Bolin Technology VCC-M2H10BI-4FN1 User manual

1
Dual Output SDI+IP
PTZ Camera
USER MANUAL
Part Two: Network Camera User Manual
Version: SN-IP-09042020
© 2020 Bolin Technology

2
Contents
PART TWO: NETWORK CAMERA USER MANUAL....................................................................................................................... 3
NETWORK CONNECTION .......................................................................................................................................................... 3
PREPARATION ........................................................................................................................................................................... 3
CHECK BEFORE LOGIN ................................................................................................................................................................. 3
LOGGING IN TO THE WEB INTERFACE ....................................................................................................................................... 4
INTRODUCTION TO THE WEB INTERFACE.................................................................................................................................. 5
PREVIEW ................................................................................................................................................................................. 6
PAN AND TILT ........................................................................................................................................................................... 6
PRESETS .................................................................................................................................................................................. 6
VIDEO ENCODE ......................................................................................................................................................................... 7
VIDEO TRANSMISSION................................................................................................................................................................. 8
IMAGE ADJUST.......................................................................................................................................................................... 9
AUDIO SETTING....................................................................................................................................................................... 12
ETHERNET.............................................................................................................................................................................. 12
FIRMWARE UPGRADE ............................................................................................................................................................... 13
RESET OPTIONS....................................................................................................................................................................... 13
ACCOUNT .............................................................................................................................................................................. 14
OSD .................................................................................................................................................................................... 14
SYSTEM TIME ......................................................................................................................................................................... 15

3
Part Two: Network Camera User Manual
Network Connection
Before accessing a network camera (also known as IP Camera or IPC) from a PC, you need to connect
the network camera to the PC directly with a network cable or via a switch or router.
Use a Shielded Twisted Pair (STP) cable to connect the network interfaces of the network camera and
the PC.
Use Shielded Twisted Pair (STP) cables to connect the network interfaces of the camera and the switch
or router.
Preparation
After you have completed the installation in accordance with the quick guide, connect the camera to
power to boot it. After the camera is booted, you can access the camera from a PC client using Internet
Explorer or a Video Management System (VMS).
The following uses Internet Explorer 11 on a Microsoft Windows 10 operating system as an example.
Check before login
⚫ The camera is powered on and connected to the network switch
⚫ The camera’s IP address is located within the same subnet as the PC
⚫ The PC is connected to the network switch
⚫ The PC’s IP address is located within the same subnet as the camera
⚫ The PC is installed with Internet Explorer 8.0 or higher (Internet Explorer 11 recommended)
⚫ Use default video format setting or set the camera video format to 1080P30 or 1080P25 using
RS485 keyboard (Refer to camera setting menu).

4
Logging in to the Web Interface
The default static IP address of the camera is 192.168.0.13, and the default subnet mask is
255.255.255.0
The following uses Internet Explorer 11 as an example to describe the login procedure.
1. Browse to the login page by entering the
correct IP (default IP is 192.168.0.13)
address of your camera in the address bar.
2. Enter the username and password, and then
click Login. For the first login, use the
default username admin and password
admin.
•The default password is used for your
first login. To ensure account security,
please change the password after your
first login. You are recommended to set a
strong password (no less than eight
characters).
•The camera protects itself from illegal
access by limiting the number of failed
login attempts. If login fails six times
consecutively, the camera locks
automatically for tenminutes.
NOTE: If your PC/laptop already installed VLC player, you can watch live preview directly after logged in. If
your PC/laptop haven’t installed VLC player yet, you may be prompted to install the VLC player.
Please download and install the correct version of VLC player (it means if your PC/ laptop operating system is
64 bit, you have to download the 64 bit version VLC, if your PC/laptop is 32 bit, so you have to download the 32
bit version VLC), after done the installation, user can re-login to the IP interface and watch the live preview.

5
Introduction to the Web Interface
1. Preview
•Used to monitor the camera video image
•Used to do camera PTZ control and preset setting
2. Video Encode
•Used to configure the camera video Main and Sub streams video parameter, such as encode
mode, resolution, bit rate, frame rate, I Frame Interval and so on
3. Video Transmission
•Used to configure the camera RTMP streaming, to push the RTMP streaming to the third-party
video platform, like the Youtube, Facebook and so on
4. Image Adjust
•Used to configure the camera image parameter, such as focus, exposure, white-balance, image,
image setting, noise reduction
5. Audio Setting
•Used to configure the camera audio parameter, such as the Encoder Mode, Sample rate and
Bitrate
6. Ethernet
•Used to configure the camera network parameter, can be static IP or DHCP, as well as HTTP port
and RTSP port configuration
7. Firmware Upgrade
•Used to display the camera current version information
•Used to do firmware upgrade
8. Reset Options
•Used to reset the camera image parameter/all parameter to default
•Used to reboot the camera
9. Account
•Used to modify the admin account password
10. OSD
•Used to overlay the time, camera name, logo and text content on the IP video
11. System Time
•Used to setting the time zone and synchronize camera system time with the NTP server

6
Preview
The preview page is used to watch the live preview
of the camera.
Play/stop Live Preview:
User can click the / button which on the
bottom toolbar, to watch live video or stop the live
video.
Mute:
User can enable or disable the audio of live preview
by click the button on bottom toolbar, while
enabled audio, user can drag the volume bar to
adjust the audio.
Fullscreen:
User can click the button to enlarge the live preview window to full screen, then click button again to
back to normal size, or press PC/laptop “Esc” button to switch back to normal size while in full screen.
Pan and Tilt
Pan and Tilt menu is used to do:
•Camera PTZ control,
•Adjust the pan / tilt / zoom speed
•Set focus mode
Pan/Tilt Speed: to adjust the pan/tilt speed, support 0-24 level selectable
Focus Speed: to adjust the focus speed, support 0-7 level selectable
Zoom Speed: to adjust the zoom speed, support 0-7 level selectable
Speed Reset: To reset the zoom and focus speed to default
PTZ Reset: To reset the PTZ control to default
Standby: If turn on standby switch, the camera will go to standby status, it is not
power off, you can get it back immediately by turn off the standby.
Presets
Presets are predetermined positions that the user can command the camera
to recall quickly.
To add a new preset:
1. Use the control panel and image viewer to pan to the desired Pan, Tilt,
Zoom, and Focus position
2. Click the triangle symbol which in the drop-down list, select a number for
this position (here we select 2 as example)
3. Click the pencil symbol and it will save this position as preset 2
4. Select a preset number and click Go button, the camera will to recall the
position quickly
5. Select a preset number and click Delete button, it will delete this preset
and you can not recall it quickly by GO button

7
Video Encode
The video encode page is used to configure settings for the compression, format, and data rates for all video
streams produced by the camera
Definitions:
•Encode Mode: The encoding standards that
are available for use (H.264 / H.265)
•Profile: Support baseline, MP and HP mode
•RTSP Address: The RTSP streaming URL
of both main stream and sub stream
•Resolution: (W x H) The number of Pixels
that make up the width of the image (W) by
the number of horizontal lines that make up
the height of the image (H)
•Bitrate: The amount of data transmitted per
second. Measured in Kilobits Per Second
(Kbps). 1000 kbps = 1Mbps
•Framerate: Rate at which image frames are
captured
•Bitrate Control:
oCBR –Constant Bit Rate
oVBR –Constrained Variable Bit Rate.
•I Frame Interval: The shorter the Interval, the
better chance you have of video being of
better quality.
I Frame also can be called “Key Frame”, a "Key
Frame" is an entire and complete and total image, that
is used as a reference for other frames ("images") that
the camera generates
•Main Stream –The main stream, viewed by default on the preview page
oEncode Mode:
▪H.264
▪H.265
oRTSP Address:
▪RTSP main stream address
▪Automatically generated based on the current IP address of the camera
▪You can copy this address and using VLC or other network video compatible player to
receive the RTSP main stream and watch the video.
oResolution:
▪1920x1080
▪1280x720
▪1024x576
oBitrate:
▪The amount of data transmitted per second. Measured in Kilobits Per Second (Kbps).
1024 kbps = 1Mbps
▪0-15360 selectable
oFramerate:
▪Rate at which image frames are captured
▪1-60 selectable
oBitrate Control:
▪CBR –Constant Bit Rate
▪VBR –Constrained Variable Bit Rate.
oI Frame Interval
▪1-100 selectable
•Sub Stream –The sub video stream produced by the camera; this can be disabled by unchecking the
box at the top of this stream’s settings we can switch to sub stream on the top bar of preview page
oEncode Mode:
▪H.264
▪H.265
oRTSP Address:
▪RTSP sub stream address

8
▪Automatically generated based on the current IP address of the camera
▪You can copy this address and using VLC or other network video compatible player to
receive the RTSP sub stream and watch the video
oResolution:
▪1280x720
▪1024x576
▪640x360
oBitrate:
▪0-15360 selectable
oFramerate:
▪Rate at which image frames are captured
▪1-60 selectable
oBitrate Control:
▪CBR –Constant Bit Rate
▪VBR –Constrained Variable Bit Rate.
oI Frame Interval:
▪1-100 selectable
Video Transmission
This camera supports RTMP
protocol, it can push streaming to
other CDN or cloud platform.
oCheck the RTMP State
Main or Sub Enable button
oCopy and paste the stream
URL from the online
platform
oCopy and paste the Stream
Key (Also known as the
Stream ID) from the online
platform.
Example shows where to copy the
information from YouTube
For Example
URL/Key: rtmp://a.rtmp.youtube.com/live2/6yeu-mg8p-txtm-mvp9-35eb
oClick Save button on camera RTMP page
oAllow a few minutes for the stream to connect. The status on your streaming platform (Such as
YouTube) will change to Live. When this happens, the camera is streaming video Live to
NOTE:
•Must enable audio on Audio Setting page before setup RTMP streaming, otherwise, RTMP streaming
may without audio source.
•Similar steps can be followed to stream to any platform that supports RTMP, such as Facebook, Twitter,
Twitch, etc.)

9
Image Adjust
Image parameters can be adjusted to control the way the image is captured and displayed
Focus
The Focus menu is used to set the items related to focus
Focus Mode:
You can set to Manual or Auto mode
Digital Zoom:
Turn Digital Zoom ON, 2x digital zoom is activated.
You can set digital zoom to ON or OFF. When turn to OFF, digital zoom does not operate, and only optical
zoom is available. When turn to ON, digital zoom takes over after optical zoom reaches MAX (20x). Up to 40x
can be zoomed digitally.
When digital zoom is available, the resolution decreases

10
Exposure
The Exposure menu is used to set the items related to exposure.
Exposure Mode
Auto: The exposure is adjusted automatically using the values set for EX-COMP (Exposure
Compensation).
Manual: Adjust the GAIN, electronic shutter speed (SPEED), iris (IRIS) manually.
Iris Priority: Iris Priority mode. The exposure is adjusted automatically using the values manually set
for iris (IRIS) and EX-COMP.
Shutter Priority: Shutter Priority mode. The exposure is adjusted automatically using the values
manually set for electronic shutter speed (SPEED) and EX-COMP.
Brightness Priority: Bright Priority mode. The exposure is adjusted automatically using the values
manually set for electronic brightness level.
When you select one from various exposure modes, some of the following setting items that can be adjusted.
Gain: Adjustable from 0 to 15 by drag the setting bar (not available in Auto, Iris, Shutter, Brightness mode)
Shutter: Adjustable from the following
1/30, 1/60, 1/90, 1/100, 1/125, 1/180, 1/250, 1/350, 1/500, 1/725, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000,
1/6000, 1/10000 (not available in Auto, Iris, Brightness mode)
Iris: Adjustable from 0 to 13 by drag the setting bar (not available in Auto, Shutter, Brightness mode)
Anti-flicker: Enable it before you to select, 50Hz and 60 Hz selectable
Brightness: Adjustable from 0 to 27 by drag the setting bar (not available in Auto, Manual, Iris, Shutter mode)
White-Balance
The White-Balance menu is used to set the items related to white balance.
White Balance Mode
Auto: This mode computes the white balance value output using color information from the entire
screen. It outputs the proper value using the color temperature radiating from a black subject based on
a range of values from 2500K to 7500K. This mode is the initial setting.
Indoor: 3200K Base Mode
Outdoor: 5800K Base Mode

11
One Push: The One Push White Balance mode is a fixed white balance mode that may be
automatically readjusted only at the request of the user (One Push Trigger), assuming that a white
subject, in correct lighting conditions, and occupying more than 1/2 of the image, is submitted to the
camera. One Push White Balance data is lost when the power is turned off. If the power is turned off,
reset One Push White Balance.
NOTE: When you select the One Push
Perform the following operations:
1. Place an image of white subject (For example: A piece of white paper) in the center ofthe
screen.
2. Press the HOME button of theinfrared remote controller.
The one-push white balance adjustment isactivated.
Auto tracking: Auto Tracking White balance (2000K to 10000K), allows the camera to adjust the tone
according to the temperature of the light source illuminating the subject
Manual: This is a mode that enables you to manually set the control of Red and Blue gain from o to 255
The Image menu is used to set the items related to image
Mirror: You can have the image as seen in a mirror, with the right side as though it were the left.
Flip: Image E-Flipper –Used when ceiling mounting or upright mounting. Set to OFF is upright mode, set to
ON is for ceiling mount.
BLC (Backlight compensation):
When the background of the subject is too bright, or when the subject is too dark, back light compensation will
make the subject appear clearer.
Gamma: The gamma can be set to value from 0 to 4
D-WDR (Wide Dynamic Range): Wide Dynamic: ON, OFF. The camera distinguishes light and dark areas
within the same scene, adjusts the brightness for dark areas, and also controls the blown-out highlights.
You can select the wide dynamic range mode between ON and OF
Image Setting
The Image Setting menu is used to set the items related to image quality
Brightness: You can adjust the values manually for electronic brightness level from 0 to 15
Sharpness: Picture sharpness value ranges from 0 to 15. You can enjoy emphasized edge and high-
resolution images.
Contrast: You can adjust the contrast level in the range from 0 to 15. The smaller the value is, the lower the

12
contrast becomes, and the larger the value is, the higher the contrast becomes.
Saturation: You can configure the color gain from 0-15. Use this setting when bright color is particularly
important.
Noise-reduction
The Noise-reduction is used to set the items related to noise, it supports 2D and 3D mode noise reduction.
You can enjoy clearer images by removing unnecessary noise.
For 3D mode, you can select Auto, or set value from 1 (MIN) to 4 (MAX).
Audio Setting
This section contains the ability to select the audio Encode Mode,
Sample rate and Bitrate.
•Encode Mode:
oAAC
oLPCM
•Sample rate:
oSelectable from 11050, 22050, 44100
•Bitrate (Kbps):
oSelectable from 32000, 48000, 64000, 96000, 128000
Ethernet
The Ethernet settings page is where the user is able to configure the
following:
•DHCP options
oDHCP –An IP address will be dynamically assigned to
the camera from the gateway (router)
oStatic IP –The user will enter / define the IP address
•IP Address
•Netmask
•Gateway
•DNS (Domain Name System)
•MAC (MAC address of the camera)
oMedia Access Control address, is a unique identifier
assigned to a network interface controller of the camera,
it comes with camera by default, can’t be changed.
•HTTP port: Default 80
oHTTP is the protocol used to access the web interface.
oChanging this port number will require the user to specify
the port number when entering the IP address to the web
browser.
oFor example, if it is changed to 8080, the IP address will
need to be entered as follows in order to access the web interface: http://192.168.0.13:8080

13
•RTSP Port: Default 554
oRTSP is the protocol used to pull real-time video over the network (using VLC Player or other
network video- compatible software)
oChanging this port number will change the way the RTSP video can be viewed. Most RTSP
streaming software uses port 554 by default, therefore it is not recommended that this port
number be changed.
oURL for receive RTSP streaming is:
Main stream –rtsp://IP:554/stream/main
Sub stream –rtsp://Ip:554/stream/sub
Firmware Upgrade
This page allows the user to get the camera current version information, camera name, serial number and to
do upgrade.
•Control version
oTo display the camera current control version
•Device Name
oThe name of this camera model, you also
can see it on the top left corner of any page.
•Serial Number
oThe unique serial number after the camera is
produced, each camera serial number is
different, and can’t be changed.
•Bootloader Version
oTo display the camera current bootloader
version
•System Version
oTo display the camera current system
version
•App version
oTo display the camera current App version
•Upgrade
oYou can upgrade the camera version when
there has new firmware available.
oNew firmware file can be obtained from BOLIN Technology
oClick “Click to upload files” button, navigate to the file (.bin), select and then can start upgrade
oIt takes a few minutes for the camera to come back online
Reset Options
This page allows user to reset parameter to default, you
can just reset image parameter or reset all parameters,
Also supports to reboot the camera
•Reset
oWill reset the camera’s image parameter
to factory default values
•Reset/Reboot
oWill reset all settings / parameters to
factory default values and camera will
auto reboot
•Reboot
oThis button performs a soft reboot
(camera will restart without needing to
disconnect power)

14
Account
This page allows user to modify admin account password,
the default password is admin;
User can login to the web interface, access to Account
page, to modify the password;
Input the new password in Password option bar, then
input the password once again in Confirm Password
option bar;
After done, click Save button to make it take effect, then
you can login the web interface with the new password.
OSD
There are On Screen Display (OSD) sections within the IP video image, each OSD section can be individually
configured to display configurable data.
Camera Name:
User can define a name for the
camera.
Background:
Background of the OSD, can be
configured as Translucent or
Transparent.
Color:
Color of the OSD content, selectable
from Black, Blue, Red, Green,
Magenta, Cyan, Yellow and White
color.
Background Color:
Background color of the OSD content, only available while Background selected Translucent mode.
Selectable from Black, Blue, Red, Green, Magenta, Cyan, Yellow and White color.
Area (Center, Area1, Area2, Area3, Area4):
OSD position on the IP video image
Any of the 5 areas (Center and Area 1 ~ Area 4)
can be configured to contain one of the following:
Close –The area will not be used, and will not
display anything;
Datetime –The internal Date and Time settings
will be used to fill the area;
Camera Name –The user will define a name for
the camera;
Logo –An image, such as a company logo can
be uploaded to be displayed within the IP video
image;
Text –User can enter the text that they wish to
be displayed

15
System Time
The interface allows user to configure the time zone and
synchronize camera system time with the NTP server.
Time Zone:
Support 24 time zones, users can choose the corresponding
time zone according to their country.
NTP Enable:
To enable and disable NTP server
NTP Update Interval:
Update interval of time synchronization between camera and
the NTP server, selectable from 30 minutes, and 1 hour to 24
hours.
NTP Server Address
To configure the address of the NTP Server
NTP Port
Port setting for NTP Server, default setting is 80

16
www.bolintechnology.com
2082 TECHNOLOGY LLC
dba
BOLIN TECHNOLOGY
