Boon FLAIR User manual

FLAIR
+ Pedestal Highchair with Pneumatic Lift
Instructions

2
E
IMPORTANT!
KEEP FOR
FUTURE REFERENCE
Failure to follow these warnings, cautions and
the assembly instructions could result in serious
injury or death.
Please read ALL instructions carefully before assembly
and use of this product.
WWARNING
• Prevent serious injury or death from falls or
sliding out.
• ALWAYS secure child using the waist, crotch and
shoulder harness restraint system. The child should
be secured in the highchair at all times by the
restraint system. The tray is not designed to hold the
child in the seat.
• ALWAYS keep child in view while in highchair.
• ALWAYS use highchair on a flat smooth surface.
• ALWAYS use brake when child is in highchair.
• NEVER leave child unattended.
• NEVER use near stairs or in any location where
hanging cords can be reached by child.
• NEVER adjust seat height when child is in highchair.
• NEVER allow child to use footrest to climb in or
out of highchair.
• It is recommended that the highchair be used only
by children capable of sitting upright unassisted.
• Do not use the highchair unless all components are
correctly fitted and adjusted.
• Do not use the highchair near open fire or other
sources of heat/flame.
• Do not use the highchair if any parts are broken,
torn or missing.
• Maximum age: 4 years
• Maximum weight: 50 lbs.
IMPORTANT: Please make sure you have all of the parts
shown on this page before beginning assembly. If you are
missing any parts, please DO NOT return this product to
the store. Please call our customer service department at
888.376.4763 or contact us at [e-mail].
Tools required for assembly: Phillips screwdriver
(not included)
PARTS
Seat
Seat pad
Shoulder straps
Waist strap
Buckles
Crotch post
Footrest
Seat base
Upper tube
Seat base cover
Lower tube
Brake Pedal
Base
Height adjustment button
SEAT ASSEMBLY
SUPPORT ASSEMBLY
BASE ASSEMBLY
Release handle on
bottom of tray
M6 bolt (x5)
M4 bolt (x2)
Tray assembly
Tray liner (x1)
WCAUTION
• Adult assembly required.
• Tool required for assembly: Phillips screwdriver
(not included).
• This product contains small parts. Keep small parts
out of children’s reach during assembly.
• Assembly components may have sharp points
and edges. Exercise care when unpacking and
assembling product.
• After assembly is complete, properly discard all
packaging materials, including notice on tray liner.

3
1
NOTE: DO NOT REMOVE the sticker holding the seat
base cover in place until after support tube has been
inserted into base.
Make sure seat base cover remains on support tube.
Insert support tube into base.
2
Rotate the tube clockwise while gently pressing down
until the tube drops into place and can no longer rotate. 3To ensure that tube is secure, first try to rotate tube counter-
clockwise. Tube should not be able to rotate. Second, try to
pull tube up out of the base. The tube may move upwards
slightly, but should remain attached to the base.
Remove the sticker holding the seat base cover in place
and discard it properly.
5
Align seat base cover with notch toward front of seat.
Attach seat base cover with (2) M4 bolts.
4
Raise tube to highest position by stepping on height
adjustment button.
Place seat on seat base aligning back of seat with brake
pedal. The front of the seat will face in the direction of
the height adjustment button. Secure with (5) M6 bolts.
IMPORTANT: The seat MUST be aligned with its BACK
toward the brake pedal for proper assembly.
Brake pedal
ASSEMBLY

4
To raise seat height, step on
height adjustment button on front
of base. The seat will raise to its
maximum position.
To lower seat height, step on height
adjustment button while pushing down
on seat. Release button BEFORE letting
go of seat. WWARNING
• NEVER adjust the seat height when child
is in highchair.
• ALWAYS use the highchair on a flat smooth surface.
• ALWAYS use brake when child is in highchair.
ADJUSTING THE SEAT HEIGHT & USING THE BRAKE
Place child in seat with one leg on each side of the
crotch post. Position crotch strap between child’s legs and
shoulder straps over shoulders. Position waist strap around
child’s waist.
Insert male buckles on both waist straps into female buckle
on crotch strap until buckles click. Pull buckles outward to
check that they are secure.
OPTIONAL SEAT PAD
A durable, foam seat pad is pre-installed in the highchair
seat. This pad provides extra support and a more secure
fit for smaller children. The seat pad can be removed to
accommodate larger toddlers. To remove the seat pad, first
remove restraint system (see diagram 1 on following page).
After removing seat pad, ALWAYS replace restraint system
using diagrams 2 and 3 on the following page BEFORE
using highchair.
RELEASING THE BUCKLES
Press down on button in the center of the buckle and then
pull both male buckles outward, as shown.
SECURING YOUR CHILD
WWARNING
• Prevent serious injury or death from falls or
sliding out.
• ALWAYS secure child using the waist, crotch and
shoulder harness restraint system. The child should
be secured in the highchair at all times by the
restraint system.
• NEVER allow child to use footrest to climb in or out
of highchair.
Shoulder strap
Crotch strap
Waist strap
Crotch post
Firmly press brake pedal all the
way down to activate brake. Ensure
brake is activated properly by
pushing the highchair sideways to
be certain it does not roll.
Press again to release brake.
If braking resistance becomes diminished, tip highchair on
its side. Using a damp cloth, wipe the raised buttons on
the brake weight so they are clean of dust and debris.

5
SHOULDER STRAP HEIGHT ADJUSTMENT
Adjust shoulder strap height if necessary. Straps may need
to be adjusted based on the height of the child. The shoulder
straps are pre-assembled using the lower slots so that the
seat can initially be used for a smaller child. As your child
grows, these straps may need to be adjusted by moving
them to the higher slots. Follow the steps below to adjust the
shoulder straps. ALWAYS use the same height slots for both
sides of the shoulder straps.
1STRAP REMOVAL
From the back of the seat, squeeze the strap tabs
together while pulling the strap from the front of the
seat. Repeat for the strap on the other side. If the seat
pad is in place, repeat this process to pull the shoulder
strap through the pad also.
ADJUSTING RESTRAINT SYSTEM STRAPS
SHOULDER STRAP LENGTH ADJUSTMENT
Pull shoulder strap through slide adjuster to tighten or
loosen. Make sure that both shoulder straps are adjusted
to the same length.
Slide adjuster
2STRAP INSERTION
Squeeze the strap tabs together and push through
opening. Repeat for the strap on the other side.
ALWAYS use the same height slots for both sides
of the shoulder straps.
3STRAP CHECK
Inspect strap tabs and ensure tabs are flat against
back of seat. Pull straps on BOTH sides to ensure
that they are secure.
WAIST STRAP ADJUSTMENT
Slide strap through the exposed inside slot from the rear
to the front of the buckle. Squeeze the side button to
expose a second slot and insert strap from the front to
the rear through the outside slot. To tighten waist strap,
squeeze the side button and pull front strap outward,
as show above. To loosen waist strap, squeeze the side
button and pull rear strap outward.
Side Button

6
USING THE TRAY LINER
REMOVING TRAY LINER
Pull release tab at back of tray outward and lift up.
REINSERTING TRAY LINER
Place front edge of tray liner into the tray then clip back
edge over tray.
USING THE TRAY
REMOVING THE TRAY OR CHANGING
ADJUSTMENT POSITIONS
To release locking tabs: 1) slide orange handle to left, then
2) pull handle toward front of tray. Make sure that tabs have
retracted fully into the tray. Pull tray out or relocate to the other
adjustment position. DO NOT place tray in dishwasher or
submerse in water.
1
To release locking tabs: 1) slide orange handle to left,
then 2) pull handle toward front of tray. Place tray on seat
arm grooves.
2
Position locking tabs at appropriate slots. Tabs should fit
into slots in seat arms. There are two adjustment positions
for the tray. Make sure that tabs are aligned in same
adjustment position slots on BOTH sides of seat and
release the handle and slide lock.
3
Pull on tray to ensure that it is firmly in place.
1
2
3
2
1
ATTACHING THE TRAY
WWARNING
• The tray is not designed to hold the child in the seat.
The child should be secured in the highchair at all
times by the restraint system.
CLEANING TRAY LINER
The tray liner may be placed in the dishwasher for cleaning
(top rack only).
DO NOT place tray in dishwasher or submerse in water.

7
1
Remove the two bolts that attach the seat base
cover to the seat. 2
Raise tube to highest position by stepping on height
adjustment button. Remove the five bolts that attach seat
to support assembly.
3
Tip the highchair on its side. Locate the large gray
weight in the center of the base and the two plastic tabs
that hold it in place. Use the flathead screwdriver to pry
one of these tabs toward the center hole of the weight
while at the same time pulling the weight slightly away
from the base. Do the same for the other tab to fully
release the weight.
DISASSEMBLY
If it should become necessary to disassemble your highchair
for transport or storage, please follow these instructions.
Tools required: Phillips screwdriver, flat-head screwdriver (not included)
WWARNING
• DO NOT disassemble any other
components of the highchair.
5
Before storing or transporting chair, reattach gray
weight to highchair base. Position gray disc in center of
star with six raised bumps facing out. Reattach disc by
fitting tabs into holes in center of disc. Make sure tabs fit
snuggly in holes.
4
Locate the metal spring tab attached to the center tube
of the base. Use the flathead screwdriver to gently pry
UP on the spring end of this tab, while at the same time
pulling the support tube out of the base. Note that it may
be easier to have two people perform this disassembly.

8
Actual product styling and colors may vary. Patents, trademarks, copyrights, and designs are exclusively
owned by BKD. Made in China.
B11068-02-INT-001
© 2014 BKD (A DIVISION OF TOMY)
1241 W WARNER RD, SUITE 101
TEMPE, AZ, USA 85284
FOR US AND CANADIAN
CUSTOMERS: 888.376.4763
BOONINC.COM
SEAT Clean with a soft cloth using warm water and mild soap. Disinfectant
wipes can also be used.
SEAT PAD
Clean the seat pad with a soft cloth using warm water and mild soap.
Household disinfectants can also be used. DO NOT place seat pad in
dishwasher or washing machine.
RESTRAINT SYSTEM
STRAPS AND BUCKLES
Clean restraint system straps and buckles using a soft cloth with warm
water and mild soap.
TRAY Clean with a soft cloth using warm water and mild soap. DO NOT place
tray in dishwasher or submerge in water.
DO NOT place any of the above parts into a dishwasher or washing
machine to clean them.
TRAY LINER Tray liner can be cleaned with a soft cloth using warm water and mild
soap or can be placed in the dishwasher (top rack only).
CLEANING & CARE
E
