Bosch WTW863S0GB User manual

1 2 3 4 5 6
Congratulations - you have chose n to buy a modern, high-qual ity
Bosch domestic appliance.
The condensation dryer with heat pump and automatic cleaning
of the heat exchanger is o utstanding in terms of e fficient energy
consumption and low maintenance re quirements apage 6.
Every dryer which leaves our factory is carefully checked to ensure that
it functions correctly and is in perfect condition.
Should you have any questions, our after-sales service will be pleased
to help.
Environmentally-responsible disposal
Dispose of packaging in an environmentally-responsible manner.
This appliance is designated according to European directive 2002/96/EC which governs waste e lectrical and electronic
equipment - WEEE).
The directive provides an EU-wide frame work for the return and recycling
of used appliances.
For further information about our products , accessories, spare parts
and services, please visit: www .bosch-home.com
Read these instructions bef ore operating the dryer.
Observe the safety instructions on pag e 13.
... and adapt to individual requ irements
Never start the dryer if it is damaged.
Inform your after-sales service. Inspecting the
dryer
Sorting and loading laundry
Remove all items from pockets.
Check for cigarette lighters.
The drum must be empty prior to loading.
See programme overview on pa ge 7.
Your new dryer Intended use Preparation Installation apage 8
Selecting and adjusting the programme
Select the drying progra mme ...
Press the ĔStar t/Stop
button
Make sure your hands are dry.
Hold the plug only. Connecting the
mains plug
All buttons are sensitive an d only
need to be touched lightly.
ʋFor domestic use only.
ʋOnly to be used for drying fabrics that have been
washed with water.
.
Do not leave children unsupervised near the dryer.
Keep pets away from the d ryer.
3
2
1
Drying
Drying
Condensation container with filte r
Control panel
Air inlet
Two-part
fluff filter
Drum
End of programme as soon as the AntiCrease/End indicator lamp lights up.
Interrupt programme Adding or removing l aundry.
The drying operation can be inte rrupted briefly to add or remove laundry. However, it must then be
continued until it has finished.
1. Open the door. The drying process is interrupted.
2. Add or remove laundry then close the doo r.
3. If required, select a new p rogramme and additional functions.
4. Press the ĔStart/Stop button. The rem aining time is updated after a few minutes.
Only use the dryer with the fluff filter
inserted.
Emptying condensation
Empty the container after each drying cycle, not during dry ing.
1. Remove the condensation container and hold it level.
2. Pour out the condensation.
3. Always push container in fully until it clicks into place.
If the Container indicator lamp flashes despite the contain erh aving been
emptied aFilter in condensation container, page 9.
Cleaning the fluff filter
The fluff filter consists of t wo parts.
Clean the inner fluff fi lter after every drying cycle.
1. Open the door. Remove fluff from the door/door area.
2. Pull out the inner fluff filter and open it out.
3. Remove the fluff (by wiping the filter with you r hand).
If the fluff filter is hea vily soiled or blocked, rinse it under
running water and dry thoroughly.
Clean the outer fluff filter after every 5 drying cycles:
4. Remove the outer fluff filter.
5. Open it and remove any fluff.
Rinse under running water and dry thor oughly.
6. Close and re-insert the fluff filter.
Switching off the dryer
Turn the programme selector to Off.
Do not leave laundry in the dryer.
Removing the laundry
Your dryer is equipped with an automatic reduced ironing function. The drum is moved a t specific time
intervals for 60 minutes once the programm e has ended. The laundry stays loose a nd fluffy
(or 120 minutes if the a dditional SReduced ironing function is selected).
Do not pull out/empty the
condensation container when drying is i n progress.
Drum interior light
(depending on
model)
Information on laundry ...
Labelling of fabric s
Follow the manufacturer's care information.
(Dry at normal temperature.
'cDry at low temperature ain additi on, select &Low heat.
)cDo not machine dry.
Always observe the safety instructions on p age 13.
Do not tumble-dry the following fab rics, for example:
– Non-breathable fabrics (e .g. rubber-coated).
– Delicate materi als (silk, curtains mad e from synthetic material) ath ese may crease.
– Oil-stained laundry.
Drying tips
– To ensure an even result, sort th e laundry by fabric type and drying pro gramme.
– Always dry very small fabrics (e.g. baby socks) together with
large items of laundry (e.g. towels).
– Close zips, hooks and eyelets, and bu tton up covers.
Tie fabric belts, apron strings, etc. together
– Do not over-dry easy-ca re laundry aRisk of creasing.
Allow laundry to finish drying in the a ir.
– Do not dry woollens in the dryer. Th ey may, however, be refreshed apage 7,
Woollens Finish programm e.
– Do not iron laundry immediately after drying; fold items up and leave for a while are sidual
moisture will then be distributed even ly.
–The drying result depends on the type of water used during washing. aFine adju stment of
the drying result apage 6.
– Knitte dfab rics (e.g. T-shirts, jerseys) often shrink slightly the first time they are tumble -dried.
aDo not use the Cupboard Dry Plus programm e.
– The drying of starched laundry should be limited. aStarch leaves behind a coating that
impairs drying.
– When washing laundry that is to be tumble-dried afterwards, use th e correct amount of
fabric softener as specified in the manufacturer's instructions.
– For pre-dried, multi-layered fabri cs or small, individual items of laundry, use the Tim ed
programme. Also suitable for subsequent drying.
Environmental protecti on / Energy-saving tip s
– Before drying, spin the laundr y thoroughly in the washing machine athe higher the spin
speed, the shorter the dryin g time will be, thus less e nergy is consumed.
Also spin easy-care laundry.
– Use the maximum recommended capacity, but do not exceed it
aProgramme overview apage 7.
– Make sure the room is well ventilated during drying.
– Do not cover or seal the air inlet.
Fine adjustment of the drying result
Adjustment of the l evels of drynes s
1 x to
the right
Press and hold &Low heat
and turn 5 x to the right
Press &Low heat until
the required level is reache d
Turn to Off Turn to Off
Important Information ...
Your dryer is designed to be par ticularly energy efficient. Its technical fea tures include
a refrigeration circuit, which u ses energy efficiently in a similar wa y to a refrigerator.
The dryer's heat exchange r is cleaned automatic ally during drying.
The fluff filters and filter in the condensati on container must be cleaned regularl y.
Never operate the dryer without the fluff filters an d/or condensation container with filter.
ʑFluff filters
During drying, fluff and hair from the laundry is trapped by the fluff filter. Blocked fluff filters
may impair the heat exchange proces s.
The fluff filters must therefore be cleaned after every drying c ycle. Rinse regularly under
running water apage 4.
ʑFilter in the condensatio n container
The filter in the condensation container cleans the condensation. This condensation is
required for the automatic cleaning pr ocess. The filter should be cleaned regul arly under
running water. Empty the condens ation container before cleaning the filter apage 4/9.
ʑFabrics
Do not dry any fabrics that have come into c ontact with solvents, oil, wax, grease or pa int:
e.g. hair styling products, nail varnish rem over, stain remover, cleaning solvent. etc.
Empty all pockets.
Do not dry non-brea thable fabrics.
Avoid drying items that produce a lot of fluff.
Woollens should be refreshed only, using the woollens programme.
L:00, L:01, L:02, L:03 are shown in sequence
Short signal w hen changing from L:03 to L:00, otherw ise long
signal.
Select On/Off for buzzer at the end of the programme. ˎ&Buzzer
Reduced temperature for d elicate fabrics 'that require a longer
drying time; e.g. polyacrylics, polyamide, e lastane, acetate silk.
ˎ&Low heat
Reduces creasing and prolongs the 'reduced ironing' phase after
the programme has finished.
ˎSReduced
ironingch:min End of programme afte r 1-24 hours (button may need to be pressed se veral times) can always be set
to the nearest full hour.
Cln Automatic cleaning of the heat exchanger.
Fine adjustment
of the drying
result
The drying result (e.g. Cupboard Dr y) can be adjusted over three levels (1 - max. 3) for the
Cottons,#Easy-Care,/Mixed Load and ASuperQui ck 40’ programmes apresetting = 0. After
one of these programmes has been fi nely adjusted, the setting is retained for th e others.
Further information apage 6.
0, 1, 2, 3
Container Empty the condensation c ontainer.
Clean the filter in the condensation c ontainer if necessary apage 9.
Filter Rinse the fluff filter s under running water apage 4.
Additional functions Display
status/
service
Programme selector
Display/
Remaining
time
Contents Page
ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2
ʋSetting the programmes . . . . . . . . . . . . . 2
ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4
ʋNotes on laundry . . . . . . . . . . . . . . . . . . 5
ʋFine adjustment of the drying result . . . . 6
ʋImportant Information . . . . . . . . . . . . . . . 6
ʋOverview of programmes . . . . . . . . . . . . 7
ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . 8
ʋFrost protection / Transport . . . . . . . . . . .8
ʋCare and cleaning . . . . . . . . . . . . . . . . . . 9
ʋTechnical data . . . . . . . . . . . . . . . . . . .10
ʋOptional accessories . . . . . . . . . . . . . . .10
ʋNormal noises . . . . . . . . . . . . . . . . . . . . 11
ʋWhat to do if ... / After-sales service . . . 12
ʋSafety instructions . . . . . . . . . . . . . . . . 13
7
Programme overview see also page 5
Sort the laundry a ccording to type of textile and fabric. Fabrics must be suitable for tumble dryin g. After drying ...
c
iron laundry

lightly iron laundry
@c
do not iron laundry
c
mangle laundry
PROGRAMMES TEXTILE TYPE AND IN FORMATION **Cottons max. 7 kg Hard-wearing fabrics, b oil-resistant fabrics made of cot ton or linen. **#Easy-Care max. 3 .5 kg Non-iron laundry made o f synthetic fibres and ble nded fabric, easy-care cotton. **/Mixed Load max. 3 kg Mixed items of laundry madeof cotton and synthetics (Mix).
Iron Dry c÷@c Fabrics suitable for ironing (iron fabrics in or dert oav oidc reasing). Cupboard Dry @Single-layer fabrics. *Cupboard Dry Plus / Very Dry @Fabrics made of thick, m ultilayered items of clothin g.
Woollens finish max. 3 kg Woollen fabrics suitabl e for washing machines . Fabrics become fluffier but notdry.
Remove fabrics once the program me has ended and allow to dry.
ASuper Quick 40’ max. 2 kg
Laundry made of synthetic fibres, cot ton or blended fabrics (for example) that needs to be dried qu ickly. The values may differ from the those specifi edd epending on the type of fabr ic, mixture of laundry to be drie d, residual moisture in the fabric and loading capacity.
ZSportswear max. 1.5 kg Fabrics with membrane coating, water-repellent fabrics, functional clothing , fleece fabrics (dry jackets/trou sers with
removable internal lining separately ).
Timed Programmes warm 30’ max. 3 kg Pre-dried,mul ti-layered, sensitive fabrics made of acrylic fibres, or sepa rate small items of laundry.
Also for subsequent d rying.
*For Cottons and #Easy-Care programmes only
**Dryness levels can be se lected individually aCupboard Dry Plus / Very Dry, Cupboard Dry and Iron Dry (depending on the mode l).
Degree of dryness can be finely adjusted; multi-layered textiles re quire a longer drying time than single-layered items of clothing. Recommendation: Dry separately.
9201 / 9000741549 *741549* Robert Bosch Hausgeräte GmbH
Carl-Wery-Str. 34
81739 München/Germany
WTW863S0GB

8
Installation
– Scope of delivery: dryer, installa tion and operating instructions.
– Check dryer for transport d amage.
– The dryer is very heavy. Do not attempt to lift it on your own.
– Be careful to avoid shar p edges.
– Do not set up in a room that is susceptible to frost. Freezing water m ay cause damage.
– If in doubt, have t he appliance connected by a specialist.
– Do not lift the dryer by protruding parts (e.g. the door) - risk of breakage.
Setting up the d ryer
– The appliance plug must always be accessible.
– Ensure that the appliance is installed on a clean , level
and firm surface.
– Do not obstruct the air inlet on the front of the
dryer.
– Keep the area around t he dryer clean.
– Make the dryer level using the threaded feet
and a spirit level.
– Do not remove the threaded feet under any
circumstances.
Mains conn ection see Safety instructions apage 13.
– Connect to an AC earthed socket. If in doubt have the so cket checked by a specialist.
– The mains voltage and the volta ge shown on the rating plate (apage 10) must be the
same.
– The connected load a nd necessary fuse protection are specified on the rating plate .
Frost protection
Preparation
1. Empty the co ndensation container apage 4.
2. Select any program me using the programme selector.
3. Press the ĔStart /Stop button acondensed water is pumped into the container
4. Wait 5 minutes and then empty the cond ensation container again.
5. Turn the programme selector to Off.
Transport
– Prepare the dryer asee F rost protection.
– Transport the dryer in a vertical upright position.
– Following transportation, do n ot use the dryer for two hours.
The dryer contains residual wa ter;
this can flow ou t if the dryer is ti lted.
1.
Take all accessory parts out
of the drum.
The drum must be empty.
Make sure that the air inlet
remains unobstructed
Clean and level
Do not set up the dryer behind a door or sliding
door, as this may obstruct the dryer door or prevent
it from opening. This will pr event a potentially fatal
danger to children from locking them selves in.
2.
Do not operate the dryer if
there is a danger of fros t.
9
Care and cleaning
Heat exchanger
The dryer's heat exchanger is cleaned automatically during drying. Cln appears in the display
panel. Do not pull out the conde nsation container during the cleaning proce ss.
Dryer housing, co ntrol panel, air in take
Wipe with a soft, damp cloth.
Do not use harsh cleaning age nts or solvents.
Remove detergent and cleaning agent resid ue immediately.
Some water may collect between the window and the seal during drying. This d oes not affect
the proper operation of your dryer in a ny way.
Filter in the condensati on container
The filter is cleaned automatically when the condensation container is em ptied.
However, the filter should still be cleaned regularly under running water aThis prevents
stubborn deposits/dirt from building up.
1. Pull out the condensation container.
2. Pull the filter out of its snap- in lock.
3. Clean the filter under runni ng water or in the dishwasher.
4. Refit the filter.
5. Insert the condensation contain er so that it locks into place.
Only operate the dryer with the filter inserted.
Moisture sensor
The dryer is equipped w ith stainless steel moisture sensor s.Mo isture sensors measure how
damp the laundry is. A thin layer of lime scale may build up on the moisture sensor s after
prolonged use.
1. Open the door.
2. Clean the moisture sensors us ing a damp sponge with a rough surface.
Do not use steel wool or abrasiv e materials.
Appliance must be switched off.
10
Technical data
ʠDimensions (DxWxH) 60 x 60 x 85 cm (height ad justable)
Weight approximately 51 kg
Max. capacity 7 kg
Condensation container 4.0 l
Connection voltage 220-240 V
Connected load max. 1000 W
Fuse protection 10 A
Ambient temperature 5 - 35 °C
Product number
Production number under the door
The rating plate can be found on the back of the dryer.
ʠConsumption ra tes These ar e guide values determined under standar d
conditions.
Spin speed
in rpm
(residual moisture)
Drying time
in min.**
Energy
consumption
in kWh**
Cottons 7 kg
Cupboard Dry* 1400 (approx. 50 %) 128 1.62
1000 (approx. 60 %) 149 1.90
800 (approx. 70 %) 169 2.19
Iron Dry* 1400 (approx. 50 %) 92 1.13
1000 (approx. 60 %) 113 1.42
800 (approx. 70 %) 133 1.70
#÷Easy-Care 3.5 kg
Cupboard Dry* 800 (approx. 40 %) 5 4 0.57
600 (approx. 50 %) 6 8 0.72
*Test programs according to D IN EN 61121
**The values may differ from those given, depending on overvoltage and undervoltage, the
type of fabric, composition of th e laundry to be dried, the r esidual moisture in the fabric and
the size of the load.
ʠDrum interior ligh t (depending on model) (bu lb E14, 25 W)
The drum lights up after the door is opened or closed, and after the programme starts, and
switches off automatically. Changing the bulb apage 1 2.
Optional accessories (from after -sales service using order number)
Washer-dryer stack connec tion set
The dryer can be placed on top of a suitable washing machine with the same wid tha nd depth
to save space. The dryer must be fasten ed to the washing machine using this connection set.
Same as WTZ 11310, but with pull-out worktop.
Installation undernea th the worktop
Instead of the appliance covering plate, you must have a metal cover fitted by a special ist.
WTZ
11310
WTZ
11300
WTZ
10290
11
Normal noises
During drying, the compressor and the pump generate some noise which is entirely normal.
The compressor in the dryer may
occasionally generate a humming noise.
The compressor in the dryer is ventilated
from time to time, which cr eates a whirring
sound.
The automatic cleaning process causes
a clicking noise.
The process of pumping the condensati on
into the condensation co ntainer generates
pumping noises.
12
What to do if...
If you cannot rectify a fault yourself (e.g. switching off/on), ple ase contact our after-sales
service. We will always find an appropr iate solution and will avoid unnecessary visits by
engineers. Trust the e xpertise of the manufact urer and rest assured tha t the repair will be
carried out by trained service te chnicians using original spare parts. The contact details of your
local after-sales service can be found in the enclosed aft er-sales service directory, or by calling
one of these numbe rs:
–GB 0844 8928979 (Calls from a BT landline will be charged at up to 3 pence per minute.
A call set-up fee of up to 6 pence may a pply.)
–IE 01450 2655
When contacting the aft er-sales service, please quote the appliance's product num ber (E no.)
and production nu mber (FD) (see und er the loading door ).
Turn the programm e selector to Off and unplug t he mains plug from the socket.
ʠThe ĔStart/ Stop indicator lamp
does not light up .
Mains plug plug ged in?
Programme se lected?
ʠThe Contain er indicator l amp
and the ĔSta rt/Stop butt on are
flashing.
Empty the condensatio n container apa ge 4.
Clean the cond ensation conta iner filter if necess ary
apage 9.
Dryer transp orted? aWait 2 hours and sta rt again.
ʠThe Filter indi cator lamp and
ĔStart/Stop but ton are flashing.
Rinse the fluff filte r under running wat er apage 4.
ʠCln appears in the display pane l. Not an error. Aut omatic clea ning of the hea t exchang er.
Do not empty the c ondensation co ntainer.
ʠDryer does not st art. ĔStart /Stop button se lected?
Door closed? P rogramme set?
Ambient temp erature grea ter than 5 °C?
ʠWater is leaking out . Make sur e the dryer is level.
ʠThe door opens by it self. Push the door clo sed until you hea r it click into place.
ʠCreasing. Laundry load ex ceeded?
Remove articl es of clothing immedia tely after the end of the
programme, ha ng up and pull in to shape.
Unsuitable prog ramme selecte d apage 7.
ʠDrying resu lt is not satis factory
(laundry feel s too damp) .
Warm laund ry feels damper tha n it actually is.
The selected pr ogramme does not su it the load. Use
another drying prog ramme or, in addition , select the time
programme ap age 7.
Use fine a djustment for the d rying result apage 1/2 and 6 .
Fine layer of limesca le on the humidity sens ors
aClean the humidi ty sensors apage 9.
Programme term ination, e.g. tank f ull, mains power supp ly
failure, door op en or maximum dry ing time reache d.
ʠDrying time too lon g. R inse the fluff filters un der running water apage 4.
Insufficient s upply of air aens ure that air can circ ulate.
Air inlet possibly b locked aClear inlet ap age 8.
Ambient tem perature hig her than 35 °C aventilate th e
room.
ʠThe humidi ty in the room
increases sign ificantly.
Make sure the room is su fficiently ventila ted.
ʠPower failure. Remove lau ndry from the dryer immedia tely and spread out.
This allows th e heat to d issipate.
ʠOther interm ittent noises
and vibrations.
Not an error.
Normal nois es apage 11.
ʠLoud humming n oise for several
seconds.
Has the cond ensation cont ainer been pro perly inserted ?
aPush the con densation co ntainer al l the way in.
Not an erro r. Normal nois es apage 11.
ʠThe interior light is not w orking
(depending on m odel).
Pull out the a ppliance plu g, remove th e cover cap in the
interior above the d oor (use Torx 20 screwd river) and
replace the bulb ap age 10. Close the co ver cap.
Never operate t he dryer without a c over cap.
13
Safety instructions
Emergency – Pull the applia nce plug out of the so cket immediately or d isconnect the fuse.
ONLYuse the
dryer...
– in rooms insid e the house.
– to dry fabric s.
The dryermust
NEVER...
– be used for purposes other t han those described a bove.
– be mo dified in terms of its technology or prop erties.
Hazards – The dryer must not be used by chi ldren or persons who h ave not been
instructed in its u se.
– Do not lea ve children unsupervise d near the dryer.
– Keep pets away from the dryer.
– Remove all objects from pock ets,
and lighters in particular aRisk of e xplosion.
– Do not le an or sit on the door aRisk of tipping.
Installation – Secure lo ose cables aRisk of tripping.
– Do not operate a dryer if there is a risk of fr ost.
Mains
connection
– Connect the dryer to an AC earth ed socket according to specifications,
otherwise it cannot be guaranteed that the app liance is completely sa fe.
– The cable cross-section must be s ufficient.
– Only use earth-leaka ge circuit breakers with the following symb ol:
– The applian ce plug and socket m ust be compatible.
– Do not u se multiple plugs/connec tors and/or extension ca bles.
– Do not touch or hold the applian ce plug with wet h ands
aRisk of electric shock.
– Never pull th e appliance plug out o f the socket by its cable .
– Do not da mage the mains lead aRisk o f electric shock.
Operation – Only load the drum with laundry .
Check the contents before you switch the dryer on.
– Do not use th e dryer if the laundry has been in contact with solvents, oil, wax,
grease or paint (e.g . hair styling products, nail varnish rem over, stain remover,
cleaning solvent, etc. ) aRisk of fire/explosion .
– Dust (e.g. coal dust, flour) poses a danger: D o not use the dryer
aRisk of explosion
– Do not p ut laundry containing f oamed material/rubber in the dryer aelastic
material may be destroyed and the dryer be damaged due to possible
deformation of the foam ed material.
– When cle aning the fluff filter, make sure that no foreign mate rial (down or filling
material) gets into the air duct ope ning. If necessary, cle an the drum
beforehand with a vacuum cle aner. If foreign material should still get into the
air duct acall the after-sales service aRis k of fire/explosion.
– Switch off th e dryer once the progra mme has ended.
– The water f rom condensation is not drinking water an d may be contaminated
with fluff.
Defect – Do not use th e dryer if it is defectiv e or if you suspect th at it is.
Repairs must only be carried out by th e after-sales service.
– Do n ot use the dryer if the mains cable is defective . To avoid danger, only have
the defective mains cable replaced by the after-sales service .
– Always pull the mains plug o ut of the socket before changing the bulb for the
interior light aRisk of el ectric shock.
Spareparts – Only use genuine spare parts and acc essories for safety reasons.
Disposal – Pull out th e appliance plug, then cut off the mains c able from the appliance.
Dispose of at a mun icipal waste disposal fa cility.
– Heat exch angers contain a f luorinated greenhou se gas covered by the Kyoto
protocol (R134a) adispos e of in a proper ma nner. Capacity: 0.22 kg.
– Packaging: Keep all pa ckaging out of reach of babies and children
aRisk of suffocation.
– All mat erials are environmen tally sound and can be reused. Dispo se of in an
environmentally-responsibl e manner.
Dryer
en Instruction manual

1 2
Congratulations - you have chosen to buy a modern, high-quality
Bosch domestic appliance.
The condensation dryer with heat pump and automatic cleaning
of the heat exchanger is outstanding in terms of efficient energy
consumption and low maintenance requirements apage 6.
Every dryer which leaves our factory is carefully checked to ensure that
it functions correctly and is in perfect condition.
Should you have any questions, our after-sales service will be pleased
to help.
Environmentally-responsible disposal
Dispose of packaging in an environmentally-responsible manner.
This appliance is designated according to European directive 2002/96/EC which governs waste electrical and electronic
equipment - WEEE).
The directive provides an EU-wide framework for the return and recycling
of used appliances.
For further information about our products, accessories, spare parts
and services, please visit: www.bosch-home.com
Read these instructions before operating the dryer.
Observe the safety instructions on page 13.
... and adapt to individ
Never start the dryer if it is damaged.
Inform your after-sales service. Insp
Sorting and loa
Remove all items from pockets.
Check for cigarette lighters.
The drum must be empty prior to loading.
See programme overview on page 7.
Your new dryer Intended use Preparation Installation apage 8
Selecting and adjusting the
Select the dry
Pres ĔMake sure your hands are dry.
Hold the plug only. Conn
m
All buttons are sens
need to be touched
ʋFor domestic use only.
ʋOnly to be used for drying fabrics that have been
washed with water.
.
Do not leave children unsupervised near the dryer.
Keep pets away from the dryer. ĔOnly use the dryer
inserted.
aS('ca&)caaaaaaaaaaa
&&
ʑaʑaʑ
Select On/Off for buzzer at the end of the programme. ˎ&Buzzer
Reduced temperature for delicate fabrics 'that require a longer
drying time; e.g. polyacrylics, polyamide, elastane, acetate silk.
ˎ&Low heat
Reduces creasing and prolongs the 'reduced ironing' phase after
the programme has finished.
ˎSReduced
ironingch:min End of programme after 1-24 hours (button may need to be pressed several times) can
to the nearest full hour.
Cln Automatic cleaning of the heat exchanger.
Fine adjustment
of the drying
result
The drying result (e.g. Cupboard Dry) can be adjusted over three levels (1 - max. 3) for t
Cottons,#Easy-Care,/Mixed Load and ASuper Quick 40’ programmes aprese
one of these programmes has been finely adjusted, the setting is retained for the others
Further information apage 6.
Container Empty the condensation container.
Clean the filter in the condensation container if necessary apage 9.
Filter Rinse the fluff filters under running water apage 4.
Additional functions Display
status/
service
Programme selector
Display/
Remaining
time
Contents Page
ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2
ʋSetting the programmes . . . . . . . . . . . . . 2
ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4
ʋNotes on laundry . . . . . . . . . . . . . . . . . . 5
ʋFine adjustment of the drying result . . . . 6
ʋImportant Information . . . . . . . . . . . . . . . 6
ʋOverview of programmes . . . . . . . . . . . . 7
ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . 8
ʋFrost protection / Transport. . . . . . . . . . . 8
ʋCare and cleaning . . . . . . . . . . . . . . . . . . 9
ʋTechnical data . . . . . . . . . . . . . . . . . . . 10
ʋOptional accessories . . . . . . . . . . . . . . . 10
ʋNormal noises . . . . . . . . . . . . . . . . . . . . 11
ʋWhat to do if ... / After-sales service . . . 12
ʋSafety instructions . . . . . . . . . . . . . . . . 13
c@c c
#/c÷@c @@AZ#a

3 4
aividual requirements
Inspecting the
dryer
loading laundry
a
the programme
drying programme ...
ress the ĔStart/Stop
button
onnecting the
mains plug
nsitive and only
ed lightly.
ʋʋ
3
2
1
Drying
Drying
Condensation container with filter
Control panel
Air inlet
Two-part
fluff filter
Drum
End of programme as soon as the AntiCrease/End indicator lamp lights up.
Interrupt programme Adding or removing laundry.
The drying operation can be interrupted briefly to add or remove laundry. However, it must then be
continued until it has finished.
1. Open the door. The drying process is interrupted.
2. Add or remove laundry then close the door.
3. If required, select a new programme and additional functions.
4. Press the ĔStart/Stop button. The remaining time is updated after a few minutes.
er with the fluff filter
Emptying condensation
Empty the container after each drying cycle, not during drying.
1. Remove the condensation container and hold it level.
2. Pour out the condensation.
3. Always push container in fully until it clicks into place.
If the Container indicator lamp flashes despite the container having been
emptied aFilter in condensation container, page 9.
Cleaning the fluff filter
The fluff filter consists of two parts.
Clean the inner fluff filter after every drying cycle.
1. Open the door. Remove fluff from the door/door area.
2. Pull out the inner fluff filter and open it out.
3. Remove the fluff (by wiping the filter with your hand).
If the fluff filter is heavily soiled or blocked, rinse it under
running water and dry thoroughly.
Clean the outer fluff filter after every 5 drying cycles:
4. Remove the outer fluff filter.
5. Open it and remove any fluff.
Rinse under running water and dry thoroughly.
6. Close and re-insert the fluff filter.
Switching off the dryer
Turn the programme selector to Off.
Do not leave laundry in the dryer.
Removing the laundry
Your dryer is equipped with an automatic reduced ironing function. The drum is moved at specific time
intervals for 60 minutes once the programme has ended. The laundry stays loose and fluffy
(or 120 minutes if the additional SReduced ironing function is selected).
Do not pull out/empty the
condensation container when drying is in progress.
Drum interior light
(depending on
model) ('ca&)caaaaaaaaaaa
&&
ʑaʑaʑ
ˎ&'ˎ&ˎScn always be set
r the
#/Aasetting = 0. After
rs.
a0, 1, 2, 3
aaʋʋʋʋʋʋʋʋʋʋʋʋʋʋʋ
c@c c
#/c÷@c @@AZ#a

56
aaĔʋʋĔaSInformation on laundry ...
Labelling of fabrics
Follow the manufacturer's care information.
(Dry at normal temperature.
'cDry at low temperature ain addition, select &Low heat.
)cDo not machine dry.
Always observe the safety instructions on page 13.
Do not tumble-dry the following fabrics, for example:
– Non-breathable fabrics (e.g. rubber-coated).
– Delicate materials (silk, curtains made from synthetic material) athese may crease.
– Oil-stained laundry.
Drying tips
– To ensure an even result, sort the laundry by fabric type and drying programme.
– Always dry very small fabrics (e.g. baby socks) together with
large items of laundry (e.g. towels).
– Close zips, hooks and eyelets, and button up covers.
Tie fabric belts, apron strings, etc. together
– Do not over-dry easy-care laundry aRisk of creasing.
Allow laundry to finish drying in the air.
– Do not dry woollens in the dryer. They may, however, be refreshed apage 7,
Woollens Finish programme.
– Do not iron laundry immediately after drying; fold items up and leave for a while aresidual
moisture will then be distributed evenly.
–The drying result depends on the type of water used during washing. aFine adjustment of
the drying result apage 6.
– Knitted fabrics (e.g. T-shirts, jerseys) often shrink slightly the first time they are tumble-dried.
aDo not use the Cupboard Dry Plus programme.
– The drying of starched laundry should be limited. aStarch leaves behind a coating that
impairs drying.
– When washing laundry that is to be tumble-dried afterwards, use the correct amount of
fabric softener as specified in the manufacturer's instructions.
– For pre-dried, multi-layered fabrics or small, individual items of laundry, use the Timed
programme. Also suitable for subsequent drying.
Environmental protection / Energy-saving tips
– Before drying, spin the laundry thoroughly in the washing machine athe higher the spin
speed, the shorter the drying time will be, thus less energy is consumed.
Also spin easy-care laundry.
– Use the maximum recommended capacity, but do not exceed it
aProgramme overview apage 7.
– Make sure the room is well ventilated during drying.
– Do not cover or seal the air inlet.
Fine adjustment of the drying result
Adjustment of the levels of dryness
1 x to
the right
Press and hold &Low heat
and turn 5 x to the right
Press &Low heat until
the required level is reached
Turn to Off Turn to Off
Important Information ...
Your dryer is designed to be particularly energy efficient. Its technical features include
a refrigeration circuit, which uses energy efficiently in a similar way to a refrigerator.
The dryer's heat exchanger is cleaned automatically during drying.
The fluff filters and filter in the condensation container must be cleaned regularly.
Never operate the dryer without the fluff filters and/or condensation container with filter.
ʑFluff filters
During drying, fluff and hair from the laundry is trapped by the fluff filter. Blocked fluff filters
may impair the heat exchange process.
The fluff filters must therefore be cleaned after every drying cycle. Rinse regularly under
running water apage 4.
ʑFilter in the condensation container
The filter in the condensation container cleans the condensation. This condensation is
required for the automatic cleaning process. The filter should be cleaned regularly under
running water. Empty the condensation container before cleaning the filter apage 4/9.
ʑFabrics
Do not dry any fabrics that have come into contact with solvents, oil, wax, grease or paint:
e.g. hair styling products, nail varnish remover, stain remover, cleaning solvent. etc.
Empty all pockets.
Do not dry non-breathable fabrics.
Avoid drying items that produce a lot of fluff.
Woollens should be refreshed only, using the woollens programme.
L:00, L:01, L:02, L:03 are shown in sequence
Short signal when changing from L:03 to L:00, otherwise long
signal.
ˎ&'ˎ&ˎSc#/Aaaaaʋʋʋʋʋʋʋʋʋʋʋʋʋʋʋ
c@c c
#/c÷@c @@AZ#a

aaĔʋʋĔaS('ca&)caaaaaaaaaaa&&ʑaʑaʑ
ˎ&'ˎ&ˎSc#/Aaaaaʋʋʋʋʋʋʋʋʋʋʋʋʋʋʋ
7
Programme overview see also page 5
Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying. After drying...
c
iron laundry

lightly iron laundry
@c
do not iron laundry
c
mangle laundry
PROGRAMMES TEXTILE TYPE AND INFORMATION **Cottons max. 7 kg Hard-wearing fabrics, boil-resistant fabrics made of cotton or linen.
**#Easy-Care max. 3.5 kg Non-iron laundry made of synthetic fibres and blended fabric, easy-care cotton. **/Mixed Load max. 3 kg Mixed items of laundry madeof cotton and synthetics (Mix).
Iron Dry c÷@c Fabrics suitable for ironing (iron fabrics in order to avoid creasing). Cupboard Dry @Single-layer fabrics. *Cupboard Dry Plus / Very Dry @Fabrics made of thick, multilayered items of clothing.
Woollens finish max. 3 kg Woollen fabrics suitable for washing machines. Fabrics become fluffier but not dry.
Remove fabrics once the programme has ended and allow to dry.
ASuper Quick 40’ max. 2 kg
Laundry made of synthetic fibres, cotton or blended fabrics (for example) that needs to be dried quickly. The values may differ from the those specified depending on the type of fabric, mixture of laundry to be dried, residual moisture in the fabric and loading capacity.
ZSportswear max. 1.5 kg Fabrics with membrane coating, water-repellent fabrics, functional clothing, fleece fabrics (dry jackets/trousers with
removable internal lining separately).
Timed Programmes
warm 30’ max. 3 kg Pre-dried, multi-layered, sensitive fabrics made of acrylic fibres, or separate small items of laundry.
Also for subsequent drying.
*For Cottons and #Easy-Care programmes only
**Dryness levels can be selected individually aCupboard Dry Plus / Very Dry, Cupboard Dry and Iron Dry (depending on the model).
Degree of dryness can be finely adjusted; multi-layered textiles require a longer drying time than single-layered items of clothing.
Recommendation: Dry separately.
9201 / 9000741549 *741549* Robert Bosch Hausgeräte GmbH
Carl-Wery-Str. 34
81739 München/Germany
WTW863S0GB

8
Installation
– Scope of delivery: dryer, installation and operating instructions.
– Check dryer for transport damage.
– The dryer is very heavy. Do not attempt to lift it on your own.
– Be careful to avoid sharp edges.
– Do not set up in a room that is susceptible to frost. Freezing water may cause damage.
– If in doubt, have the appliance connected by a specialist.
– Do not lift the dryer by protruding parts (e.g. the door) - risk of breakage.
Setting up the dryer
– The appliance plug must always be accessible.
– Ensure that the appliance is installed on a clean, level
and firm surface.
– Do not obstruct the air inlet on the front of the
dryer.
– Keep the area around the dryer clean.
– Make the dryer level using the threaded feet
and a spirit level.
– Do not remove the threaded feet under any
circumstances.
Mains connection see Safety instructions apage 13.
– Connect to an AC earthed socket. If in doubt have the socket checked by a specialist.
– The mains voltage and the voltage shown on the rating plate (apage 10) must be the
same.
– The connected load and necessary fuse protection are specified on the rating plate.
Frost protection
Preparation
1. Empty the condensation container apage 4.
2. Select any programme using the programme selector.
3. Press the ĔStart/Stop button acondensed water is pumped into the container
4. Wait 5 minutes and then empty the condensation container again.
5. Turn the programme selector to Off.
Transport
– Prepare the dryer asee Frost protection.
– Transport the dryer in a vertical upright position.
– Following transportation, do not use the dryer for two hours.
The dryer contains residual water;
this can flow out if the dryer is tilted.
1.
Take all accessory parts out
of the drum.
The drum must be empty.
Make sure that the air inlet
remains unobstructed
Clean and level
Do not set up the dryer behind a door or sliding
door, as this may obstruct the dryer door or prevent
it from opening. This will prevent a potentially fatal
danger to children from locking themselves in.
2.
Do not operate the dryer if
there is a danger of frost.
9
Care and cleaning
Heat exchanger
The dryer's heat exchanger is cleaned automatically during drying. Cln appears in the display
panel. Do not pull out the condensation container during the cleaning process.
Dryer housing, control panel, air intake
Wipe with a soft, damp cloth.
Do not use harsh cleaning agents or solvents.
Remove detergent and cleaning agent residue immediately.
Some water may collect between the window and the seal during drying. This does not affect
the proper operation of your dryer in any way.
Filter in the condensation container
The filter is cleaned automatically when the condensation container is emptied.
However, the filter should still be cleaned regularly under running water aThis prevents
stubborn deposits/dirt from building up.
1. Pull out the condensation container.
2. Pull the filter out of its snap-in lock.
3. Clean the filter under running water or in the dishwasher.
4. Refit the filter.
5. Insert the condensation container so that it locks into place.
Only operate the dryer with the filter inserted.
Moisture sensor
The dryer is equipped with stainless steel moisture sensors. Moisture sensors measure how
damp the laundry is. A thin layer of limescale may build up on the moisture sensors after
prolonged use.
1. Open the door.
2. Clean the moisture sensors using a damp sponge with a rough surface.
Do not use steel wool or abrasive materials.
Appliance must be switched off.
ʠʠ#÷ʠa
ʠĔʠĔaaaʠĔaʠʠĔʠʠʠaʠaaaaʠaaaaaʠʠʠaʠaaʠaaaaaaaaaaaaaa

aaaĔaaa
10
Technical data
ʠDimensions (DxWxH) 60 x 60 x 85 cm (height adjustable)
Weight approximately 51 kg
Max. capacity 7 kg
Condensation container 4.0 l
Connection voltage 220-240 V
Connected load max. 1000 W
Fuse protection 10 A
Ambient temperature 5 - 35 °C
Product number
Production number under the door
The rating plate can be found on the back of the dryer.
ʠConsumption rates These are guide values determined under standard
conditions.
Spin speed
in rpm
(residual moisture)
Drying time
in min.**
Energy
consumption
in kWh**
Cottons 7 kg
Cupboard Dry* 1400 (approx. 50 %) 128 1.62
1000 (approx. 60 %) 149 1.90
800 (approx. 70 %) 169 2.19
Iron Dry* 1400 (approx. 50 %) 92 1.13
1000 (approx. 60 %) 113 1.42
800 (approx. 70 %) 133 1.70
#÷Easy-Care 3.5 kg
Cupboard Dry* 800 (approx. 40 %) 54 0.57
600 (approx. 50 %) 68 0.72
*Test programs according to DIN EN 61121
**The values may differ from those given, depending on overvoltage and undervoltage, the
type of fabric, composition of the laundry to be dried, the residual moisture in the fabric and
the size of the load.
ʠDrum interior light (depending on model) (bulb E14, 25 W)
The drum lights up after the door is opened or closed, and after the programme starts, and
switches off automatically. Changing the bulb apage 12.
Optional accessories (from after-sales service using order number)
Washer-dryer stack connection set
The dryer can be placed on top of a suitable washing machine with the same width and depth
to save space. The dryer must be fastened to the washing machine using this connection set.
Same as WTZ 11310, but with pull-out worktop.
Installation underneath the worktop
Instead of the appliance covering plate, you must have a metal cover fitted by a specialist.
WTZ
11310
WTZ
11300
WTZ
10290
11
Normal noises
During drying, the compressor and the pump generate some noise which is entirely normal.
The compressor in the dryer may
occasionally generate a humming noise.
The compressor in the dryer is ventilated
from time to time, which creates a whirring
sound.
The automatic cleaning process causes
a clicking noise.
The process of pumping the condensation
into the condensation container generates
pumping noises.
ʠĔʠĔaaaʠĔaʠʠĔʠʠʠaʠaaaaʠaaaaaʠʠʠaʠaaʠa
aaaaaaaaaaaaa

aaaĔaaaʠʠ#÷ʠa
12
What to do if...
If you cannot rectify a fault yourself (e.g. switching off/on), please contact our after-sales
service. We will always find an appropriate solution and will avoid unnecessary visits by
engineers. Trust the expertise of the manufacturer and rest assured that the repair will be
carried out by trained service technicians using original spare parts. The contact details of your
local after-sales service can be found in the enclosed after-sales service directory, or by calling
one of these numbers:
–GB 0844 8928979 (Calls from a BT landline will be charged at up to 3 pence per minute.
A call set-up fee of up to 6 pence may apply.)
–IE 01450 2655
When contacting the after-sales service, please quote the appliance's product number (E no.)
and production number (FD) (see under the loading door).
Turn the programme selector to Off and unplug the mains plug from the socket.
ʠThe ĔStart/Stop indicator lamp
does not light up.
Mains plug plugged in?
Programme selected?
ʠThe Container indicator lamp
and the ĔStart/Stop button are
flashing.
Empty the condensation container apage 4.
Clean the condensation container filter if necessary
apage 9.
Dryer transported? aWait 2 hours and start again.
ʠThe Filter indicator lamp and
ĔStart/Stop button are flashing.
Rinse the fluff filter under running water apage 4.
ʠCln appears in the display panel. Not an error. Automatic cleaning of the heat exchanger.
Do not empty the condensation container.
ʠDryer does not start. ĔStart/Stop button selected?
Door closed? Programme set?
Ambient temperature greater than 5 °C?
ʠWater is leaking out. Make sure the dryer is level.
ʠThe door opens by itself. Push the door closed until you hear it click into place.
ʠCreasing. Laundry load exceeded?
Remove articles of clothing immediately after the end of the
programme, hang up and pull into shape.
Unsuitable programme selected apage 7.
ʠDrying result is not satisfactory
(laundry feels too damp).
Warm laundry feels damper than it actually is.
The selected programme does not suit the load. Use
another drying programme or, in addition, select the time
programme apage 7.
Use fine adjustment for the drying result apage 1/2 and 6.
Fine layer of limescale on the humidity sensors
aClean the humidity sensors apage 9.
Programme termination, e.g. tank full, mains power supply
failure, door open or maximum drying time reached.
ʠDrying time too long. Rinse the fluff filters under running water apage 4.
Insufficient supply of air aensure that air can circulate.
Air inlet possibly blocked aClear inlet apage 8.
Ambient temperature higher than 35 °C aventilate the
room.
ʠThe humidity in the room
increases significantly.
Make sure the room is sufficiently ventilated.
ʠPower failure. Remove laundry from the dryer immediately and spread out.
This allows the heat to dissipate.
ʠOther intermittent noises
and vibrations.
Not an error.
Normal noises apage 11.
ʠLoud humming noise for several
seconds.
Has the condensation container been properly inserted?
aPush the condensation container all the way in.
Not an error. Normal noises apage 11.
ʠThe interior light is not working
(depending on model).
Pull out the appliance plug, remove the cover cap in the
interior above the door (use Torx 20 screwdriver) and
replace the bulb apage 10. Close the cover cap.
Never operate the dryer without a cover cap.
13
Safety instructions
Emergency – Pull the appliance plug out of the socket immediately or disconnect the fuse.
ONLY use the
dryer...
– in rooms inside the house.
– to dry fabrics.
The dryer must
NEVER...
– be used for purposes other than those described above.
– be modified in terms of its technology or properties.
Hazards – The dryer must not be used by children or persons who have not been
instructed in its use.
– Do not leave children unsupervised near the dryer.
– Keep pets away from the dryer.
– Remove all objects from pockets,
and lighters in particular aRisk of explosion.
– Do not lean or sit on the door aRisk of tipping.
Installation – Secure loose cables aRisk of tripping.
– Do not operate a dryer if there is a risk of frost.
Mains
connection
– Connect the dryer to an AC earthed socket according to specifications,
otherwise it cannot be guaranteed that the appliance is completely safe.
– The cable cross-section must be sufficient.
– Only use earth-leakage circuit breakers with the following symbol:
– The appliance plug and socket must be compatible.
– Do not use multiple plugs/connectors and/or extension cables.
– Do not touch or hold the appliance plug with wet hands
aRisk of electric shock.
– Never pull the appliance plug out of the socket by its cable.
– Do not damage the mains lead aRisk of electric shock.
Operation – Only load the drum with laundry.
Check the contents before you switch the dryer on.
– Do not use the dryer if the laundry has been in contact with solvents, oil, wax,
grease or paint (e.g. hair styling products, nail varnish remover, stain remover,
cleaning solvent, etc.) aRisk of fire/explosion.
– Dust (e.g. coal dust, flour) poses a danger: Do not use the dryer
aRisk of explosion
– Do not put laundry containing foamed material/rubber in the dryer aelastic
material may be destroyed and the dryer be damaged due to possible
deformation of the foamed material.
– When cleaning the fluff filter, make sure that no foreign material (down or filling
material) gets into the air duct opening. If necessary, clean the drum
beforehand with a vacuum cleaner. If foreign material should still get into the
air duct acall the after-sales service aRisk of fire/explosion.
– Switch off the dryer once the programme has ended.
– The water from condensation is not drinking water and may be contaminated
with fluff.
Defect – Do not use the dryer if it is defective or if you suspect that it is.
Repairs must only be carried out by the after-sales service.
– Do not use the dryer if the mains cable is defective. To avoid danger, only have
the defective mains cable replaced by the after-sales service.
– Always pull the mains plug out of the socket before changing the bulb for the
interior light aRisk of electric shock.
Spare parts – Only use genuine spare parts and accessories for safety reasons.
Disposal – Pull out the appliance plug, then cut off the mains cable from the appliance.
Dispose of at a municipal waste disposal facility.
– Heat exchangers contain a fluorinated greenhouse gas covered by the Kyoto
protocol (R134a) adispose of in a proper manner. Capacity: 0.22 kg.
– Packaging: Keep all packaging out of reach of babies and children
aRisk of suffocation.
– All materials are environmentally sound and can be reused. Dispose of in an
environmentally-responsible manner.

aaaĔaaaʠʠ#÷ʠaʠĔʠĔaaaʠĔaʠʠĔʠʠʠaʠaaaaʠaaaaaʠʠʠaʠaaʠaaaaaaaaaaaaaa
Dryer
en Instruction manual
