CLIC DOUBLE PANE BATH SCREEN NBDSC1150
INSTALLATION INSTRUCTIONS
A

IMPORTANT - Please read before installation
Please read these instructions carefully before starting
installation and keep in a safe place for future reference.
Check the contents of the pack carefully before installation.
Simpsons will not be held responsible for any de-fit / re-fit costs
where faulty product has been fitted.
If any fault is found with materials or workmanship, it must be
reported immediately to the manufacturer. Remedial action will
be taken, based on information received, on condition that:
1. Full details are supplied to the manufacturer;
2. The bath screen has not been modified or tampered with;
3. The manufacturer is informed of any damage/shortages
prior to installation.
We do not accept responsibility for any problems that may occur
through incorrect installation.
The success of the installation and operation of any bath screen
is, of course, dependant on the squareness, alignment and
construction of the walls to which fixing is to be carried out.
VERY IMPORTANT
You must complete all tiling and grouting, and the bath MUST be
level and fully sealed to the tiles before installation. If you do not
fit the bath screen onto a tiled surface, or seal the tiles to the bath
before installation, water may soak into the wall behind the wall
profiles.
INSTALLATION - Advice and safety
The installation instructions are based on typical use and
conditions.
All doors are designed to open outwards and inwards.
These hints have been prepared for your guidance, you must
exercise due care at all times.
For Health and Safety 2 people must carry out the installation
of this enclosure.
Handle glass with care. Although the glass supplied is
toughened safety glass (EN12150), impacts can damage both
the glass and the frame.
Warning!
Please check for any hidden pipes or cables before
drilling holes in the wall.
When using power tools always follow the manufacturers user
instructions.
If the Framework is sealed to the bath on the inside, any water
that may get into the framework will not be able to drain back
into the bath, this may cause the enclosure to leak.
Leave the silicone sealant to dry for 24 hours before using the
enclosure.
CARE AND CLEANING
Do not use solvents or abrasive material or chemicals to clean
the bath screen.
1
Only clean using soapy water and a soft cloth, rinse
thoroughly afterwards.
INSTALLATION - Left and Right hand
●Left entry: The parts detailed as “ LH ” should be used.
●Right entry: The parts detailed as “ RH ” should be used.
LH RH
This product is reversible for left or right hand opening.
Please follow the diagram, and refer to the detail for your
choice of installation.
A

CLIC DOUBLE PANE BATH SCREEN
2
Drill, 6mm Masonry drill bit, Tape measure,Knife,Rubber Mallet,Wood,Philips screwdriver, Spirit level, Pencil, Silicone sealant.
Tools and equipment needed
CONTENTS
Top Pivot Cover x 1
Q
Bottom Pivot Cover (LH) x 1
Top Pivot x 1
N
ST4 *40mm Screw x 3
A
Wall Plug x 4
B
Steady x 1
C
D
Bottom Pivot x 1
E
Cover x 1
I
J
K
L
Support Bar x 1
G
H
F
O
P
A
Waterproof Strip x 1
M
Cover x 1
ST3.5*25mm Screw x 2
Bottom Pivot Cover (RH) x 1
Seal x 1
ST4 *40mm Screw x 1
Cover x 1
R
Cover x 1
S
2mm Allen Key x 1
Sealing Strip x 1

Left Hand (LH)
3
Please follow diagram below for the correct assembly for Left or Right hand installation.
Right Hand (RH)
C
D
A
E
F
C
D
F
E

B
A
Step 1 - FITTING AND POSITIONING WALL CHANNEL
4
Step 2
Place wall channel in position on the bath (10mm in from the edge of the
bath), use a spirit level to ensure that it is vertical, and mark all 3 fixing
holes on the wall.
Drill holes in the positions marked using a 6mm masonry drill bit. Insert wall
plugs (B) into all of the holes (beyond the thickness of the tile).
Fix the wall channel to the wall using 3 screws (A).
Note: Inject silicone sealant into the holes before inserting the screws
to seal the holes.
Push the pivot door into the wall channel.
A
15mm
G
Step 3
G
H

Step 4
5
Step 5
I
A
D
S
a
b
J
K
K

Step 6
6
Step 7
A
B
L
Place wall bracket (L) in position
Use a spirit level to check the level.
Mark the hole positions on to the wall.
Drill holes in the positions marked using a 6mm masonry
drill bit. Insert wall plugs (B) into the two holes.
(beyond the thickness of the tile).
N
M
O
P
Q
Q

Step 8
7
For any further information please contact
Simpsons on: 0845 873 5808
Or visit our web-site at
www.simpsons-enclosures.co.uk
The manufacturer reserves the right to make technical
modifications without prior notice.
