UTI312
• Expandable from 3 up to 12 zones using ZX3 modules
• Up to 24 programmable paging zone groups
• Telephone interfaces: loop start trunk, ground start trunk,
station access (analog ring-up), page port contact closure
activation, page port voice activation
• Simple 2-switch interface setup
• Programmable activation of AUX contacts
• C-form contact per zone
• 24V DC, 1A internal power supply
• Provides audio drive for up to 150 one-way self-amplified
speakers per zone
• Adjustable output limiter with threshold control and
active indicator
• Two background music busses, selectable per zone
• Two high-impedance transformer isolated background
music inputs
• Stereo combining inputs for background music busses
• All-Call paging zone group
• Auto Select paging zone group
• Override paging (using loop start trunk or page port
contact closure activation) with zone group
• Night Ringer (90V and contact closure activation) with
zone group
• Two Tone Triggers (tone and duration selectable, closure
activated) with individual zone groups
• Select tone burst, chime, double chime, or slow whoop
• Code Calling with zone group
• 2 to 5 Digit dialing with flexible dialing plan for zone and
zone group numbers
• Non-volatile memory for setup data (no backup battery
required)
• Pre-Announce Tone
• Confirmation Tone
• Setup Tone to assist in volume setting
• Pluggable terminal strips
• Microcontroller-based operation
• DTMF programming
• DTMF Block to help suppress DTMF tones over paging
system
• Programmable timers control page duration (station and
trunk)
• Wall- or Rack-mountable
• Two-Year Warranty (both UTI312 and ZX3)
ZX3
• One ZX3 module pre-installed with UTI312
• 3 zones per module
• Audio output with level control per zone
• Zone contact closure
• Zone activity LEDs
• Pluggable terminal strips
Features
Description
Specifications subject to change without notice.
© 2005 Bogen Communications, Inc.
Part No. 54-8023-17A Printed in U.S.A. 0501
3 To 12 Zone
Paging Controller
with Paging Module
Models UTI312, ZX3
The UTI312 Zone Paging Contoller provides multi-zone paging for one-way applications such as self-amplified
speaker systems, with each output capable of providing audio for up to 150 self-amplified speakers.The UTI312
is compatible with all standard analog port types.
Each UTI312 comes with a pre-installed ZX3 module for three zones of paging and is expandable up to
12 zones. The UTI312 offers up to 24 programmable paging zone groups as well as all-call, auto select,
override, night ring, two tone triggers, and code calling zone groups.The UTI312 also offers flexible dialing.
ZX3
3-Zone
Expansion Module
UTI312

The UTI312 Zone Paging Controller shall provide multi-
zone paging for one-way applications such as self-amplified
speaker systems expandable from 3 to 12 zones using ZX3
modules. It shall also provide up to 24 programmable paging
zone groups.
It shall be compatible with all standard analog port types:
loop start trunk, ground start trunk, station access (analog
ring-up), page port contact closure activation, and page port
voice activation.
The UTI312 shall include a pre-installed ZX3 zone module
for up to three zones of paging with an audio output with
level control per zone. Each output shall provide audio for
150 self-amplified speakers. Each zone shall include zone
activity LEDs.
The unit shall provide 1A @ 24V DC (+20 CU) for power-
ing external equipment.
It shall include two high impedance transformer-isolated
background music inputs with volume control. Background
music source shall be selectable per zone.
It shall include an adjustable output limiter with threshold
and active indicator.
The UTI312 shall provide override paging (using loop start
trunk or page port contact closure activation) with zone
group.
The UTI312 shall include an all-call paging zone group, an
auto select paging zone group, night ringer (90V and contact
closure activation) with zone group and two tone triggers
(tone and duration selectable, closure activated) with indi-
vidual zone groups.The unit shall include code calling with
zone group.
The UTI312 shall include a flexible dialing plan for zone and
zone group numbers, programmable from two to five digits.
DTMF programming shall be available through the override
input. It shall include DTMF block to help suppress DTMF
tones from being heard over the paging system.
The unit shall include programmable timers to control page
duration (station and trunk) that can be inhibited.
The unit shall include programmable pre-announce and con-
firmation tones that can be set to be heard at the speakers
being paged or at the calling telephone or both, as well as a
setup tone to assist in volume setting, both of which can be
inhibited.
The unit shall include a tone level control that sets the level
for all tones.
The unit shall include a night ring level control.
The unit shall include a programming reset to return the
UTI312 system to the original factory default values.
Each zone output shall provide a dual form contact rated at
2A @ 30V DC and 0.6A @ 125V AC that changes state
when the zone is accessed.
The UTI312 shall allow the installer to program a number
of different parameters to control the way in which the AUX
relay contacts activate.The UTI312 shall allow programming
of which input events the AUX relay will respond to,
whether it will respond to the event only or to a combina-
tion of the event and its place in the priority structure, and
if it will respond during the event or after the event ends.
It shall include non-volatile memory for setup data (no back-
up battery required)
The UTI312 shall be wall and rack mountable using
reversible brackets included with the unit.
The UTI312 shall be C-UL approved (UL60950), FCC Part
68 Registered, FCC Part 15 Compliant, and Industry Canada
CS-03.
Dimensions of the unit shall be 16-3/8" W x 3-1/2" H x
4-7/8" D and 19" W x 3-1/2" H x 4-7/8" D with mounting
flanges. Product weight shall be 8 lb.
Architect &
Engineer
Specifications*
50 Spring Street, Ramsey, NJ 07446, U.S.A.
201-934-8500 FAX: [phone]
Web Site: www.bogen.com
Technical
Specifications
Input Impedance: 600 ohms (nominal)
Input Level: -10 dBm (nominal)
VOX Sensitivity: -30 dBm
Background Music
Input Impedance: 20k ohms
Music Input Level: -10 dBm (nominal)
Output Level: -10 dBm nominal
Output Impedance: 8 ohms
Speaker Drive Capacity: 150 per zone
Timer Duration: Default: 10s to 990s
(both defeatable) VOX: 1s to 9s
CPC Disconnect: Pulse greater than 300ms
ZX3 Contact Closure: 2A @ 30V AC, 0.5A @ 125V AC
AUX Contact Closure: 2A @ 30V DC, 0.6A @ 125V AC
DC Output: 1A @ 24V DC
Voltage: 120V AC
Current: 0.75A
Temperature: 0 to 104º F (-18 to 40º C)
Humidity: 0 to 85% non-precipitating
Approvals: C-UL (UL60950);
FCC Part 68 Registered;
FCC Part 15 Compliant;
Industry Canada CS-03
Dimensions: 16-3/8" W x 3-1/2" H x 4-7/8" D
19" W x 3-1/2" H x 4-7/8" D
(with mounting flanges)
Product Weight: 8 lb.
* Architect and Engineer Specifications are available online in a
Word document to assist you with preparing your bids.
