Sega UFO CATCHER User manual

BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING:
To maintain safety:
To ensure the safe operation of this product, be sure to read the following before usage.
The following instructions are intended for the users, operators and the personnel in charge of the
operation of the product. After carefully reading and sufficiently understanding the warning
displays and cautions, handle the product appropriately. Be sure to keep this manual close to the
product or in a convenient place for future reference.
Herein, explanations which require special attention are enclosed with dual lines. Depending on
the potentially hazardous degrees, the terms of DANGER, WARNING, CAUTION, etc. are used.
Be sure to understand the contents of the displays before reading the text.
Indicates that mishandling the
product by disregarding this
pictograph will cause severe
injury or death.
Indicates that mishandling the
product by disregarding this
warning will cause a potentially
hazardous situation which can
result in death or serious injury.
Indicates that mishandling the
product by disregarding this
caution will cause a slight
hazardous situation which can
result in personal injury and/or
material damage.
For the safe usage of the product, the following pictographs are used:
Indicates "HANDLE WITH CARE." In order to protect the human body and
equipment, this display is attached to places where the Owner's Manual, Serviceman
Manual and/or Service Manual should be referred to.
Indicates a "Protective Earth Terminal." Before operating the equipment, be sure to
connect it to the Ground.
(The step may be omitted for products in which a power cord with earth is used.)
❍Perform work in accordance with the instructions herein stated.
Instructions for work are explained by paying attention to the aspect of accident prevention.
Failing to perform work as per the instructions can cause accidents. In the case where only
those who have technical expertise should perform the work to avoid hazardous situation, the
instructions herein state that the site maintenance personnel should perform such work.
❍Be sure to turn off the power before working on the machine.
To prevent an electric shock, be sure to turn off the power before carrying out any work that
requires direct contact with the interior of the product. If the work is to be performed in the
power-on status, the Instruction Manual herein always states to that effect.
❍Be sure to ground the Earth Terminal.
(This is not required in the case where a power cord with earth is used.)
This product is equipped with the Earth Terminal. When installing the product, connect the
Earth Terminal to the "accurately grounded indoor earth terminal" by using an earth wire.
Unless the product is grounded appropriately, the user can be subject to an electric shock.
After performing repair, etc. for the control equipment, ensure that the Earth Wire is firmly
connected to the control equipment.
❍Ensure that the Power Supply used is equipped with an Earth Leakage Breaker.
This product does not incorporate the Earth Leakage Breaker. Using a power supply which is
not equipped with the Earth Leakage Breaker can cause a fire when earth leakage occurs.
❍Be sure to use fuses which meet the specified rating.
(Only for the machines which use fuses.)
Using fuses exceeding the specified rating can cause a fire and an electric shock.

❍Specification changes (removal of equipment, conversion and addition) not
designated by SEGA are not allowed.
The parts of the product include warning labels for safety, covers for personal protection, etc.
It is very hazardous to operate the product by removing parts and/or modifying the circuits.
Should doors, lids and protective parts be damaged or lost, refrain from operating the product,
and contact where the product was purchased from or the office herein stated.
SEGA shall not be held responsible for any accidents, compensation for damage to a third
party, resulting from the specifications not designated by SEGA.
❍Ensure that the product meets the requirements of appropriate Electrical
Specifications.
Before installing the product, check for Electrical Specifications. SEGA products have a
nameplate on which Electrical Specifications are described. Ensure that the product is
compatible with the power supply voltage and frequency requirements of the location. Using
any Electrical Specifications different from the designated Specifications can cause a fire and
an electric shock.
❍Install and operate the product in places where appropriate lighting is
available, allowing warning labels to be clearly read.
To ensure safety for the customers, labels and printed instructions describing potentially
hazardous situations are applied to places where accidents can be caused. Ensure that where
the product is operated has sufficient lighting allowing the warnings to be read. If any label is
peeled off, apply it again immediately. Please place an order with where the product was
purchased from or the office herein stated.
❍When handling the monitor, be very careful.
(Applies only to the product with a monitor.)
Some of the monitor (TV) parts are subject to high tension voltage. Even after turning off the
power, some portions are still subject to high tension voltage sometimes. Monitor repair and
replacement should be performed only by those technical personnel who have knowledge of
electricity and technical expertise.
❍Be sure to adjust the monitor/projector properly.
(Applies only to the product with a monitor/projector.)
Do not operate the product leaving on-screen flickering or blurring as it is. Using the product
with the monitor/projector not properly adjusted may cause dizziness or a headache to an
operator, a player, or the customers.
❍When transporting or reselling this product, be sure to attach this manual to
the product.
In the case where commercially available monitors and printers are used in this product, only
the contents relating to this product are explained herein. Some commercially available
equipment has functions and reactions not stated in this manual. Read this manual together
with the specific Instruction Manual of such equipment.
* Descriptions herein contained may be subject to improvement changes without notice.
* The contents described herein are fully prepared with due care. However, should any
question arise or errors be found, please contact SEGA.
INSPECTIONS IMMEDIATELY AFTER TRANSPORTING THE PRODUCT TO THE LOCATION
Normally, at the time of shipment, SEGA products are in a status allowing for usage immediately
after transporting to the location. Nevertheless, an irregular situation may occur during
transportation. Before turning on the power, check the following points to ensure that the product
has been transported in a satisfactory status.
❐Are there any dented portions or defects (cuts, etc.) on the external surfaces of the cabinet?
❐Are Casters and Adjusters damaged?
❐Do the power supply voltage and frequency requirements meet with those of the location?
❐Are all wiring connectors correctly and securely connected? Unless connected in the correct
way, connector connections can not be made accurately. Do not insert connectors forcibly.
❐Do power cords have cuts and dents?
❐Do the fuses used meet specified ratings? Is the Circuit Protector in an energized status?
❐Are all accessories available?
❐Can all Doors and Lids be opened with the Accessory Keys? Can Doors and Lids be firmly
closed?

i
20
21
22
23
24
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
TABLE OF CONTENTS
BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING:
TABLE OF CONTENTS
INTRODUCTION
1HANDLING PRECAUTIONS
PRECAUTIONS REGARDING INSTALLATION LOCATION
2-1 LIMITATIONS OF USAGE
2-2 OPERATION AREA
PRECAUTIONS REGARDING PRODUCT OPERATION
3-1 BEFORE OPERATION
3-2 DURING OPERATION (PAYING ATTENTION TO CUSTOMERS)
PART DESCRIPTIONS
ACCESSORIES
INSTALLATION
6-1 SECURE THE UNIT AT THE INSTALLATION SITE
(MANIPULATE THE ADJUSTERS)
6-2 REMOVE SHIPPING BRACKETS
6-3 ATTACH PARTITION
6-4 CONNECT POWER CORD
6-5 ACTIVATE POWER SUPPLY
PRECAUTIONS WHEN MOVING
PRIZE REPLACEMENT
GAME CONTENT
GAME BOARD
EXPLANATION OF TEST AND DATA DISPLAY
11-1 SWITCH UNIT AND CASH BOX
11-2 VFD DISPLAY CONTENT
11-3 EXPLANATION OF TEST MODE
DIP SW SETTINGS
2
3
4
5
••••••••••••••••••••••••••••••••••••••••••••••••••1
••••••••••••••••4
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••4
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••5
•••••••••••••••••••6
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••6
•••••••••••••••••••••••••••••7
••••••••••••••••••••••••••••••••••••••••••••••••••••••••8
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••9
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••11
••••••••••••••••••••••••••••••••••••••••••••••12
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••13
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••15
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••16
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••17
•••••••••••••••••••••••••••••••••••••••••••18
•••••••••••••••••••••••••••••••••••••••••••••••••••••19
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••21
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••23
•••••••••••••••••••••••••••25
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••25
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••26
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••31
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••33
E0-0706 420-7061
6
7
8
9
10
11
12
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••i
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••iii

ii
20
21
22
23
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
24
13 ARM MECHANISM
13-1 ARM REPLACEMENT
13-2 ADJUSTMENT OF SENSOR BRACKET POSITION
13-3 SPRING STRENGTH ADJUSTMENT AND SPRING REPLACEMENT
13-4 SHOVEL REPLACEMENT AND ADJUSTMENT
13-5 OPEN ARM ANGLE ADJUSTMENT
MAINTENANCE OF Z-ORIENTED MECHANISM
COIN SELECTOR
15-1 REMOVING THE COIN SELECTOR
15-2 REMOVING A JAMMED COIN
15-3 CLEANING THE COIN SELECTOR
15-4 COIN INSERTION TEST
REPLACEMENT OF FLUORESCENT LIGHTING, LAMPS, AND FUSES
16-1 FLUORESCENT LIGHTING REPLACEMENT
16-2 LAMP REPLACEMENT
16-3 FUSE REPLACEMENT
PERIODIC INSPECTION
ERROR MESSAGES
TROUBLESHOOTING
DESIGN-RELATED PARTS
OPTIONAL ITEMS
21-1 DOLLAR BILL VALIDATOR
21-2 SECURITY BAR
21-3 LCD UNIT (LCD CASE + CABLE COVER)
21-4 TICKET DISPENSER DOOR
21-5 TICKET DISPENSER BOX
PARTS LIST
WIRE COLOR CODE TABLE
WIRING DIAGRAM
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••37
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••37
•••••••••••••••••••••••••••••••••••••••••••••40
•••••••••••••••••••43
••••••••••••••••••••••••••••••••••••••••••••••••••45
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••46
••••••••••••••••••••••••••47
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••49
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••49
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••50
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••51
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••51
••••••••52
••••••••••••••••••••••••••••••••••••••••••••••••••••••52
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••53
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••56
••••••••••••••••••••••••••••••••••••••••••••••••••••57
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••58
•••••••••••••••••••••••••••••••••••••••••••••••••••••••59
••••••••••••••••••••••••••••••••••••••••••••••••••60
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••61
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••63
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••65
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••69
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••75
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••80
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••83
•••••••••••••••••••••••••••••••••••••••••••••••122
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••123
14
15
16
17
18
19
20
21
22
23
24

iii
INTRODUCTION
INTRODUCTION
This manual is intended to provide detailed descriptions together with all the necessary information covering the
general operation of electronic assemblies, electro-mechanicals, servicing control, spare parts, etc. for the product,
"SEGA UFO CATCHER".
This manual is intended for the owners, personnel and managers in charge of operation of the product.
Operate the product after carefully reading and sufficiently understanding the instructions.
In the unlikely event that the product does not function correctly, DO NOT allow anyone other than a technician
to touch the internal system. Turn off the power to the machine, making sure to unplug the electrical cord from the
outlet, and contact the office listed below or the point-of-purchase for this product.
Use of this product is unlikely to cause physical injuries or damage to property. However, points that require special
attention are indicated by bold text, the word "IMPORTANT" and the symbol below
Indicates important information that, if ignored, may result in the mishandling of the
product and cause faulty operation or damage to the product.
IMPORTANT
Sega Amusements U.S.A., Inc.
800 Arthur Avenue, Elk Grove Village, IL 60007-5215, U.S.A.
TEL: [phone]
TOLL FREE: 1-888-877-2669
FAX: [phone]
Installation space: 1,688 mm (66.5 in) [Width] x 875 mm (34.4 in) [Depth]
<Full options assembled: 2,023 mm (79.6 in) [Width] x 1,007 mm (39.6 in) [Depth]>
Height: 1,972 mm (77.6 in)
Weight: 299 kg (659.2 lb)
Power, maximum current: 267 W, 2.4 A (AC 120 V, 60 Hz)
SPECIFICATIONS

iv
INTRODUCTION
Definition of 'Site Maintenance Personnel or Other Qualified Individuals'
Procedures not described in this manual or marked as ‘to be carried out by site
maintenance personnel or other qualified professionals’ should not be carried
out by personnel without the necessary skill or technology. Work carried out by
unqualified persons may cause serious accidents, including electrocution.
Parts replacement, maintenance inspections and troubleshooting should be carried out by site maintenance personnel
or other qualified professionals. This manual includes directions for potentially dangerous procedures which should
only be carried out by professionals with the appropriate specialized knowledge.
The site maintenance personnel or other qualified professionals mentioned in this manual are defined as follows:
Site maintenance personnel:
Individuals with experience in maintaining amusement equipment, vending machines, etc., working under the
supervision of the owner/operator of this product to maintain machines within amusement facilities or similar
premises by carrying out everyday procedures such as assembly, maintenance inspections, and replacement of
units/expendable parts.
Activities to be carried out by site maintenance personnel:
Amusement equipment/vending machine assembly, maintenance inspection and replacement of units/expendable
parts.
Other qualified professionals:
Persons employed by amusement equipment manufacturers, or involved in design, production, testing or
maintenance of amusement equipment. The individual should have either graduated from technical school or hold
similar qualifications in electrical/electronics/mechanical engineering.
Activities to be carried out by other qualified professionals:
Amusement equipment/vending machine assembly, repair/adjustment of electrical/electronic/mechanical parts.

1
HANDLING PRECAUTIONSAS
1
HANDLING PRECAUTIONS1
When installing or inspecting the machine, be very careful of the following points and pay attention to ensure that
the player can enjoy the game safely.
Non-compliance with the following points or inappropriate handling running counter to the cautionary matters
herein stated can cause personal injury or damage to the machine.
• Before performing work, be sure to turn the power off and unplug the electrical
cord from the outlet. Performing the work without turning the power off can
cause an electric shock or short circuit. In the case work should be performed
in the status of power on, this manual always states to that effect.
• To avoid an electric shock or short circuit, do not plug in or unplug quickly.
• To avoid an electric shock, do not plug in or unplug with a wet hand.
• Do not expose power cords or earth wires on the surface, (floor, passage, etc.).
If exposed, the power cords and earth wires are susceptible to damage.
Damaged cords and wires can cause an electric shock or short circuit.
• To avoid causing a fire or an electric shock, do not put things on or damage the
power cords.
• When or after installing the product, do not unnecessarily pull the power cord. If
damaged, the power cord can cause a fire or an electric shock.
• In case the power cord is damaged, ask for a replacement through where the
product was purchased from or the office herein stated. Using the cord as is
damaged can cause fire, an electric shock or leakage.
• Be sure to perform grounding appropriately. Inappropriate grounding can cause
an electric shock.
• Be sure to use fuses meeting the specified rating. Using fuses exceeding the
specified rating can cause a fire or an electric shock.
• Completely make connector connections for IC BD and others. Insufficient
insertion can cause an electric shock.
• Specification changes, removal of equipment, conversion and/or addition, not
designated by SEGA are not permitted.
- Failure to observe this may cause a fire or an electric shock. Non-compliance
with this instruction can have a bad influence upon physical conditions of the
players or the onlookers, or result in injury during play.
- SEGA shall not be held responsible for damage, compensation for damage to
a third party, caused by specification changes not designated by SEGA.
• Be sure to perform periodic maintenance inspections herein stated.

2
1
HANDLING PRECAUTIONSAS
• For the IC board circuit inspections, only the logic tester is allowed. The use of a
multiple-purpose tester is not permitted, so be careful in this regard.
• Static electricity from your body may damage some electronics devices on the
IC board. Before handling the IC board, touch a grounded metallic surface so
that the static electricity can be discharged.
• Some parts are the ones designed and manufactured not specifically for
this game machine. The manufacturers may discontinue, or change the
specifications of, such general-purpose parts. If this is the case, Sega cannot
repair or replace a failed game machine whether or not a warranty period has
expired.
• This game machine can be installed at a storefront but could tip over due to
sudden strong drafts or building winds. It could also tip over from man-made
loads. If the game machine does fall down, a serious accident could result. To
prevent the machine from falling down, carry out the following procedures and
make every effort to operate the machine safely.
- Never place the product at a site that is inclined or has level differences.
If there are inclines or level differences, make sure the site is level before
placing the machine on it.
- Do not add decorations to the product that will cause its center of gravity to
be elevated. Also, be aware that there are cases in which it is illegal to add
electrical units to the product interior.
- Make sure that the adjusters are always in contact with the floor.
- Use rope, chain, and/or fixtures for securing furniture to secure the product so
that it will not fall down in an earthquake.
IMPORTANT

3
HANDLING PRECAUTIONSAS
1
CONCERNING THE STICKER DISPLAY
This SEGA product has stickers attached describing
the product manufacture No. (Serial No.) and Electrical
Specifications. When inquiring about or asking for
repairs, mention the Serial No. and Name of Machine
indicated on the Sticker. The Serial Number indicates
the product register. Identical machines could have
different parts depending on the date of production. Also,
improvements and modifications might have been made
after the publication of this manual. In order to ensure
you order the correct parts, mention the Serial No. when
contacting the applicable places.
CONCERNING WARNING DISPLAYS
FIG. 1
This SEGA product has warning displays on stickers,
labels and/or printed instructions adhered/attached
to or incorporated in the places where a potentially
hazardous situation could arise. The warning displays
are intended for accident prevention for customers
and for avoiding hazardous situations relating to
maintenance and servicing work. Some portions of the
cabinet contain high voltage and may cause accidents
if touched. When performing maintenance, be very
careful of the warning displays. It is especially
important that any complex repair and replacement
work not mentioned herein should be performed by
those technical personnel who have knowledge of
electricity and technical expertise.
In order to prevent accidents, caution any customer
ignoring the warnings to cease and desist immediately.
SERIAL NO. DISPLAY
440-CS0245-EG
440-CS0245-EG
440-WS0286-EG
440-WS0027-EG
440-WS0002XEG
440-WS0286-EG
(Opposite Side)
Same on 2P side
UL CERTIFICATION DISPLAY
440-CS0316-EG
