DANTE AV PTZ Camera
USER MANUAL
Part One: Camera Use
VERSION: D-09232021
DANTE AV CAMERA D412
© 2021 Bolin Technology

2
Contents
IMPORTANT INFORMATION ..................................................................................................................................................... 5
WHAT’S IN THE BOX ................................................................................................................................................................. 7
OVERVIEW................................................................................................................................................................................ 8
FEATURES ................................................................................................................................................................................. 8
CAMERA DIAGRAMS................................................................................................................................................................ 9
REMOTE CONTROLLER ...................................................................................................................................................................... 10
CAMERA INSTALLATION ......................................................................................................................................................... 11
CEILING MOUNT INSTALLATION.......................................................................................................................................................... 12
WALL MOUNT INSTALLATION............................................................................................................................................................. 13
SYSTEM CONFIGURATION....................................................................................................................................................... 14
OBTAIN VIDEO SIGNAL ..................................................................................................................................................................... 15
AUDIO IN....................................................................................................................................................................................... 15
CAMERA CONTROL METHODS AND SYSTEM CONFIGURATIONS............................................................................................. 16
USE THE INFRARED REMOTE CONTROLLER ............................................................................................................................................ 16
USE RS-232 (VISCA)...................................................................................................................................................................... 16
USE RS-422(VISCA)....................................................................................................................................................................... 18
RS422 (VISCA) CONNECTION ........................................................................................................................................................... 18
PELCO P/D KEYBOARD RS485 CONNECTION ...................................................................................................................................... 20
VISCA OVER IP CONTROL ........................................................................................................................................................ 22
TALLY LIGHT GPI I/O CONNECTION ......................................................................................................................................... 23
DIP SWITCH SETTINGS................................................................................................................................................................. 25
ADJUSTING AND SETTING WITH MENUS................................................................................................................................. 27
EXPOSURE MENU ......................................................................................................................................................................... 28
WHITE BALANCE MENU................................................................................................................................................................ 29
PICTURE 1MENU.......................................................................................................................................................................... 30
PICTURE 2MENU.......................................................................................................................................................................... 30
PAN TILT ZOOM MENU................................................................................................................................................................. 31
SYSTEM MENU ............................................................................................................................................................................ 33
STATUS MENU ............................................................................................................................................................................ 34
FIRMWARE UPGRADE............................................................................................................................................................. 34
UPGRADING MCU FIRMWARE........................................................................................................................................................... 34
UPGRADING DANTE AV FIRMWARE..................................................................................................................................................... 34
OPERATION USING THE INFRARED REMOTE CONTROLLER ..................................................................................................... 35
PAN/TILT AND ZOOM OPERATION ...................................................................................................................................................... 35
OPERATING MULTIPLE CAMERAS WITH INFRARED REMOTE CONTROLLER................................................................................................... 36
ADJUSTING THE CAMERA FOCUS......................................................................................................................................................... 36

3
STORING THE CAMERA SETTINGS IN MEMORY —THE PRESETTING FEATURE ............................................................................................... 37
MENU CONFIGURATION ......................................................................................................................................................... 41
TROUBLESHOOTING ............................................................................................................................................................... 43
WARRANTY ............................................................................................................................................................................ 44
SUPPORT CONTACT INFO........................................................................................................................................................ 45
DIMENSIONS .......................................................................................................................................................................... 46

4
Operating Instructions
Thank you for purchasing our product. If there are any questions, please contact the authorized dealer.
Before operating the unit, please read this manualthoroughly and retain it for futurereference.
Copyright
Copyright 2015-2021 Bolin Technology all rights reserved. No part of this manual may be copied,
reproduced, translated, or distributed in any form or by any means without prior consent in writing from
our company.
Trademark Acknowledgement
and other Bolin's trademarks and logos are the property of Bolin Technology Other
trademarks, company names and product names contained in this manual are the property of their
respective owners.
Trademarks and Registered Trademark Acknowledgement
•Microsoft, Windows, ActiveX, and Internet Explorer are registered trademarks of Microsoft Corporation
in the U.S. and/or other countries.
•HDMI, the HDMI logo and High-Definition Multimedia Interface are the trademarks or registered
trademarks of HDMI Licensing, LLC in the United States and other countries.
•The Software may contain h.264/AVC video technology, the use of which requires the following notice
from MPEG-LA, L.L.C.:
THIS SOFTWARE IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL
AND NON-COMMERCIAL USE OF A CONSUMER TO (I) ENCODE VIDEO IN COMPLIANCE WITH THE AVC
STANDARD ("AVC VIDEO") AND/OR (II) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER
ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR
ANY OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE
http://www.mpegla.com.
•HEVC/H.265 Covered by one or more claims of patents listed at patentlist.hevcadvance.com
•DanteTM, Dante AVTM is the trademarks of Audinate, Inc., company name and product name contained
in this manual are the property of their respective owners.
•Other trademarks, company names and product names contained in this manual are the property of
their respective owners.

5
IMPORTANT INFORMATION
Legal Notice
Attention:
To ensure account security, please change the password after your first login. You are recommended to set a
strong password (no less than eight characters). Password login does not apply to some models that do not
need password login.
The contents of this document are subject to change without prior notice. Updates will be added to the new
version of this manual. We will readily improve or update the products or procedures described in the manual.
Best effort has been made to verify the integrity and correctness of the contents in this document, but no statement,
information, or recommendation in this manual shall constitute formal guarantee of any kind, expressed or implied.
We shall not be held responsible for any technical or typographical errors in this manual.
The product appearance shown in this manual is for reference only and may be different from the actual
appearance of yourdevice.
This manual is a guide for multiple product models and so it is not intended for any specific product.
In this manual, the illustrations of displayed interface, parameters displayed, drawings and value ranges may vary
with models. Please see the actual product for details.
Due to uncertainties such as physical environment, discrepancy may exist between the actual values and reference
values provided in this manual.
Use of this document and the subsequent results shall be entirely on the user’s own responsibility.
Symbols
Symbol
Description
WARNING!
Contains important safety instructions and indicates situations that may cause bodily injury.
CAUTION!
User must be careful and improper operations may cause damage or malfunction of product.
NOTE!
Indicates useful or supplemental informationabout the use of product.
Safety Information
WARNING!
Installation and removal of the unit and its accessories must be carried out by qualified personnel. You must
read all the Safety Instructions supplied with your equipment before installation andoperation.
Warnings:
•If the product does not work properly, please contact your dealer. Never attempt to disassemble the camera
yourself. (We will not assume any responsibility for problems caused by unauthorized repair or
maintenance.)
•This installation should be made by a qualified service person and should conform to all the local codes.
•When shipping, the camera should be packed in its originalpackaging.
•Make sure the power supply voltage is correct before using the camera.
•Do not drop the camera or subject it to physicalshock.

6
•Do not touch sensor modules with fingers. If cleaning is necessary, use a clean cloth with a bit of ethanol
and wipe it gently. If the camera will not be used for an extended period of time, put on the lens cap to
protect the sensor fromdirt.
•Do not aim the camera lens at the strong light such as sun or incandescent lamp. The strong light can
cause fatal damage to the camera.
Maintenance Precautions:
•If there is dust on the front glass surface, remove the dust gently using an oil-free brush or a rubber
dust blowing ball.
•If there is grease or a dust stain on the front glass surface, clean the glass surface gently from the
center outward using anti-static gloves or an oil-free cloth. If the grease or the stain still cannot be
removed, use anti-static gloves or an oil-free cloth dipped with detergent and clean the glass surface
gently until it is removed.
•Do not use organic solvents, such as benzene or ethanol when cleaning the front glass surface.
Regulatory Compliance
FCC Part 15
This equipment has been tested and found to comply with the limits for digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his own
expense.
This product complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause undesired operation.
LVD/EMC Directive
This product complies with the European Low Voltage Directive 2006/95/EC and EMC Directive
2004/108/EC.
WEEE Directive–2002/96/EC
The product this manual refers to is covered by the Waste Electrical & Electronic Equipment
(WEEE) Directive and must be disposed of in a responsible manner.
Disclaimer
The contents of this document are subject to change without prior notice. Any updates and content changes will be added
to the subsequent new manual version.
If there are any concerns, please contact Bolin Support Team at www.bolintechnology.com
Website Reference and other information
For related product information please visit Bolin Technology website https://bolintechnology.com/

7
WHAT’S IN THE BOX
Accessories (Optional)

8
Overview
This user guide is suitable for the following models: D412
Features
•Dante AV powered by Dante AV Module, support Unicast or Multicast Dante AV video streaming
over Standard 1Gbps Ethernet.
•1/2.8 Inch “Exmor R” CMOS sensor, Effective pixel number: 8.29 Megapixels.
•Resolution: Up to 2160P60, 1080P60, 1080i59.94; supports 23.98 frame rate.
•Video Format-HDMI 2.0, Color Space supports YUV(YCbCr), RGB.
•IP Resolution: Up to 2160P60, 1080P60
•Zoom: Optical 12X, Digital 16X.
•Image stabilizer and true WDR 120dB.
•Support Day/Night mode, PTZ Trace Memory, Noise Reduction, Tally Light.
•Video Output: HDMI(4K), Dante AV(4K) simultaneously.
•Codec with Ultra-low Latency mode
•Synchronized Video and Audio.
•Dante Ecosystem Friendly, Instant Dante Ecosystem compatibility with existing Dante-enabled
products, Unified control of audio and video using Dante tools - Dante Controller.
•±175 degrees continuous pan, +90 degrees to -30 degrees continuous tilt.
•128 presets, Speed up to 150°/S.
•Standard mounting and ceiling mounting with E-Flip function
•Control supports RS-232 control, RS-422/485 control, VISCA-over-IP, IR Remote Controller.
•Image parameter setting restore with presets and quick access operation
•Supports MIC/LINE audio input, Audio output with HDMI, embedded with Dante AV IP signal.
•Power: DC 12V, PoE++ (IEEE802.3bt).
•Firmware upgrade via USB2.0 or Dante Upgrade Tool.

9
Camera Diagrams
1. 12V DC power port
Connect the supplied DC power adaptor and cord.
2. Video format selector (For video format selection)
3. DIP switch
4. IR remote ID selector
5. IR receivers
6. MIC/LINE input
ø3.5 mm stereo mini jack, input impedance: high impedance
During MIC input, supported mic: stereo mic (plug-in power) supply voltage: 2.5V ±0.5V
During LINE input, input level: approx. –10 dB ±3 dB
7. USB2.0 (Firmware upgrade only)
8. RJ45 port for RS232 control port
9. RJ45 port for RS-422/485 control port
10. LAN/POE++(IEEE802.3bt) for Dante video output
11. HDMI 2.0 (4K) video output
12. HDMI Cable Secure Mount
13. Power Indicator
14. Lens - with 12X optical zoom
15. Tally lamps
16. Status Indicator
17. Camera Bottom pads
18. Fixed mounting thread
19. Tripod mounting thread

10
Remote Controller
1. MENU, on screen menu display ON/OFF
2. Camera IR ID Selector for Remote Control.
3. AI Features, available when AI button (13#) is pressed. (Set for fan speed adjustment)
4. Positioning Function and Number Buttons
•Preset Position Calling and Setting
5. Value adjusting + for Feature Item NO.11.
6. Preset button, to set preset position.
7. Zoom. Telescope and Wide with slow speed.
8. Auto Framing. (Not activated).
9. Direction Control
•PAN-TILT direction control
•OSD menu navigator
•HOME: Home position, confirm button, Enter
button.
10. FOCUS
•Manual Focus, Far, Near
•Auto Focus
11. Features Direct Control, work with Value Adjust key +
and –to make the feature adjustments.
•Gain, Image gain adjustments
•Color, Image color saturation adjustments
•Black L, Image Black Level adjustments
•WB.R, Image White Balance Red adjustments
•PT S, Pan/Tilt Speed adjustments
•Zoom S, Zoom Speed adjustments
•Preset S, Preset Speed adjustments
•WB.B, Image White Balance Blue adjustments
•WDR, Wide Dynamic Range adjustments
•Freeze, To get a frozen image.
•B Light, Back Light compensation
•OPW, One Push White Balance
12. Video Format Switching, Works with pressing and
holding Fn button (15#).
•You can change the video format by keep
pressing the button. (When video format is
changed, the camera would restart, and the
screen turns black for few seconds.)
13. AI Mode key (Set for fan speed adjustment)
•Press AI button once, the button illuminated,
then press one of the AI features (Printed in
blue font) to adjust the speed of the fan.
14. Power (Press and hold for 3 second)
•Power ON the camera from standby mode to
operational status.
•Power OFF the camera to turn the camera to
standby status.
•When the camera is powered OFF, the
camera lens turns to the back for standby mode.
•When the camera is powered ON, the camera lens turns to the front.
•Powering the camera ON/OFF would not restart the camera.
15. Fn Function Mode key
•Press and hold the Fn key and press one of the function buttons that printed in brown font.
16. Reset button: to delete preset that has been set.
17. Zoom. Telescope and Wide with fast speed.
18. One Push AF
•Press once to focus.
Notes
•AAA Battery isnot included with the remote controller.

11
Camera Installation
This device is designed for indoor use only.
It is not designed to be used outdoors. Do not operate the device where it may meet constant heavy water. Please avoid
installing the unit in a location commonly exposed to sunlight for extended periods of time. Do not install the unit near
temperature adjustment device, such as a heating or cooling unit.
Failure to comply may cause abnormal behavior during operation or physical damage to the device.
Do not install the device in the following type of locations:
•In locations where the temperature is below -10 Celsius (32F) or above 40 Celsius (104F)
•On walls without proper mounting method and brackets
•In locations where humidity is 81% or higher
•In locations where it may be exposed to harmful chemicals
•Near sea where device can be exposed to corrosion
•In locations where the device will be exposed to strong radiation
•In locations where the device will be exposed to strong radio waves
•In locations where the device will be exposed to strong magnetic fields
•For other potentially questionable locations email Bolin Support for any questions or concerns
Safety Matters
For your safety, please disconnect all power to the device when installing and removing the device. Always use supplied
accessories and do not modify the supplied power adaptor.
Only qualified personnel should install and remove this device. Please make sure the installation environment is safe and
follows best practices prior, during, and after the installation process. Bolin does not accept any responsibility or liability
for any accident or damages resulting from malpractice or improper installations.
The following chapters will introduce the installation methods of the Dante AV camera.
Before mounting your camera, please make sure you have purchased the optional accessories needed
for the installation.
•Disconnect the power from the camera before camera installation.
•Accessories such as the Wall mount and Ceiling mount are necessary for the installation.
•Verify the bearing capacity of the mounted position.
•Tighten all the screws to hold the camera securely.

12
Ceiling Mount Installation
Need to use Ceiling Mount bracket and M4*6PW/M3*6PW screws for this installation. Ceiling mount is sold
separately. Please following the below diagrams for ceiling mount installation.
Required accessories and components:
Ceiling mount installation:

13
Wall Mount Installation
Need to use Wall Mount bracket and M4*6PW screws for this installation. Wall mount is sold separately.
Please following the below diagrams for wall mount installation.
Required accessories and components:
Wall mount pendant installation:
Wall mount standard installation

14
System Configuration
Connection
The camera’s pan, tilt, zoom can be controlled with a keyboard controller by connecting a control cable (crossover
cable, RS232, RS-422/485). The Dante AV decoder can be used to decode the Dante AV camera view and output it to
a monitor via HDMI. The decoder also has an RS-422 interface, allowing a keyboard controller to control the camera that
is subscribed to the decoder. The keyboard controller can alsocontrol the camera directly through the network (by using
Visca over IP protocol).
HDMI cables, Visca control cables, and network cables are required in this configuration setup. To obtain these
third-party components or accessories, consult the dealer where you bought yourcamera.
Power
•Use only the DC power adaptor (JEITA type4) supplied with the unit. Do not use
any otherDC power adaptor.
•If using POE to power the camera, POE++ (IEEE802.3bt) is supported.
•Ensure that the POE power source has sufficient power budget to power the camera, or some features
may not function properly.
Cable Requirements
For optimal experience with Dante AV, it is recommended that the following cables are used for the
application:
•HDMI2.0 or higher (due to 4K60 and color depth concern of our Bolin Dante AV PTZ Camera)
•Cat5e or Cat6 cable
Display monitor (recommended specs)
Any regular TV monitor with HDMI video output can be used for video display.
For optimal experience with Dante AV, it is recommended that the following display be used during application
testing/use:
•A monitor with high end color support
•A monitor with 1ms response time (forlatency testing and iflatency isa concern)
•3840 x 2160 resolution (4K UHD capable device)
•HDMI 2.0 port devices
•Support4.2.2 and 4.4.4 color modes

15
Obtain Video Signal
The camera can simultaneously have HDMI and Dante AV IP video output.
HDMI Video signal
1. Connect the camera to a UHD Monitor/TV using HDMI cable.
2. Turn on the camera, video will display on the monitor after initialization.
3. Information of the camera’s initial setting status will display for about 5 seconds.
4. You can set the video format of the camera to the one you want to display.
Dante AV IP Video Signal
1. You need a Dante AV decoder to obtain the Dante AV IP video stream
2. Use Cat6 network cable to connect Dante AV decoder and Dante AV camera to the same POE
network switch.
3. Connect Dante AV decoder to the HDMI display device.
4. Use Cat6 network cable to connect the PC with Dante Controller Software to the same network switch.
5. Running the Dante Controller, check to subscribe the video TX (camera HDMI video) to RX (decoder
HDMI video) connection.
6. Dante video will be displayed on the HDMI monitor via the Dante AV decoder.
Audio IN
•The camera is equipped with a 3.5mm audio
input interface, supports Line in or Mic audio
signal input.
•On rear panel, a microphone or audio source
can be connected to the MIC/LINE Input port,
which feeds audio into the camera
•User can select the audio input type to be LINE
or MIC via the HDMI OSD menu, to adapt the
input audio signal.
NOTE: If the audio Input Type is selected as MIC,
user can also set Plugin Power to ON, so that the
camera can supply power to the connected
microphone. The power supply voltage is 2.5V.
•Audio is embedded with Camera HDMI and Dante AV video signal.
Camera Initial setting status Information
Information of the camera initial setting status will display for 5
seconds.
1. Camera PELCO ID for RS-485 control
2. Camera ID for IR Remote Controller
3. Baud Rate setting
4. COM Port setting
5. Video format setting
6. HDMI setting
7. Model Type
8. MCU firmware version
PELCO ID 001
IR ID 1
BAUD RATE 9600
COMM TYPE 232
FORMAT 2160P29.97
HDMI OUT YUV422
MODEL TYPE ----
MCU FW: V0C260B40040AA008
Camera Status Info Display

16
Camera Control Methods and System Configurations
There are multiple ways of controlling the camera and various system configuration capabilities by using
optional products. This section describes controlling methods with typical system examples and the required
components of each.
1. Use the Infrared Remote Controller
2. Use RS-232 (VISCA)
3. Use RS-422/485 (VISCA/PELCO P/D)
4. IP Control (See Network Camera User Manual)
Use the Infrared Remote Controller
To operate the camera from a short distance.
For IR remote control detail, please refer to Operation Using the Infrared Remote Controller.
Use RS-232 (VISCA)
You can use RS-232 port to connect optional controllers, such as joystick keyboard controller or PC control
station, to operate the camera. To perform pan/tilt and zoom operations, use the joystick of the keyboard
controller. Preset operation can be done using the control buttons on the keyboard as well.
An application software that supports this camera is needed if using a PC station.
RS232 Connection
1. Set RS232 control method on rear panel Dip Switch.
2. Set Baud Rate on Bottom Dip Switch to the same as Baud Rate setting on the keyboard.
3. Set specific VISCA address to control the camera for with the Bottom Dip Switch located on the camera.
4. If you want to have the camera address automatically assigned by VISCA controller, set camera Dip Switch
address to 0.
5. Reboot the camera after the Dip Switch has been set up correctly.
6. Camera supports Daisy Chain connection up to 7 cameras.
7. Use the RJ45 to RS232 (VISCA) control cable. The controller must be VISCA compatible.

17
8. You can make RS232 connection cable if you have the following applications:
9. Use the included RJ45 to RS232 8 pin Mini Din adaptor to make RS232 connection for your control device.
10. Use the included RJ45 to RS422/232 Phoenix terminal contact adaptor to make RS232 connection for your
control device.
11. Or you can use CAT5/6 network cable (T-568B standard pinout) to make RS232 connection by
following the pin definition below:

18
12. How to make RS232 Daisy Chain multiple camera connection with standard RS232 serial port
controller as below:
Use RS-422(VISCA)
You can use RS-422/485 port to connect optional controllers, such as joystick keyboard controller or PC
control station, to operate the camera. To perform pan/tilt and zoom operations, use the joystick of the
keyboard controller. Preset operation can be done using the control buttons on the keyboard as well. An
application software that supports this camera is needed if using a PC station.
RS422 (VISCA) connection
1. Set RS422 control method on Bottom Dip Switch.
2. Set Baud Rate on Bottom Dip Switch to the same as Baud Rate setting on the keyboard you are using.
3. Set specific camera address that you want to control the camera for via the Bottom Dip Switch.
4. If you want to have the camera address automatically assigned by VISCA controller, set camera Dip Switch
address to 0.
5. Reboot the camera after the Bottom Dip Switch has been set up correctly.
6. Use the RJ45 to RS422 control cable. The controller must be VISCA compatible.
7. Camera supports Daisy Chain connection up to 7 cameras.
8. The connection of SONY keyboard is different than other VISCA (Non-Sony) keyboard.
9. How to make RS422 connection and RS422 Daisy Chain connection with SONY controller is shown below

19
SONY Keyboard RS422 Connection
10. How to make RS422 connection and RS422 Daisy Chain connection with Non-Sony controller as below:
VISCA (Non-Sony) Keyboard RS422 Connection
11. Use included RJ45 to RS422 Phoenix connecter adaptor to make RS422 connection for your control device.

20
12. Or you can use CAT5/6 T-568B Standard Ethernet cable direct connect between the camera and the controller
to make RS422 connection by following the pin definition below:
13. How to make RS422 Daisy Chain multiple camera connection with RS422 standard serial port controller:
PELCO P/D Keyboard RS485 Connection
NOTE: Use RS422 ports for RS485 connection. Only use TX+ and TX- for RS485 connection.
•Set RS422 control method on Bottom Dip Switch.
•Set Baud Rate on Bottom Dip Switch to the same as Baud Rate setting on the keyboard.
•Set the camera ID on OSD menu by remote controller
•Reboot the camera after the Bottom Dip Switch has been set up correctly.
•Use PELCO P/D compatible keyboard.
•Use preset 95 on the keyboard to bring up/exit camera OSD menu.
