Bluestream RX18G User manual

RX18G QUICK REFERENCE GUIDE
www.blustream.com.au |www.blustream-us.com |www.blustream.co.uk
RX18G
Quick Reference Guide
01
The RX18G receiver is an industry leading uncompressed, unconverted HDMI 2.0 4K
60Hz 4:4:4 HDCP 2.3/2.2 solution utilising the latest in HDBaseT™ technology.
The RX18G supports uncompressed distribution of the latest HDR resolutions
including HDR10/10+ and Dolby Vision resulting in the ultimate in picture quality for
your critical viewing areas.
The RX18G supports bi-directional IR, RS-232 and PoC up to lengths of 100m over a
single CAT6A cable while also providing enhanced features including ARC via HDMI
or Optical (S/PDIF), and 1Gb Ethernet pass through.
Introduction
FEATURES:
• Advanced HDBaseT™ spec 3.0 technology oering distribution of video and audio over a single CAT6A cable
• Supports uncompressed HDMI2.0 18Gbps 4K 60Hz 4:4:4 specification including HDR
• Extends HDMI 1080p video up to 150m (HDBaseT™ long-reach mode)
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports ARC (Audio Return Channel) from connected display via HDMI or Optical digital inputs (when used with
compatible Blustream matrix)
• Bi-directional 1Gb Ethernet pass through when used with compatible Blustream matrix solution
• Supports all known HDMI audio formats including Dolby Atmos, Dolby TrueHD, Dolby Digital Plus and DTS-HD
Master Audio transmission
• Bi-directional RS-232 pass-through
• Supports bi-directional IR pass-through from compatible Blustream matrix
• Supports PoC (Power over Cable) from compatible Blustream matrix
• HDCP 2.3 support
• Recommended receiver to be used with Blustream HMX88-18G and HMX44-18G matrix
24V 1.25AETHERNET HDBT IN RS-232 IR IN IR OUTHDMI OUT OPT OUTL/R OUT
TX RX
RX18G
OPT IN
LRM
ON OF
FO
NOFFCTRL FW
RS-232 ARC

RX18G QUICK REFERENCE GUIDE
Contact: [e-mail] |[e-mail] |[e-mail] 02
Panel Descriptions
Front Rear
1Power Status Indicator
2HDMI Signal Link Indicator
3Optical Audio Input - Toslink audio input. Connects to the Optical output of the local display device for Audio Return
Channel feature
4Long Reach Mode Switch - Enable to support 1080p video up to 150m (Matrix/Transmitter must support this
function)
5RS-232 Port Mode Selection Switch. Firmware upgrade mode or normal operating mode.
6Audio Return Channel Switch - Enables or disables ARC functionality
7Ethernet Connection - Connect to network / device for 1Gb LAN pass-through to / from Receiver
8HDBaseT™ Input - Connect to matrix or transmitter via CAT6A cable
9RS-232 3-pin Phoenix Connector
qIR In (to Blustream 5V 3.5mm IR receiver)
wIR Out (to Blustream 5V 3.5mm IR emitter)
eHDMI Output - connect to HDMI on display
rOptical Toslink audio output. Connects to local AV amplifier and allows local HDMI audio breakout of source audio
tAnalogue Audio L/R Output - 3.5mm stereo jack de-embedded audio from HDMI source input (2ch PCM audio only)
y24V/1.25A DC Power Input 4-Pin Connector
421 3 7 8 9 10 11 12 13
Advanced Functions
The RX18G has been designed to partner with all Blustream HDBaseT™ matrix products and will receive audio and
video from these devices, as well as bi-directional IR and RS-232 control. Advanced functions such as ARC, Ethernet
passthrough and uncompressed 18Gbps video will only function with a compatible matrix or transmitter product.
The below chart outlines the matrix products that support these advanced functions:
MATRIX / TRANSMITTER UNCOMRPESSED 18G VIDEO ARC ETHERNET PASSTHROUGH
HMX88-18G Yes Yes Yes
HMX44-18G Yes Yes Yes
PLA88CS No No No
HMXL88ARC No No No
HMXL66ARC No No No
HMXL44ARC No No No
HMXL42ARC No No No
AMF42AU No No No
C88CS No No No
C66CS No No No
C44CS No No No
24V 1.25AETHERNET HDBT IN RS-232 IR IN IR OUTHDMI OUT OPT OUTL/R OUT
TX RX
RX18G
OPT IN
LRM
ON OF
FO
NOFFCTRL FW
RS-232 ARC
5 6 14 15

RX18G QUICK REFERENCE GUIDE
www.blustream.com.au |www.blustream-us.com |www.blustream.co.uk
03
Terminating the Interconnecting HDBaseT™ CAT Cable
It is important that the interconnecting CAT cable between the Blustream HDBaseT™ products is terminated using the
correct RJ45 pin configuration. The link CAT6A cable MUST be a ‘straight’ (pin-to-pin) cable and it is advised that this is
wired to the T568B wiring standard as this format is less prone to EMI (Electro-Magnetic Interference).
When installing CAT cable for HDBaseT™ it is advised that the best possible CAT cable quality is used without ANY
connections in the cable between the RJ45 plugs.
HDMI distribution over the new HDBaseT™ VS3000 chipset will ONLY work if used with CAT6A standard cable, or above,
for extended distances due to the 16Gbps HDBaseT™ link required. The distance capabilities of this technology is
significantly reduced over CAT5e or CAT6 cabling because of the increase in data being sent.
Blustream recommends using U/FTP cable for HDBaseT™ VS3000 installations, especially when running over longer
distances, in areas of high EMI, or for 4K signal distribution.
Understanding the HDBaseT™ Signal Status Lights
The Blustream HDBaseT™ extender solutions include status LED indicators on both the Matrix/Transmitter and
Receiver products to show all connections are active and to help diagnose possible problems.
Understanding the Status Lights
RX18G Receiver:
• The HDMI signal link light will be o when there is no connection with a display / sink
• The HDMI link light will be on when there is an active connection with a display
• The orange HDBaseT™ link light will be o when there is no CAT cable / active HDBaseT™ connection on the RJ45 HDBaseT™ output
• The orange HDBaseT™ link light will blink if there is an unstable connection between the Transmitter / Matrix and Receiver
• The orange HDBaseT™ link light will be lit when a CAT cable is connected to the HDBaseT™ RJ45 output on the Transmitter
and an active connection is achieved with the Receiver / Matrix
• The green HDBaseT™ HDCP light will be o when no video signal is received
• The green HDBaseT™ HDCP light will flash when there is video signal without HDCP being received
• The green HDBaseT™ HDCP light will be on when there is video signal with HDCP being received
• The power link light will be o when no power is connected to the receiver, or to the connected Transmitter unit
• The power link light will be on when power is connected directly to the receiver or is being received from the Transmitter unit
RJ45 Wiring - T568B

RX18G QUICK REFERENCE GUIDE
Contact: [e-mail] |[e-mail] |[e-mail]
RX18G_QRG_REVA4
Package ContentsSpecifications
RX18G
• 1 x RX18G
• 1 x Mounting Bracket Set
• 1 x Quick Reference Guide
Maintenance
Clean this unit with a so, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit.
NOTE: Specifications are subject to change without
notice. Weights and dimensions are approximate.
RX18G
• Video Input Connectors: 1 x HDBaseT™ RJ45 connector
• Video Output Connectors: 1 x HDMI Type A, female
• RS232 Input Port: 1 x 3-pin Phoenix connector
• Audio Output Connectors: 1 x Analogue audio L/R (3.5mm stereo jack),
1 x Optical (S/PDIF)
• Audio Input Connectors: 1 x Optical (S/PDIF)
• Ethernet Port: 1 x RJ45 connector
• IR Input Port: 1 x 3.5mm stereo jack
• IR Output Port: 1 x 3.5mm mono jack
• Mounting Kit included
• Casing Dimensions (W x H x D): 190 x 100 x 25mm
• Dimensions Including Connections (W x H x D): 190 x 108 x 25mm
• Power Supply: 24V/1.25A DC, 4-pin DIN
• Shipping Weight: 1.0Kg
• Operating Temperature: 32°F to 104°F (-5°C to +55°C)
• Storage Temperature: -4°F to 140°F (-25°C to +70°C)
FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION - changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
CANADA, INDUSTRY CANADA (IC) NOTICES
This Class B digital apparatus complies with Canadian ICES-003.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
CORRECT DISPOSAL OF THIS PRODUCT
This marking indicates that this product should not be disposed with other household wastes. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and collection systems or contact the retailer where the product was
purchased. They can take this product for environmentally safe recycling.
Certifications
