BMI Gaming SideShow 1889 Instruction Manual

1
Single player Sideshow installation
and maintenance
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

2
1. Installation
1.1 Unpacking
1.2 Assembling
1.3 Set up
2. Game operation
2.1 Gun consoles
2.2 Main cabinet
2.3 Target descriptions
2.3.1 Stars and Spiral
2.3.2 Ducks
2.3.3 Spinning plates
2.3.4 Bow tie
2.3.5 Running lights
3. Access
4. Maintenance
4.1 No electrical power
5. 5.Unable to hit targets
6. Schematic drawing- gun board, timer module, sound module
7. Contacts
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

3
1. Installation
1.1 Unpacking
Carefully remove all packaging material, and site the machine on a flat and level floor.
The machine is designed for indoor use only.
1.2 Assembling
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

4
1.3 Set up
The machine is delivered with the following settings:-
Coin mechanism £1 per game
Shots per game 20
Tickets per hit 1
Settings can be altered using the red dip switches in the following picture
Turn Power Off Before Altering Dip Switches
1 2 3
Dip Switch Settings Dip Switch Settings Dip Switch Settings
Tickets Out Price of Play Shots per Game
SW2 Dip Switch SW1 Dip Switch SW3 Dip Switch
Tickets
T1
T2
T3
T4
Price
S1
S2
S3
S4
Shots
S1
S2
S3
S4
1 ticket
Off
Off
Off
Off
50p/EC
Off
Off
Off
Off
1 shot
Off
Off
Off
Off
2 tickets
On
Off
Off
Off
60p/EC
On
Off
Off
Off
2 shots
On
Off
Off
Off
3 tickets
Off
On
Off
Off
70p/EC
Off
On
Off
Off
4 shots
Off
On
Off
Off
4 tickets
On
On
Off
Off
80p/EC
On
On
Off
Off
6 shots
On
On
Off
Off
5 tickets
Off
Off
On
Off
90p/EC
Off
Off
On
Off
8 shots
Off
Off
On
Off
6 tickets
On
Off
On
Off
100p/EC
On
Off
On
Off
10 shots
On
Off
On
Off
7 tickets
Off
On
On
Off
110p/EC
Off
On
On
Off
12 shots
Off
On
On
Off
8 tickets
On
On
On
Off
120p/EC
On
On
On
Off
14 shots
On
On
On
Off
9 tickets
Off
Off
Off
On
130p/EC
Off
Off
Off
On
16 shots
Off
Off
Off
On
10 tickets
On
Off
Off
On
140p/EC
On
Off
Off
On
18 shots
On
Off
Off
On
11 tickets
Off
On
Off
On
150p/EC
Off
On
Off
On
20 shots
Off
On
Off
On
12 tickets
On
On
Off
On
160p/EC
On
On
Off
On
22 shots
On
On
Off
On
13 tickets
Off
Off
On
On
170p/EC
Off
Off
On
On
24 shots
Off
Off
On
On
14 tickets
On
Off
On
On
180p/EC
On
Off
On
On
26 shots
On
Off
On
On
15 tickets
Off
On
On
On
190p/EC
Off
On
On
On
28 shots
Off
On
On
On
16 tickets
On
On
On
On
200p/EC
On
On
On
On
30 shots
On
On
On
On
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

5
2. Game operation
2.1 Gun consoles
When a coin is inserted, and the gun trigger is squeezed, infra red light is emitted from the
gun barrel.
2.2 Main Cabinet
Each target has an infra red detector, which senses a beam of light from the gun. The target
operates a relay on the timer module, which in turn sends a signal to the target animation.
The length of time a target operates is adjustable on the timer module, but this is factory set
and should not need to be altered.
2.3 Target descriptions
2.3.1 Stars and Spirals
There are 2 stars and one spiral, which spin when they are hit. They are all driven by
electric motors.
2.3.2 Ducks
The profile ducks are fastened to a toothed timing belt, driven
by a geared motor which runs continuously when the machine is connected to a power
supply. Two electrical solenoids are spaced at equal intervals in front of the ducks, and trip
the ducks over when the target is hit and the tripping mechanism is in line with a duck.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

6
2.3.3 Spinning plates
When the target is hit power is applied to a motor which spins the plate.
2.3.4 Clown bow tie
When the target is hit power is applied to a motor which spins the bow tie.
2.3.5 Running lights
When the target is hit the lights run.
2.4 Bowtie bonus feature, and background music
The sound module E705 is fitted from machine serial number SW089.An audio message
signals the start of the bonus period, when hitting the bowtie gives double score and double
tickets. The interval between bonus periods is random. The red dip switches alter the
features.
1
2
3
4
Continuous background music
off
off
No background music
on
on
Background music, on for one minute, off for one minute
off
on
Background music, on for two minutes, off for two minutes
on
off
Duration of bonus period 10 seconds
off
off
Duration of bonus period 25 seconds
on
on
Duration of bonus period 15 seconds
off
on
Duration of bonus period 20 seconds
on
off
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

7
3. Access
The tubular key fits the cash door. The flat key will open all the other doors. Gun consoles –
Undo the 2 locks on the top face of the consoles, the top is hinged at the back, and will lift
complete with the gun.
Coin doors –Opening the top door gives access to the coin mechanism, and opening the
bottom door gives access to the cash box.
Main cabinet –A door on one side of the cabinet allows access to the duck drive and to the
targets. The rear door allows access to the timer, sound and light chaser boards and
electrical components.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

8
4. Fault finding
4.1 No electrical power
Check the wall socket for a supply. Check the fuse in the plug, and in the machine rear
socket where the power enters the machine.
If no power to the gun consoles, check the connections and wiring from the main cabinet
to the consoles. Check the console power supply (in the consoles centre back) for a red light,
and press the reset button next to the light.
If no power to one gun section, check the connections from the power supply, the
connections on the gun board, and fuses.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

9
4.2 Unable to hit targets
No
Is there a gun noise when
the gun is operated?
Yes
Is there a blockage in
the gun barrel?
Is the purple wire
through the gun
hose broken ?
No
Change gun circuit
board
Does system work?
No
Replace emitter in gun, observing
correct polarity (hole at top, pink
on right
Check fuse on circuit
board, check speaker
Remove trigger assembly
and check operation of the
switch with a meter
Is the purple or pink wire
through the gun hose broken
No
Replace gun board
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

10
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

11
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

12
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

13
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

14
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

15
Side show machine parts are covered by a guarantee for 12 months from the
date of delivery.
6.Contacts
Manufacturers :-Pan Amusements
Austerlands Mill
Huddersfield Road
Oldham, UK
OL4 3QB
Telephone [phone]
0161 624 5578
Fax [phone]
Email info @panamusements.com
Website www.panamusements.com
Manual part number SD091 version 4 9/1/12
