Bosch UniversalRake 900 User manual
Robert Bosch Power Tools GmbH
70538 Stuttgart
GERMANY
www.bosch-pt.com
F 016 L94 459 (2022.07) O / 37
en Original instructions
ar
fa
F 016 L94 459
UniversalRake 900 |
UniversalVerticut 1100
English | 3
English
Safety Notes
Warning! Read all safety warnings and all instructions.
Make yourself familiar with the controls and the proper
use of the product. Please keep the instructions safe for
later use!
Explanation of symbols on the machine
General hazard safety alert.
Read instruction manual.
Make sure that bystanders are not injured by
foreign
objects being thrown away.
Warning: Keep a safe distance to the product
when operating.
Caution: Do not touch rotating blades. Sharp
blade(s). Beware of severing toes or fingers.
Switch off and remove plug from mains before
adjusting, cleaning or if the cable is entangled
and before leaving the garden tool unattended
for any period. Keep the power cord away from
the raking tines/blades.
Wait until all machine components have com-
pletely stopped before touching them. The
tines/blades continue to rotate after the ma-
chine is switched off, a rotating blade can
cause injury.
Do not use the product in the rain or leave it
outdoors when it is raining.
Beware electric shock hazard.
Keep supply flexible cord away from cutting
means.
Do not use a high-pressure washer or a garden
hose to clean the machine.
Carefully check the area where the tool is to be
used for wildlife and pets. Wildlife and pets
may be injured while the machine is in opera-
tion. Thoroughly check the working area and
remove any stones, sticks, wires, bones and foreign objects.
When using the machine, ensure that no wildlife, pets or
small tree stumps are hidden in the dense grass.
Operation
uNever allow children or people unfamiliar with these in-
structions to use the product. Local regulations may re-
strict the age of the operator. When not in use store the
product out of reach of children.
uNever allow children, persons with physical, sensory or
mental limitations or a lack of experience and/or know-
ledge and/or people unfamiliar with these instructions to
use the product. Local regulations may restrict the age of
the operator.
uNever operate the product when you are tired, ill or under
the influence of alcohol, drugs or medicine.
uNever work while people, especially children, or pets are
nearby.
uChildren should be supervised to ensure that they do not
play with the product.
uThe user is responsible for accidents or hazards occurring
to other people or their property.
uAlways wear hearing protection and safety glasses when
working with the product.
uDo not wear open rubber shoes or sandals when using the
product. Always wear sturdy shoes and long trousers. Do
not use barefoot.
uThoroughly inspect the area where the product is to be
used and remove all stones, sticks, wires, bones and
other foreign objects.
uBefore using, always visually inspect to see that the tines
and tine assembly are not worn, damaged or loose.
uReplace worn or damaged tine and assemblies in sets to
preserve balance. On multi-tined machines, take care as
rotating one tine can cause other tines to rotate.
uWalk, never run.
uRake/Verticut only in daylight or in good artificial light.
uIf possible, avoid using the product on wet grass or take
additional precautions to avoid slipping.
uDo not rake/verticut excessively steep slopes.
uWorking on banks can be dangerous.
Always be sure of your footing on slopes or wet grass.
Rake/Verticut across the face of slopes never up and
down.
− Exercise extreme caution when changing direction on
slopes.
uUse extreme caution when stepping back or pulling the
machine towards you do not overreach and keep balance
at all times.
uAlways push the product forward when raking/verticut-
ting the lawn and never pull it towards the body.
Bosch Power Tools F 016 L94 459 | (25.07.2022)
4 | English
uWait until the tines/blades stop if the machine has to be
tilted for transportation when crossing surfaces other
than grass and when transporting the product to and from
the area to be raked/verticut.
uNever operate the machine with defective guards or
shields, or without safety devices, for example deflectors
and/or grass box in place.
uSwitch on the motor according to the instructions with
feet well away from rotating parts.
uDo not tilt the product when starting or switching on the
motor, except if the machine has to be tilted for starting
in long grass. In this case, do not tilt it more than abso-
lutely necessary and tilt only the part which is away from
the operator. Always ensure that both hands are in the
operating position before returning the machine to the
ground.
uDo not put hands or feet near or under rotating parts.
uAlways stand clear of the discharge zone when operating
the machine.
uNever pick up or carry the machine while the motor is run-
ning.
uWhen storing, make sure that all 4 wheels of the garden
tool stand on the ground/floor.
uOnly lift the garden tool with the carrying handle. Use the
carrying handle with care.
uDo not modify the machine. Unauthorized modifications
can impair the safety of your machine, lead to increased
noise and vibrations, and poor performance.
uBe careful during adjustment of the product to prevent
entrapment of the feet and hands between moving tines/
blades and fixed parts of the machine.
uAvoid operating the product in bad weather conditions
especially when there is a risk of lightning.
uRegularly inspect the machine including the supply cable
and any extension cables for damaged casings, cable
sheaths, exposed wires and cable grips. Do not connect
damaged cables to the supply or touch a damaged cable
before it is disconnected from the supply. A damaged
cable can lead to contact with live parts. Beware electric
shock hazard when inspecting for potential contact
between water and electricity.
uDo not touch the tines before the machine is disconnec-
ted from the supply and the tines have come to a com-
plete stop.
uKeep supply cables and extension cables away from
the tines. The tines can cause damage to the cables and
lead to contact with live parts. Beware electric shock haz-
ard when inspecting for potential contact between water
and electricity.
Additional safety warnings
uPlease read this in conjunction with the instruction
manual.
uUse extreme caution when stepping back or pulling the
machine towards you do not overreach and keep balance
at all times.
uRegularly inspect the machine including the supply cable
and any extension cables for damaged casings, cable
sheaths, exposed wires and cable grips. Do not connect
damaged cables to the supply or touch a damaged cable
before it is disconnected from the supply. A damaged
cable can lead to contact with live parts. Beware electric
shock hazard when inspecting for potential contact
between water and electricity.
uKeep supply cables and extension cables away from
the tines. The tines can cause damage to the cables and
lead to contact with live parts. Beware electric shock haz-
ard when inspecting for potential contact between water
and electricity.
uOnly use this product when connected into a socket
which is protected by a circuit-breaker that would be ac-
tuated by a 30 mA residual current.
uFor electrical safety use a Residual Current Device (RCD)
with a tripping current of not more than 30 mA. Always
check your RCD every time you use it.
Remove the plug from the socket:
– Whenever you leave the machine.
– Before clearing a blockage.
– Before checking, cleaning or working on the machine.
– After striking a foreign object. Inspect the machine for
damage and change the blade as necessary.
– If the machine starts to vibrate abnormally (check imme-
diately).
Connecting to the mains
uThe voltage of the power source must correspond with
the data on the type plate of the product.
uOnly use this product when connected into a socket
which is protected by a circuit-breaker that would be ac-
tuated by a 30 mA residual current.
uOnly use or replace power supply cables for this unit
which correspond to the types indicated by the manufac-
turer. See the operating instructions for the order no. and
types.
uNever touch the mains plug with wet hands.
uDo not run over, crush or pull the power supply cord or
extension cord, otherwise it may be damaged. Protect the
cable from heat, oil and sharp edges.
uThe extension lead must have a cross section in accord-
ance with the operating instructions and be protected
against splashed water. The connection must not be in
water.
uAlways wear gardening gloves when handling or work-
ing near the sharp blade/tines.
Electrical Safety
Warning! Switch the product off and pull the
mains plug before any maintenance or
cleaning. The same applies when the mains
cable is damaged, cut or entangled.
F 016 L94 459 | (25.07.2022) Bosch Power Tools
English | 5
uThe blade/tines continues to rotate for a few seconds
after the machine is switched off.
uCaution do not touch the rotating blade/tines.
Your product is double insulated for safety and requires no
earth connection. The operating voltage is 230V AC, 50Hz
(for non-EU countries 220V, 240V as applicable). Contact
your Bosch Service Centre for details. If in doubt contact a
qualified electrician or the nearest Bosch Service Centre.
uFor electrical safety use a Residual Current Device (RCD)
with a tripping current of not more than 30 mA. Always
check your RCD every time you use it.
Keep the supply cables away from moving hazardous parts
and avoid damage to the cables; this can lead to contact with
live parts.
The connections (plugs and sockets) should be kept dry and
off the ground.
The supply cables must be inspected for signs of damage at
regular intervals and may only be used if in perfect condi-
tion.
If the supply cable on the product is damaged, it must only
be replaced by a Bosch Service Centre. Only use approved
extension cables.
Use only extension cords, cables, leads and cable reels that
comply with EN 61242/IEC 61242 or IEC 60884-2-7 and
are of type H05VV-F or H05RN-F.
If you want to use an extension cable when operating your
product, only the following cable dimensions should be
used:
– Nominal conductor area of 1.25mm2 or 1.5mm2
– Maximum length 30m for a Cord Extension Set or max-
imum length of 60m for a Cable Reel with Residual Cur-
rent Device (RCD).
Note: If an extension cable is used it must be earthed and
connected through the plug to the earth cable of your supply
network in accordance with prescribed safety regulations.
If in doubt contact a qualified electrician or the nearest
Bosch Service Centre.
WARNING! Inadequate extension cables can
be dangerous. Extension cable, plug and
socket must be of watertight construction
and intended for outdoor use.
For products not sold in GB:
WARNING: For your safety, it is required that the plug at-
tached to the product is connected with the extension cord.
The coupling of the extension cord must be protected
against splash water, be made of rubber or coated with rub-
ber. The extension cord must be used with a cable strain re-
lief.
Products sold in GB only:
Your product is fitted with an BS 1363/A approved electric
plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an au-
thorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
Products that are only sold in AUS and NZ: Use a residual
current device (RCD) with a nominal residual current of 30
mA or less.
Maintenance
uAlways wear gardening gloves when handling or work-
ing near the sharp tines/blades.
uKeep all nuts, bolts and screws tight to ensure safe work-
ing with the product.
uCheck the grass box frequently for wear or deterioration.
uInspect the product and replace worn or damaged parts
for safety.
uEnsure replacement parts fitted are Bosch-approved.
uBefore storing, make sure that the product is clean and
free of residue. If necessary, clean with a soft dry brush.
Symbols
The following symbols are important for reading and under-
standing the original instructions. Please take note of the
symbols and their meaning. The correct interpretation of the
symbols will help you to use the product in a better and safer
manner.
Symbol Meaning
Movement direction
Reaction direction
Wear protective gloves
Weight
Switching on
Switching off
Permitted action
Prohibited action
CLICK!
Audible noise
Accessories/Spare Parts
Intended Use
The garden tool is intended for domestic lawn raking, vertic-
utting or aerating.
The garden tool is not intended for hedge cutting, trimming,
shredding, etc.
Bosch Power Tools F 016 L94 459 | (25.07.2022)
6 | English
The garden tool is intended for use at ground level.
Technical Data
Raker/Verticutter UniversalRake 900 UniversalVerticut 1100
Article number 3600H8A0.. 3600H8A1..
Rated power input W 900 1100
Cutting width cm 32 32
Grassbox, capacity l 50 50
Cutting system
– Double wound tines
– Pivoting blades
●
–
–
●
Collection system Jet Collect Jet Collect
Height of cut mm +10/+5/0/-5 +5/0/-5/-10
Weight according to EPTA‑Procedure 01:2014 kg 10.0 10.5
Protection class / II / II
Serial number see type plate on garden tool
The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-specific models.
All values in this manual are measured for usage below or equal to 2000 meters above nominal sea level.
Noise/Vibration Information
3600H8A0.. 3600H8A1..
Noise emission values determined according to EN 50636-2-92.
Typically the A-weighted noise levels of the product are:
– Sound pressure level dB(A) 81 80
– Uncertainty K dB = 2.5 = 2.5
– Sound power level dB(A) 94 94
– Uncertainty K dB = 1.0 = 2.0
Vibration total values ah (triax vector sum) and uncertainty K determined according to EN 50636-2-92
– Vibration emission value ahm/s24.0 2.9
– Uncertainty K m/s2= 1.6 = 1.5
Mounting and Operation
uDo not connect the product to the mains socket before
it is completely assembled.
Action Figure Page
Delivery scope A24
Assembly
Connecting the extension cable
B24
Assembling the grassbox C25
Grassbox assembly D25
Adjusting the working height E26
Switching On and Off UniversalRake
900 F26
Action Figure Page
Switching On and Off UniversalVerti-
cut 1100 G27
Maintenance, Cleaning and Storage H27
F 016 L94 459 | (25.07.2022) Bosch Power Tools
English | 7
Working Advice
Raking/Verticutting
Place the product on the
edge of the lawn, as close to
the mains socket as pos-
sible. Work away from the
mains socket.
Position the cable to oppos-
ite side (already raked/ver-
ticut lawn) at the end of
each turn.
When raking/verticutting do
not overload the motor.
UniversalRake 900:
In case of overload, the speed of the motor drops and the
motor sound changes. In this case, stop, release the start/
stop lever and adjust to a higher working height. Failure to
do so could damage the machine.
UniversalVerticut 1100:
The motor is protected by a safety cut out, which is activated
when the blades become jammed, clogged or if the motor is
overloaded. When this occurs, switch the product off.
The safety cut out is only reset when the start/stop lever is
released.
Pull the mains plug, remove any blockages and wait one
minute before restarting the product so that the safety cut
out can reset itself.
uAlways wear gardening gloves when handling or work-
ing near the sharp tines/blades.
Note: When waiting for a reset of the safety cut out and actu-
ating the start/stop lever too early with the product plugged
into the socket outlet, the reset time of the safety cut out will
increase.
If the product cuts out again, increase the working height or
postpone use until conditions improve. Please refer to the
Trouble Shooting Chart" and "Raking/Verticutting Tips".
Raking/Verticutting Tips
Optimum conditions for raking/verticutting are when the
grass is short and slightly moist. Raking or verticutting the
lawn when the soil is very soft or hard can damage it and
cause the product to collect poorly.
– Kill moss with a commercially-available moss killer before
raking/verticutting.
– Start the product at the highest working height and lower
it as required.
– Rake/Verticut the lawn in the one direction, then proceed
at right angles a week later until the whole lawn has been
completed.
– Depending on the condition of the lawn, raking/verticut-
ting moss and dead plant parts can lead to ragged and
bare patches.
Note: In conditions with excessive tree debris (e.g. leaves,
twigs, etc.), first clear the surface by using the product with
the working height set to 3 or 4.
For best results mow the lawn before reseeding. Promote
the spread of grass into bare and weak areas with good qual-
ity lawn seed after raking/verticutting. Allow fresh grass
seed to root and establish before fertilising, where neces-
sary water to prevent fresh seeds drying out.
Ideal times for raking/verticutting are spring and late au-
tumn.
Lawns can also be maintained by raking/verticutting on a
higher setting after every six cuts.
Troubleshooting
The following chart lists problem symptoms, possible causes and corrective action, if your product does not operate properly.
If these do not identify and correct the problem, contact your service agent.
uWarning: Switch off and remove plug from mains be-
fore investigating fault.
Problem Possible Cause Corrective Measure
Garden tool does not
operate Power turned off Turn power on
Mains socket faulty Use other socket
Extension cable damaged Inspect cable, replace if damaged
Fuse faulty / blown If fuse blows continuously, please check your
electricity supply system or contact Bosch cus-
tomer service agent
Possible clog Check underneath the garden product and clear
out as necessary (always wear protective gloves)
Safety cut out is active (only UniversalVerti-
cut1100) See below A)
Bosch Power Tools F 016 L94 459 | (25.07.2022)
8 | English
Problem Possible Cause Corrective Measure
Setting for raking/verticutting too low for the con-
ditions Increase working height
Obstructed rotor Clear obstruction (always wear protective gloves)
Blocked side grilles Clear debris from the outside of the side grilles
Grassbox full Empty the grassbox regularly
Garden tool runs inter-
mittently Extension cable damaged Inspect cable, replace if damaged
Internal wiring of garden tool defective Contact Bosch customer service agent
Worn/Missing tines/blades Contact Bosch customer service agent
Conditions too wet Increase working height (see "Tips for Raking/Ver-
ticutting Lawns")
Too much debris on the ground See below A)
Possible clog Check underneath the garden tool and clear out
as necessary (always wear protective gloves)
Setting for raking/verticutting too low for the con-
ditions Increase working height
Grass too long Cut grass
Very uneven surface Increase working height
Grassbox full Empty the grassbox regularly
Garden tool runs stiffly
or belt squeaks Working height too low Increase working height (see "Adjusting the Work-
ing Height")
Cutting tines/blades
not rotating Cutting tines/blades obstructed by grass Clear obstruction (always wear protective gloves)
Belt slipping or damaged Contact Bosch customer service agent
Excessive vibrations/
noise Cutting tines/blades damaged Contact Bosch customer service agent
Poor work perform-
ance Ground too moist for raking/verticutting Increase working height (see "Tips for Raking/Ver-
ticutting Lawns")
Setting for raking/verticutting too low for the con-
ditions Increase working height
Possible clog Check underneath the garden tool and clear out
as necessary (always wear protective gloves)
Blocked side grilles Clear debris from the outside of the side grilles
Missing tines (only UniversalRake900) Contact Bosch customer service agent
A) In conditions with excessive tree debris (e.g. leaves, twigs, etc.), first clear the surface by using the product with the working height set to
3 or 4.
Maintenance and Service
After-Sales Service and Application Service
Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. You can find explosion drawings and information on
spare parts at: www.bosch-pt.com
The Bosch product use advice team will be happy to help you
with any questions about our products and their accessor-
ies.
In all correspondence and spare parts orders, please always
include the 10‑digit article number given on the nameplate
of the product.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham Uxbridge
UB 9 5HJ
At www.bosch-pt.co.uk you can order spare parts or arrange
the collection of a product in need of servicing or repair.
Tel. Service: (0344) 7360109
E-Mail: [email protected]
You can find further service addresses at:
www.bosch-pt.com/serviceaddresses
F 016 L94 459 | (25.07.2022) Bosch Power Tools
English | 9
Disposal
The product, accessories and packaging should be sorted
for environmental-friendly recycling.
Do not dispose of products into household
waste!
Only for EU countries:
According to the European Directive 2012/19/EU on Waste
Electrical and Electronic Equipment and its implementation
into national law, power tools that are no longer usable must
be collected separately and disposed of in an environment-
ally friendly manner.
If disposed incorrectly, waste electrical and electronic
equipment may have harmful effects on the environment and
human health, due to the potential presence of hazardous
substances.
Only for United Kingdom:
According to The Waste Electrical and Electronic Equipment
Regulations 2013 (SI 2013/3113) (as amended), products
that are no longer usable must be collected separately and
disposed of in an environmentally friendly manner.
Bosch Power Tools F 016 L94 459 | (25.07.2022)
10 |
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
F 016 L94 459 | (25.07.2022) Bosch Power Tools
| 11
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
Bosch Power Tools F 016 L94 459 | (25.07.2022)
12 |
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
F 016 L94 459 | (25.07.2022) Bosch Power Tools
| 13
CLICK!
UniversalRake 900UniversalVerticut 1100
3600H8A0..3600H8A1..
9001100
3232
5050
●
–
–
●
Jet CollectJet Collect
5- / 0 / 5+ / 10+10- / 5- / 0 / 5+
10,010,5
II / II /
. . 230 [ U ]
. 2000
t
A
24
B
24
C
25
D
25
E
26
F
26
G
27
H
27
Bosch Power Tools F 016 L94 459 | (25.07.2022)
14 |
t
t
F 016 L94 459 | (25.07.2022) Bosch Power Tools
| 15
Bosch Power Tools F 016 L94 459 | (25.07.2022)
16 |
F 016 L94 459 | (25.07.2022) Bosch Power Tools
| 17
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
Bosch Power Tools F 016 L94 459 | (25.07.2022)
18 |
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
F 016 L94 459 | (25.07.2022) Bosch Power Tools
| 19
t
t
t
t
t
t
t
t
t
t
t
t
t
t
Bosch Power Tools F 016 L94 459 | (25.07.2022)
20 |
CLICK!
UniversalRake 900UniversalVerticut 1100
3600H8A0..3600H8A1..
W9001100
cm3232
l5050
●
–
–
●
Jet CollectJet Collect
+10/+5/0/-5+5/0/-5/-10
kg10.010.5
II / II /
. . 230 [U]
. 2000
t
A
24
B
24
C
25
D
25
E
26
F
26
G
27
H
27
F 016 L94 459 | (25.07.2022) Bosch Power Tools
Other manuals for UniversalRake 900
2
This manual suits for next models
1
Table of contents
Languages:
Other Bosch Lawn Mower manuals
Bosch
Bosch CityMower 18 User manual
Bosch
Bosch ALM 34 User manual
Bosch
Bosch ARM 3200 User manual
Bosch
Bosch Rotak 32 User manual
Bosch
Bosch INDEGO 350 User manual
Bosch
Bosch Rotak 32 User manual
Bosch
Bosch Rotak 34 R User manual
Bosch
Bosch Easy Mower 18V-32-200 User manual
Bosch
Bosch EasyMower 18V-32-150 User manual
Bosch
Bosch Indego User manual
Bosch
Bosch INDEGO 400 User manual
Bosch
Bosch Rotak 400 ER User manual
Bosch
Bosch ARM 320 User manual
Bosch
Bosch AHM 30 User manual
Bosch
Bosch ALR 900 User manual
Bosch
Bosch ALR 900 User manual
Bosch
Bosch INDEGO 350 Use and care manual
Bosch
Bosch Rotak 36 LI User manual
Bosch
Bosch Rotak 32 LI S User manual
Bosch
Bosch Rotak User manual
