Bosch TRACI Tag User manual

Operating Instructions
Bosch Asset Tracing Solution (TRACI)
Bosch TRACI Tag
PART NO | 0 273 600 046
Model: EU (868MHz)
Advant age s
Manufacturer-independent solution for retrofitting or
extending existing systems
Simplified configuration and visualization via mobile or
web application
Runs without external power supply
Robust design for harsh environment
Areas of Application:
SAMPLE
- Customer specific adaptation upon request -

Bosch Asset Tracing Solution | Bosch TRACI Tag
2
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | July 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
Table of Content
1About these Operating Instructions 4
2Product Identification 5
2.1 Main Function 5
2.1.1 O ve r vi e w 6
2.2 Intended Use 7
2.2.1 EU Declaration of Conformity 7
2.2.2 References to CE Standards 7
2.2.3 Open Source Licenses (FOSS) 8
2.2.4 Export Restrictions 8
2.3 Safety and Warning Notes 9
2.3.1 Safety Notes 9
2.3.2 Warning Notes 10
2.4 Labeling of the Product 11
2.5 Dimensions and Weight 12
2.6 Power Consumption / Power Output 12
2.7 General Remarks on Service, Repair and Maintenance 13
2.7.1 Ser vi ce 13
2.7.2 Support 13
2.7.3 Repair 13
2.7.4 Mainten an ce 13
2.8 Dat a Se curit y 14
2.9 Disposal and Recycling 14
2.9.1 Disposal 14
2.9.2 Recycling 14
3Syste m De scription 15
3.1 System of Interest (SOI) 15
3.2 Hardware and Software interfaces 15
4Te chnical Data 16
4.1 Functions 16
4.2 Mechanical Characteristics 16
4.3 Electrical Characteristics 17
4.4 Climate Char acteristics 17
4.5 Chemical Characteristics 17
4.6 Acoustic characteristics 18
4.7 Lifetime 18
4.8 Transport, mounting, start and end of operation, storage 18

Bosch Asset Tracing Solution | Bosch TRACI Tag
3
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | July 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
4.8.1 Transport 18
4.8.2 Mounting 19
4.8.3 Installation, Configuration & Operation 20
4.8.4 Deactivation 20
4.8.5 Storage 20
5Series-accompan yin g te sts 21
6Te sting 21
6.1 Testin g b y BOSCH 21
6.2 Testing by the Customer 21
7Assessment of products returned from the field 21

Bosch Asset Tracing Solution | Bosch TRACI Tag
4
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | Jul y 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
1About these Operating Instructions
Ensure that the B osch TRACI Ta g is working correctly by:
Reading these operating instructions carefully before using the Bosch TRACI Tag.
Always following these instructions.
Caution
Indicates a hazardous situation in which the user must proceed as noted.
Always follow these instructions.
Notice
Indicates a non-hazardous situation which should be noted and handled accordingly to avoid
damage to materials.
Always follow these instructions.
Info
General information and/or instructions. Instructions must be followed.
Tip
Practical advice.
These operating instructions provide the basis for the safe use and operation of the Bosch TRACI
Tag. These operating instructions and, in particular, the included safety instructions have to be
observed by all individuals working with Bosch TRACI Tags. In addition, all rules and regulations
regarding accident prevention which apply in the specific region and/or at the site of operation where
the Bosch TRACI Tag is used are to be complied with.
Valid for hardware version: R1
Version of this documentation: 3.3
Valid from: 2018-07-01
Checked by: PS-IG /PRM1 BUECHNER
Issued by: PS-IG/GP GERHARDT
Contact: PS-IG/PRM1 BUECHNER

Bosch Asset Tracing Solution | Bosch TRACI Tag
5
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | Jul y 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
2Product Identification
2.1 Main Function
The Bosch TRACI Tag is part of the the Bosch Asset Tracing Solution (hereafter referred to as
“TRACI”). TRACI is a system solution for remote localization and monitoring of vehicles, machiner y
and goods. TRACI comprises hardware, software (e.g. App) and services (e.g. connectivity, cloud
services). The Bosch TRACI Tag is the major hardware component of the system.
The Bosch TRACI Tag is a robust, durable and retrofittable Internet of Things (“IoT”) unit. It records
and transmits sensor data to a cloud via various radio standards. For all vehicles. machinery and
goods that are fitted with the Bosch TRACI Tag, the system is able to provide, exchange and visualize
information regarding position and operating conditions.
The customer must ensure that the Bosch scope of delivery complies with the requirements on the
functional safety within the overall system. It is the customer’s responsibility to validate these
documented requirements, their implementation and the assumptions made for this purpose.
The Bosch TRACI Tag is only avaible in combination with a Bosch Asset Tracing Solution
contracting. The contracting includes the “Terms of Service”, “Data Privacy Statements” and
“Contracting for Order Data Processing” (“ODP”).

Bosch Asset Tracing Solution | Bosch TRACI Tag
6
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | Jul y 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
2.1.1 Overview
Bosch TRACI System
Bosch TRACI Tag
Sensors
Motion Acceleration
(3 axis)
Temperature Magnetic
Field
Connectivity
GNSS
Bluetooth®
LoRa®
Figure 1: Overview Bosch TRACI System & Bosch TRACI Tag

Bosch Asset Tracing Solution | Bosch TRACI Tag
7
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | Jul y 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
2.2 Intended Use
Bosch complied with the country-specific regulations of the European Union when developing the
product.
2.2.1 EU Declarationof Conformity
The CE mark on the device confirms that this product complies with the European regulations
for safety, health, environmental protection and personal protection.
Devices marked with “CE” are destined for the European market.
We decare under our sole responsibility that all relevant provisions of the directives 2011/65/EU
including their amendments and complies with the following standards: EN 50581.
Robert Bosch GmbH herewith declares that the product is in accordance with the basic requirements
and other relevant regulations of the Directive 2014/53/EC.
Furthermore we declare under our sole responsibility that the product is in conformity with all relevant
provisions of the Directive 2014/53/EU and complies with the following standards:
The full text of the EU declaration of conformity is available at the following internet address:
http://eu-doc.bosch.com
2.2.2 References to CE Standards
Electromagnetic Compatibillity
According to article 3.1-b of the directive
2014/53/EC
EMC 2014/30/EC
EN 301 489-1
EN 301 489-3
EN 301 489-17
EN 301 489-19
Efficient use of the radio frequencies
spectrum
According tot he article 3.2 of the
directive 2014/53/EC
RED 2014/53/EC
EN 300 220-1
EN 300 220-2
EN 300 328
EN 300 330
EN 303 413
Safe ty, He alth of persons and animals
According tot he article 3.1-a of the
directive 2014/53/EC
EN 60950-1
EN 60950-22
EN 62368-1
EN 62368-22
Exposure of magnetic fields
EN 62479
Address of Manufactorer:
Robert Bosch GmbH
Powertrain Solutions
We rne rstraße 51
70469 Stuttgart-Feuerbach
Ge rmany

Bosch Asset Tracing Solution | Bosch TRACI Tag
8
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | Jul y 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
2.2.3 Open Source Licenses (FOSS)
Open Source Licenses (FOSS) can be found on the TRACI homepage under www.bos ch .co m.
2.2.4 Export Restrictions
Due to legal regulations the device is only avail able within the European Union.
If other or additional regulations are required for marketing the product or marketing is effected outside
the named target markets, the customer requests compliance with the specific regulations of the target
market from Bosch, or ensures these by itself.
Provided that the Bosch TRACI Tag is used within the conditions (environment, application,
installation, loads) as described in these operating instructions and the corresponding agreed upon
documents, Bosch ensures that the product complies with the properties defined in chapter 4
“Technical Data”. Agreements beyond this require the written approval by Bosch. The product is
considered fit for the intended use when the product has successfully passed the tests in accordan ce
with the TCD and agreed upon documents.
It is the responsibility of the customer to ensure the proper application of the product in the overall
system.
Bosch does not assume any responsibility for changes to the environment of the product that deviate
from the TCD and the agreed upon documents.
For further important information regarding the use of the Bosch TRACI Tag, please refer to the
chapter 2.3 “Safety and Warning Notes”.
Caution
Safety Aspects!
The device allows a satellite-based position determination. Location and time will be recorded.
The device does not track in re al time !
►The device is not designed and therefore not suitable for safety functions! The device is
not designed for recording and forwarding of position information on a real-time basis. Do not
use the device for monitoring of persons and objects in hazardous areas and safety areas.
For turning off the device, please referto chapter4.8.8 “Deactivation”.
Notice
Personnel Data Security!
The device allows a satellite-based position determination. Location and time will be recorded.
Use of TRACI may be subject to data protection legislation. Customer shall adhere to
applicable data protection legislation.

Bosch Asset Tracing Solution | Bosch TRACI Tag
9
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | Jul y 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
2.3 Safety and Warning Notes
2.3.1 Safety Notes
Warning
Read all safety instructions.
All safety instructions have to be read and followed before
working with the Bosch TRACI Tag in order to ensure safe
operation.
Store the safety instructions and guidelines in a safe place and
provide them when transferring the BOSCH TRACI Tag, or any
a sset carrying it, to a third party.
Ignoring the safety instructions can cause accidents, electric
shocks, fire and/or heavy injuries.
General safety instructions and work station security:
►Fixing or mounting of the Bosch TRACI Tag may at no time affect the safe use of the
tagged asset. In particular, the following places are not suitable for mounting the Bosch TRACI
Tag:
-protective equipment,
-ventilation shaft and louvers,
-control elements,
-moving or rotating components,
-nameplates, official license plates and lighting equipment,
-service and clutch areas as well as soft grip surfaces,
-areas in close proximity to flying sparks as well as areas with strong thermal or mechanical
impact,
-Areas of importance for the structural integrity of the object.
Assembly instrcutions and mounting situation
High temperatures and heat effect can damage the battery
-Do not expose the Bosch TRACI Tag to direct sunlight.
-Mount the Bosch TRACI Tag in a safe distance to hot surfaces (for example engines, coolers
or exhaust systems).
Avoid contact with corrosive media, these can damage the Tag.
►Deployment of the Bosch TRACI Tag in areas with explosion protection requirements is
not allowed.
Use and treatment:
►Do not open the housing
-The housing is watertight. Do not open the housing. Do not try to exchange the battery.
Opening the housing will impair the tightness of the case.
-If the housing is damaged, do not to use the Bosch TRACI Tag under any circumstances.
This guideline provides assistance for the compliance with legal demands, however, it does not
exempt the distributors and users from the requirement of making themselves familiar and ensuring
compliance with applicable laws and regulations.

Bosch Asset Tracing Solution | Bosch TRACI Tag
10
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | Jul y 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
2.3.2 Warning Notes
Caution
Lithium Battery!
The Bosch TRACI Tag contains a lithium battery. The device is not designed to change the battery!
It is not allowed to open the housing! Use of non-original (e.g. opened) Bosch TRACI
Tags may lead to hazards.
Handling the battery incorrectly could cause a fire. It is not allowed to change the battery!
When the batteryis empty, please referto chapter 2.9 “Disposal and Re cycling” for
further information.
►Do not exchange or recharge the battery
-Bosch TRACI Tag is equipped with a non-rechargeable lithium battery. Improper use can
cause leakage of battery liquid. Avoid contact with battery liquid. Leaking battery liquid can
cause skin irritations or skin burns. In case of contact, wash off with water immediately. In
case of contact of the battery liquid with the eyes, consult medical assistance. In case of
damages to the battery, fumes can escape. These fumes can cause irritations to the
respiratory tract. Provide sufficient fresh air and consult a doctor when feeling signs of
discomfort.
►Short circuit prote ction
-A broken housing of the Bosch TRACI Tag can lead to a short circuit. For storage, transport
and disposal of a damaged Bosch TRACI Tag, keep it away from paper clips, coins, keys,
nails, screws or other small metal objects which can cause a short circuit between the
contacts of the battery. A short circuit can cause fire.
Notice
Precautions!
Do not use or store the Bosch TRACI Tag in a place where it is exposed to direct sunlight,
high temperatures, or sources of heat. Failure to do so could result in battery leakage,
overheating, or damage. This can result in burns or other injuries.
Install the product at a sufficient distance from e ngines, exhaust systems and electrical
equipment.
For any question regarding service, please refer to chapter 2.7 “General Remarks on
Service, Repair and Maintenance”.
Info
Radio Frequency Radiation Exposure
The radiated output power of the Bosch TRACI Tag is below radio frequency exposure limits.
Nevertheless, it is recommended to avoid constant exposure of humans to the device.

Bosch Asset Tracing Solution | Bosch TRACI Tag
11
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | Jul y 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
2.4 Labeling of the Product
Symbol
Name
Description
Name and
Adress
of Manufactorer
Robert Bosch GmbH
Powertrain Solutions
Wernerstraße 51
D-70469 Stuttgart
Product Name
BOSCH Asset Tracing Tag
Product Number
0 273 600 046
Battery features
Chemistry
Voltage
Power
Li-SOCl
2
Lithium Thionyl Chloride
3,6V DC
6600mAh; 23,76Wh
Certification mark of the
european union
This product complies with the applicable
requirements commited in the hamonized legislation
of the European Community.
Symbol for separate
collection of waste
This symbol indicates separate collection of waste for
electrical and electronic equipment and for batteries.
Data matrix Code
This code can be scanned with the smartphone and
serves to identify the Bosch TRACI Tag. It contains
the Serial Number S/N (see below)
Serial Number S/N:
e.g. FC:D6:Bd:00 :12 :00 :00 :00 (Hex Format)

Bosch Asset Tracing Solution | Bosch TRACI Tag
12
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | Jul y 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
2.5 Dimensions and Weight
Dimensions of TRACI Tag
We ight of TRAC I Tag: 138g (without accessories & packaging)
2.6 Power Consumption / Power Output
The TRACI Tag has no external power input or output interfaces.

Bosch Asset Tracing Solution | Bosch TRACI Tag
13
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | Jul y 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
2.7 General Remarks on Service, Repair and Maintenance
The Bosch TRACI Tag is watertight. Hence, exposure to dirt etc. should not cause any restrictions
to the functionality. Do not use solvents or chemical additions to clean the Bosch TRACI Tag. This
can lead to a damage of the housing. Use mild cleanser to remove dirt.
Opening the housing will impair the tightness of the case. This present risks to the user and will void
any warranty.
In case of a damage, please exchange the Bosch TRACI Tag. Do not try to repair the Bosch TRACI
Tag. Environmental friendly disposal of the damaged device (see chapter 2.9 “Disposal and
Recycling”) and compliance with the guideline for transport are required.
2.7.1 Service
In case of damage or malfunction to the Bosch TRACI Tag please contact our customer support (see
chapter 2.7.2 “Support”).
For disposal, please refer to chapter 2.9 “Disposal and Recycling”.
Notice
Risk of Data Loss
In case of end of battery lifetime, no data can be measured or stored and previously measured
data which have not yet been send to the backend may be lost.
2.7.2 Support
In case you require any kind of support in regard to the Bosch TRACI Tag please contact us at:
Robert Bosch GmbH
Powertrain Solutions
Tel.+ 49 711 811 52331
[e-mail]
www.bos ch.co m
2.7.3 Repair
Repair of the Bosch TRACI Tag is not possible.
2.7.4 Maintenance
Repair or Maintenance of the Bosch TRACI Tag is not possible.
Opening the housing presents risks to the user and will void any warranty.

Bosch Asset Tracing Solution | Bosch TRACI Tag
14
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | Jul y 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
2.8 Data Security
Notice
Data Security
LoRa® targets key requirements of the IoT s uch as secure bi-directional communication, mobility
and localization services. A secure communication also with regard to critic
al data such as
confidential and/or personal data is achieved by several layers of encryption:
Unique Network key (AES128) ensures data integrity on network level
Unique Application key (AES128) ensures data security on network level
2.9 Disposal and Recycling
2.9 .1 Disposal
Disposing of this product correctly will help save valuable resources and prevent any potential
negative effects on human health and the environment, which could otherwise arise from
inappropriate waste handling.
Please contact your local authority for further details of your nearest designated collection point.
Penalties may be applicable for incorrect disposal of this waste, in accordance with your national
legislation.
2.9 .2 Recycling
Disposal according to the WEEE Directive 2012/19/EU and Battery Directive
2006/66/EU
Electrical appliances, batteries and packaging should be supplied to an environmental
friendly recycling. Do not dispose electrical appliances and batteries in the domestic
waste.According to the European directive 2012/19/EC and 2006/66/EC defective
devices or batteries must be collected and recycled.
Integrated batteries may only be removed for disposal by specialist staff. The tightness of the Bosch
TRACI Tag will be destroyed by opening the housing.
Within the European Union any non-functional Bosch TRACI Tags can be disposed at all public
collection points for batteries or electric old devices. The unit, accessories and packaging should be
sorted for environmental friendly recycling. Do not dispose of the device into household waste!
For disposal in countries outside of the European Union
This symbol is only valid in the European Union (EU). For disposal in countries outside of the
European Union, please find out about the legal disposal guidelines and directives applying in this
country. If you wish to discard this product please contact your local authorities or dealer and ask for
the correct method of disposal.

Bosch Asset Tracing Solution | Bosch TRACI Tag
15
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | Jul y 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
3System Description
3.1 System of Interest (SOI)
The TRACI Tag is only available as part of the Bosch Asset Tracing Solution. The content of the Bosch
Asset Tracing Solution is defined individually for each customer in the system description (attachment of
customer contract).
3.2 Hardware and Software interfaces
The TRACI Tag has no electrical hardware interfaces. The mechanical interfaces for mounting are
described in chapter 4.8.2. “Mounting”. All software interfaces are realized via the Bosch Asset
Tracing Solution.

Bosch Asset Tracing Solution | Bosch TRACI Tag
16
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | Jul y 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
4Technical Data
4.1 Functions
ATTRIBUTE
VALUE
Integrated Sensors:
GNSS sensor
3 axis accelerometer
3 axis magnetic field sensor
Temperature sensor
GNSS reception: GPS, GLONASS, EGNOS
GNSS accuracy:
2.5 m CEP
1
Acceleration (range):
± 16 g
Acceleration (resolution): 2g range: 1mg
4g range: 2mg
8g range: 4mg
16g range: 8mg
Magnetic field (range)
± 1300 µT
Magnetic field (resolution) 0.3 µT
Temperature (resolution): 0.5 °C
4.2 Mechanical Characteristics
ATTRIBUTE
VALUE
DESCRIPTION
Robustness Dust & Water: IP 69K 2
Robustness against dust &
p
owerful high temperature
water jets
Robustness Vibration & Shock:
IEC 60721-3-5 class 5M3
3
Robustness against 4 g sine
average
vibrations & 100 g
shock peak
Robustness Impact: IEC 60721-3-5 cl ass 5M2 3
IK 09
4
Robustness against impact
with 10 J
1CEP, 5 0%, 24 hours st at ic, -130 dBm, > 6 SVs
2ISO 20653:2013 “Road vehicles - Degrees of prot ect ion (IP code) - Prot ect ion of elect rical equipment against foreign object s, wat er and acce ss”
3IEC 6072 1 -3-5:1997“CLASSIFICATION OF ENVIRONMENTAL CONDITIONS - Part 3: Classificat ion of groups of environment al paramet er s
and t heir severit ies - Sect ion 5: Ground vehicle inst allat ions“
4EN 50102:1995 “Degrees of prot ect ion provided by enclosures for elect rical equipment against ext ernal mechanical impact s (IK code)”

Bosch Asset Tracing Solution | Bosch TRACI Tag
17
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | Jul y 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
4.3 Electrical Characteristics
ATTRIBUTE
VALUE
Power supply:
3,6 V / 6600 mAh / 23.76 Wh
Antennas: Integrated GNSS, LoRa®, Bluetooth® & NFC™
GNSS Signal: High sensitivity GNSS, 72 channels
LoRa® Communication:
LoRaWAN™ (Low-power wide area network)
LoRa® Frequency Range:
868.1 … 868.5 MHz
LoRa® Transmission Power: <20 mW
Bluetooth® Communication: Bluetooth® 4.2 (EM9304 - BT 5.0 ready)
Bluetooth® Frequency Range:
2.400.0 … 2.483.5 MHz
Bluetooth® Transmission Power:
Max. 5 dBm
NFC™ Communication:
NFC™ passive
NFC™ Frequency Range: 13.56 MHz
4.4 Climate Characteristics
ATTRIBUTE
VALUE
DESCRIPTION
Optimal Operating Temperature Range:
-20 … +55 °C
Optimal Storage Temperature Range: 0 °C … + 40 °C
Robustness: IEC 60721-3-5 class 5K4H 5
Min.:
-25 °C; Max.:+85 °C
4.5 Chemical Characteristics
ATTRIBUTE
VALUE
DESCRIPTION
Battery type: Lithium-Thionyl Chloride Li-
SOCI
2
(non-rechargeable)
Robustness against Chemicals and Fluids IEC 60721-3-5 class 5C2 5&
IEC 60721-3-5 class 5F3 5
Includes salt
mist, salt water
Includes oils, grease, fuel
Housing materials
Polyamid with Glas Fibers;
Stainless Steel
Robustness: IEC 60721-3-5 class 5B3 5
Robustness against mould,
fungus, rodents, termites
5IEC 60721-3-5 : 1997 „CLASSIFICATION OF ENVIRONMENTAL CONDITIONS - Part 3: Classification of groups
of environmental parameters and their severities -Section 5: Ground vehicle installations“

Bosch Asset Tracing Solution | Bosch TRACI Tag
18
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | Jul y 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
4.6 Acoustic characteristics
No appreciable noise
4.7 Lifetime
With respect to the use and usage conditions described in this operating instructions, the life of the
Bosch TRACI Tag is designed for a maximu m of 15,000 GNSS fixes (clear sky, unobstructed line of
sight to satelite, optimal temperature range) & 20,000 LoRa® messages or a maximu m of 3 years
(whichever occurs first).
The commercial warranty and liability is not affected by this and is governed separately by the delivery
conditions.
4.8 Transport, mounting, start and end of operation,
storage
4.8 .1 Transport
The contained lithium batteries are subject to the Dangerous Goods Legislation requirements. The
user can, however, transport the Bosch TRACI Tag by road without specific requirements.
When being transported by third parties (e.g.: air transport or forwarding agency), special
requirements on packaging and labelling must be observed. For preparation of the item being
transported, consulting an expert for hazardous material is required.
No special safety procedures apply to the storage of lithium batteries with low power. When storing
larger amounts (> 7 m ³) attention has to be paid on the regulations for fire prevention (e.g. no
storage with other products and monitoring of rooms with fire detectors).
Please pay special attention to the safety and warning notes!
Notice
Transport
In order to protect the Bosch TRACI Tag the device must be transported in its original packaging
and only be unpacked shortly before mounting.
Bosch TRACI Tags with damaged housing (e.g. dropped during shipment) must not be
used anymore. In case of a damage, please referto chapter2.9 “Disposal and Recycling”.
Devices with used, discharged batteries should be replaced and properly disposed in a
time ly manner.
For any question regarding disposal, please refer to chapte r 2.9 “
Disposal and
Re cycling”.

Bosch Asset Tracing Solution | Bosch TRACI Tag
19
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | Jul y 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
4.8 .2 Mounting
To provide on-board sensor technology’s functionality throughout the entire service life, a permanent
connection between the two housing bushings of the Bosch TRACI Tag and the tagged vehicle,
machine or other asset is necessary.
When mounting the Bosch TRACI Tag, please
make sure that the side with the Bosch Logo is
facing upwards.
To mount of the Bosch TRACI Tag, use M6
scre
ws strength class 8.8 with a ZnNi
coating. The tightening torque should be
9Nm±2Nm. The maximum pre load force of
10kN may not be exceeded. For any affixing
of the Bosch TRACI Tag deviating from this,
it has to be made sure that this connection
bears all loads occurring during usage.
The Bosch TRACI Tag’s housing may only touch
the mounting surface in the zones of the housing
bushings. For this reason, the evenness of the
mounting surface must be ensured. Also, the
mounting of the Bosch TRACI Tag at the two
fixing points must be carried out on the same
mounting structure.
Notice
Mounting the Device
The Bosch TRACI Tag should be mounted in unshielded conditions. It should be mounted more
than 3m away from any atenna.
The responsibility for the device’s permanent fixation to the tagged vehicle, machine or other
asset throughout the entire service life lies with the customer.
Mounting the Bosch TRACI Tag with rivets is not permitted.
The use of washers or spacers sleeves between the housing bushing and screw-on
surface is not permitted.
Mounting the Bosch TRACI Tag simultaneously on 2 or more diffe re nt
surfaces/structures is not permitted.
The material the Bosch TRACI tag gets fixated on has to be sufficiently corrosion-
resistant and has to ensure the safe fixation throughout the entire service life.
Note, that the loads can strongly vary depending on the machine type to be monitored, the
place of action, the installation location, the means of transport and so on.
Info
Accessories
Screws and tools must be purchased separately.

Bosch Asset Tracing Solution | Bosch TRACI Tag
20
Oper a t i n g I n s tr ucti on s | Pri n ted i n G er m a ny | Jul y 2018
Pow ert ra i n Sol u ti on s | R obert Bosch G m bH
4.8 .3 Installation, Configuration & Operation
In order to install, configure and operate the TRACI Tag device, please get in contact with the Bosch
application support via [e-mail].
4.8 .4 Deactivation
In order to deactivate the TRACI Tag device, please get in contact with the Bosch application support
via [e-mail].
4.8 .5 Storage
The optimal storage temperature range is 0°C to 40°C.
Do not store the Bosch TRACI Tag in a place where it is exposed to direct sunlight, high temperatures,
or sources of heat. Failure to do so could result in battery leakage, overheating, or damage. This can
result in burns or other injuries.
No special safety procedures apply to the storage of lithium batteries with low power. For the storage
of larger amounts attention has to be paid on the regulations for fire prevention (e.g. no storage with
other products and the storeroom is to be monitored by a fire detector).
