Bolin Technology D Series User manual

1
D
Flo
D Series
D2-210H and D2-220H
USER GUIDE
VERSION: D-1
DANTE AV-H™PTZ CAMERA D2-210H &D2-220H
© 2023 Bolin Technology

2
D
Flo
Table of Contents
Welcome to Bolin Technology…………………………………………….4
Important Information.........................................................................5
What's in the Box?………………………………………………………………………..8
Camera Features & Software Installation……………………………………….9
D2- 210 H and D2- 220 Camera Overview……………………………10
IR Remote Control……………………………………………………….11
Camera Installation………………………………………………………11
Ceiling Mount Installation……………………………………………………..13
Wall Mount Installation………………………………………………………..15
Camera Power & HDMI Output Setup ………………………………..16
Power & Video Signal Connections…………………………………………16
Audio In………………………………………………………………………...15
Camera Control Options & Configurations……………………………18
Using the Infrared Remote Control………………………………………… 18
Using RS-232 (VISCA) ……………………………………………………….19
VISCA Over IP & Dip Switch Settings Overview…………………………...19
Using RS422 (VISCA) & connections………………………………………..21
PELCO P/D Controller RS485 Connection………………………………….23
VISCA over IP Control……………………………………………………24
Bolin Controller VISCA Over IP Setup Overview…………………….. 25
On Screen Display (OSD) Settings & Options………………………...26

3
D
Flo
Firmware Upgrade…………………………………………………………29
Upgrading Dante AV-H™Firmware…………………………………………...30
Basic Dante AV-H™System Setup……………………………………...30
Audinate Dante Controller Overview……………………………………..31
Dante Controller Device Info, Clock Status and Network Status……………32
Dante Controller Device View, Overview………………………………………33
Dante AV-H™Streaming Workflow Example…………………………………36
Web User Interface Overview……………………………………….........37
Settings Menu > Fast Settings…………………………………………………..40
Settings Menu > Camera Settings………………………………………………41
Settings Menu > Image Settings………………………………………………...42
Settings Menu > Audio Settings…………………………………………………44
Settings Menu > Network Settings………………………………………………44
Settings Menu > System Settings……………………………………………….47
Settings Menu > Operation Settings…………………………………………….48
FAQs & Support Contact Information……………………………………..48
Warranty…………………………………………………………………………….50
Dimensions…………………………………………………………………...51

4
D
Flo
Thank you for purchasing your Dante AV™Bolin camera. If you have any questions
regarding the camera, please contact your authorized dealer.
Our website also offers a support page and user stories to inspire you to get the
most out of your Bolin camera.
Copyright
Copyright 2015-2023 Bolin Technology all rights reserved. No part of this manual may be
copied, reproduced, translated, or distributed in any form or by any means without prior
consent in writing from our company.
Trademark Acknowledgement
and other Bolin trademarks and logos are the property of Bolin Technology.
Other trademarks, company names and product names contained in this manual are the
property of their respective owners.
Trademarks and Registered Trademark Acknowledgement
oMicrosoft, Windows, ActiveX, and Internet Explorer are registered trademarks of Microsoft
Corporation in the U.S. and/or other countries.
oHDMI, the HDMI logo and High-Definition Multimedia Interface are the trademarks or
registered trademarks of HDMI Licensing, LLC in the United States and other countries.
oThe Software may contain h.264/AVC video technology, the use of which requires the
following notice from MPEG-LA, L.L.C:
THIS SOFTWARE IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE
PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER TO (I) ENCODE VIDEO IN
COMPLIANCE WITH THE AVC STANDARD ("AVC VIDEO") AND/OR (II) DECODE AVC VIDEO THAT
WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY
AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO
LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION
MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE http://www.mpegla.com.
oHEVC/H.265 Covered by one or more claims of patents listed at:
patentlist.hevcadvance.com
oDante™and Dante AV-H™are the trademarks of Audinate, Inc. Company name and
product name contained in this manual are the property of their respective owners.
oOther trademarks, company names and product names contained in this manual are the
property of their respective owners.
Important Information
Welcome to Bolin Technology

5
D
Flo
Legal Notice
Attention:
To ensure account security, please change the password after your first login. We recommend
setting a strong password (no less than eight characters). Password login does not apply to
certain models.
The contents of this document are subject to change without prior notice. Updates will be added
to new versions of this manual. We will readily improve or update the products or procedures
described in the manual.
We have made our best effort to verify the integrity and correctness of the contents in this
document, but no statement, information, or recommendation in this manual shall constitute
formal guarantee of any kind, expressed or implied. We shall not be held responsible for any
technical or typographical errors in thismanual.
The product appearance shown in this manual is for reference only and may be different from
the actual appearance of yourdevice.
This manual is a guide for multiple product models and so it is not intended for any specific
product.
In this manual, the illustrations of displayed interface, parameters displayed, drawings and value
ranges may vary with models. Please see the actual product for details.
Due to uncertainties such as physical environment, discrepancy may exist between the actual
values and reference values provided in this manual.
Use of this document and the subsequent results shall be entirely on the user’s own
responsibility.
Symbols
Symbol
Description
WARNING!
Contains important safety instructions and indicates situations that may cause bodilyinjury.
CAUTION!
User must be careful and improper operations may cause damage or malfunction of product.
NOTE!
Indicates useful or supplemental informationabout the use of product.
Safety Information
WARNING!
Installation and removal of the unit and its accessories must be carried out by qualified
personnel. You must read all the Safety Instructions supplied with your equipment before
installation andoperation.
Important Information

6
D
Flo
Warnings:
oIf the product does not work properly, please contact your dealer. Never attempt to
disassemble the camera yourself. (We will not assume any responsibility for problems
caused by unauthorized repair or maintenance.)
oThis installation should be made by a qualified service person and should conform to all
the local codes.
oWhen shipping, the camera should be packed in its originalpackaging.
oMake sure the power supply voltage is correct before using the camera.
oDo not drop the camera or subject it to physicalshock.
oDo not touch sensor modules with fingers. If cleaning is necessary, use a clean cloth
with a bit of ethanol and wipe it gently. If the camera will not be used for an extended
period of time, put on the lens cap to protect the sensor from dirt.
oDo not aim the camera lens at the strong light such as sun or incandescent lamp. The
strong light can cause fatal damage to the camera.
Maintenance Precautions:
oIf there is dust on the front glass surface, remove the dust gently using an oil-free brush
or a rubber dust blowing ball.
oIf there is grease or a dust stain on the front glass surface, clean the glass surface
gently from the center outward using anti-static gloves or an oil-free cloth. If the grease
or the stain still cannot be removed, use anti-static gloves or an oil-free cloth dipped
with detergent and clean the glass surface gently until it is removed.
oDo not use organic solvents, such as benzene or ethanol when cleaning the front glass
surface.
Regulatory Compliance
FCC Part 15
This equipment has been tested and found to comply with the limits for digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
This product complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
1.This device may not cause harmful interference.
2. This device must accept any interference received, including interference that
may cause undesired operation.

7
D
Flo
LVD/EMC Directive
This product complies with the European Low Voltage Directive 2006/95/EC and EMC
Directive 2004/108/EC.
WEEE Directive–2002/96/EC
The product this manual refers to is covered by the Waste Electrical & Electronic
Equipment (WEEE) Directive and must be disposed of in a responsible manner.
Disclaimer
The contents of this document are subject to change without prior notice.
Any updates and content changes will be added to the subsequent new manual version.
If there are any concerns, please contact Bolin Support Team at:
www.bolintechnology.com
Website Reference and other information
For related product information please visit Bolin Technology website
https://bolintechnology.com/

8
D
Flo
Accessories (Optional)
What’s in the Box?

9
D
Flo
This user guide is suitable for the following Bolin Dante AV™cameras:
D2-210 H and D2-220H
Camera features
oDante AV™H supports Unicast or Multicast video streaming over a standard 1Gbps Ethernet.
oSony 1/2.8 Inch CMOS sensor, Effective pixel number: 2.13 Megapixels.
oResolution: Up to 1920×1080p60/50/30/25fps.
oColor Space supports YUV(YCbCr) and RGB.
oIP Resolution: Up to 1080P60.
oThe D2-210H has a 10X optical and 16X digital zoom and the D2-220H a 20X optical and 16X
digital zoom.
o3G-SDI video output: D2-220H only.
oHDMI1.4 -Type A and USB 2.0 - Type C.
oOn screen display (OSD), WDR On/Off, Day/Night mode On/Off, Contrast, Color Hue, Color Matrix,
Gamma (0 to 4) and High Sensitivity.
oAuto and Manual Exposure, Shutter / Day/NIght / Brightness priority.
oFocus Zone: Face Priority, All Area, Upper Area, Central Area and Lower Area
oAI Face Detection Focus and Exposure.
o2D and 3D Noise Reduction (1-255).
oFour PTZ Trace Memory supported via IP interface, Noise Reduction and Tally Light.
oVideo Output: HDMI 1.4 and Dante AV-H™simultaneously.
oLatency Codec <280ms at 1080p60
oSynchronized Video and Audio.
oDante AV™Ecosystem integration with existing Dante-enabled products, Unified control of audio.
and video using Dante Controller.
o±175 degrees continuous pan, +90 degrees to -30 degrees continuous tilt.
o255 presets, Speed up to 150°/S, accuracy: 0.05°with 6 presets on remote control.
oStandard mounting and ceiling mounting with E-Flip function.
oControl via RS-422(RJ45 x1) IP controls (RJ45 x1) and IR Remote Control.
oImage parameter setting restore with presets and quick access operation.
oMIC/LINE audio input (D2-210H only) and USB port to 3.5mm audio jack (D2-220H).
oPower: DC 12V, PoE+ (IEEE802.3at).
oFirmware upgrade via USB2.0 or Dante AV™software.
Software Installation
❖Required software from Audinate: Download and install Dante Controller from Audinate’s website
on your PC: https://my.audinate.com/support/downloads/dante-controller
❖Suggested additional software available from Audinate: Dante Studio™to stream PTZ camera and
Dante AV content by seamlessly integrating your PC and applications such as vMix, Zoom, OBS
etc. https://my.audinate.com/forms/dante-studio-trial-survey
Camera Features & Software

10
D
Flo
Note: The D2-210H can be powered using the included power supply
adapter, an Ethernet Switch with PoE+ support or PoE+ device.







DC12V Power input
LAN/PoE +
Ethernet port
HDMI 1.4 Port
3.5mm audio input
RS232/RS422/4
85 Control port
USB 2.0 Type
C Audio / Video
IP streaming
USB2.0







D2-210H Camera Overview

11
Flo
Note: The D2-220H can be powered using the included power supply
adapter, an Ethernet Switch with PoE+ support or PoE+ device.
The D2-220H does not have a 3.5mm audio input connection.
Please use the USB port to 3.5mm audio jack to input audio.

























D2-220H Camera Overview

12
D
Flo
1Menu - On Screen Display (OSD) ON/OFF
13. AI only active when AI button is activated.
oPress the AI button to turn it on (highlighted when
activated) and use the # 2 (I) and 3 (III) to adjust
the fan speed of the camera.
14 Power: Press and hold for 3 seconds.to turn the camera
ON /OFF.
oPower OFF the camera is on standby mode.
oWhen the camera is ON, the lens is turned to the
front.
oWhen the camera is OFF, the lens is turned to
the back (standby mode).
oPowering the camera ON/OFF will restart the
camera.
2.IR ID Selector up to 3 cameras can be controlled
15 Fn button: Press and hold and press any of the function
buttons in brown below (STD, REV, Scan, etc.)
4Use number 1 through 9 to save and recall a Preset or
Reset saved parameters.
6 Preset: Make parameter adjustments. Press and hold the
Preset button and select a # (1 through 9) to store the
selected parameters.
7 Slow Zoom control and 8 Auto Framing (not activated)
16 Reset: Press and hold the Reset button and press the
preset # (1 through 9) you wish to cancel.
17 Fast Zoom control.18 One Push AF: Press once to
activate (Auto-Focus).
9 Direction Control: Pan and Tilt and OSD navigation
HOME button confirm / Enter selection.
10 Focus: Manual Focus: Use the Far and Near buttons.
Auto: Auto-Focus
11 Select a function in red (highlighted when selected) and
use the +and –buttons (5) to adjust the selected function.
oGain: Image gain settings
oColor: Image color saturation settings
oBlack.L: Image Black Level settings
oWB.R: Image White Balance Red settings
oPT.S: Pan/Tilt Speed settings
oZoom S: Zoom Speed settings.
oPreset S: Preset Speed settings.
oWB.B: Image White Balance Blue settings
oWDR: Wide Dynamic Range settings
oFreeze: To get a frozen image.
oB Light: Back Light compensation
oOPW: One Push White Balance
12 Resolution (Video Format Switching): Press and hold the Fn button (#15) until format change. The camera will
restart after the video format is changed and the screen will turn black for a few seconds.
Note: AAA Batteries are not included with the remote control.
IR Remote Control

13
D
Flo
This device is designed for indoor use only.
It is not designed to be used outdoors. Do not operate the device in environments where it may meet
constant heavy water. Please avoid installing the unit in a location commonly exposed to sunlight for
extended periods of time. Do not install the unit near temperature adjustment devices, such as a heating
or cooling unit.
Failure to comply may cause abnormal behavior during operation or physical damage to the device.
Do not install the device in the following type of locations:
oIn locations where the temperature is below -10 Celsius (32F) or above 40 Celsius (104F)
oOn walls without proper mounting method and brackets
oIn locations where humidity is 81% or higher
oIn locations where it may be exposed to harmful chemicals
oNear the sea or ocean where device can be exposed to corrosion
oIn locations where the device will be exposed to strong radiation
oIn locations where the device will be exposed to strong radio waves
oIn locations where the device will be exposed to strong magnetic fields
oFor other potentially questionable locations email Bolin Support for any questions or concerns
Safety Matters
For your safety, please disconnect all power to the device when installing and removing the device.
Always use supplied accessories and do not modify the supplied power adaptor.
Only qualified personnel should install and remove this device. Please make sure the installation
environment is safe and follows best practices prior, during, and after the installation process. Bolin does
not accept any responsibility or liability for any accident or damages resulting from malpractice or
improper installations.
The following chapters will introduce the installation methods of the Dante AV camera.
Before mounting your camera, please make sure you have purchased the optional accessories
needed for the installation.
oDisconnect the power from the camera before camera installation.
oAccessories such as the Wall mount and Ceiling mount are necessary for the installation.
oVerify the bearing capacity of the mounted position.
oTighten all the screws to hold the camera securely.
HDMI Cable Secure Mount Installation
HDMI Cable Secure Mount is included with the purchase, it is used to fix the HDMI cable to
prevent the cable from loosening and falling off.
Camera Installation

14
D
Flo
Ceiling mount is sold separately. Please follow the diagrams below to install the camera
ceiling mount.
Required accessories and components: Ceiling Mount brackets and M4*6PW/M3*6PW screws.
Bracket A Bracket B Safety Rope M4*6PW M3*6PW
Ceiling Mount Installation:
Install Bracket A at the desired position on the celling. All necessary cables (HDMI, SDI,
DC power, Cat5e/6 cables etc.) should be available at the bracket A location.
Bracket A Attach Bracket B to the bottom of the
camera using the M4*6PW screws.
Attach the safety rope to Bracket A and B



Celling Mount Installation

15
D
Flo
Slide Bracket B with Camera into Backet A
.
Insert M3*6PW screw in the front bracket and M3*6PW in the back of the bracket.



16
D
Flo
Wall Mount is sold separately. Please follow the diagrams below to install the wall mount.
Required accessories and components: Wall Mount bracket and M4*6PW screws.
oWall mount pendant installation:
oWall mount standard installation





Wall Mount Installation

17
D
Flo
Camera Power
oUse only the DC power adaptor (JEITA type4) supplied with the unit.
oDo not use any other DC power adaptor.
oPOE+ (IEEE802.3at) is supported to power the camera.
Note: Verify that the POE+ power source has sufficient power to power the camera, or some features may
not function properly. After connecting the DC power, the camera will automatically turn, tilt, and scan its
range.
Camera Connection via HDMI /3G-SDI
Note: A HDMI 1.4 (or higher) cable, 3G-SDI cable (D2-220H camera), are required in this configuration
setup. To obtain these third-party components or accessories, consult the reseller.
oConnect the HDMI/SDI cable(s) from the camera to the monitor(s). Information about the
camera’s initial setting status will display on the monitor(s) for about 5 seconds.
Display Monitor Recommendations
oAny regular TV monitor with HDMI video output can be used for video display.
oFor the Bolin D2-220H camera, a high-quality Monitor with a 3G-SDI connection is
recommended.
Note: The camera can simultaneously output HDMI/3G-SDI and Dante AV IP videos.
Also, the SDI and IP port can output two different video formats.










Camera Power & HDMI Output Setup
Also, the

18
D
Flo
Audio IN
The D2-210H is equipped with a 3.5 mm MIC/LINE audio input
jack on the rear panel. A microphone or audio source can be
directly connected to feed audio into the camera. You can select
Audio ON/OFF and the input type (MIC / LINE) using the
IR remote control Menu (OSD) under SYSTEM.
Note: With the D2-220H, you can use an USB to 3.5 mm audio jack adapter (not
included), to bring audio into the camera. If the MIC audio input type is selected,
you can also set Plugin Power to ON, so that the camera can supply power to the
connected microphone. The power supply voltage is 2.5V. The audio input is
embedded with the camera HDI/SDI and Dante AV video signal.
Camera Initial OSD Information
Information about the camera’s initial setting status will display for 5 seconds upon power.
1. Camera PELCO ID for RS-485 control
2. Camera ID for IR Remote Control
3. Display Info (On/Off)
4. Audio On/Off
5. Preset Settings
6. Factory Reset
7. Tally Mode On/Off
8. Reload Preset 1 On/Off
9. Video Format Setting
10.SV Number
PELCO ID 001
IR-RECEIVE ON
DISPLAY INFO ON
AUDIO ON
PRESET SETTINGS
FACTORY RESET
TALLY MODE OFF
RELOAD PRESET 1 ON
VIDEO FMT 1080p60
SV: V0A170B44040AD1T5
Camera Status Info Display
D2- 210H Camera

19
Flo
Camera Control Options and System Examples
There are multiple ways to control the camera using included accessory and /or third-party equipment.
This section describes different controlling system examples.
oUse the Infrared Remote Control (included)
oUse RS-232 (VISCA), VISCA Over IP
oUse RS-422/485 (VISCA/PELCO P/D)
Use the Infrared Remote Control
Recommended control distance to be within 10 meters. Control up to three Bolin cameras (ID # 1,2,3)
Use RS-232 (VISCA)
You can use RS-232 port to connect optional controllers, such as joystick controller or PC control station, to
operate the camera. To perform pan/tilt and zoom operations, use the joystick of the keyboard controller.
Preset operation can be done using the control buttons on the keyboard as well.
An application software that supports this camera is needed if using a PC station.
Camera Control Options & Configurations

20
D
Flo
VISCA Over IP, Color, Video Format, and IR ID Dip Switch Settings
D2-210H / 220H camera bottom view

 






B











Note: Any DIP Switch changes should
be done with the camera turned off.


