UNIS Ticket Dome R User manual

Operation Manual
IMPORTANT

Ticket Dome R Manual
03/16/2020
1
WE ARE HERE TO ASSIST
For parts and service
Have Questions? Contact us!
UNIS SERVICE CENTER
Tel: [phone]
Email: [e-mail]

Ticket Dome R Manual
03/16/2020
2
CONTENT
IMPORTANT SAFETY INSTRUCTIONS.......................................................................3
1. SPECIFICATIONS....................................................................................................5
2. CONTENTS OF THE ACCESSORY KIT................................................................... 6
3. PART NAME............................................................................................................7
4. SET UP & INSTALLATION...................................................................................... 8
5. HOW TO PLAY......................................................................................................14
6. GAME OPTION..................................................................................................... 15
7. TROUBLESHOOTING............................................................................................21
8. MAINTENANCE & INSPECTION..........................................................................22
9. OVERALL CONSTRUCTION................................................................................. 36
10. WIRING DIAGRAM............................................................................................ 62

Ticket Dome R Manual
03/16/2020
3
Thank you for purchasing Ticket Dome R. We hope you enjoy the product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of
product operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technical personnel
should under no circumstance attempt to service the machine. Contact your distributor or
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may
cause fire, electric shock or personal injury. Unplug the game from the outlet when not in
use, when moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated by signs of warning. Depending
on the potential hazardous degree, the terms: NOTE,NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before
continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock.
Do not touch.

Ticket Dome R Manual
03/16/2020
4
Use the following safety guidelines to help ensure your own personal safety and to help
protect your equipment and surrounding environment from potential damage.
This product is an indoor game machine. Do not install outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury
and/or machine malfunctioning:
Places subject to rain/moisture, or places subject to high humidity.
Places subject to direct sunlight, or places subject to extremely hot or cold
temperatures to ensure that it is used within the specified operating range.
Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire.
On unstable or sloped surfaces. The machine may topple or cause unforeseen
accidents.
Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures.
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL
RISKS.
Note: The contents of this manual may be updated without notice.

Ticket Dome R Manual
03/16/2020
5
1. SPECIFICATIONS
Rated power supply: AC110V 50/60Hz; AC220V -240V~ 50/60Hz (It is subject to the
nameplate on the back of the machine.)
Min. Power consumption: 240W
Max. Power consumption: 380W
Dimension:Width: 58.66’’ (1490mm)
Depth: 58.66’’ (1490mm)
Height: 56.94’’(1515mm)
Weight：Approximately 380.37 lb (345kg)
Model No: T-351
Part No: T151
NOTICE: After turning off the game, please wait at least 1 minute
before restarting again.
Note: Game specifications are subject to change without notice.

Ticket Dome R Manual
03/16/2020
6
2. CONTENTS OF THE ACCESSORY KIT
Open the package and make sure all the items are included:
Following accessories
NOTE: Part models are subject to change without notice.
No.
Part No.
Code No.
Name
Spec.
Qty
1
T151-801-000
41440000308
Manual
English
1
2
T151-802-000
25300171002
Key
171A
1
3
T151-803-000
25300172002
Key
171B
1
4
T151-804-000
23301000001
Power cord
1.8M
1
5
T151-805-000
21901000043
Fuse
6.3A
2
6
T151-806-000
26601090367
Micro Switch
D3V-6G-1C24
1
7
T151-807-000
26601101735
Micro Switch
/
1
8
T151-808-000
26601101736
Optical coupler
/
1
9
T151-809-000
26601101738
Extended line
1.2M
(Maintenance
and use)
1
/
10
T151-408-000
26601101737
Display
SMG8102_3W
.PCB V3.0
1

Ticket Dome R Manual
03/16/2020
7
3. PART NAME
Key Components
Button
Speaker
Coin mechanism
Ticket dispenser
Marquee
Scoop

Ticket Dome R Manual
03/16/2020
8
leveler
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install outdoors.
Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid
Place the unit on a dry level surface
Ventilation openings in the back of the unit must not be obstructed by objects or by
wall.
4.1 Transporting the Game
If you need to move the game, adjust the levelers back to an “up” position.
NOTICE
Be careful not to damage the machine during transport.
Always unplug the game before moving.
For longer distance transport, package the game properly to prevent damages.
Please keep the machine in upright position during transport.
We do not recommend using power tools as they may cause damage.
NOTICE

Ticket Dome R Manual
03/16/2020
9
leveler
This procedure requires 4 people assistance.
4.2 Level Adjustment
Install this game on a flat surface. If the game is installed on an unsuitable floor, it could
cause game malfunction.
To secure the game, loosen the nut, utilize wrench to adjust the leveler down until it
touches the floor, lifting the casters off the ground by 0.2 in. Repeat the same for all
levelers.
NOTICE
Make sure the machine is level.

Ticket Dome R Manual
03/16/2020
10
4.3 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Play area: 20 in
Play area

Ticket Dome R Manual
03/16/2020
11
4.4 Instruction of Resetting The Machine to Normal Mode
In order to avoid damage during transportation, the machine is preset to Transportation
mode, in which all the scoops are lowered and fixed.
Warning: The machine needs to be reset to Normal mode upon unpacking. Please follow
the steps.
Step 1 Remove all the PE-film and foam.
Step 2 Open the Service door between Yellow and Blue player, where the IO-board locates.
Step 3 Turn the Switch as Right picture shown.
Step 4 Power on the machine.
(Factory Restore mode)
(Normal mode)
SW1
SW2

Ticket Dome R Manual
03/16/2020
12
4.5 Card Reader Installation
Step 1 Locate the Coin door. Open the coin door. Utilize Allen wrench(2.5mm) to loosen 4
screws to remove Card reader plate.
Step 2 Utilize knife or scissors to cut properly decal position for Card reader. Utilize Spanner
to loosen 2 nuts indicated by circles. Place Card reader receiver on it and install it by 2
nuts.
Step 3 Place Card reader on it. Utilize Allen wrench(2.5mm) to tighten 4 screws to Card
reader. Connect Card reader connector.
NOTE: The installation of the Card reader is to be completed by each individual location. (Not included)
Card reader receiver
Card reader
Card reader plate

Ticket Dome R Manual
03/16/2020
13
4.6 DBV Installation
Step 1 Locate the Coin door. Open the coin door. Utilize Spanner(5.5/7) to loosen 4 nuts to
remove DBV plate.
Step 2 Utilize knife or scissors to cut properly decal position for DBV.
Step 3 Place DBV on it. Utilize Spanner(5.5/7) to tighten 4 nuts to DBV. Connect DBV
connector.
NOTE: The installation of the DBV is to be completed by each individual location. (Not included)
DBV plate
DBV

Ticket Dome R Manual
03/16/2020
14
5. HOW TO PLAY
1 Please insert coin(s) /swipe/tap card to play.
2 Aim at ticket rolls and press Button to scoop.
3 Ticket rolls drop down to be collected.
4 Ticket rolls will activate BONUS mode.
4 Press Button to stop the spinning light and try to land on “Win BONUS” for more prizes!
Prizes drop down
and push to win
more prizes.
Note: Do not put more
than 4.4lb prizes totally
on the plate. Otherwise
the motor will be
damaged.

Ticket Dome R Manual
03/16/2020
15
6. GAME OPTION
6.1 Ticket Dome I/O chart:
Item
Value
SW1
1
2
3
4
5
6
7
8
Coin Per Game
1/4
off
off
off
1/3
on
off
off
1/2
off
on
off
1/1
on
on
off
2/1
off
off
on
3/1
on
off
on
4/1
off
on
on
5/1
on
on
on
Scoop Times*
4
off
off
8
on
off
12
off
on
16
on
on
Demo Music
NO
off
YES
on
Game Mode
Normal
off
off
Free Play
on
off
Bonus
off
on
Factory Restore
on
on
*Scoop times: When the player win BONUS, the machine will automatically scoop the prizes to the disk.
Scoop times is 4, 4 scoops will scoop once. Scoop times is 8, 4 scoops will scoop twice.
Item
Value
SW2
1
2
3
4
5
6
7
8
BONUS Odds
3%
off
off
5%
on
off
10%
off
on
20%
on
on
Wait Time (second)
to Start Auto Play
Wait all the time
off
off
20
on
off
25
off
on
30
on
on
OFF
OFF
OFF
OFF

Ticket Dome R Manual
03/16/2020
16
Item
Value
Controller
1
2
3
4
5
6
7
8
Stepping Motor
Setting
off
off
off
off
off
off
off
on
Main board input:
Extension board input
INPUT
Content
INPUT
Content
INPUT
Content
INPUT
Content
J1-1
(1)
1P Coin
mechanism
J1-9
(9)
2P Coin
mechanism
J7-1 (1)
3P Coin
mechanism
J7-9 (9)
4P Coin
mechanism
J1-2
(2)
1P Button
J1-10
(10)
2P Button
J7-2 (2)
3P Button
J7-10
(10)
4P Button
J1-3
(3)
J1-11
(11)
J7-3 (3)
J7-11
(11)
J1-4
(4)
J1-12
(12)
J7-4 (4)
J7-12
(12)
J1-5
(5)
1P Reset
button
J1-13
(13)
2P Reset
button
J7-5 (5)
3P Reset
button
J7-13
(13)
4P Reset
button
J1-6
(6)
1P Service
button
J1-14
(14)
2P Service
button
J7-6 (6)
3P Service
button
J7-14
(14)
4P Service
button
J1-7
(7)
Tilt alarm R
J1-15
(15)
J7-7 (7)
J7-15
(15)
Dome Up
J1-8
(8)
J1-16
(16)
J7-8 (8)
J7-16
(16)
Dome Down
Main board output:
OUTPUT
Content
OUTPUT
Content
OUTPUT
Content
J2-1 (1)
J3-9 (9)
1P Coin
mechanism GND
J7-1 (17)
1P Coin counter
J2-2 (2)
J3-10 (10)
2P Coin
mechanism GND
J7-2 (18)
2P Coin counter
J2-3 (3)
J3-11 (11)
3P Coin
mechanism GND
J7-3 (19)
3P Coin counter
J2-4 (4)
J3-12 (12)
4P Coin
mechanism GND
J7-4 (20)
4P Coin counter
J2-5 (5)
J3-13 (13)
J7-5 (21)
1P Button light
J2-6 (6)
J3-14 (14)
J7-6 (22)
2P Button light
J2-7 (7)
J3-15 (15)
J7-7 (23)
3P Button light
J2-8 (8)
J3-16 (16)
J7-8 (24)
4P Button light

Ticket Dome R Manual
03/16/2020
17
Sub board input:
Extension board input:
INPUT
Content
INPUT
Content
INPUT
Content
INPUT
Content
J1-1 (1)
1P Claw depth
SW
J1-9 (9)
3P Claw depth
SW
J1-1 (1)
Turntable
zero sensor
J1-9
(9)
J1-2 (2)
1P Scoop
upper sensor
J1-10
(10)
3P Scoop upper
sensor
J1-2 (2)
J1-10
(10)
J1-3 (3)
1P Scoop
lower sensor
J1-11
(11)
3P Scoop lower
sensor
J1-3 (3)
J1-11
(11)
J1-4 (4)
J1-12
(12)
J1-4 (4)
J1-12
(12)
J1-5 (5)
2P Claw depth
SW
J1-13
(13)
4P Claw depth
SW
J1-5 (5)
J1-13
(13)
J1-6 (6)
2P Scoop
upper sensor
J1-14
(14)
4P Scoop upper
sensor
J1-6 (6)
J1-14
(14)
J1-7 (7)
2P Scoop
lower sensor
J1-15
(15)
4P Scoop lower
sensor
J1-7 (7)
J1-15
(15)
J1-8 (8)
J1-16
(16)
J1-8 (8)
J1-16
(16)
Sub board output:
Extension board output:
OUTPUT
Content
OUTPUT
Content
OUTPUT
Content
OUTPUT
Content
J2-1
(1)
1P Lift motor
A
J3-1
(9)
3P Lift motor A
J1-1 (1)
Pusher
Motor A
J1-1 (1)
2P Light
J2-2
(2)
1P Lift motor
B
J3-2
(10)
3P Lift motor B
J1-2 (2)
Pusher
Motor B
J1-2 (2)
3P Light
J2-3
(3)
1P Scoop
motor A
J3-3
(11)
3P Scoop
motor A
J1-3 (3)
1# Scoop
light
J1-3 (3)
4P Light
J2-4 (4)
1P Scoop
motor B
J3-4
(12)
3P Scoop
motor B
J1-4 (4)
2# Scoop
light
J1-4 (4)
J2-5 (5)
2P Lift motor
A
J3-5
(13)
4P Lift motor A
J1-5 (5)
3# Scoop
light
J1-5 (5)
J2-6 (6)
2P Lift motor
B
J3-6
(14)
4P Lift motor B
J1-6 (6)
4# Scoop
light
J1-6 (6)
J2-7 (7)
2P Scoop
motor A
J3-7
(15)
4P Scoop
motor A
J1-7 (7)
Stepping
motor EN
J1-7 (7)
J2-8 (8)
2P Scoop
motor B
J3-8
(16)
4P Scoop
motor B
J1-8 (8)
1P Light
J1-8 (8)

Ticket Dome R Manual
03/16/2020
18
Separate port J5：
Main board
PROT
Content
5V
12V
GND
P10
P11
P12
RXD
P13
TXD
Separate port:
Sub board
PROT
Content
5V
12V
GND
P10
Light ring SCK
P11
Light ring RCK
P12
Light ring SI
P13
Stepping motor CP
Error code:
E01
Scoop upper sensor error
E02
Scoop lower sensor error
Add
Scoop Micro Switch error
E04
Tilt alarm
E07
Stepping motor zero sensor
E08
Communication error
Note:Please reset the machine to Normal mode after removing the packing.(Refer to
Instruction of Resetting The Machine to Normal Mode)
Separate port J6：
Main board
PROT
Content
5V
12V
GND
P14
Display SCK
P15
Display RCK
P16
Display SI
P17
LED display:
Time
Ticket
LED:
1,2,3 bit
4,5,6,7 bit
8,9,10 bit
11,12,13,14 bit
15,16,17 bit
18,19,20,21 bit
22,23,24 bit
25,26,27,28 bit
Memory clear:
Press"TEST" and "SERVICE"
button to restart the machine
to clear memory.

Ticket Dome R Manual
03/16/2020
19
6.2 Ticket Dome R I/O Chart
6.2.1 M3_MB.PCB board
Input：J20
INPUT
Content
INPUT
Content
INPUT
Content
INPUT
Content
IN1
IN9
1#Gate motor
initial
IN17
Switch DIP1
J25-T1_IN
1#Ticket
feedback
IN2
IN10
2#Gate motor
initial
IN18
Switch DIP2
J25-T2_IN
2#Ticket
feedback
IN3
IN11
3#Gate motor
initial
IN19
Switch DIP3
IN4
IN12
4#Gate motor
initial
IN20
Switch DIP4
IN5
1#Ticket reset
IN13
IN21
Switch DIP5
IN6
2#Ticket reset
IN14
IN22
Switch DIP6
IN7
3#Ticket reset
IN15
3#Ticket
feedback
IN23
Switch DIP7
IN8
4#Ticket reset
IN16
4#Ticket
feedback
IN24
Switch DIP8
Output：J21
J22
J23
J25
OUTPUT
Content
OUTPUT
Content
OUTPUT
Content
OUTPUT
Content
OUT1
1#Gate motor
A
OUT9
1#Ticket
meter
OUT17
OUT2
2#Gate motor
A
OUT10
2#Ticket
meter
OUT18
J25-T2_OUT
2#Ticket
drive
OUT3
3#Gate motor
A
OUT11
3#Ticket
meter
OUT19
3#Ticket drive
J25-T1_OUT
1#Ticket
drive
OUT4
4#Gate motor
A
OUT12
4#Ticket
meter
OUT20
4#Ticket drive
OUT5
1#Pusher
Motor
OUT13
1#Gate motor
B
OUT21
1#Out of ticket
light
OUT6
2#Pusher
Motor
OUT14
2#Gate motor
B
OUT22
2#Out of ticket
light
OUT7
3#Pusher
Motor
OUT15
3#Gate motor
B
OUT23
3#Out of ticket
light
OUT8
4#Pusher
Motor
OUT16
4#Gate motor
B
OUT24
4#Out of ticket
light
