Bosch CDG634B.1B User manual

[en] Instruction manual
Steamer
CDG634B.1B

en
3
Table of contents
[en]Instruction manual
8Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(Important safety information . . . . . . . . . . . . . . . 4
]Causes of damage . . . . . . . . . . . . . . . . . . . . . . . . 5
7Environmental protection . . . . . . . . . . . . . . . . . . 6
Saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Environmentally-friendly disposal . . . . . . . . . . . . . . . . . 6
*Getting to know your appliance . . . . . . . . . . . . . 7
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Heating types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Further information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Cooking compartment functions . . . . . . . . . . . . . . . . . 9
_Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Accessories included . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Inserting accessories . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . 10
KBefore using for the first time. . . . . . . . . . . . . . 10
Before using for the first time . . . . . . . . . . . . . . . . . . . 10
Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Calibrating the appliance and cleaning the cooking
compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Cleaning the accessories. . . . . . . . . . . . . . . . . . . . . . 11
1Operating the appliance . . . . . . . . . . . . . . . . . . 12
Switching the appliance on and off . . . . . . . . . . . . . . 12
Starting the operation. . . . . . . . . . . . . . . . . . . . . . . . . 12
Filling the water tank . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setting the type of heating and temperature . . . . . . . 13
After each use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
OTime-setting options . . . . . . . . . . . . . . . . . . . . . 14
Setting the cooking time . . . . . . . . . . . . . . . . . . . . . . 14
Setting the end time . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setting the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
PDishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Applying settings for dishes . . . . . . . . . . . . . . . . . . . . 16
Instructions for the dishes . . . . . . . . . . . . . . . . . . . . . 17
Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
AChildproof lock. . . . . . . . . . . . . . . . . . . . . . . . . . 18
Activating and deactivating . . . . . . . . . . . . . . . . . . . . 18
QBasic settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Changing the basic settings . . . . . . . . . . . . . . . . . . .19
List of basic settings. . . . . . . . . . . . . . . . . . . . . . . . . .19
Power cut . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Changing the time . . . . . . . . . . . . . . . . . . . . . . . . . . .19
DCleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
cleaning agents . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Descale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Removing and fitting the appliance door . . . . . . . . . .22
Removing and installing the door panels . . . . . . . . . .22
Cleaning the rails . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
3Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . 24
Rectifying faults yourself . . . . . . . . . . . . . . . . . . . . . . .24
Replacing the cooking compartment bulb . . . . . . . . .25
Replacing the glass cover or seals . . . . . . . . . . . . . .25
Changing the door seal . . . . . . . . . . . . . . . . . . . . . . .26
4Customer service . . . . . . . . . . . . . . . . . . . . . . . . 26
E number and FD number . . . . . . . . . . . . . . . . . . . . .26
JSettings table and tips. . . . . . . . . . . . . . . . . . . . 27
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Ovenware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Cooking time and quantity . . . . . . . . . . . . . . . . . . . . .27
Distributing food evenly . . . . . . . . . . . . . . . . . . . . . . .27
Pressure-sensitive food. . . . . . . . . . . . . . . . . . . . . . . .27
Cooking a menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Vegetables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Side dishes and pulses . . . . . . . . . . . . . . . . . . . . . . .28
Poultry and meat . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Fish. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Soup vegetables, miscellaneous . . . . . . . . . . . . . . . .30
Dessert, compote . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Reheating food . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Prove dough . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Extracting juice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Preserving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Frozen products . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Test dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Produktinfo
Additional information on products, accessories,
replacement parts and services can be found at
www.bosch-home.com and in the online shop
www.bosch-eshop.com

en Intended use
4
8Intended use
Intendeduse Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for future
use or for subsequent owners.
This appliance is only intended to be fully fitted
in a kitchen. Observe the special installation
instructions.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
Only a licensed professional may connect
appliances without plugs. Damage caused by
incorrect connection is not covered under
warranty.
This appliance is intended for domestic use
only. The appliance must only be used for the
preparation of food and drink. The appliance
must be supervised during operation. Only
use this appliance indoors.
This appliance is intended for use up to a
maximum height of 2000 metres above sea
level.
This appliance may be used by children over
the age of 8 years old and by persons with
reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around the
appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 8 years old and are
being supervised.
Keep children below the age of 8 years old at
a safe distance from the appliance and power
cable.
Always slide accessories into the cooking
compartment the right way round.
~"Accessories" on page 9
(Important safety
information
Importantsafetyinformation :Warning – Risk of burns!
■The appliance becomes very hot. Never
touch the interior surfaces of the cooking
compartment or the heating elements.
Always allow the appliance to cool down.
Keep children at a safe distance.
Risk of serious burns!
■Accessories and ovenware become very
hot. Always use oven gloves to remove
accessories or ovenware from the cooking
compartment.
Risk of burns!
■Hot steam may escape during operation.
Do not touch the ventilation openings. Keep
children away.
:Warning – Risk of scalding!
■The accessible parts become hot during
operation. Never touch the hot parts. Keep
children at a safe distance.
Risk of scalding!
■Water in a hot cooking compartment may
create hot steam. Never pour water into the
hot cooking compartment.
Risk of scalding!
■When you open the appliance door, hot
steam can escape. Steam may not be
visible, depending on its temperature. When
opening, do not stand too close to the
appliance. Open the appliance door
carefully. Keep children away.
Risk of scalding!
■The water in the evaporator dish is still hot
even after the appliance has been switched
off. Do not empty the evaporator dish
immediately after switching off the
appliance. Allow the appliance to cool down
before cleaning it.
Risk of scalding!
■Hot liquid may spill over the sides of the
accessory when it is removed from the
cooking compartment. Remove hot
accessories with care and always wear
oven gloves.
:Warning – Risk of injury!
■Scratched glass in the appliance door may
develop into a crack. Do not use a glass
scraper, sharp or abrasive cleaning aids or
detergents.
Risk of injury and risk of fire!
■Flammable liquids can catch fire in the
cooking compartment when it is hot
(explosion). Do not fill the water tank with
any flammable fluids (e.g. alcoholic drinks).
Only fill the water tank with water or with the
descaling solution that is recommended by
us.

Causes of damage en
5
:Warning – Risk of electric shock!
■Incorrect repairs are dangerous. Repairs
may only be carried out by one of our
trained after-sales engineers. If the
appliance is faulty, unplug the mains plug or
switch off the fuse in the fuse box. Contact
the after-sales service.
Risk of electric shock and serious injury!
■The cable insulation on electrical
appliances may melt when touching hot
parts of the appliance. Never bring
electrical appliance cables into contact with
hot parts of the appliance.
Risk of electric shock!
■Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
■When replacing the cooking compartment
bulb, the bulb socket contacts are live.
Before replacing the bulb, unplug the
appliance from the mains or switch off the
circuit breaker in the fuse box.
Risk of electric shock!
■A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
]Causes of damage
Causesofdamage Caution!
■Accessories, foil, greaseproof paper or ovenware on
the cooking compartment floor: Do not place
accessories on the cooking compartment floor. Do
not cover the cooking compartment floor with any
sort of foil or greaseproof paper. The cooking
compartment floor and the evaporator dish must
always be kept clear. A build-up of heat may
damage the appliance. Always place ovenware in a
perforated cooking container or on a wire rack.
■Aluminium foil in the cooking compartment must not
come into contact with the door panel. This could
cause permanent discolouration of the door panel.
■Ovenware: Ovenware must be heat and steam
resistant.
■Ovenware with areas of rust: Do not use any
ovenware which displays areas of rust. Even the
smallest spots of rust can lead to corrosion in the
cooking compartment.
■Dripping liquids: When steaming with a perforated
cooking container, always insert the baking tray, the
universal pan or the solid cooking container
underneath. Dripping liquid is caught.
■Moisture in the cooking compartment: Over an
extended period of time, moisture in the cooking
compartment may lead to corrosion. Allow the
cooking compartment to dry after use. Do not keep
moist food in the closed cooking compartment for
extended periods of time. Do not store food in the
cooking compartment.
■Extremely dirty seal: If the seal is very dirty, the
appliance door will no longer close properly during
operation. The fronts of adjacent units could be
damaged. Always keep the seal clean.
~"Cleaning" on page 20
■Appliance door as a seat, shelf or worktop: Do not
sit on the appliance door, or place or hang anything
on it. Do not place any cookware or accessories on
the appliance door.
■Inserting accessories: depending on the appliance
model, accessories can scratch the door panel
when closing the appliance door. Always insert the
accessories into the cooking compartment as far as
they will go.
■Carrying the appliance: do not carry or hold the
appliance by the door handle. The door handle
cannot support the weight of the appliance and
could break.
■Looking after the appliance: The cooking
compartment on your appliance is made of high-
quality stainless steel. Improper care may lead to
corrosion in the cooking compartment. Refer to the
care and cleaning instructions in the instruction
manual. Remove food residues from the cooking
compartment as soon as the appliance has cooled.
■Hot water in the water tank: Hot water can damage
the pump. Only fill the water tank with cold water.

en Environmental protection
6
■Descaling solution: Do not allow descaling solution
to come into contact with the control panel or other
sensitive surfaces. These will damage the surfaces.
If this does happen, remove the descaling solution
immediately with water.
■Cleaning the water tank: Do not clean the water tank
in the dishwasher. Otherwise, the water tank will be
damaged. Clean the water tank with a soft cloth and
standard washing-up liquid.
7Environmental protection
Environmentalprotection Your new appliance is particularly energy-efficient. Here
you can find tips on how to save even more energy
when using the appliance, and how to dispose of your
appliance properly.
Saving energy
■Only preheat the appliance if this is specified in the
recipe or in the tables in the operating instructions.
■Use dark, black lacquered or enamelled baking tins.
They absorb heat particularly well.
■Open the appliance door as infrequently as possible
during operation.
■It is best to bake several cakes one after the other.
The cooking compartment is still warm. This reduces
the baking time for the second cake. You can place
two cake tins next to each other in the cooking
compartment.
■For longer cooking times, you can switch the
appliance off 10 minutes before the end of the
cooking time and use the residual heat to finish
cooking.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly
manner.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning
used electrical and electronic appliances
(waste electrical and electronic equipment -
WEEE). The guideline determines the
framework for the return and recycling of used
appliances as applicable throughout the EU.

Getting to know your appliance en
7
*Getting to know your
appliance
Gettingtoknowyourappliance In this chapter, we will explain the displays and controls.
You will also find out about the various functions of your
appliance.
Note: Depending on the appliance model, individual
details and colours may differ.
Control panel
In the control panel, you can use the various buttons,
touch fields and the rotary selector to set the different
appliance functions. The current settings are shown on
the display.
The overview shows the control panel when the
appliance is switched on with a selected heating type.
Controls
The individual controls are adapted for the various
functions of your appliance. You can set your appliance
simply and directly.
Buttons and touch fields
Here you can find a short explanation of the various
buttons and touch fields.
'
KRWDLU
PV
RQ
RII
VWDUW
SDXVH
a&
6WHDPLQJ
\PV
#
 

(Buttons
The buttons on the left- and right-hand side of the
control panel have a pressure point. Press these
buttons to activate them.
For appliances that do not have a stainless steel
front, these two button touch fields do not have a
pressure point.
0Touch fields
There are sensors under the touch fields. Simply
touch the respective symbol to select the function.
8Rotary selector
The rotary selector is fitted so that you can turn it
indefinitely to the left or right. Press it lightly and
move it in the direction required using your finger.
@Display
You can see the current adjustment values,
options or notes in the display.
Symbol Meaning
Buttons
ÿon/off Switching the appliance on and off
lStart/Stop Starting, pausing or cancelling (hold down
for approx. 3 secs) an operation
External touch fields
tTimer Selects the timer
DChildproof lock Activating and deactivating (hold down for
approx. 4 secs) the childproof lock
°Information Appliance switched on: Display notes
Appliance switched off: Press and hold
(approx. 3 seconds) to call up the basic
settings
VDescale Selects Descale
Internal touch fields
SSteam Selects the Steam heating type
TProve dough Selects the Prove dough heating type
UReheat Selects the Reheat heating type
BDefrost Selects the Defrost heating type

en Getting to know your appliance
8
--------
The touch field, which has a value on the display that
can be changed or displayed in the foreground, lights
up red.
Rotary selector
You can use the rotary selector to change the setting
values shown in the display.
In most selection lists, such as the temperature, you
have to turn the rotary selector back the other way if
you reach the minimum or maximum value.
Display
The display is structured so that the information can be
read at a glance in any situation.
The value that you can currently set is in focus. It is
displayed in white lettering and underlined in white. The
value in the background is displayed in grey.
Display ring
The display ring can be found around the outside of the
display.
If you change a value, the display ring shows you where
you are in the selection list. Depending on the settings
area and length of the selection list, the display ring
may be continuous or divided into segments.
During operation, the display ring turns red at second-
long intervals. After every full minute, the segments turn
red again from the beginning. As the cooking time
counts down, one segment disappears every second.
Temperature display
After operation has started, the current cooking
compartment temperature is displayed graphically in
the display.
Note: Due to thermal inertia, the temperature displayed
may be slightly different to the actual temperature inside
the oven.
Heating types
Your appliance has various heating types which can be
selected using the control panel.
}Temperature Selects the temperature in the cooking
compartment
%AutoCook Selects the operating mode for dishes
with cooking programmes
sTime-setting
options
Select time-setting options
aWeight Selects the weight for the operating mode
for dishes
Focus The value in focus can be changed directly with-
out first being selected.
After starting an operation, either the temperature
or the level is always in focus. At the same time,
the white line is the heating line and gradually
turns red.
Enlargement As you change the value in focus using the rotary
selector, only this value is displayed larger.
Heating line The white line under the temperature turns red from
left to right as the cooking compartment heats up.
When you are preheating the appliance, the optimal
time for placing the food in the cooking compart-
ment is when the line has completely turned red.
Residual heat
indicator
When the appliance is switched off, the display ring
shows the residual heat in the cooking compart-
ment. As the residual heat cools down, the display
ring becomes darker and disappears completely at
some point.

7\SHVRIKHDWLQJ
_
7H[W
7H[W
7HPSHUDWXUH

&
_
7H[W
7H[W
+HL]DUWHQ

P

V
6
a&
Type of heating Temperature Use
SSteaming 30-100 °C For vegetables, fish, side dishes, for juicing fruit and for blanching
UReheating 80-100 °C For plated meals
Cooked food is gently reheated. The steam ensures that the food does not dry out
TDough proving 30-50 °C For yeast dough
Dough will rise considerably more quickly than at room temperature. The surface of the dough
does not dry out
BDefrosting 30-60 °C For fruit and vegetables
The moisture gently transfers the heat to the food. The food does not dry out or lose its shape

Accessories en
9
Default values
The appliance suggests a temperature or setting for
each heating type. You can accept this value or change
it in the appropriate area.
Further information
In most cases, the appliance provides notes and further
information on the action just carried out.
Touch the °field. The note is shown in the display for a
few seconds. Use the rotary selector to scroll to the end
of longer notes.
Some notes are displayed automatically, for example as
confirmation, or to provide an instruction or warning.
Cooking compartment functions
The functions in the cooking compartment make your
appliance easier to use. This, for example, enables the
cooking compartment to be well lit and a cooling fan to
prevent the appliance from overheating.
Opening the appliance door
If you open the appliance door during an on-going
operation, the operation is paused. The operation
continues to run when you close the door.
Interior lighting
When you open the appliance door, the interior lighting
switches on. If the door remains open for longer than
around 15 minutes, the lighting switches off again.
For most operating modes, the interior lighting switches
on as soon as the operation is started. When the
operation has finished, the lighting switches off.
Note: You can set the interior lighting not to come on
during the operation in the basic settings. ~"Basic
settings" on page 19
Cooling fan
The cooling fan switches on and off as required. The
hot air escapes above the door.
Caution!
Do not cover the ventilation slots. Otherwise, the
appliance may overheat.
So that the cooking compartment cools down more
quickly after the operation, the cooling fan continues to
run for a certain period afterwards.
Note: You can change how long the cooling fan
continues to run in the basic settings. ~"Basic
settings" on page 19
_Accessories
Accessories Your appliance is accompanied by a range of
accessories. Here, you can find an overview of the
accessories included and information on how to use
them correctly.
Accessories included
Your appliance is equipped with the following
accessories:
--------
Only use genuine accessories. They are specially
adapted for your appliance.
You can buy accessories from the after-sales service,
from specialist retailers or online.
Inserting accessories
The cooking compartment has four shelf positions. The
shelf positions are counted from the bottom up.
Caution!
■Do not place anything on the cooking compartment
floor. Do not cover it with aluminium foil. A build-up
of heat could damage the appliance.
The cooking compartment floor and the evaporator
dish must always be kept clear. Always place
ovenware in a perforated cooking container or on a
wire rack.
■Do not slide any accessories between the shelf
positions, or they may tip.
Locking function
The accessories can be pulled out approximately
halfway until they lock in place. The locking function
prevents the accessories from tilting when they are
pulled out. The accessories must be inserted into the
Steam container, perforated, size L
For the steaming of whole fish or large
quantities of vegetables, for juicing ber-
ries, etc.
Steam container, unperforated, size
L
For catching dripping liquid when
steaming and for cooking rice, pulses
and cereals
(Evaporator dish
0Water tank in the water tank recess






en Before using for the first time
10
cooking compartment correctly for the tilt protection to
work properly.
When inserting the wire rack, ensure that the lug ƒis
facing downwards and the ‚safety lug on the wire rack
is at the rear and is facing upwards.
When inserting steam containers, ensure that the lug „
is facing downwards.
Optional accessories
You can buy optional accessories from the after-sales
service, from specialist retailers or online. *You will find
a comprehensive range of products for your appliance
in our brochures and online.
Both availability and whether it is possible to order
online differ between countries. Please see your sales
brochures for more details.
When purchasing, please always quote the exact order
number of the optional accessory.
Note: Not all optional accessories are suitable for every
appliance. When purchasing, please always quote the
exact identification number (E-no.) of your appliance.
~"Customer service" on page 26
--------
KBefore using for the first
time
Beforeusingforthefirsttime Before you can use your new appliance, you must
make some settings. You must also clean the cooking
compartment and accessories.
Before using for the first time
Before using the appliance for the first time, enquire
about the water hardness of your tap water from your
water supplier.
So that the appliance can reliably remind you to
decalcify it when required, you must correctly set your
water hardness range.
Caution!
The appliance may become damaged due to the use of
unsuitable liquids.
Do not use distilled water, highly chlorinated tap water
(> 40 mg/l) or other liquids.
Only use cold, fresh tap water, softened water or
uncarbonated mineral water.
Notes
■If your water is very hard, we recommend that you
use softened water.
■If you only use softened water, you can set the water
hardness range to "softened" in this case.
■If you use mineral water, set the water hardness
range to "4 very hard".
■If you use mineral water, you must only use non-
carbonated mineral water.
Special accessories Order number
Steam container, perforated, size S HEZ36D163G
Steam container, solid, size S HEZ36D163
Steam container, perforated, size L HEZ36D643G
Steam container, solid, size L HEZ36D643
Wire rack for steamer HEZ36DR4
Porcelain cooking container, solid, size S HEZ36D153P
Porcelain cooking container, solid, size L HEZ36D353P
Decorative trims
For concealing the lower shelf of the unit and the
base of the appliance.
HEZ660060
D
D
E
FF
Water hardness range Setting
0 00 softened
1 (up to 1.3 mmol/l) 01 soft
2 (1.3 - 2.5 mmol/l) 02 medium
3 (2.5 - 3.8 mmol/l) 03 hard
4 (above 3.8 mmol/l) 04 very hard
