Borg & Overstrom 818 Original operating instructions

INSTALLATION &
OPERATION GUIDE
818 SPORT MODELS

Contents
1. Range Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 4
2. Installation and Operation Guides . . . . . . . . . . . . . . . . . . . . . . Page 10
3. Sanitisation and Cleaning Guides . . . . . . . . . . . . . . . . . . . . . . Page 22
4. Troubleshooting Guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 25
5. Exploded Diagrams. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 32
6. Complete Parts Listing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 40
7. Appendices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 47
818 Sport Models
Technical
Manual

Section1
Technical Manual
818 Sport

818 Sport Models
4
Range Overview
A range of compact countertop water dispensers, available in two different operational
types:
• 818 Cold and Ambient (Low Pressure Tank System)
• 818 CS Cold and Sparkling (Direct Chill System)
Both types are available as:
• Countertop
• With optional base cabinet (Close fitting to create Floor Standing style appearance)

818 Sport Models
5
All Types
All B&O 818 Sport models are self contained machines with robust steel framed cabinets and attractively injection
moulded plastic front, side and top panels. There is sufficient space internally for most filters to be fitted behind
the right side panel.
An IEC Power Lead is supplied for connection to the IEC socket found on the rear of all models (An additional
Schuko type is supplied for the European market).
Optional Floorstanding Base Cabinet
A sturdy, steel-sided cabinet with an opening door and service access ports in the rear panel. Adjustable feet are
standard.
818 Cold and Ambient Model
Water is fed into the insulated Cold Tank under mains pressure. We strongly recommend fitting a Pressure
Reducing Valve is fitted to all supplies to regulate the pressure to 3.5 bar/355 kPa. Water bypasses the cold tank
for the ambient dispense option. The cold tank is chilled via the outer evaporation coil of the capillary controlled
refrigeration compression system.
Dispense is at inlet pressure via the DC current operated solenoid valves.
The Cold Temperature is thermostatically controlled via the adjustment screw on the back of the machine. This
setting is factory set and is not necessary to adjust in most cases (see Controls).
The Cold Tank can be drained via the lower of the two Drain Ports on the rear of the machine.
818 Cold and Sparkling Model
A Direct Chill cold water dispenser where water is used as the cooling medium in the Direct Chill tank. This is
automatically filled and controlled by the level control system upon installation. This tank is then chilled via the
outer evaporation coil of the capillary controlled refrigeration compression system.
Water is chilled as it passes through the coil immediately before dispense or being pumped under pressure into the
carbonator which it fitted inside the same coil. The carbonator is also level controlled and allows the sparkling
effect to occur through saturation with CO2.
The level control system also incorporates a leak detection device within the cabinet which switches the machine
off in the event of detecting water.
The Cold Temperature is thermostatically controlled via the adjustment screw on the back of the machine. This is
factory set and is not necessary to adjust in most cases (see Controls).
The Cold Tank can be drained via the upper of the two Drain Parts on the rear of the machine.

818 Sport Models
6
Controls
Cold & Ambient Models
On/Off switch – at upper rear of machine. Switches Cooling Operation on/off.
Cold Thermostat – at rear of machine.
Factory set to:
NB: Turn clockwise to decrease water temperature
Ambient Button Press to dispense Ambient water
Cold Button Press to dispense Cold water
Green LED (LH) Colours to show Cooling Operation is switched on
Green LED (RH) Colours to show when compressor is operating/water is above set point
10A Fuse On rear of machine, integral with IEC socket
Cold and Sparkling Models
On/Off switches – at upper rear of machine
Cold – switches Cooling Operation on/off
Soda – switches Sparkling Operation on/off
The thermostat setting is the same as for the Cold & Ambient model as above.
Sparkling Button Press to dispense Sparkling Water
Cold Button Press to dispense Cold Water
Green LED (LH) Colours to show Cooling Operation is switched on
Green LED (RH) Shows when compressor is operating
Yellow LED (bottom RH) Colours to show the Sparkling Operation is switched on
10A Fuse On rear of machine, integral with IEC socket
+C
-C

818 Sport Models
7
Base Cabinet
Either 818 model is designed to fit straight onto the top of the cabinet. Ensure the feet of the machine securely
locate in the nesting positions.
The Door Panel is hinged and fastened with Magnetic Catches. The Cabinet can be levelled using the adjustable
feet. Service entry points are positioned in the back of the cabinet.
Every Base Cabinet is supplied with a Level Sensor Kit, comprising:
• Water Container
• Sensor Unit (c/w 2 no. CR3032 batteries)
• Drip Tray with Drainage Outlet
Simply exchange the Drip Trays, connect the Drainage Tubing, that is pre-fitted down the front left hand side of the
cabinet, into the top of the container and remove the transit seal from around the float shaft to enable operation.
A warning tone will sound when the water rises. Upon emptying the container, the warning tone will stop.

818 Sport Models
8
Specifications
COOLING SYSTEM All High efficiency compression system with capillary
control. Premium quality long life hermetic
compressor. Compact internal condenser – fan
assisted for greater efficiency. Environmentally
friendly R134A refrigerant.
818 High volume 3.5 litre stainless steel pressurised
cold tank for optimum water capacity on demand
and hygiene. Low sanitisation and maintenance.
Insulated tank for energy conservation. Large
volume output performance via high pressure
valves. Thermostatically controlled chilled water
temperature (range down to 1°C minimum).
Integrated stainless steel carbonator on sparkling
water machine option.
818 CS 3.5 litre stainless steel chiller tank with level
control containing stainless steel cold water direct
chill coil. Stainless steel carbonator tank with
independent level control fitted inside coil. High
capacity, low voltage diaphragm inlet pump.
COLD TEMPERATURE 2°C to 11°C.
THROUGHPUT PER HOUR 18 litres cold < 12°C / 16 litres sparkling <12°C.
DISPENSE Ergonomically designed and situated light touch
sensitive controls.
MAXIMUM RUNNING
POWER CONSUMPTION
85 watt. Cold and ambient.
180 watt. Cold and sparkling.
POWER REQUIREMENTS 230 volt/50Hz supply required.
POWER SUPPLY IEC power socket.
WATER CONNECTION 1/4inch quick connection.
CO2CONNECTION 1/4 inch quick connection.
COUNTERTOP
DIMENSIONS
(w x d x h) 320 x 440 x 415mm
WEIGHTS 818 14.5 kg
818 CS 21.0 kg

Section2
Technical Manual
818 Sport

818 Sport Models
10
818 Sport
Cold and Ambient Model
Contents:
• Major Components
• Water Connection
• Operation
• Safety
• Sanitisation Guide (See section 3)
Operation

818 Sport Models
11
Major Components
Water Connection
Top Cover
Cold Water Tank
Ambient Water Button
Cold Water Button
Control Panel
Inlet Water (1/4”)
Drain Port

818 Sport Models
12
Operation
1. After connecting the water the tank will begin to fill. Put the
plug in the socket and the indicator lights will be lit. Try
pressing the cold water button to see if water comes out.
When water flows out of the dispenser, the cold power switch
may be turned on and it is ready to use. Please do not turn on
the power switch until water flows out of the machine, to avoid
damage. Allow up to one hour for minimum temperature
water. Flush through 10 litres of water.
2. When the cold power switch is
turned on, the chilling LED will be
on. When the set temperature is
reached, the LED will go out.
Cold Power Switch
Fused IEC Socket

818 Sport Models
13
3. Press the ambient water button for ambient water.
4. Press the cold water button for cold water.
Ambient Water Button
Cold Power
Indicator
Chilling System
Indicator
Cold Water Button

818 Sport Models
14
Safety
Be sure to use single outlet socket with correct power
voltage. Plug the power cord directly into the electrical
socket.
Leave a space no less than 15cm between the wall and
dispenser.
Keep the machine away from sunlight, heat and
moisture.

818 Sport Models
15
818CS
Cold and Sparkling Model
Contents:
• Major Components
• Water and CO2Connection
• Cold Water Operation
•CO
2Bottle Installation
• Sparkling Operation
• Safety
• Leak Detection
• Sanitisation Guide (See Section 3)
Operation

818 Sport Models
16
Major Components
Water and CO2Connection
Top Cover
Sparkling Water Tank
Cold Water Tank
Control Panel
CO2Connector (1/4”)
Inlet water (1/4”)
Drain Port

818 Sport Models
17
Cold Water Operation
2. Turn on the cold power switch and the cold water and
chilling LEDs will show. The temperature of cold
water can be set from 4°C to 10°C. When the chilling
LED is off the set temperature has been reached.
1. After connecting the water the tank will begin to fill
with water. Plug in the power and the indicator LEDs
will be on. Try pressing the cold button until the water
comes out. When water flows out of the dispenser,
the power switch may be turned on and the machine
is ready to use. Allow up to one hour for minimum
temperature water.
Cold water power
Carbonated
Water Power
Fused IEC Socket
Cold Water Indicator
Sparkling Water Indicator

818 Sport Models
18
CO2Bottle Installation
1. Attach the regulator to the disposable CO2bottle, ensuring the regulator is closed.
2. Connect the assembled CO2bottle and regulator to the machine.
3. Do not open the regulator valve until the Carbonated switch has been turned on.
1. After completing the water
installation, turn on the soda power
switch. When the pump switches off
open the CO2regulator. Do not
exceed 5 bar pressure.
2. Initially please flush through
approximately 10 litres of water.
3. It will be necessary to leave the
machine for up to one hour for
sparkling water to develop, by
absorbing the CO2.
CO2Refill Tube
Carbonated Power Switch
Soda Water Indicator
Soda Water Button

818 Sport Models
19
Safety
Leave a space no less than 15cm between the wall and
dispenser.
Keep the machine away from sunlight, heat and moisture.
Be sure to use single outlet socket with correct power
voltage. Plug the power cord directly into the electrical
socket.

818 Sport Models
20
Leak Detection
Notice:
This machine is equipped with a leakage detection device. When leaking is detected, the power will be cut off
automatically.
When the power has been cut off:
1. Unplug the machine, then remove the left side plate.
2. Detection probe found in the bottom front left hand corner and dry probes and machine with a dry cloth.
3. Plug in the machine to test if the leaking has stopped.
