Booth & Co AXBRIDGE BC-AXB-188-CP User manual

This instruction booklet covers model:
BC-AXB-188-CP
BC-AXB-188-BN
Version 2, 1-8-19
VADO
Wedmore Road, Cheddar,
Somerset, England BS27 3EB
tel [phone]
fax [phone]
www.vado.com
[e-mail]
AXBRIDGE
BC-AXB-188-CP
BC-AXB-188-BN
INSTALLATION GUIDE

2 3
Contents of Packaging
AXB RI DG E
BC-A X B -188-C P
BC-A X B -188-B N
INST AL L AT IO N GUID E
Installation guide &
User manual Tumbler
Holder
Fixing box
Mounting plate
Hex key
Screws x 2 Wall plugs x 2
Brush
Cleaning instructions
The electroplating on this product is finished to the highest standard.
Due care needs to be taken to ensure the appearance is retained.
We recommend cleaning all products with a soft damp cloth ONLY and
advise strongly against the use of all aggressive/corrosive cleaning
products i.e. powders and liquids. If these instructions are not followed,
this may invalidate your guarantee in the event of a problem occurring.
Please read these instructions carefully before starting installation and
keep for future reference.
Remove all packaging and check the product for missing parts or
damage before starting installation. Please take great care when
installing this mixer not to damage its surface.
Warning! Please check for any hidden cables and pipes before drilling
holes in the wall.
Note: The fixings supplied are for solid walls only. If you are fitting the
accessory to a partition or wall of particularly soft substrate you will
need specialist fixings.
Important - please read
Expertly designed in our home town of Cheddar, Somerset, each
Booth & Co. product is as time-honoured on the outside as it is
pioneering within.
Hand-crafted to exude a distinct, timeless sophistication, this product
has passed through stringent quality assurance processes and
demanding lifecycle mechanical testing to ensure an unrivalled quality.
Our leading 15 year guarantee certifies excellence within every detail.
Part of the VADO family, Booth & Co. retains the same outstanding
customer service and large scale development support that earned
VADO a globally trusted reputation. For any technical or operation
queries, please contact our experienced Aftersales team on
01934 745 163.
Indulge in luxury as it should be.
Welcome to Booth & Co.

4 5
Dimensions Installation - Quick guide
382mm
Ø82mm137mm
2 1
35
4

6
Installation
Place the mounting plate in the
required position and mark the two
fixing holes. Drill the marked holes
to a suitable depth for the wall
plugs, secure with supplied screws.
If you are fitting to a partition
wall or a wall of particularly soft
substrate you will need specialist
fixings.
Using the supplied hex key tighten
the grub screw on the underside
holder body.
Place the tumbler into the holder
followed by the brush into the
tumbler.
Place the holder over the mounting
plate, make sure that the holder is
level, the grub screw should be in
the 6 o'clock position.
Mounting
plate
Screws
Wall plugs
Mounting
plate
Grub screw
Hex key
All VADO and Booth & Co. products come with a 2 year guarantee as standard. Within this
guarantee period VADO will provide replacement parts and any labour [SEE NOTE 1] needed to
complete the product repair.
This standard guarantee may be extended by registering your product to give up to a
15 year guarantee period. Once registered:
VADO chromed brassware and stainless steel products have a 12 year guarantee
(2 years parts and labour plus 10 years parts only).
Individual by VADO and Booth & Co. products have a 15 year guarantee (2 years parts plus 13 years
parts only) with the exception of Sensori products (please see details of guarantee below).
VADO Sensori Smart Touch and Smart Dial products have a 5 year guarantee
(parts and labour).
VADO Identity and i-tech products have a 5 year guarantee (2 year parts and labour plus 3 years
parts only).
All other VADO products have a 3 year guarantee (2 years parts and labour plus 1 year parts only)
[SEE NOTE 2].
VADO electric showers have a 2 years parts and labour guarantee.
Guarantee conditions
Our products are guaranteed against manufacturing defects from the date of purchase until the
expiry of the relevant guarantee period shown above.
The guarantee is only valid if:
• The product has been installed, used and maintained in accordance with VADO’s instructions and
subjected to normal use only.
• The defect is not due to use of an unsuitable or inadequate water or power supply.
• The defect is not due to accident, misuse, neglect or incorrect/inappropriate repair
(other than by VADO or VADO authorised agents) or damage caused by foreign objects or
substances.
• The extended guarantee is only available if you have completed the Guarantee Registration
Process.
This can be done via the VADO website or via phone to our aftersales team. Registration must be
completed within 6 months from date of purchase.
Under the extended guarantee period VADO will, at its option, offer to supply any replacement
product (or component part) assessed to be defective [SEE NOTE 3].
The guarantee (whether standard or extended) is non-transferable to any subsequent owner. All
claims under the guarantee should be notified in the first instance to our Aftersales department,
contact details below, this must be done no later than the last day of the relevant guarantee period.
All claims must be accompanied by proof of purchase (sales receipt or delivery note) from an
official VADO dealer.
The guarantee does not extend to any consequential loss or damage.
After repair or replacement, the relevant guarantee period will be calculated from the original date
of purchase.
VADO operates a policy of continuous product development and therefore reserves the right to
change the product, packaging and documentation specifications without notice.
NOTES:
[1] Labour via our engineer network is only available in the UK. Attendance by a VADO engineer or
sub- contract engineer will be under our standard terms and conditions.
[2] VADO spare parts and shower hoses are under a parts only guarantee.
[3] VADO reserves the right to charge in advance for a product (or replacement part) pending
collection and investigation (at VADO expense) to confirm a defect is due to a manufacturing issue.
If a defect is found the charge will be refunded or cancelled. This guarantee is in addition to and
does not affect your statutory rights as a consumer.
