Bona FlexiSand Power Drive User manual

Bona®FlexiSand
Power Drive™
Operating Manual

Bona®FlexiSand Power Drive™Manual
2
bona.com
800.872.5515
For a new manual contact:
Bona US
2550 S. Parker Rd.
Suite 600
Aurora, CO 80014-1622
Tel [phone]
+1 800.872.5515
Fax [phone]
www.bona.com
Foreword

3
Table of Contents
Foreword 2
Table of Contents 3
Technical Data 4
Material Specification 5
Drive Plates & Accessories 6
Safety Instructions 7
Maintenance, Service & Repairs 10
Maintenance 10
Service 11
Spare parts and exploded views 11
Warranty 11
Bona®FlexiSand Power Drive™in General 12
Normal use 12
Risks 13
Handling 13
Assembling the dust skirt 14
Assembling the FlexiSand Power Drive™ 14
Attaching dust containment 15
Using the FlexiSand Power Drive™ 15
The sanding process 17
Transport position 18
Additional Notes 19

4
bona.com
800.872.5515
Bona®FlexiSand Power Drive™Manual
Technical Data
Motor type: 1 phase
Voltage (± 5%): 220-230
Frequency: 60 Hz
Power: 1.9kW 2.6 HP
Rated current: 13A
Safety devices: 16A overload switch (manual reset),
thermal protection in motor (automatic reset)
Recommended fuses: 15A
Capacitors: 50+160µF
Motor insulation class: F
Protection class: IP44
Final drive speed (unloaded): 155 rpm
Total weight: 111 lbs (50.35 kg)
Diameter of disc: 16" (407mm)
Hour counter: <99,999 hours
Height/Width/Depth: 46"/19.5"/25.2" (1170mm/490mm/640mm)
We congratulate you on your purchase of the Bona®FlexiSand Power Drive™, a powerful and versatile
machine for sanding, cleaning, buffing, and oiling wooden floors! With the Bona®FlexiSand Power Drive™
attached, you are able to perform direction-free sanding to bare wood. Four counter-rotating discs provide a
high cut rate which can reach very close to the wall and as such reduces the need for edge sanding.
Carefully read through the entire user manual before you begin working with the machine. This machine is
intended for professional or commercial use.

5
Material Specification
Standard (included on delivery)
Key Article Article Number
ABona®FlexiSand Power Drive™AMO310002.2
B Bona®Pad Driver ASO312511
C Dust skirt ASO312102
D Dust tube ASO316650
E Extension cable 50 ft (15.2m) ASO904015
F Face mask, ear caps (compl.) ASO991232
G Box spanner (tool) ASO990640 - L Type Wrench 19mm
HBona®Power Drive™AS0312540
I User manual & instruction guide N/A

Bona®FlexiSand Power Drive™Manual
6
bona.com
800.872.5515
Drive Plates & Accessories
Article Application Recommended
Abrasives & Equipment
Bona®Pad Drive™, 16"
Included on delivery
Art. nr. ASO312511
Standard drive plate for a
wide variety of jobs. Equip
with a suitable pad for
cleaning, oiling, buffing and
fine sanding of untreated
and treated wood.
Bona®Abrasive Pads
Bona®Screen
Bona®Double Sided Sanding Discs
Bona®Cloths
Bona®FlexiSand Power Drive™
4 x 150mm
Art. nr. ASO312540
Geared drive plate for
high-power wood sanding.
Removes old lacquer
and paint coatings while
flattening the surface for a
perfectly smooth finish.
Bona®GREEN Ceramic Abrasives
Bona®BLUE Abrasives
Bona®SiC Abrasives
Bona®Diamond Abrasives
Internal Spur Gear
Art. nr. ASO312082
Spur gear for the
Bona®Power Drive™N/A
Bona®Multi Disc™
6 x 150mm
Art. nr. ASO312520
Fine sanding of wooden
floors. Suitable as a final
finish after belt sanding.
Bona®GREEN Ceramic Abrasives
Bona®BLUE Abrasives
Bona®SiC Abrasives
Bona®Diamond Abrasives
LED Lamp
Art. nr. ASO319070
FlexiSand™Working Lamp
220V/60 Hz
For better visibility while
sanding. The sanding result
becomes easier to see.
N/A

7
NOTE: The reading and understanding of the Owner’s Manual is imperative prior to operating this machine. If you or your operator(s)
cannot read English, have this manual explained fully before attempting to operate this machine. Children should be supervised to
ensure that they do not play with the appliance. This machine is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge.
DANGER means: You or other staff can suffer a serious injury or death if the instructions marked
with DANGER on this machine or in these user instructions are ignored or not followed. Read the
entire user manual before you use the machine.
WARNING means: You or other staff can suffer an injury if the instructions marked with WARNING
on this machine or in this user manual are ignored or not followed. The machine or other property
may also be damaged if instructions marked with WARNING are ignored.
Under adverse conditions, a mixture of dust and air can be explosive. Sanding/polishing wooden
floors can create an environment that can be explosive. The safety routines below must be followed:
• Cigarette lighters, control lamps and all other sources of ignition can cause explosions if they
are active during sanding. All sources of ignition should be extinguished or, if possible, removed
completely from the work area.
• In work areas with poor ventilation, an explosive environment can occur if certain flammable
materials (solvents, thinners, alcohol, fuel, certain polishes, wood dust, etc) are in the
atmosphere. Floor grinders can cause slightly flammable materials and vapors to burn. Read the
manufacturer's label on all chemicals to be used so that you can determine the flammability.
Ensure that the work area always has good ventilation.
• Hitting a nail during sanding can produce sparks and cause an explosion or fire. Always use a
hammer to pound in any metal pieces before sanding the floor. Always keep a fire extinguisher
(ABC-class or water) available.
Use of a machine that is not complete or that is not fully mounted can result in personal injury
or damage to property. Never use these machines before they are fully mounted. Ensure that all
fastening devices are fixed. Make adjustments as defined in the machine specifications.
Read through the safety instructions carefully and inform your employees and users so no one comes to harm when using the machine.
Then, save the instructions. The manufacturer is not liable for personal injury or machine damage due to incorrect operation of the
machine. The machine may only be used by authorized persons that have been trained in its function.
Voltage: Make sure the voltage stated on the machine's rating plate corresponds to the voltage in the power outlet before you start
the machine.
Safety Instructions

Bona®FlexiSand Power Drive™Manual
8
bona.com
800.872.5515
Safety Instructions (Cont.)
Never remove or disable the ground in the electric cable.
Consult an electrician if the ground is missing or if you suspect that your circuit is not
properly grounded.
There is a risk of electric shock if the machine is used in a circuit that breaks repeatedly or is under-
sized. Allow an authorized electrician to control the fuse, breaker or power supply.
There is a risk of personal injury if the grinder runs over and damages the cord. Ensure that the cord
does not come into contact with the sanding disc. Always lift the cord over the machine and grind in
a direction away from the cord. Do not pull the machine by the cord.
Always use a ground that breaks the current immediately in the event of a fault in the electrical
system or in the extension cord.
In order to prevent unintentional start of the machine, the power cord must be
removed when the machine is not in use or during service.
Moving parts of the machine can cause serious personal injury and/or material damage. Keep hands,
feet and loosely fitting clothing away from all moving parts of the grinder.
Because dust from sanding (red lead, certain types of wood and metal) is hazardous to health, a face
mask of at least class P2 must be used.
There is a risk of damage to the eyes and/or body if protective clothing and/or protective
equipment is not used during sanding. Always use protective glasses, protective clothing, ear
protection and a face mask of at least class P2 during sanding.
Read the instructions
contained in this user
and maintenance
manual before using
the machine.
Hearing protection
during use is
recommended.
Protection of the
airways during use
is recommended.
Hazard due to
moving parts.
Hazard due
to electricity.

9
To minimize dust in the environment use a vacuum cleaner intended for wood dust. The air flow
on the vacuum cleaner should be at least 245m³/h. We strongly recommend the Bona®DCS™
for best results.
Store contained wood dust outdoors in a safe place due to the risk of fire. Never leave contained
wood dust unsupervised.
Always keep a fire extinguisher (ABC-class or water) available.
Take precautionary measures to ensure that the machine is not damaged during transport.
Be careful with cords. Use the correct power cord with the correct length (see accessories list).
Never carry the machine by the cord. Never pull power cords from the machine or wall socket
with strong movements. Protect the power cords against heat, oil and sharp edges. Power cords
longer than 50 ft (15.24m) should not be used.
Remove the power cord from the machine when it is not in use. Ensure that the machine does
not start unintentionally. Never carry a connected machine. Ensure that the breaker is not on once
the machine is connected to a power socket. Never use the machine if the start handle does not
function as it should.
Inspect the machine regularly. If you discover damaged parts, replace them at once. If necessary,
contact Bona or staff approved by Bona.
Because this construction is in many ways unique, use of other spare parts and accessories than
Bona®original spare parts can cause a risk of personal injury and/or damage to the machine.
Ensure that the machine is always in good condition. Keep the machine clean for better and safer
use. Follow the instructions concerning the replacement of accessories. Inspect the power cords
regularly. Repair or replace defective parts if they are damaged.
Store the machine in a dry and locked area when not in use.
Do not forget to put on the tool before you start the machine. Always check that the sanding
paper is correctly adjusted before you begin sanding.
Keep unauthorized persons away from the work site. Do not allow unauthorized persons to come
into contact with the machine or power cords.
Do not misuse the machine. The machine works better when it is used according to its capacity
and design. Allow the motor to "rest" during periods of heavier use. The motor will cool better,
thus increasing its lifespan.
Safety Instructions (Cont.)

Bona®FlexiSand Power Drive™Manual
10
bona.com
800.872.5515
Never use a machine for anything else or use accessories other than those
described in this manual.
Service or repairs performed by unauthorized persons can cause damage or accidents. If service
and repairs are performed by unauthorized persons, the warranty may become invalid. Service
and repairs must be performed by Bona or staff approved by Bona.
Be aware when you work. Use common sense. Do not use the machine if you are tired,
have consumed alcohol or have taken medication that can affect your judgment or your body
control. Due to the potential fire hazard involved with sanding dust, smoking is not permitted
while sanding.
Always use a grounded circuit breaker.
Safety Instructions (Cont.)
Maintenance, Service & Repairs
To keep the machine in a safe and functioning condition, perform maintenance on the machine regularly.
Always disconnect the power cable to the machine before it is cleaned, tools are changed, maintenance is
performed or when worn parts are replaced.
Daily maintenance
• Remove accessories when not in use
• Use compressed air and a vacuum cleaner to remove dust after each use
• Wipe the machine and cord off with a clean cloth
• Check start and stop function
• Check cord and plug
Every 250 work hours or at least once a year
• Wheels
• Cable stand
• Dust skirt
• Micro switches
• Motor and gearbox
• Handle shaft function including hydraulic system
Maintenance

11
Warranty
Maintenance, Service & Repairs (Cont.)
The Bona®FlexiSand Power Drive™is a high quality machine and is tested by authorized test staff at the factory before delivery.
However, electrical and mechanical parts wear down and age during long-term use.
Only Bona's original parts may be used because the machine is considered unique, otherwise safety functions can become impaired.
When you contact Bona or staff approved by Bona in the event of a fault or to order spare parts, always specify the type and serial
number of your machine. This information is located on the data plate of the machine.
The machine may never be cleaned using a high-pressure washer or hose.
On the Internet you will find a list of spare parts and exploded views for the Bona®FlexiSand Power Drive™and other machines in our
product range. Visit http://spareparts.bona.com/
During the factory warranty period, repairs may only be carried out by Bona or staff approved by Bona. Other repairs (after the warranty
period) of mechanical or electrical parts on the machine may only be carried out by Bona AB or staff approved by Bona AB who has
experience and knowledge concerning safety regulations.
There is a 24 month factory warranty (from the date of invoice) against material and manufacturing faults.
In the event of a warranty claim, the machine or agreed upon part must be returned to Bona or staff approved by Bona with paid freight
for warranty testing and for potential repair or replacement under warranty.
During the factory warranty period, repairs may only be carried out by Bona or staff approved by Bona. We do not undertake any other
form of compensation or liability to damages.
Service
Spare parts and exploded views

Bona®FlexiSand Power Drive™Manual
12
bona.com
800.872.5515
Bona®FlexiSand Power Drive™in General
The machine is only intended for work on level surfaces with a maximum slope
of 2%. The machine is not intended for pure concrete sanding. Never run the
machine over power cables, or you may risk a short circuit.
The operation of the Bona®FlexiSand Power Drive™is subject to applicable national regulations.
Beyond the user manual and the applicable rules in the country for preventing accidents, the applicable technical trade provisions for
safety and professional work methods must be followed.
The Bona®FlexiSand Power Drive™is only intended for indoor use at temperatures between 10˚C (50˚F) and 35˚C (95˚F) and in good
lighting. When you work with the machine, be observant of the surroundings and particularly persons nearby. Do not use the machine
around children. The manufacturer is not responsible for injuries that occur via such use. In this case, the user assumes full risk. In
addition to the normal usage instructions, the manufacturer's care and maintenance instructions must also be followed.
The manufacturer is not liable for any damage to the machine resulting from prohibited changes. The manufacturer is not liable for
damage to the machine or to the floor covering to be sanded.
Warranty (Cont.)
THE WARRANTY DOES NOT COVER
• Consumable materials such as wheels, electrical cables, abrasives, lamps, etc.
• Indirect damage, damage and errors that occur due to external damage, accidents, and/or repairs performed outside of our knowledge
and approval, or damages for another reason outside of our control.
• Transport damage or transport costs. In the event of transport damage it is up to the receiver to contact the relevant transport
company for compensation.
• Cases of incorrect use, overloading, carelessness or poor maintenance
• The use of parts produced by another company outside of our control.
• Electrical components, if the voltage variations are beyond those set out in the technical specification.
• If payment for the machine is not made according to the agreement.
Normal use

13
Bona®FlexiSand Power Drive™in General (Cont.)
Handling
The user is expressly obliged only to use the machine in accordance with this manual. If the machine is used in any other manner, this
is solely at the user's own risk. The manufacturer's liability ceases fully in this case.
The machine may not be used in areas where explosive or flammable substances are stored or manufactured (petrol, thinners, fuel oil,
solvents, etc.). The machine's electrical components and mechanical parts can cause these substances to ignite.
Never work with worn, damaged or incorrect equipment, which can cause damage to the floor.
The power cable with extension may not exceed 50 ft (15.24m). Longer lengths should incorporate the Bona®Power Station™.
When the machine is not in use, the power cable must be disconnected from the wall socket in order to prevent damage to the floor
and unlawful use. For transport in lifts, the applicable user and safety instructions must be followed, especially where load capacity is
concerned. In order to prevent unauthorized use of the machine, it must always be stored in a suitable location. Regularly check the
power cable and the machine for wear or aging.
The Bona®FlexiSand Power Drive™ can be used for many different types of floor preparation/sanding depending on the type of drive
plate mounted to the machine. As a standard, one Drive Plate is included on delivery which can be used to drive nylon pads, screens
and abrasives, etc. Always use a soft pad underneath the Drive Plate before attaching screens and abrasives. Never use the Drive Plate
directly towards the floor.
For instructions on using another drive plate, see the instructions for that drive plate.
Normal use (cont.)
Risks

Bona®FlexiSand Power Drive™Manual
14
bona.com
800.872.5515
Handling (Cont.)
Place the dust skirt in the intended notch on the rubber strip.
Never use the dust skirt when oiling. Always remove
the skirt when transporting the machine.
Assembling the dust skirt
1) Take the Internal Spur Gear (A), place it against the chassis
and align it with the screw holes on the underside of the
machine (B). Screw the self-tapping screws provided into the
prepared fixing points as seen in the picture.
3) To install the Power Drive™drive plate, place the drive plate
into position and turn it to engage the interlock (A). Once it is
in place, turn the small flat paddle lever (B) to make sure that it
is bolted into place.
2) Ensure that the screws are tight and flat against the
cogged ring.
4) To remove the Power Drive™drive plate, turn the paddle lever so
it is in the unlocked position (A). Place the tip of the supplied box
spanner between the driving axle and drive plate bracket, then push
against the drive plate to release the interlock (B). Turn one of the
sanding discs counterclockwise until the drive plate can be freed.
Assembling the FlexiSand Power Drive™

15
Handling (Cont.)
Attach the dust containment hose to the dust tube on the Bona®FlexiSand Power Drive™. If using Bona®DCS™, connect DCS™cuff to
dust tube and fasten with provided clamp.
Lower the handles to a comfortable working position by pressing the button located on the top of the handle. The handle should
be held at approximately chest height and not taken down to waist height as is normal with other work using a buffing machine.
The air flow on the vacuum should be at least 245m³/h.
Using the FlexiSand Power Drive™
Attaching dust containment

Bona®FlexiSand Power Drive™Manual
16
bona.com
800.872.5515
Handling (Cont.)
If the machine becomes difficult to handle, release the start handles and the machine will stop immediately.
Remember to connect the machine to a Bona®DCS™or other suitable vacuum system before starting work.
Using the FlexiSand Power Drive™(cont.)
1) If you have not already, press the button on the top of the handle then lower the handle shaft to a comfortable working position. The
shaft must be lowered at least 10˚ or the machine will not start.
3) Press the start handle. Once the start handle is pressed down
the switch lock button can be released.
2) Press and hold one of the buttons (A) to activate the
switch lock.
If you have not operated a Bona®FlexiSand Power Drive™previously, ensure that
no one or nothing is nearby before you start the machine.

17
Handling (Cont.)
It is important to make sure that the sanding is carried out in a methodical fashion to ensure that all areas
of the floor surface are sanded equally. Although the FlexiSand Power Drive™can be used in any direction
on the floor, making it ideal for patterned floor, for the best results on a strip or plank floor walk forwards and
backwards with the grain of the wood in a slow, steady manner.
Using the FlexiSand Power Drive™(cont.)
The sanding process
The FlexiSand Power Drive™system is not used like a 'normal' buffing machine with the handles held at the waist and the machine
moving from side to side when sanding.The counter-rotating cog construction of the Bona® FlexiSand Power Drive™equalizes the sanding
force so that the machine stands more or less still during operation and is controlled by simply walking backwards and forwards in the
same way as a belt sander is used.
The Bona®FlexiSand Power Drive™system is designed to be used in a variety of different sanding situations. However, it is not designed
to replace a traditional belt sanding machine and where a floor is uneven due to cupping or similar issues it is recommended that an
initial sanding using a belt sander with a 36/40 grit belt is made. For other sanding operations, the following methods are suggested:
To remove finish from a coated floor:
1) Start sanding with Bona GREEN Ceramic abrasives, grit
36 – 60 depending on how aggressive you need to be to
remove old finish and stain. Check the abrasives frequently
and replace as required to maintain a full, aggressive cut.
3) For final cut, use Bona BLUE abrasives in either grit 100
or 120 along with the ¼” Intermediate Pads to final prep
flooring surface for a sealer coat.
2) After using Bona GREEN Ceramic abrasives on the coarse –
medium cuts, switch to Bona BLUE abrasives for the medium
– fine cuts along with the ¼” Intermediate Pads: 60 – 120
grits.
4) For a final cut for a stained floor, Black 120 grit
with the ¼” Intermediate Pad is recommended.
Disclaimer: Depending on the specie or flooring type being sanded (strip vs. parquet or multi-specie), extra steps or variations of the steps listed
above may be required. You may also want to use the ¼” Intermediate Pads on all sanding steps to minimize scratch depth and bouncing or
hopping of the Bona® FlexiSand Power Drive™. Contact your local Bona Territory Manager or Technical Services with questions.

Bona®FlexiSand Power Drive™Manual
18
bona.com
800.872.5515
Handling (Cont.)
The sanding process (cont.)
Transport position
To sand after a belt sander has been used:
Follow the same process as noted on the previous page. If belt sanding has been carried to a higher grit, such as 80 grit, then simply
use the FlexiSand Power Drive™system for the final sanding.
When sanding prior to staining:
It is important that scratches are not left on the floor as the staining process will highlight any remaining scratches. The Bona®
FlexiSand Power Drive™is perfect for the final preparation before staining. The final sanding grit required for the Bona®stain systems
will be noted in the appropriate data sheet.
Bona®Interface Pads:
The Bona®FlexiSand Power Drive™as supplied has 4 x 150mm grinding pads that provide uniform sanding on a hardwood floor.
However, if the floor is uneven then the machine may 'jump' a little when sanding to bare wood. A 1/4" intermidiate pad may be used to
stabilize sanding. Some movement is normal during rough sanding and can indicate that more sanding is needed to get the surface flat.
Another issue that may be faced is that on soft wood species 'dish out' of the wood grain can sometimes happen.
To reduce the possibility of these issues, 4 x 6" (150mm), .25" (5mm) thick Interface Pads are supplied with the FlexiSand Power
Drive™. To fit them, first make sure that the grinding plate is clean. Place the Interface Pad onto it with the soft dark black side facing
towards the machine with the hook and loop side facing outwards. Then, apply the required Bona®abrasive disc.
Using the Interface Pads will allow the FlexiSand Power Drive™to follow the contours of the floor more efficiently, making the sanding
process easier and more comfortable.
Always remove the dust skirt and the drive plate or sanding disc before transportation. Always vacuum and
clean machine after use. When transporting the machine via vehicle, make sure that the machine is securely
fastened through the wheels to avoid movement.
1) Remove the drive plate. 2) Tip the machine backwards and remove the dust skirt.

19
Additional Notes

bona.com
800.872.5515
REV092816
