Table top gas cooktop
PNP0E6...I PNW1E6...I
[en] User manual and installation
instructions

2
Further information and explanations are
available online:
Table of contents
1 Safety ...........................................3
1.1 General information................... 3
1.2 Intended use.............................. 3
1.3 Restriction of the user group .... 3
1.4 Safe use .................................... 3
2 Environmental protection and
saving energy..............................7
2.1 Disposing of packaging ............ 7
3 First steps....................................7
3.1 Read the safety instructions...... 7
3.2 Unpacking the appliance .......... 7
4 Installation and connection........7
4.1 Installing and connecting the
appliance................................... 7
5 Familiarising yourself with
your appliance.............................9
5.1 Appliance .................................. 9
5.2 Control knob............................ 10
5.3 Burners.................................... 10
6 Accessories...............................10
6.1 Upper rack for small items
of cookware............................. 10
6.2 Baati stand .............................. 11
6.3 Burner cleaner......................... 11
7 Before using for the first time ..11
7.1 Initial use ................................. 11
7.2 Placing burner parts and
pan supports in their correct
positions .................................. 11
8 Cookware...................................12
8.1 Suitable cookware................... 12
8.2 Using cookware ...................... 12
8.3 Cooking with a direct flame .... 13
9 Basic operation .........................13
9.1 Switching on the appliance ..... 13
9.2 Switching off the appliance ..... 13
10 Easy Clean & Lift.....................14
10.1 Cleaning below the cook-
top ......................................... 14
11 Cleaning and servicing...........15
11.1 Cleaning the appliance ......... 15
11.2 Recommended cleaning
methods................................. 15
12 Troubleshooting......................16
13 Customer Service....................18
13.1 Product number (E-Nr.) and
production number (FD)........ 18

Safety en
3
1 Safety
Observe the following safety instructions.
1.1 General information
¡Read this instruction manual carefully.
¡Keep the instruction manual and the product information safe
for future reference or for the next owner.
¡Do not connect the appliance if it has been damaged in transit.
1.2 Intended use
The appliance can only be used safely if it is correctly installed in
accordance with the installation instructions. The customer is re-
sponsible for ensuring that the appliance is properly installed.
Only use this appliance:
¡for cooking purposes with Liquefied petroleum gas (LPG).
¡Under supervision. Never leave the appliance unattended when
cooking.
¡In a private household and in a domestic environment.
Do not use the appliance:
¡On boats or in vehicles.
¡as a room heater.
¡For drying towels, clothes, etc. over it.
1.3 Restriction of the user group
Do not allow children to use this appliance without supervision.
1.4 Safe use
WARNING‒Risk of explosion!
Escaping gas may cause an explosion. WHAT TO DO IF YOU
SMELL GAS OR IF THERE ARE FAULTS IN THE GAS INSTALLA-
TION
▶Immediately shut off the gas supply or close the gas cylinder
valve.
▶Immediately extinguish all naked flames and cigarettes.

en Safety
4
▶Do not operate any light switches or appliance switches.
▶Open windows and ventilate the room.
▶Call customer service or the gas supplier.
Escaping gas may cause an explosion. Small amounts of gas can
collect over a longer period of time and ignite.
▶Close the regulator valve for the gas supply when the appliance
is out of use for prolonged periods.
Escaping gas may cause an explosion. If the liquefied gas bottle
is not upright, liquefied gas(LPG) can enter the appliance. Intense
darting flames may therefore escape from the burners. Compon-
ents may become damaged and start to leak over time so that
gas escapes uncontrollably.
▶Always use liquefied gas bottles in an upright position.
If the appliance is moved carelessly, gas may escape.
▶If you move the appliance do not disturb the gas supply or pipe.
WARNING‒Risk of suffocation!
Using the gas cooking appliance leads to a build-up of heat,
moisture and combustion products in the room where the appli-
ance is installed.
▶Ensure that the kitchen is sufficiently ventilated, in particular
when operating the gas cooking appliance.
▶If the appliance is used intensively and for prolonged periods,
ensure that there is additional ventilation so that the combustion
products are safely fed to the outside, e.g. if using existing vent-
ilation equipment, set a higher performance level and, at the
same time, ensure that the air is replaced with fresh air in the
room where the appliance is installed.
▶Consult specialist personnel when installing additional ventila-
tion equipment.
WARNING‒Risk of fire!
Leaving fat or oil cooking on an unattended cooktop can be dan-
gerous and may lead to fires.
▶Never leave hot oil or fat unattended.
▶Never attempt to extinguish a fire using water; instead, switch
off the appliance and then cover with a lid or a fire blanket.

Safety en
5
The appliance becomes very hot.
▶Never place flammable objects on the cooktop or in its immedi-
ate vicinity.
▶Never store any objects on the cooktop.
The appliance becomes very hot, fabrics and other objects may
ignite.
▶Keep fabrics (e.g. garments or curtains) away from the flames.
▶Never reach over the flames.
▶Do not place combustible objects (e.g. tea towels or newspa-
pers) on, next to or behind the appliance.
Escaping gas may ignite.
▶If the burner does not ignite after 5seconds, turn the control
knob to the "Off" position and open the door or window in the
room. Do not attempt to re-ignite the burner for at least one
minute.
▶In the event of the burner flames being accidentally extin-
guished, turn off the burner control knob. Do not attempt to re-
ignite the burner for at least one minute.
Food may catch fire.
▶The cooking process must be continuously monitored.
WARNING‒Risk of burns!
Empty cookware becomes extremely hot when set on gas burners
that are operating.
▶Never heat up empty cookware.
The appliance becomes hot during operation.
▶Allow the appliance to cool down before cleaning.
WARNING‒Risk of injury!
Faults or damage to the appliance and repairs that have not been
carried out correctly are dangerous.
▶Never switch on the appliance if there is a fault with it.
▶Always have repairs carried out to the appliance and damaged
gas lines replaced by trained, specialist personnel.

en Safety
6
An appliance with a cracked or broken glass surface can cause
cuts.
▶Do not use the appliance if it has a cracked or broken glass
surface.
▶Do not hammer the glass.
▶Do not keep vessels on the glass surface.
Strong temperature fluctuations may cause the glass to break.
▶When using the cooktop, avoid draughts and spilling cold and
hot liquids.
▶Do not pour water on the glass when it is hot.
Cookware that is not the right size, or that is damaged or incor-
rectly positioned may cause serious injuries.
▶Baati, Taandor, inverted vessel or similar utensils shall be used
only with baati stand provided with the cooktop.
▶See the notes on cookware.
WARNING‒Risk of suffocation!
Children may put packaging material over their heads or wrap
themselves up in it and suffocate.
▶Keep packaging material away from children.
▶Do not let children play with packaging material.
Children may breathe in or swallow small parts, causing them to
suffocate.
▶Keep small parts away from children.
▶Do not let children play with small parts.

Environmental protection and saving energy en
7
Environmental protection and saving energy
2 Environmental protec-
tion and saving energy
Environmental protection and saving energy
2.1 Disposing of packaging
The packaging materials are environ-
mentally compatible and can be re-
cycled.
▶Sort the individual components by
type and dispose of them separ-
ately.
First steps
3 First steps
First steps
All steps from unpacking your appli-
ance to using it for the first time are
listed here.
3.1 Read the safety instruc-
tions
▶→"Safety", Page3
3.2 Unpacking the appliance
1. Carefully lift the cooktop out of the
packaging.
2. Take all other parts and the ac-
companying documents out of the
packaging. Save all parts for using
afterwards.
3. Remove any packaging material
left on the cooktop.
4. Remove any protective film or
stickers.
5. Check the cooktop and parts for
any damage in transit.
If you have any complaints, con-
tact the dealer who sold you the
appliance or our Customer Ser-
vice.
→"Customer Service", Page18
Installation and connection
4 Installation and con-
nection
Installation and connection
4.1 Installing and connecting
the appliance
The gas connection must be estab-
lished via a gas hose or a fixed con-
nection.
WARNING
Risk of explosion!
Escaping gas may cause an explo-
sion
▶If the alignment of the gas inlet
nozzle has to be changed to allow
connection to a gas cylinder, con-
tact customer service.
→"Customer Service", Page18
▶Ensure that electrical appliances or
fuel-burning appliances are in-
stalled at a safe distance from the
LPG installation: as the cooker, the
hose, the regulator and the gas
cylinder.
Note
Observe this information when you
are using a gas hose:
¡The hose clamp is not included.
Hose clamps are available at any
hardware shops.
¡The gas hose must be short and
completely leak-tight.
¡Do not extend the gas hose from
one room to another. Do not route
the gas hose through doors, win-
dows, walls, separating walls, con-
crete plates, ceilings or floors.
¡An approved connection to the
gas connection must be secured.
Use a gas hose approved by the
local authorities for the gas con-
nection. We recommend using an
ISI-labelled gas hose.

en Installation and connection
8
¡We recommend exchanging the
gas hose at least once a year.
ATTENTION!
Incorrect installation may damage the
appliance.
▶Do not use force to install the ap-
pliance. If you have difficulty as-
sembling the appliance, contact
the customer service.
→"Customer Service", Page18
Incorrect installation may damage the
gas hose.
▶The gas hose must not touch any
parts of the appliance.
▶Do not place the gas hose under-
neath the appliance.
1. Place the gas cylinder on a level
surface. Do not tip the gas cylinder
or placed it horizontally when in
use.
2. Fit the flexible safety gas hose and
use a screw connection or a cable
clamp to tighten it securely.
3. Secure the gas hose securely to
the appliance to prevent a gas
leak.

Familiarising yourself with your appliance en
9
Familiarising yourself with your appliance
5 Familiarising yourself with your appliance
Familiarising yourself with your appliance
5.1 Appliance
You can find an overview of the parts of your appliance here.
The images shown in these instructions are for guidance only.
1
2 3
1 24 4
5 566 2
PNW1E6..1I PNP0E6..1I
3
PNP0E6..0IPNW1E6..0I
11 2 44
2 35 566
1
1
Symbol Burner Burner rates
in g/h
Burner rates
in l/h
Burner rates
in kcal/h
1
Large 226g/h 92l/h 2466kcal/h
2
Medium 192g/h 78l/h 2090kcal/h
3
small 153g/h 62l/h 1662kcal/h
4
Control knob -
5
Gas connection -
6
Rating plate -
Only for use with LPG at 2.942kN/
m²(30gf/cm²).

en Accessories
10
5.2 Control knob
You can use the control knobs to set
the burner output. Each control knob
is labelled with the burner that is con-
trolled by it.
Note:Do not tamper with or force the
control knob.
Symbol Explanation
Zero setting
Minimum power
Maximum power
Burner assigned to the
control knob.
5.3 Burners
You can find an overview of the parts
of the burner here.
1
2
1
Burner cover
2
Burner base
Ensure that burner covers and pan
supports are positioned correctly to
ensure that the appliance can work
correctly.
Accessories
6 Accessories
Accessories
You can buy accessories from cus-
tomer service, from specialist retail-
ers or online. Only use original ac-
cessories, as these have been spe-
cifically designed for your appliance.
These operating instructions refer to
various models. The accessories for
your appliance depend on the model.
Note:The product warranty is voided,
if damage is caused due to the us-
age of accessories not manufactured
or recommended by Bosch.
6.1 Upper rack for small
items of cookware
Properties Use
Only to be used
on the small and
medium burner
and with cook-
ware with a dia-
meter smaller
than 100mm.
We do not re-
commend cook-
ing meals directly
on the access-
ory.

Before using for the first time en
11
6.2 Baati stand
Properties Use
Only to be used
for cooking with
Baati cooker,
Tandoor, inverted
vessel or similar
utensils. Ensure
that these spe-
cial cookware
have a diameter
between
180mm to 290
mm.
6.3 Burner cleaner
Attributes Use
For cleaning
burner blocked
holes for all of
the burners
Before using for the first time
7 Before using for the
first time
Before using for the first time
Configure the settings for initial start-
up. Clean the appliance and ac-
cessories.
7.1 Initial use
1. Remove the appliance from the
packaging.
2. Ensure that all of the plastic mater-
ial has been removed.
3. Place the appliance on a level sur-
face or worktop.
4. Connect the LPG pipeline to the
cooktop inlet.
5. Use the clamp to secure the gas
line connection to the appliance.
6. Ensure that no gas is escaping be-
fore you ignite the burner.
‒Brush the connection points of
the gas line with a brush and
soapy water.
‒Open the gas valve and care-
fully observe whether bubbles
occur at the connection points.
‒Close the gas valve immediately
if bubbles form.
‒Adjust any leaking connection
points.
‒Repeat the process until no
bubbles appear at the connec-
tion points.
7.2 Placing burner parts and
pan supports in their cor-
rect positions
You can find out how to correctly po-
sition the burner parts here.
1. Ensure that the burner parts are
clean and dry.
2. Position the burner lid precisely
and evenly.
The size of the burner lid must
match that of the burner.

en Cookware
12
Cookware
8 Cookware
Cookware
This information has been provided to help you save energy and avoid dam-
aging your cookware.
8.1 Suitable cookware
Only use cookware with a suitable diameter. The cookware must not protrude
over the edge of the cooktop.
Burners Use Minimum dia-
meter of the base
of the cookware
Maximum dia-
meter of the base
of the cookware
Small burner ¡Simmering
¡Warming up
¡Keeping warm
100mm 160mm
Medium burner ¡Simmering
¡Cooking
¡Frying
¡Warming up
¡Sautéing
100mm 240mm
Large burner ¡Rapid cooking
¡Deep-frying
¡Cooking
¡Frying
¡Searing
¡Steaming
100mm 260mm
8.2 Using cookware
The selection and positioning of the
cookware affects the safety and en-
ergy efficiency of your appliance.
WARNING
Risk of fire!
Flammable objects may ignite.
▶Maintain a distance of at least
50mm between the cookware and
flammable objects.
WARNING
Risk of injury!
Cookware that is not the right size, or
that is damaged or incorrectly posi-
tioned may cause serious injuries.
▶See the notes on cookware.
¡Ensure that the size of the cookware is suitable for the
burner size.
¡Never use small items of cookware on large burners.
¡Ensure that the flame does not touch the sides of the
cookware.

Basic operation en
13
¡Do not use deformed cookware.
¡Position the cookware in the middle of the burner, other-
wise it may tip over.
¡If small items of cookware are used, reduce the flame to a
lower level for optimal use.
¡Place the cookware on the pan supports.
¡Never place the cookware directly on the burner.
¡Never place the hot cookware directly on the glass sur-
face.
¡Before using the appliance, ensure that the pan supports
and the gas burner covers are positioned correctly.
¡Handle the cookware that is on the cooktop carefully.
¡Do not place heavy weights on the cooktop.
Always use the baati stand when cooking with a baati
cooker, tandoor, inverted vessel or similar cookware that
completely covers the burner. Always use the Baati stand
when using similar baking applications that generate high
heat that can damage the glass.
8.3 Cooking with a direct
flame
Always use a pan support if you are
cooking food directly above the
burner.
Basic operation
9 Basic operation
Basic operation
9.1 Switching on the appli-
ance
Requirements
¡The burner and pan supports are
installed correctly.
¡The burner is clean and dry.
¡Always keep the appliance clean.
1. Place suitable cookware on the
pan support.
→"Cookware", Page12
2. Push in the control knob for the se-
lected burner as far as it goes and
turn it anti-clockwise to the power
level that you require.
3. Light the burner with a gas lighter.
9.2 Switching off the appli-
ance
▶Turn the control knob for the re-
quired burner to the zero position.

en Easy Clean & Lift
14
Easy Clean & Lift
10 Easy Clean & Lift
Easy Clean & Lift
The Easy Clean & Lift helps you
when cleaning below the cooktop.
10.1 Cleaning below the
cooktop
ATTENTION!
The incorrect use of the cleaning
support legs may damage the appli-
ance.
▶Do not store any cookware or
cleaning materials below the cook-
top.
▶Never use the work surface below
this for any tasks other than clean-
ing.
▶Do not leave the appliance in a
tilted position for longer than 10
minutes.
▶Never lean against or load the ap-
pliance while it is in a tilted posi-
tion.
Requirements
¡The appliance has cooled down.
¡No cookware is located on the
cooktop.
1. Remove the pan supports and
burners.
2. Grip the cooktop from the front
and lift it.
3. Grip the cleaning support legs in
the centre and pull them out.
4. Set the cleaning support legs
down on the work surface.
5. Ensure that the appliance is se-
cure.
6. Clean below the cooktop.
Do not leave the appliance in a
tilted position for longer than 10
minutes.
7. To fold the legs back in, slightly lift
the cooktop and then fold the
cleaning support legs in.

Cleaning and servicing en
15
Cleaning and servicing
11 Cleaning and servi-
cing
Cleaning and servicing
To keep your appliance working effi-
ciently for a long time, it is important
to clean and maintain it carefully.
11.1 Cleaning the appliance
1. Clean the appliance after every
use.
2. Allow the appliance to cool down
before cleaning.
3. Never touch the appliance while it
is hot.
4. Always remove spilled liquids im-
mediately after the appliance has
cooled down. Burnt-on residues
and milk are difficult to remove.
5. Do not use metal cleaner or sharp
objects to remove stubborn stains.
6. Do not use harsh or abrasive
cleaning products or chemicals.
7. Do not use flammable cleaning
agents.
8. Remove the pan supports and
burners before cleaning.
9. The removable parts are not dish-
washer-safe.
10.Never remove the support feet for
cleaning.
11.Allow the cleaning liquid to work
for a few minutes.
12.Clean the appliance with a sponge
or soft cloth.
13.Do not pour too much water on the
glass.
14.Dry with a soft cloth.
15.Install the pan supports and burn-
ers after cleaning.
16.Ensure that all parts are positioned
correctly before next using the ap-
pliance.
11.2 Recommended cleaning
methods
This is where you can find out how to
clean certain components.
Compon-
ent
Recommended cleaning
method
Control
knob
The control knobs can
be removed for cleaning.
Refit the control knobs
before next using the ap-
pliance.
Clean the control knobs
with soapy water and a
soft, damp cloth. Do not
pour water over the but-
tons.
Burner The burners can be re-
moved for cleaning.
Clean the burners with
tap water, washing-up li-
quid and a brush. Do not
use sharp objects to
clean them, otherwise
the surface may be dam-
aged.
If the holes in the flame
distributors are blocked,
clean these using the
burner cleaner tool. To
do this, remove the
burner from the appli-
ance. Guide the tool
through the openings
until the visible dirt is re-
moved.
After long use, the brass
burner parts become
darker due to natural ox-
idation. This discoloura-
tion does not affect their
usability.

en Troubleshooting
16
Troubleshooting
12 Troubleshooting
Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshoot-
ing information before contacting after-sales service. This will avoid unneces-
sary costs.
WARNING
Risk of injury!
Improper repairs are dangerous.
▶Repairs to the appliance should only be carried out by trained specialist
staff.
▶If the appliance is defective, call Customer Service.
→"Customer Service", Page18
Fault Cause and troubleshooting
There is a smell of
gas in the kitchen.
The gas cylinder connection is leaking.
1. Ventilate the room.
2. Check the gas cylinder connection.
The gas pipe to the appliance is leaking.
1. Ventilate the room.
2. Call the gas supplier.
The burner does not
ignite.
The burner parts are positioned incorrectly.
▶Position the burner parts precisely and evenly.
Burner parts are wet.
▶Carefully dry the burner parts.
Openings on the burner are soiled.
▶Clean and dry the openings on the burner.
The safety valve for the gas line is closed.
▶Open the safety valve for the gas line.
The gas cylinder is empty.
▶Replace the gas cylinder.
Burner goes out
straight after being ig-
nited.
Openings on the burner are soiled.
▶Clean and dry the openings on the burner.
The gas cylinder is almost empty.
▶Replace the gas cylinder.
A draught extinguishes the flames.
▶Stop the draught.
The burner flame is
not uniform.
The burner parts are positioned incorrectly.
▶Position the burner parts precisely and evenly.
Openings on the burner are soiled.
▶Clean and dry the openings on the burner.

Troubleshooting en
17
Fault Cause and troubleshooting
The burner flame
goes out while the ap-
pliance is in operation.
The gas cylinder is empty.
▶Replace the gas cylinder.
Burner parts become
darker.
Natural oxidation of brass
▶This is normal. This discolouration does not affect
their usability.
Heat shield becomes
discoloured.
Natural behaviour of the material.
▶This is normal. This discolouration does not affect
their usability.
The edges of the pan
supports become dis-
coloured.
Natural behaviour of the material due to direct flame
contact.
▶This is normal. This discolouration does not affect
their usability.
Paint of the pan sup-
port may burn-off dur-
ing first usage.
Natural behaviour of the material due to direct flame
contact.
The base material could be exposed. Not using the
cooktop for prolonged time may cause corrosion of
the exposed area.
▶Important: Clean the pan support before cooking
with direct flame.

en Customer Service
18
Customer Service
13 Customer Service
Customer Service
Detailed information on the warranty
period and terms of warranty in your
country is available from our after-
sales service, your retailer or on our
website.
If you contact Customer Service, you
will require the product number (E-
Nr.) and the production number (FD)
of your appliance.
The contact details for Customer Ser-
vice can be found in the enclosed
Customer Service directory or on our
website.
Helpline no.: 1800-266-1880
(Monday to Saturday – 8am to
8pm)
Email ID: service.in@bosch-
home.com
Chat with us (WhatsApp):
[phone]
13.1 Product number (E-Nr.)
and production number
(FD)
You can find the product number (E-
Nr.) and the production number (FD)
on the appliance's rating plate.
The rating plate is located on the rear
of the appliance.
Make a note of your appliance's de-
tails and the Customer Service tele-
phone number to find them again
quickly.

Thank you for buying a
Bosch Home Appliance!
Register your new device on MyBosch now and profit directly from:
• Expert tips & tricks for your appliance
• Warranty extension options
• Discounts for accessories & spare-parts
• Digital manual and all appliance data at hand
• Easy access to Bosch Home Appliances Service
Free and easy registration – also on mobile phones:
www.bosch-home.com/welcome
Looking for help?
You'll find it here.
Expert advice for your Bosch home appliances, help with problems
or a repair from Bosch experts.
Find out everything about the many ways Bosch can support you:
www.bosch-home.com/service
Contact data of all countries are listed in the attached service direct-
ory.
*8001204857*
8001204857 (030907)
en
BSH Household Appliances Manufac-
turing Pvt. Ltd.
Arena house, 2nd floor, Main building,
Plot no 103, Road no 12, MIDC,
Andheri,
Mumbai - 400 093
www.bosch-home.com
