must be capable of handling
the weight of the tool and the manual
effort required to operate the tool.
Failure to follow these instructions could
result in death or serious personal injury
and property damage.
Previously installed pipe may be grooved
with a RG1200 tool, provided that the pipe
is supported securely and that the system is
completely depressurized and drained. Pipe
hangers must be capable of handling the weight
of the tool (27.7 pounds/12.6 kilograms), plus
the manual effort required to operate the tool
(approximately 75 ft-lbs/101.7 N•m of torque).
1. Ensure that there is adequate clearance
around the pipe to permit proper tool rotation
during the grooving process. Refer to the “Tool
Dimensions and Specifications” section.
2. Mount the tool on the pipe, then turn the
groove diameter adjustment nut clockwise to
lower the upper roll until the tool rests snugly on
the pipe.
10 REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual

POWER DRIVE SETUP
DANGER
• DO NOT connect electrical
power until instructed
otherwise.
Failure to follow this instruction
could result in serious personal
injury.
The RG1200 tool can be attached to a power
drive using the provided drive shaft adapter.
If necessary, contact Victaulic for more
information on the optional power drive height
adjustment bracket.
1. Remove all components from the packaging,
and ensure that all necessary items are
included. Refer to the “Receiving the Tool”
section.
2. Select a location for the power drive and tool
by taking into consideration the following factors:
a. The required power supply (refer to the
power drive manufacturer’s instructions)
b. Adequate space to handle pipe lengths
c. A firm and level surface for the power
drive
d. Adequate clearance around the tool for
adjustment and maintenance
3. Using a flat-head screwdriver, remove the
caps on the support arm ports.
4. Screw the support arms into the ports until
hand-tight. Do not overtighten.
5. Insert the power drive adapter into the power
drive until the adapter collar meets the drive
collet.
6. Insert the tool drive shaft into the power drive
adapter until the tool body meets the adapter.
11
REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual

7. Using the hex key provided, tighten
the shoulder bolt until hand-tight. Do not
overtighten.
8. Tighten the shoulder nut until hand-tight. Do
not overtighten.
9. Ensure that the tool is stable and is centered
on the power drive support arms.
GROOVING OPERATION
Before proceeding, verify that all instructions in
the previous sections of this manual have been
followed.
MANUAL GROOVING
1. Each rotation line around the groove diameter
adjustment nut signifies 0.016 inches / 0.4 mm
of groove diameter adjustment.
2. Using the provided handle, turn the hand
drive nut to begin grooving.
12 REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual

3. Alternate turning the groove diameter
adjustment nut with turning the hand drive nut.
Do NOT turn the groove diameter adjustment
nut more than 0.016 inches/0.4 mm (one line)
at once.
NOTICE
• Do NOT turn the groove diameter
adjustment nut more than 0.016
inches/0.4 mm (one line) at once.
Failure to follow this instruction could
overload the tool, resulting in reduced tool
life or tool damage.
4. To check the groove diameter during
grooving, use the groove confirmation gauge set
provided. Place the tab of the gauge lengthwise
into the groove. If there is space between the
long edge of the gauge and the pipe length
when the tab meets the bottom of the groove,
continue grooving. If there is no space, stop
grooving and measure with the provided
Go/No-Go Groove Diameter Tape.
NOTICE
• The groove confirmation gauge is
provided for convenience during the
grooving process. The final groove must
still be checked with the provided groove
diameter tape to ensure that it meets
Victaulic specifications.
5. While supporting the tool, loosen the groove
diameter adjustment nut and remove the tool
from the pipe.
6. Carefully check the groove diameter of
the pipe (“C” dimension) with the provided
Go/No-Go Groove Diameter Tape.
13
REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual

POWERED GROOVING
1. Each rotation line around the groove diameter
adjustment nut signifies 0.016 inches / 0.4 mm
of groove diameter adjustment.
2. Ensure that the tool is properly secured to the
power drive, as explained in the “Power Drive
Setup” section.
3. Plug the power drive cord into the provided
safety foot switch, as shown above. Refer to the
power drive manufacturer’s operating manual
for additional information.
Place the safety foot switch on the same side
of the tool as the power drive switch, with
adequate clearance for ease of use and to avoid
a tripping hazard.
WARNING
• The power drive must be operated with
a safety foot switch. If the power drive
is not supplied with a safety foot switch,
contact Victaulic.
Operating the tool without a safety foot
switch could result in serious personal
injury.
4. Turn the switch on the side of the power
drive to FWD (forward).
5. Alternate turning the groove diameter
adjustment nut with pressing the safety foot
switch. Do NOT turn the groove diameter
adjustment nut more than 0.016 inches/0.4 mm
(one line) at once.
NOTICE
• Do NOT turn the groove diameter
adjustment nut more than 0.016 inch/
0.4 mm (one line) at once.
Failure to follow this instruction could
overload the tool, resulting in reduced tool
life or tool damage.
14 REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual

6. To check the groove diameter during
grooving, use the groove confirmation gauge set
provided. Disconnect power, then place the tab
of the gauge lengthwise into the groove. If there
is space between the long edge of the gauge
and the pipe length when the tab meets the
bottom of the groove, continue grooving. If there
is no space, stop grooving and measure with
the provided Go/No-Go Groove Diameter Tape.
NOTICE
• The groove confirmation gauge is
provided for convenience during the
grooving process. The final groove must
still be checked with the provided groove
diameter tape to ensure that it meets
Victaulic specifications.
7. While supporting the tool, loosen the groove
diameter adjustment nut and remove the tool
from the pipe.
8. Carefully check the groove diameter of
the pipe (“C” dimension) with the provided
Go/No-Go Groove Diameter Tape.
ROLL CHANGING
The RG1200 Roll Grooving Tool is designed
with rolls to accommodate several pipe sizes,
eliminating the need for frequent roll changes.
When moving between 2–3 inch/60.3–88.9
mm pipe and 4–6 inch/114.3–168.3 mm pipe,
the upper and lower rolls must be changed.
DANGER
• Always disconnect the tool
from the electrical source
before changing rolls.
Failure to follow this
instruction could result in
serious personal injury.
UPPER ROLL CHANGING
This end (with
markings)
faces out
(away) from
tool body
1. Verify the appropriate roll size by checking
the marking on the edge of the roll.
2. Using the 3 mm hex key provided, loosen the
set screw on the side of the upper roll assembly.
15
REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual

3a. Remove the upper roll shaft by drawing it
out from the upper roll assembly.
3b. Remove the upper roll from the tool body.
GOOD
BAD
4. Place the alternate upper roll into the tool
body. Note the orientation of the upper roll. The
longer end of the upper roll, which contains the
size markings, shall face out (away) from the tool
body, as shown above.
5. Replace the upper roll shaft into the upper
roll assembly and re-tighten the set screw until
hand-tight.
LOWER ROLL CHANGING
1. Verify the appropriate roll size by checking the
marking on the front of the roll.
2. Using the 8 mm hex key provided, loosen the
set screw on the back of the drive shaft.
16 REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual

3. Grasp the drive shaft with one hand, then use
the other hand to pull the lower roll straight off
of the tool.
4. Replace the lower roll with the alternate size
provided.
5. Grasp the tool with one hand, then use the
other hand to push the lower roll into the tool.
6. Using the 8 mm hex key provided, tighten
the set screw on the back of the drive shaft to
hand-tight.
MAINTENANCE
This section provides information about keeping
the tool in proper operating condition.
LUBRICATION
1. After every 8 hours of operation, lubricate the
two grease fittings on the tool with a No. 2EP
lithium-based grease.
2. Once per week, apply a light oil to the
threads where the groove diameter adjustment
screw passes through the tool housing.
17
REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual

SHEAR PIN REPLACEMENT
If the tool will not travel around the pipe,
the shear pin in the hand drive nut must be
replaced.
Remove the shear pin using the shear pin
punch and replace with an intact shear pin. If
all provided shear pins have been used, contact
Victaulic to order replacements.
PARTS ORDERING
INFORMATION
When ordering parts, the following information
is required for Victaulic to process the order and
send the correct part(s). Parts can be ordered
by calling 1-800-PICK VIC.
1. Tool Model Number
2. Tool Serial Number
3. Quantity, Item Number, Part Number, and
Description
4. Where to send the part(s) – Company
Name and Address
5. To whose attention to send the part(s) –
Person’s Name
6. Purchase Order Number
7. Billing Address
18 REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual

TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
Tool does not travel around
pipe when turning hand
drive nut.
A shear pin on the manual drive nut is
broken.
Remove the damaged shear pin from the drive nut and replace
with a new shear pin. Refer to the“Shear Pin Replacement”
section.
The amount of travel is too great for the groove diameter
adjustment.To prevent further breakage, lessen the input force
and amount of groove diameter adjustment.
“A”dimension is out of
specication.
Tool is not fully pushed onto the pipe. Cut o the pipe end. Regroove the pipe with the tool pushed all the
way onto the pipe end.
Incorrect roll set used for grooving. Verify that the roll set is the appropriate size for the pipe to be
grooved. Install the correct roll set for the pipe to be grooved.
In the event of tool malfunction outside the scope of the troubleshooting section, contact Victaulic for
assistance.
19
REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual

ROLL GROOVE SPECIFICATIONS OGS-200 FOR SCHEDULE 40 AND SCHEDULE 80 CARBON STEEL PIPE
Size Dimensions – inches/millimeters
Nominal
Size
inches/
mm
Actual Pipe
Outside
Diameter
inches/mm
Pipe Outside Diameter1Gasket Seat “A”2Groove Width “B”3Groove Diameter “C”4
Groove
Depth
“D” (ref.)5
Max.
Allow.
Flare Dia.
“F”6
Max. Min. Basic Max. Min. Basic Max. Min. Max. Min.
22.375 2.399 2.351 1.000 1.031 0.969 0.344 0.354 0.334 2.250 2.235 0.063 2.404
50 60.3 60.9 59.7 25.4 26.2 24.6 8.7 9.0 8.5 57. 2 56.8 1.6 61.1
2 ½ 2.875 2.904 2.846 1.000 1.031 0.969 0.344 0.354 0.334 2.720 2.702 0.078 2.909
73.0 73.8 72.3 25.4 26.2 24.6 8.7 9.0 8.5 69.1 68.6 2.0 73.9
33.500 3.535 3.469 1.000 1.031 0.969 0.344 0.354 0.334 3.344 3.326 0.078 3.540
80 88.9 89.8 88.1 25.4 26.2 24.6 8.7 9.0 8.5 84.9 84.5 2.0 89.9
44.500 4.545 4.469 1.125 1.156 1.062 0.344 0.354 0.334 4.334 4.314 0.083 4.575
100 114. 3 115 .4 113.5 28.6 29.4 27.0 8.7 9.0 8.5 110 .1 109.6 2.1 116 . 2
66.625 6.688 6.594 1.125 1.156 1.062 0.344 0.354 0.334 6.455 6.433 0.085 6.718
150 168.3 169.9 167.5 28.6 29.4 27.0 8.7 9.0 8.5 164.0 163.4 2.2 170.6
1Outside diameter: The outside diameter of roll grooved pipe shall not vary more than the tolerance listed. For IPS pipe, the maximum allowable tolerance from square cut ends is
0.032 inch/0.81 mm for 2–3 inch/DN50–DN80; and 0.063 inch/1.60 mm for 4–6 inch/DN100–DN150, measured from the true square line.
2Gasket seat “A”: The pipe surface shall be free from indentations, roll marks, and projections from the end of the pipe to the groove to provide a leak-tight seal for the gasket. All loose
paint, scale, dirt, chips, grease, and rust must be removed. It continues to be Victaulic’s first recommendation that pipe be square cut. When using beveled end pipe, the gasket seat “A” is measured from the end of the pipe. IMPORTANT: Roll grooving of beveled end pipe may result in unacceptable pipe end flare. See Maximum Allowable Flare Diameter column.
3Groove width “B”: Bottom of groove to be free of loose dirt, chips, rust, and scale that may interfere with proper coupling assembling. 4Groove diameter “C”: The groove must be of uniform depth for the entire pipe circumference. The groove must be maintained within the “C” diameter tolerance listed. 5Groove depth “D”: For reference only. The groove must conform to the groove diameter “C” listed. 6Maximum allowable pipe end flare diameter “F”: Measured at the most extreme pipe end diameter, square cut or beveled.
NOTES • Do not apply coatings to the gasket seat “A” nor within the groove width “B” on the pipe exterior. • Any corrective action to gasket seat “A” to provide a good sealing surface as required in footnote #2 (listed above) must not result in file, grind, or sand marks going across gasket seat “A.”
• Roll grooving removes no metal, instead cold forming a groove by the action of an outer grooving roll being forced into the pipe as it is rotated by an inner support roll. • For use on schedules 40 and 80 IPS carbon steel pipe. Contact Victaulic for all other pipe material inquiries.
A B
D
COD F
T
20 REV_D
TM-RG1200 / Operating and Maintenance Instructions Manual
