Moen Felicity 9000 User manual

6-9/16"
(167mm)
ESCUTCHEON DIA.
1-7/8"
(47mm)
ESCUTCHEON DIA.
2-3/8"
(60mm)
1-1/4” (32mm) MAX.
DECK THICKNESS
3-5/8"
(92mm)
3-5/8"
(92mm)
6-3/8"
(162mm)
7-5/8"
(193mm)
8" (203mm) - 16" (406mm)
Centers
2-13/16"
(72mm)
DESCRIPTION
• Metal construction with various finishes identified by suffix
• 1/2" IPS connections will accept standard ball nose connection
for 3/8” tubing
• Hydrolock™ quick connect installation
• Includes metal pop-up waste assembly
• Designed to be installed through 3, 1-1/8” dia. holes
OPERATION
• Lever style handles
• Maximum handle rotation angle is 90˚ to full on for either handle
• Rotate hot side handle counterclockwise to open and clockwise to close
• Rotate cold side handle clockwise to open and counterclockwise to close
FLOW
• Flow is limited to 1.5 gpm max (5.7 L/min) at 60 psi
• Features a laminar flow pattern for dramatic water presentation
CARTRIDGE
• 1224 cartridge design with nonmetallic/nonferrous
and stainless steel materials
STANDARDS
• Third party certified to WaterSense,® CSA B125.1, ASME A112.18.1,
ICC A117.1 and all applicable requirements referenced therein
• Certified to ANSI/NSF 61/9
• Contains no more than 0.25% weighted average lead content
• Complies with California Proposition 65 and with the Federal Safe
Drinking Water Act
• ADA for lever handle
WARRANTY
• Lifetime limited warranty against leaks, drips and finish defects to the
original consumer purchaser
• 5 year warranty if used in commercial installations
FELICITY™
Two-Handle Widespread
Lavatory Faucet Trim
Models: TS448 series
Valve: 9000
CRITICAL DIMENSIONS
(DO NOT SCALE)
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
Specifications
Rev. 3/11
