Bonnet Precisio Series User manual

EQUATOR 6
COMBI OVENS
PRECISIO
BUILDER’S SPECIFICATIONS
Part C: Maintenance manual
- WARRANTY -
In order to guarantee this equipment, we recommend that you comply with the
MANUFACTURER’S INSTRUCTIONS in this manual.
However if you can not undertake the required maintenance operations, our installation and
service network is available to provide you with a personalized contract.
- WARNING -
• The product delivered to you complies with current standards. If any modifications are made
the manufacturer cannot accept any responsibility whatsoever. The manufacturer can not be
held responsible in the event of an incorrect use of the appliance.
• Keep your manuals.
3BE390692NM

Page 1 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
TABLE OF CONTENTS
COMBI OVENS
PRECISIO
1. PRESENTATION OF THE SCREEN DROP-DOWN MENUS.................................................................. 2
2. FUNCTIONING AND MARKING OF THE MAXI RELAY CARD.............................................................. 3
3. PARAMETER SETTING OF THE UC RELAY CARD.............................................................................. 4
3.1 GENERALITIES....................................................................................................................................................4
3.2 PARAMETER SETTING OF THE CONFIGURATION KEY.................................................................................5
3.3 PARAMETER SETTING OF THE FACIA BOARD (In case the whole card has been changed).........................6
4. OPERATING FAILURES.........................................................................................................................7
5. CHANGING THE EQUIPMENT FROM ONE GAS TO ANOTHER .......................................................... 8
5.1 LISTOFAUTHORISEDGASES/PRESSSURESACCORDINGTOCATEGORIESANDCOUNTRIES...........................................8
5.2 CHANGE OVER FROM ONE GAS TO ANOTHER:.............................................................................................9
5.3 GAS FLOW-RATES AND POWERS..................................................................................................................11
5.4 CHART OF NOZZLES........................................................................................................................................11
6. MAINTENANCE .................................................................................................................................... 14
6.1 SERVICING THE CONDENSER........................................................................................................................14
7. VERIFICATION OF TEMPERATURE SENSORS.................................................................................. 15
8. DOOR ADJUSTMENT AND CLOSING................................................................................................. 17
8.1 8 AND 12 LEVEL OVENS...................................................................................................................................17
8.2 20 LEVEL OVENS ..............................................................................................................................................18
9. RENEWAL OF THE DRIVING SHAFT GASKET................................................................................... 20
10. FRONT LINE PARTS......................................................................................................................... 22
11. PARAMETER SETTING / MAINTENANCE PROGRAMME............................................................... 24
11.1 06 MAINTENANCE.............................................................................................................................................24
11.2 061 MAINTENANCE: Usual maintenance..........................................................................................................25
11.3 0611 MAINTENANCE: Technical assistance.....................................................................................................26
11.4 06111 MAINTENANCE: Technical assistance...................................................................................................27

Page 2 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
1. PRESENTATION OF THE SCREEN DROP-DOWN MENUS
Initialisation
Or
TIME REMAINING
TILL NEXT
REVISION:
00202
H
MAINTENANCE
Vuc 1.41 VG 1.29
IMPERATIVE
REVISION
MAINTENANCE
Vuc1.41 VG 1.29
AUTO COOKING
MAN. COOKING
BANQUETING
CLEANING
PROGRAMMING
MAINTENANCE
025
c
GENERAL
0
FAM :
CHICKEN
PROD :
DUCK BREAST
TYPE
:
SHORT OPTIMAL
-
COLORE
+
COLORE
UNDERDON ROSE
SUR
:
GRILLED
2
H
35
MN
++
025
c
AUTO COOKING
01
RETURN
PREHEATING
?
MAN. COOKING
02
MODE:
DRY
185
c
172
c
--
H
--
MN
65
c
--.-
c
20
%
RETURN
PREHEATING
FAM :
BEEF
PROD:
ROAST
TYPE : SHORT-OPTIMAL
PROGRAMMING
05
RETURN
COPY
MODIFY
DELETE
DISPLAY: YES
Idem
Auto cooking
AUTO COOKING: PREHEAT
01
?
FROZ. CHICKEN
WITH SENSOR
WAIT
BEFORE PUTTING THE
PRODUCT INTO THE
OVEN
025
c
STOP
COOKING
CLEANING
04
SETTING
TEMPERATURE
WAIT BEFORE
APPLYING THE
CLEANING AGENT
-
+
0
H
40
MN
00
H
02
MN
90
c
STOP
...
...
PROGRAMMING
051
VALID
BEEF
ROAST No1
IN A TRAY AND SAUCE
MODE
DRY 220 00H20
STEAM 075 50
STEAM 060 55
STEAM 055 99H00
SEC 230 PRECHAUFFAGE
PROD
:
LAMB SAUTE
TYPE
:
IN A TRAY
SUR
:
FULL TRAY + COUVER
2
H
35
MN
++
125
c
BANQUETING
03
RETURN
PREHEATING
Idem
Auto cooking
AUTO COOKING: PREHEAT.
01
?
FROZ. CHICKEN
WITH SENSOR
OK
PUT PRODUCT INTO OVEN
230
c STOP
COOKING
CLEANING
04
APPLY CLEANING
PRODUCT
0
H
35
MN
00
H
04
MN
70
c
STOP
...
...
MAINTENANCE
06
RETURN
NEXT SERVICING: 00202H
SWITCHED ON:
00548H
DRY:
00100H
STEAM: 00200H
COMBI: 00080H
COOLINGS:
00092
DOOR OPENINGS:
00108
CLEANINGS:
00058
INSTAL - ASS
(CODE) : AAAA
PARAMETER SETTING
0847
PARAMETER SETTING
061
RETURN
LANGUAGE:
FR
(UK
-
ES
-
NL
)
C / F :
C
DISPLAY:
SIMPLE
(DETAILED)
MODIFICATION :
(CODE) :
AAAA
FREE
(INTER - LOCK)
CONTRAST:
BUZZER :
Detail
DUCK BREAST
SHORT-OPTIMAL
-
COLORE
+
COLORE
SAIGNNAT ROSE
2
H
34
MN
++
AUTO COOKING
01
STOP
?
...
230
AUTO COOKING
01
?
ROAST BEEF
MODE :
DRY
230
c
195
c
02
H
33
MN
00
H
02 MN
65
c
12.8
c
20
%
...
...
STOP
CLEANING
04
CLEANING
IN PROGRESS
0
H
09
MN
00
H
25
MN
70
c
STOP
...
...
INSTAL
-
ASSERVICE
062
RETURN
COUNTERS
:
ACTIV SAFETY INLET: 00000
DURATION T OVER 70 C:
00000
QTY OF AUTO RESETS:
00001
PARAMETER SETTING:
KEY:
1002010000
FREQUENCY ASS:
00750H
TECHNICAL ASSISTANCE
OVEN ADDRESS: AZBK
RESET NEXT REVISION
INSTAL
–
ASS: RESET
063
RETURN
RESET NEXT REVIS.
RESET Counters
RESET
Chef’s programmes
Chef
RESET Counters + Prog
SOFT PARAMETERS
AUTO COOKING
01
?
ROAST BEEF
EN CROUTE
OK
COOKING COMPLETED
MAINTIEN EN T EN COURS
65
c
STOP
NETTOYAGE
04
OK
CLEANING COMPLETED
0
H
00
MN
00
H
45
MN
43
c
RETURN
...
...
7 SAFETY CONTACTOR
14 TRIAC +VENTILATION (7+14+15)
17 TRIAC+VENTIL+INV (7+14+17)
8 DRY HEATING 1/3
22 DRY HEATING 2/3
18 STEAM HEATING
4&5 LIGHTING / VENTIL
24 MOTOR VALVE IN
25 OURA MOTOR
23 COOLING TURBINE
10 WATER INJECTION SOL. VLVE
9 CONDENSER SOL. VLVE
21 QUICK FILLING SOL. VLVE
20 CLEANING SOL. VLVE
19 ADO SOL. VLVE
TECHNICAL ASSISTANCE.
0621
RETURN
INLETS
26 BOILER DRAINAGE OFF
T : E1: 044
E2 : 040
E2-b : 129
E2-c : 128
E4 DOOR SENSOR: 0 /1
E5 CONDENSER INLET: 0 /1
E6 SAFETY INLET: 0 /1
E7 LEVEL SENSOR INLET:
E8 0 VALVE INLET IN: 0 /1
E9 0 OURA INLET: 0 /1
TECHNICAL ASSISTANCE
0622
RETOUR
0 /1
SORTIES
E3 : 92
STOP: It stops thecycle in progress after
confirmation and turns back to the inlet menu RETURN: Comes back to the inlet menu

Page 3 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
2. FUNCTIONING AND MARKING OF THE MAXI RELAY CARD
Outlets (230V) control oven functions Card info inlet E4 Door sensor
E5 Condenser klixon
E6 Cardsafetydevice
AR (gas oven)
E7 Boiler water level
Control
E8
Limit switch Valve in
E9 Ouravalvelimitswitch
GND
Common to all
inlets. All connec-
ted together
Fuse:
This protects all
outlets against a
failure except 4,
5, 14, 15, 16
and 17
Facia board / Relay connecting ribbon
Warning: To insert the
connecting ribbon
between the UC card
and the facia card, take
care to support the
printed circuit under
the connector.
Fuse:
This only
protects against
a lighting failure
Connection of the
generator sensor
1
4
3
2
Connection of a
core probe
connector
Connection of a capacity sensor
Motor supply
inlet
*Warning : In case of a
gas Precision oven,
remove the resistance
and connect the boiler
temperature sensor.
Fuse: This only
protects against
a capacity
ventilator failure
3A1525 1A 3 2 1
EA1
OVA EA2 OVA
EA2cEA2b
E4
OVA EA3
GND
E5 E6
GND
E7 E8
GND
E9 E10
GND
24 23 26 22 7891012 6 5 4 18192021 17 16 15 1314 10A

Page 4 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
3. PARAMETER SETTING OF THE UC RELAY CARD
3.1 GENERALITIES
Before applying the procedure, check whether your oven is set in Celsius or Fahrenheit degrees. For
this purpose, try to set the temperature at O.
If the set temperature shows 0: Celsius degrees, if it shows 32: Fahrenheit degrees.
When you change the min UC relay card, there are two possibilities:
- Keep the customer parameters (counters, °C/°F, si mple/detailed display)
* Recuperate one or more memory components from the old card and place them on the
new card in the same support and in the same way.
3A15
251A
E4
GND
E5 E6
GND
E7 E8
GND
E9
E10
GND
242326227
8
9
10
12654
* Set the new card in place.
* Check the configuration key.
- Without keeping the customer parameters:
* Change the whole card.
* Programme the configuration key.
Switch
Memories

Page 5 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
3.2 PARAMETER SETTING OF THE CONFIGURATION KEY
Open the facia board.
Push the switch of the UC relay card on OFF (towards the right).
Oven parameter setting
Configuration key
INSTAL
-
ASS
062
RETURN
COUNTERS
:
ACTIV SAFETY INLET:
00000
DURATION OF T OVER 70 C
:
00000
QTY OF AUTO RESETS:
00001
PARAMETER SETTING
:
KEY:
1002010000
ASS FREQUENCY:
00750H
TECHNICAL ASSISTANCE
OVEN ADDRESS:
AZBK
RESET TILL NEXT SERV.
By means of the selection button, position the cursor on KEY.
Validate with the Validation button
The parameter (0, 1, 2 …) of the key can be modified with the selection button.
Configuration key
Technical code Designation
C01 C02 C03 C04 C05 C06 C07 C08 C09 C10
EQ4+81/1.PC Electric Précisio oven 6 GN1/1
EQ4+121/1.PC Electric Précisio oven 10 GN1/1 1 0 1 3 1 1 0 0 0 0
EQ4+201/1.PC Electric Précisio oven 10 GN2/1
EQ4+202/1.PC Electric Précisio oven 20 GN1/1
EQ4+81/1.PC.G Gas Précisio oven 6 GN1/1
EQ4+121/1.PC.G Gas Précisio oven 10 GN1/1 1 1 1 3 1 1 0 0 0 0
EQ4+201/1.PC.G Gas Précisio oven 20 GN1/1
EQ4+202/1.PC.G Gas Précisio oven 20 GN2/1
Push the switch of the UC relay card on ON (towards the left)
Close the facia board.

Page 6 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
3.3 PARAMETER SETTING OF THE FACIA BOARD (In case the whole card has been
changed).
Language selection (FR,
ES, NL, UK)
Choice between T°in °C or
°F
Choice of permanent
display: SIMPLE or
DETAILED
This enables the Chef, after
he has entered a code, to
change from a FREE mode to
the INTER and LOCK modes,
limiting the possibility of
modification of personalised
recipes.
PARAMETER SETTING
061
RETURN
LANGUAGE:
FR
(UK
-
ES
-
NL
)
C / F :
C
DISPLAY :
SIMPLE
(DETAILED)
MODIFICATION :
(CODE) :
AAAA
FREE
(INTER - LOCK)
CONTRAST:
BUZZER VOLUME:

Page 7 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
4. OPERATING FAILURES
Sensor failures
- E40: 1 or 2 (out of 3) core probe sensors are cut.
- E41: 1 or 2 (out of 3) core probe sensors are short-circuited.
- E61: Short-circuited ambient probe.
- E62: Cut ambient probe.
- E63: Core probe missing or cut.
- E64: Short-circuited core probe.
- E69: Steam boiler at +110°C.
- E70: Short circuited boiler sensor.
- E71: Cut boiler sensor.
Other failures
- E42: Maximum temperature within the electronic facia exceeded.
- E43: Saturated steam inlet activated more than 30 seconds in steam mode.
(Choked condenser nozzle, condenser supplied with hot water or insufficient flow-rate).
- E45: Inoperative boiler drainage.
- E46: Defective communication bus I2C.
- E47: Saturated USB flash drive (in case of option).
- E51: Set ambient temperature at 0.
- E52: Set duration or core temperature at 0.
- E53: Ventilation: failure to operate.
- E67: Activated gas safety inlet.
- E68: Capacity temperature at + 290°C.

Page 8 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
5. CHANGING THE EQUIPMENT FROM ONE GAS TO ANOTHER
Generalities:
In the following chapters, the different gases are referenced by their international codification:
G 20 NATURAL GAS Group H, (Methane, Lacq gas).
G 25 NATURAL GAS Group L, (Groningue type gas).
G 30 BUTANE
G 31 PROPANE
5.1 LISTOFAUTHORISEDGASES/PRESSSURESACCORDINGTOCATEGORIESANDCOUNTRIES
Countries Categories Gases Pressures (mbar)
Austria I
2H
G20 20
I
3B/P
G30 and G31 50
I
3P
G31 50
Finland - Denmark I
2H
G20 20
Sweden – Norway I
3B/P
G30 and G31 30
Czech Republic I
2H
G20 20
I
3B/P
G30 and G31 30
I
3+
G30 / G31 28-30 / 37
I
3P
G31 37 and 50
Spain I
2H
G20 20
United Kingdom I
3+
G30 / G31 28-30 / 37
I
3P
G31 37 and 50
Germany G20 20
Luxemburg I
2ELL
G25 20
I
3B/P
G30 and G31 30
I
3P
G31 50
Switzerland I
2H
G20 20
I
3B/P
G30 and G31 50
I
3+
G30 / G31 28-30 / 37
I
3P
G31 37 and 50
Greece I
2H
G20 20
Italy I
3B/P
G30 and G31 30
I
3+
G30 / G31 28-30 / 37
I
3P
G31 37
Ireland I
2H
G20 20
Portugal I
3+
G30 / G31 28-30 / 37
I
3P
G31 37
Netherlands I
2L
G25 25
I
3B/P
G30 and G31 30
I
3P
G31 50
France G20 20
I
2Esi
G25 25
I
3+
G30 / G31 28-30 / 37
I
3P
G31 37 and 50
Belgium I
2E(s)B
G20 / G25 20 / 25
I
3+
G30 / G31 28-30 / 37
I
3P
G31 37

Page 9 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
5.2 CHANGE OVER FROM ONE GAS TO ANOTHER:
5.2.1 BEFORE SEPTEMBER 29TH, 2010 : TO N°P27516226C
According to the country of installation and the category of the appliance (indicated on the firm plate),
the changeover from one gas to another may require 3 operations:
CI: Change of nozzles (burners) (See 5.4)
CV: Change of gas valve
With the valve no 147 773 : Addition of a pressostat
With the valve no 147 772 : Removal of the pressostat
(See 5.4)
CR: Change of air adjustment (See 5.4)
PROCEDURE:
On the firm plate, check:
- The category (ies) of the equipment.
- The gas and pressure for which it is adjusted.
In the following chart, select:
- The country concerned.
- The gas and the category of the appliance (see above).
- The gas and the pressure for which the appliance is going to be adjusted.
- Note and carry out the required operations.
- Replace the adjustment plate (code: 308 875), and mark the new gas used.
Countries
concerned Category and GAS OF ORIGIN (or new gas) NEW GAS and category (or gas of origin) Required operations
Category Gas P (mbar) Gas P (mbar) Category
Austria I
2H
G20 20 G30 / G31
50 I
3B/P
/ I
3P
CV – CI - CR
I
3B/P
G30 50 G31 50 I
3P
CR
Finland - Norway I
2H
G20 20 G30 / G31
30 I
3B/P
CV – CI - CR
Sweden – Denmark
I
3B/P
G30 30 G31 30 I
3B/P
-
Czech Republic I
2H
G20 20 G30 / G31
28-30/37/50 I
3+
/ I
3B/P
/ I
3P
CV – CI - CR
I
3B/P
/ I
3+
G30 28-30 G31 30-37-50 I
3P
CR
I
3P
G31 37 G31 50 I
3P
-
Spain I
2H
G20 20 G30 / G31
28-30/37/50 I
3+
/ I
3P
CV – CI - CR
United Kingdom I
3+
G30 28-30 G31 37-50 I
3P
CR
I
3P
G31 37 G31 50 I
3P
-
Germany I
2ELL
G20 20 G25 20 CI - CR
Luxemburg I
2ELL
G25 / G25 20 / 25 G30 / G31
50 I
3B/P
/ I
3P
CV – CI - CR
I
3B/P
G30 50 G31 50 I
3P
CR
Switzerland I
2H
G20 20 G30 / G31
28-30/37/50 I
3+
/ I
3B/P
/ I
3P
CV – CI - CR
I
3+
/ I
3B/P
G30 28-30 / 50 G31 37-50 I
3P
CR
I
3+
G30 28-30 G30 50 I
3B/P
-
I
3P
G31 37 G31 50 I
3P
-
Greece I
2H
G20 20 G30 / G31
28-30/37 I
3+
/ I
3B/P
/ I
3P
CV – CI - CR
Italy I
3+
/ I
3B/P
G30 28-30 G31 37 I
3P
CR
Irlande I
2H
G20 20 G30 / G31
28-30/37 I
3+
/ I
3P
CV – CI - CR
Portugal I
3+
G30 28-30 G31 37 I
3P
CR
Netherlands I
2L
G25 25 G30 / G31
28-30/50 I
3B/P
/ I
3P
CV – CI - CR
I
3B/P
G30 30 G31 50 I
3P
CR
France I
2Esi
G20 20 G25 25 CI - CR
I
3+
G30 28-30 G31 37/50 I
3P
CR
I
3P
G31 37 G31 50 I
3P
-
Belgium I
2E(s)B
G20 / G25 20 / 25 G30 / G31
28-30/37 I
3+
/ I
3P
CV – CI - CR
I
3+
G30 28-30 G31 37 I
3P
CR
* The categorychange is only to be carried out under the responsibility of the Company T.G.C.P. or our local agent.

Page 10 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
5.2.2 AFTER SEPTEMBER 29TH, 2010 : FROM N°P27516226C
According the country of installation and the category of the appliance (indicated on the firm plate), the
adaptation from one gas to another may require 1 operation:
CI: Change of nozzles (burners) (See 4.4)
PROCEDURE:
On the firm plate, check:
- The category (ies) of the equipment.
- The gas and pressure for which it is adjusted.
In the following chart, select:
- The country concerned.
- The gas and the category of the appliance (see above).
- The gas and the pressure for which the appliance is going to be adjusted.
- Note and carry out the required operations.
- Replace the adjustment plate (code: 308 875), and mark the new gas used.
Countries
concerned Category and GAS OF ORIGIN (or new gas) NEW GAS and Category (or gas of origin) Required operations
Category Gas P (mbar) Gas P (mbar) Catégorie
Austria I
2H
G20 20 G30 / G31
50 I
3B/P
/ I
3P
I
3B/P
G30 50 G31 50 I
3P
CI
Finland - Norway I
2H
G20 20 G30 / G31
30 I
3B/P
CI
Sweden – Denmark
I
3B/P
G30 30 G31 30 I
3B/P
CI
Czech Republic I
2H
G20 20 G30 / G31
28-30/37/50 I
3+
/ I
3B/P
/ I
3P
-
I
3B/P
/ I
3+
G30 28-30 G31 30-37-50 I
3P
CI
I
3P
G31 37 G31 50 I
3P
CI
Spain I
2H
G20 20 G30 / G31
28-30/37/50 I
3+
/ I
3P
-
United Kingdom I
3+
G30 28-30 G31 37-50 I
3P
CI
I
3P
G31 37 G31 50 I
3P
CI
Germany I
2ELL
G20 20 G25 20 CI
Luxemburg I
2ELL
G25 / G25 20 / 25 G30 / G31
50 I
3B/P
/ I
3P
CI
I
3B/P
G30 50 G31 50 I
3P
CI
Switzerland I
2H
G20 20 G30 / G31
28-30/37/50 I
3+
/ I
3B/P
/ I
3P
CI
I
3+
/ I
3B/P
G30 28-30 / 50 G31 37-50 I
3P
CI
I
3+
G30 28-30 G30 50 I
3B/P
-
I
3P
G31 37 G31 50 I
3P
-
Greece I
2H
G20 20 G30 / G31
28-30/37 I
3+
/ I
3B/P
/ I
3P
CI
Italy I
3+
/ I
3B/P
G30 28-30 G31 37 I
3P
CI
Ireland I
2H
G20 20 G30 / G31
28-30/37 I
3+
/ I
3P
CI
Portugal I
3+
G30 28-30 G31 37 I
3P
CI
Netherlands I
2L
G25 25 G30 / G31
28-30/50 I
3B/P
/ I
3P
CI
I
3B/P
G30 30 G31 50 I
3P
CI
France I
2Esi
G20 20 G25 25 CI
I
3+
G30 28-30 G31 37/50 I
3P
CI
I
3P
G31 37 G31 50 I
3P
-
Belgium I
2E(s)B
G20 / G25 20 / 25 G30 / G31
28-30/37 I
3+
/ I
3P
CI
I
3+
G30 28-30 G31 37 I
3P
CI
* The categorychange is only to be carried out under the responsibility of the Company T.G.C.P. or our local agent.

Page 11 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
5.3 GAS FLOW-RATES AND POWERS
See paragraph 1: Technical characteristics (Installation manual).
5.4 CHART OF NOZZLES
5.4.1 BEFORE SEPTEMBER 29TH, 2010 : TO N°P27516226C
6 and 10 level ovens
GASES NOZZLES Air
Regulating
Designation Pressure Qty Diameter Code Marking Adjust. valve
Family Type
(mbar)
(1/100
e
)
(stamped) d (stamped)
G20 20 1 8.5 368 551 - 3.5 147 772Natural gas
G25 20 or 25 1 No nozzle - 2.6 147 772
G31 30 or 37 4.6 147 773
or 50 1 5.7 368 550
1 groove
Burner
G.P.L.
G30 30 or 50 1 5.7 368 550 1 groove 9.2 147 773
20 level ovens
GASES NOZZLES Régl. vanne de
Designation Pression Qty Qty ∅
∅∅
∅Code Marking
d’air régulation
Family Type
(mbar)
dry steam (1/100
e
)
(stamped) d (stamped)
G20 20 2 1 8.5 368 551 - 3.5 147 772Natural
gas G25 20 or 25 2 1 No nozzle - 2.6 147 772
G31 30 or 37 4.6 147 773
or 50 2 1 5.7 368 550
1 groove
Burner
G.P.L.
G30 30 or 50 2 1 5.7 368 550 1 groove 9.2 147 773
Nozzle marking Air adjustment
Air adjustment is carried out by means of a distancing
ring with a d size specified in the previous chart.
d
d Code
2.6 368 603
3.5 368 604
4.6 368 605
9.2 368 606
1 groove on injectors Ø 5.7
Ø = 8.5 mm
Code: 368 551
Ø = 5.7 mm
Code: 368 550

Page 12 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
5.4.2 AFTER SEPTEMBER 29TH, 2010 : FROM N°P27516226C
6 and 10 level ovens
GASES NOZZLES
Designation Pressure Qty ∅
∅∅
∅Code Marking
Family Type
(mbar)
(1/100
e
)
(stamped)
G20 20 1 6.1 368 890 0 grooveNatural gas
G25 20 or 25 1 8.5 368 891 1 groove
G31 30 or 37
or 50 1 4.1 368 893 3 grooves
Burner
L.P.G
G30 30 or 50 1 3.75 368 892 2 grooves
20 level ovens
GASES INJECTEURS
Designation Pressure Qty Qty ∅
∅∅
∅Code Marking
Family Type
(mbar)
dry steam (1/100
e
)
(stamped)
G20 20 2 1 6.1 368 890 0 grooveNatural
gas G25 20 ou 25 2 1 8.5 368 891
1 groove
G31 30 ou 37
ou 50 2 1 4.1 368 893
3 grooves
Burner
L.P.G
G30 30 ou 50 2 1 3.75 368 892 2 grooves
Identification of nozzles
1 groove on the nozzle Ø 8.5
2 grooves on the nozzle Ø 3.75
3 grooves on the nozzle Ø 4.1

Page 13 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
Positioning of the nozzle and the air distancing ring
Regulating valve
Air distancing
ring
Nozzle

Page 14 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
6. MAINTENANCE
To ensure the proper, long-lasting and safe functioning of the equipment, service twice a year by
qualified personnel from our company, and especially:
- Dismantle burners, checking and cleaning venturis.
- Clean the nozzles.
- Clean the ventilating apertures.
- Investigate possible leaks.
- Check controls, regulation and safety systems.
- Check the hydraulic circuit and condenser.
6.1 SERVICING THE CONDENSER
The water injection nozzle and the temperature sensor are to be checked and cleaned regularly.

Page 15 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
7. VERIFICATION OF TEMPERATURE SENSORS
SENSOR PT100 (1 point for the capacity sensor, 1 point for the core probe)
Components of the sensor PT100
PT100
Temperature sensor composed of a resistance sensor with the value of 100 ohms for a temperature of
0°, 138.5 ohms for a temperature of 100°. The varia tion of the resistance depending on the temperature is
linear. The reading of the resistance gives directly the measured temperature. The sensor is not polarised.
The sensor is lengthened by a copper wire.
Correspondence of Temperature in °C and Resistance in Ω
ΩΩ
Ωfor PT100 sensor
°C 0 1 2 3 4 5 6 7 8 9
0 100.00
100.39 100.78 101.17 101.56 101.95 102.34 102.73 103.12 103.51
10 103.90
104.29 104.68 105.07 105.46 105.85 106.24 106.63 107.02 107.4
20 107.79
108.18 108.57 108.96 109.35 109.73 110.12 110.51 110.90 111.28
30 111.67
112.06 112.45 112.83 113.22 113.61 113.99 114.38 114.77 115.15
40 115.54
115.93 116.31 116.70 117.08 117.47 117.85 118.24 118.62 119.01
50 119.40
119.78 120.16 120.55 120.93 121.32 121.70 122.09 122.47 122.86
60 123.24
123.62 124.01 124.39 124.77 125.16 125.54 125.92 126.31 126.69
70 127.07
127.45 127.84 128.22 128.60 128.98 129.37 129.75 130.13 130.51
80 130.89
131.27 131.66 132.04 132.42 132.80 133.18 133.56 133.94 134.32
90 134.70
135.08 135.46 135.84 136.22 136.60 136.98 137.36 137.74 138.12
100 138.50
138.88 139.26 139.64 140.02 140.39 140.77 141.15 141.53 141.91
110 142.29
142.66 143.04 143.42 143.80 144.17 144.55 144.93 145.31 145.68
120 146.06
146.44 146.81 147.19 147.57 147.94 148.32 148.70 149.07 149.45
130 149.82
150.20 150.57 150.95 151.33 151.70 152.08 152.45 152.83 153.20
140 153.58
153.95 154.32 154.70 155.07 155.45 155.82 156.19 156.57 156.94
150 157.31
157.69 158.06 158.43 158.81 159.18 159.55 159.93 160.30 160.67
160 161.04
161.42 161.79 162.16 162.53 162.90 163.27 163.65 164.02 164.39
170 164.76
165.13 165.50 165.87 166.24 166.61 166.98 167.35 167.72 168.09
180 168.46
168.83 169.20 169.57 169.94 170.31 170.68 171.05 171.42 171.79
190 172.16
172.53 172.90 173.26 173.63 174.00 174.37 174.74 175.10 175.47
200 175.84
176.21 176.57 176.94 177.31 177.68 178.04 178.41 178.78 179.14
210 179.51
179.88 180.24 180.61 180.97 181.34 181.71 182.07 182.44 182.80
220 183.17
183.53 183.90 184.26 184.63 184.99 185.36 185.72 186.09 186.45

Page 16 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
How to read the chart:
To find the resistance corresponding to the temperature of 164°C.
Find the intersection of the line 160°C and the col umn 4°C.
The reading shows 162.53 Ohms.
Check
Ω
PT100
MΩ
Check sensor resistance with an ohmmeter gauged at 200 ohms (less than 107 ohms for 20°).
Check the sensor insulation between one of the leads and the metal part with the ohmmeter gauged at
20 megohms (a value over 15 megohms).
Check the continuity between the screen and the metal part of the sensor.

Page 17 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
8. DOOR ADJUSTMENT AND CLOSING
WARNING: This adjustment must be carried out everytime the door or the door closing system is serviced
(hinges, closing device...), or after a steam leak in the way of the capacity seal.
8.1 8 AND 12 LEVEL OVENS
- Check that the oven is levelled.
- Door closed. Level the door by unscrewing both fixation screws of the upper hinge on the oven.
- Level the door, tighten and block the screws.
- Loosen the fixation screw of the upper hinge on the door.
- Push the door against the seal so that tightness is perfect. Warning! It is useless to squeeze the seal
flat, it will not result in better tightness.
- Block the fixation screw of the hinge.
- Bring the upper distance between the door and the capacity to the lower part of the door by loosening
the fixation screws of the lower hinge.
At this stage, if the procedure has been properly executed, the door should be at the same height as
the oven top. If not, readjust before the next step
Screws
Door
Screw
Door

Page 18 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
- open the door and measure the distance between the door top and the tip of the closing piston.
- Measure the distance between the top of the oven and the bottom of the hook groove.
Distance between the top and the piston tip Distance between the top and the groove bottom
- The distance between the top of the oven and the closing hook must be 1 to 2 mm greater than the
distance between the top of the door and the piston tip. If not, loosen the closing hook screw and adjust
the distance.
8.2 20 LEVEL OVENS
- Make sure that the oven is properly secured to the floor. Level the oven.
- Door closed. Level the door by unscrewing both fixation screws of the upper hinge on the oven.
Screws

Page 19 3BE390692NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
- Level the door, tighten and block the screws.
- Loosen the fixation screw of the upper hinge on the door.
- Push the door against the seal so that tightness is perfect. Warning! It is useless to squeeze the seal flat,
it will not result in better tightness.
- Block the fixation screw of the hinge.
- Bring the upper distance between the door and the capacity to the lower part of the door by loosening
the fixation screws of the lower hinge.
Screw
