Bosch UFLED User manual

AEGIS UFLED
UFLED
en Installation Manual

AEGIS UFLED Table of Contents | en 3
Bosch Security Systems Installation Manual F.01U.123.987 | 1.0 | 2010.04
Table of Contents
1Safety 4
1.1 Safety precautions 4
1.2 Important safety instructions 4
1.3 Important notices 5
1.4 Notifications 7
1.5 Certifications 8
1.6 FCC & ICES compliance 8
1.7 UL certification 10
1.8 Bosch notices 12
2Overview 13
2.1 Features 13
2.2 Lens / Beam pattern matching 13
2.3 Achievable distances 14
3 Installation 15
3.1 Setting up 15
3.2 Connections 17
3.2.1 Telemetry input connection 19
3.2.2 Day/Night switching output connection 19
3.2.3 Photocell Sensitivity 19
3.2.4 Power adjustment 20
3.3 Remote Switching 20
3.3.1 Camera (or other switching device) Leading 20
3.3.2 Looping Multiple Illuminators 21
3.3.3 Illuminator Leading 21
4 Specifications 22
4.1 Dimensions 23

4en | Safety AEGIS UFLED
F.01U.123.987 | 1.0 | 2010.04 Installation Manual Bosch Security Systems
1Safety
1.1 Safety precautions
1.2 Important safety instructions
Read, follow, and retain for future reference all of the following
safety instructions. Heed all warnings on the unit and in the
operating instructions before operating the unit.
1. Cleaning - Generally, using a dry cloth for cleaning is
sufficient but a moist, fluff-free cloth or leather shammy
may also be used. Do not use liquid cleaners or aerosol
cleaners.
2. Heat Sources - Do not install the unit near any heat
sources such as radiators, heaters, stoves, or other
equipment (including amplifiers) that produce heat.
3. Liquids - Never spill liquid of any kind, other than water, on
the unit.
4. Lightning - Take precautions to protect the unit from
power and lightning surges.
DANGER!
High risk: This symbol indicates an imminently hazardous
situation such as “Dangerous Voltage” inside the product.
If not avoided, this will result in an electrical shock, serious
bodily injury, or death.
WARNING!
Medium risk: Indicates a potentially hazardous situation.
If not avoided, this could result in minor or moderate bodily
injury.
CAUTION!
Low risk: Indicates a potentially hazardous situation.
If not avoided, this could result in property damage or risk of
damage to the unit.

AEGIS UFLED Safety | en 5
Bosch Security Systems Installation Manual F.01U.123.987 | 1.0 | 2010.04
5. Controls adjustment - Adjust only those controls specified
in the operating instructions. Improper adjustment of
other controls may cause damage to the unit.
6. Power sources - Operate the unit only from the type of
power source indicated on the label.
7. Servicing - Unless qualified, do not attempt to service this
unit yourself. Refer all servicing to qualified service
personnel.
8. Replacement parts - Use only replacement parts specified
by the manufacturer.
9. Installation - Install in accordance with the manufacturer's
instructions and in accordance with applicable local codes.
10. Attachments, changes or modifications - Only use
attachments/accessories specified by the manufacturer.
Any change or modification of the equipment, not
expressly approved by Bosch, could void the warranty or,
in the case of an authorization agreement, authority to
operate the equipment.
1.3 Important notices
Grounding - For mounting the unit in potentially damp
environments, ensure to ground the system using the ground
connection of the power supply connector (see section:
Connecting external power supply).
WARNING!
When the lamp is running it is hot to the touch. Before touching
switch off the illuminator and allow to cool for a minimum
period of 10 minutes.
WARNING!
LED Radiation
Do not view directly with optical instruments (magnifiers).
Do not stare directly into the lamp at a distance of less than
1.7 m (5.6 ft).

6en | Safety AEGIS UFLED
F.01U.123.987 | 1.0 | 2010.04 Installation Manual Bosch Security Systems
U.S.A. models only - Section 810 of the National Electrical Code,
ANSI/NFPA No.70, provides information regarding proper
grounding of the mount and supporting structure, grounding of
the coax to a discharge unit, size of grounding conductors,
location of discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode.
Environmental statement - Bosch has a strong commitment
towards the environment. This unit has been designed to
respect the environment as much as possible.
Disposal - Your Bosch product was developed and
manufactured with high-quality material and components that
can be recycled and reused. This symbol means that electronic
and electrical appliances, which have reached the end of their
working life, must be collected and disposed of separately
from household waste material. Separate collecting systems
are usually in place for disused electronic and electrical
products. Please dispose of these units at an environmentally
compatible recycling facility, per European Directive 2002/96/
EC
CAUTION!
Class I LED Product
Invisible LED radiation when open (850 nm and 940 nm
models). Avoid exposure to beam.

AEGIS UFLED Safety | en 7
Bosch Security Systems Installation Manual F.01U.123.987 | 1.0 | 2010.04
1.4 Notifications
NOTICE! Class 3R notification for 850 nm models
The product is tested and compliant to IEC/EN 60825-1 (2001)
under normal operating conditions, and is classified as a Class
3R LED product. The measured output under the thermal
hazard test (Class 1/3R) was 36.9 mW, peak at 850 nm
wavelength.
The following notification label is placed on the side of the
product:
NOTICE! Class 1M notification for 940nm models
The product is tested and compliant to IEC/EN 60825-1 (2001)
under normal operating conditions, and is classified as a Class
1M LED product. The measured output under the thermal
hazard test (Class 1M) was 22.7mW, peak at 940nm
wavelength. No notification label is placed on the product.

8en | Safety AEGIS UFLED
F.01U.123.987 | 1.0 | 2010.04 Installation Manual Bosch Security Systems
1.5 Certifications
This product complies with European Directive 89/336/EEC and
73/23/EEC Low Voltage Directive meeting the following
standards:
1.6 FCC & ICES compliance
FCC & ICES Information
(U.S.A. and Canadian Models Only)
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
– reorient or relocate the receiving antenna;
Safety Electrical Safety: IEC/EN60598-2-5
C22.2 No. 250.0-08
UL 1598
UL 2108
Eye Safety: IEC/EN60825-1
EMC Radiated and Conducted
Emissions
EN55022:1998
ICES-003 Issue 4:2004
Immunity EN50130-4:1995
FCC CFR 47:2007 Part 15.107 &
15.109 CLASS B LIMIT
IP Ingress Protection P67 in accordance with BS
EN60529:1992

AEGIS UFLED Safety | en 9
Bosch Security Systems Installation Manual F.01U.123.987 | 1.0 | 2010.04
– increase the separation between the equipment and
receiver;
– connect the equipment into an outlet on a circuit different
from that to which the receiver is connected;
– consult the dealer or an experienced radio/TV technician
for help.
Intentional or unintentional modifications, not expressly
approved by the party responsible for compliance, shall not be
made. Any such modifications could void the user's authority to
operate the equipment. If necessary, the user should consult
the dealer or an experienced radio/television technician for
corrective action.
The user may find the following booklet, prepared by the
Federal Communications Commission, helpful: How to Identify
and Resolve Radio-TV Interference Problems. This booklet is
available from the U.S. Government Printing Office,
Washington, DC 20402, Stock No. 004-000-00345-4.
Informations FCC et ICES
(modèles utilisés aux États-Unis et au Canada uniquement)
Suite à différents tests, cet appareil s'est révélé conforme aux
exigences imposées aux appareils numériques de classe B, en
vertu de la section 15 du règlement de la Commission fédérale
des communications des États-Unis (FCC), et en vertu de la
norme ICES-003 d'Industrie Canada. Ces exigences visent à
fournir une protection raisonnable contre les interférences
nuisibles lorsque l'appareil est utilisé dans le cadre d'une
installation résidentielle. Cet appareil génère, utilise et émet
de l'énergie de radiofréquences et peut, en cas d'installation ou
d'utilisation non conforme aux instructions, engendrer des
interférences nuisibles au niveau des radiocommunications.
Toutefois, rien ne garantit l'absence d'interférences dans une
installation particulière. Il est possible de déterminer la
production d'interférences en mettant l'appareil
successivement hors et sous tension, tout en contrôlant la
réception radio ou télévision. L'utilisateur peut parvenir à

10 en | Safety AEGIS UFLED
F.01U.123.987 | 1.0 | 2010.04 Installation Manual Bosch Security Systems
éliminer les interférences éventuelles en prenant une ou
plusieurs des mesures suivantes:
– Modifier l'orientation ou l'emplacement de l'antenne
réceptrice;
– Éloigner l'appareil du récepteur;
– Brancher l'appareil sur une prise située sur un circuit
différent de celui du récepteur;
– Consulter le revendeur ou un technicien qualifié en radio/
télévision pour obtenir de l'aide.
Toute modification apportée au produit, non expressément
approuvée par la partie responsable de l'appareil, est
strictement interdite. Une telle modification est susceptible
d'entraîner la révocation du droit d'utilisation de l'appareil.
La brochure suivante, publiée par la Commission fédérale des
communications (FCC), peut s'avérer utile : How to Identify and
Resolve Radio-TV Interference Problems (Comment identifier et
résoudre les problèmes d’interférences de radio et de télévision).
Cette brochure est disponible auprès du U.S. Government
Printing Office, Washington, DC 20402, États-Unis, sous la
référence n° 004-000-00345-4.
1.7 UL certification
Disclaimer
Underwriter Laboratories Inc. (“UL”) has not tested the
performance or reliability of the security or signaling aspects of
this product. UL has only tested fire, shock and/or casualty
hazards as outlined in UP's Standard(s) for Safety for Closed
Circuit Television Equipment, UL 2044. UL Certification does not
cover the performance or reliability of the security or signaling
aspects of this product.
UL MAKES NO REPRESENTATIONS, WARRANTIES, OR
CERTIFICATIONS WHATSOEVER REGARDING THE
PERFORMANCE OR RELIABILITY OF ANY SECURITY OR
SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.

AEGIS UFLED Safety | en 11
Bosch Security Systems Installation Manual F.01U.123.987 | 1.0 | 2010.04
Disclaimer
Underwriter Laboratories Inc. (“UL”) has not tested the
performance or reliability of the security or signaling aspects of
this product. UL has only tested fire, shock and/or casualty
hazards as outlined in UP's Standard(s) for Safety for Information
Technology Equipment, UL 60950-1. UL Certification does not
cover the performance or reliability of the security or signaling
aspects of this product.
UL MAKES NO REPRESENTATIONS, WARRANTIES, OR
CERTIFICATIONS WHATSOEVER REGARDING THE
PERFORMANCE OR RELIABILITY OF ANY SECURITY OR
SIGNALING-RELATED FUNCTIONS OF THIS PRODUCT.

12 en | Safety AEGIS UFLED
F.01U.123.987 | 1.0 | 2010.04 Installation Manual Bosch Security Systems
1.8 Bosch notices
Copyright
This manual is the intellectual property of Bosch Security
Systems and is protected by copyright. All rights reserved.
Trademarks
All hardware and software product names used in this
document are likely to be registered trademarks and must be
treated accordingly.
Note:
This manual has been compiled with great care and the
information it contains has been thoroughly verified. The text
was complete and correct at the time of printing. The ongoing
development of the products may mean that the content of the
user guide can change without notice. Bosch Security Systems
accepts no liability for damage resulting directly or indirectly
from faults, incompleteness or discrepancies between the user
guide and the product described.
More information
For more information please contact the nearest Bosch Security
Systems location or visit www.boschsecurity.com

AEGIS UFLED Overview | en 13
Bosch Security Systems Installation Manual F.01U.123.987 | 1.0 | 2010.04
2Overview
2.1 Features
The AEGIS UFLED range of infrared and white light illuminators
for CCTV, features patent-pending illumination technology and
installation friendly design.
– Patent pending Constant Light technology automatically
compensates for LED degradation to deliver a constant
level of lighting performance for the life of the illuminator
– 3D Diffuser technology enables increased surveillance
range, wider beam patterns and evenly illuminated night-
time images
– Energy efficient, low voltage operation means quick and
easy installation
– High efficiency surface mount LEDs deliver improved
thermal management, long life and low cost of ownership
– Semi-covert, covert and visible white light versions
available
– Easy integration with day/night cameras with relay
contacts COM/NC/NO that indicate whether the photocell
has activated the illuminator
– Telemetry input connection allows illuminator to be
switched via a voltage free relay contact from a day/night
camera signal, remote signal or PIR.
– Pressure equalisation valve prevents thermal expansion
and pressure cycling problems within the illuminator head.
2.2 Lens / Beam pattern matching
The illuminator should be matched to the scene and the camera
lens focal length. Before installation ensure that the illuminator
has been correctly specified to support the CCTV system. When
planning a system take into account the achievable distances,
the lens/beam pattern and filters.

14 en | Overview AEGIS UFLED
F.01U.123.987 | 1.0 | 2010.04 Installation Manual Bosch Security Systems
2.3 Achievable distances
Illumination distance achievable depend on the characteristics
of the CCD camera and lens used.
Notes:
Achievable distance is based on a 20dB s/n ratio using a 1/2-in.
Ex-View CCD and F1.4 lens aperture.
Wavelength at 850 nm infrared is semi-covert, 940 nm is covert,
and white light is visible.
Product Code Wave-
length
Beam
Angle
Achievable Distance HOV
UFLED10-8BD 850 10 220 m (720 ft) 40 m (125 ft)
UFLED20-8BD 850 20 150 m (490 ft) 55 m (175 ft)
UFLED30-8BD 850 30 110 m (360 ft) 60 m (195 ft)
UFLED60-8BD 850 60 70 m (230 ft) 80 m (265 ft)
UFLED95-8BD 850 95 50 m (165 ft) 110 m (360 ft)
UFLED120-8BD 850 120 35 m (115 ft) 120 m (400 ft)
SLED10-9BD 940 10 135 m (440 ft) 25 m (80 ft)
UFLED20-9BD 940 20 80 m (260 ft) 28 m (100 ft)
UFLED30-9BD 940 30 65 m (210 ft) 35 m (115 ft)
UFLED60-9BD 940 60 40 m (130 ft) 45 m (145 ft)
UFLED95-9BD 940 95 30 m (100 ft) 65 m (210 ft)
UFLED120-9BD 940 120 20 m (65 ft) 70 m (230 ft)
UFLED10-WBD White 10 60 m (195 ft) 10 m (30 ft)
UFLED20-WBD White 20 40 m (130 ft) 15 m (50 ft)
UFLED30-WBD White 30 35 m (115 ft) 20 m (65 ft)
UFLED60-WBD White 60 25 m (80 ft) 30 m (100 ft)
UFLED95-WBD White 95 20 m (65 ft) 45 m (150 ft)
UFLED120-WBD White 120 15 m (50 ft) 50 m (165 ft)

AEGIS UFLED Installation | en 15
Bosch Security Systems Installation Manual F.01U.123.987 | 1.0 | 2010.04
3 Installation
3.1 Setting up
Set up the unit correctly to obtain the best performance.
Optimum results are achieved by setting up at night and
viewing the results on a monitor. Use the illustration below to
assist with installation.
Figure 3.1 Installing an AEGIS UFLED lamp
1 Nearest point
2 Furthest object
CAUTION!
When the unit has been operating for a while it becomes hot.
Switch off the illuminator and allow it to cool for a minimum of
10 minutes before touching.
Do not look directly into the unit at a distance of less than
1.7 m.

16 en | Installation AEGIS UFLED
F.01U.123.987 | 1.0 | 2010.04 Installation Manual Bosch Security Systems
1. Attach the illuminator to a pan and tilt unit, wall bracket or
camera housing as required.
2. Connect the illuminator to a 12–24 VDC or to a 24 VAC
(±15%, 50/60 Hz) power supply.
3. Commission the mains supply, camera, and monitoring
control equipment.
4. Adjust the pan of the illuminator to match the camera’s
field of view.
5. Loosen the bolts on each side of the unit and adjust the
vertical alignment to maximize the results; re-tighten the
bolts.
6. Tilt the unit downwards until the near part of required field
of view is saturated with light as viewed on the monitor.
7. Slowly tilt the unit upwards until the furthest part of the
required field of view is illuminated correctly on the
monitor.

AEGIS UFLED Installation | en 17
Bosch Security Systems Installation Manual F.01U.123.987 | 1.0 | 2010.04
3.2 Connections
Figure 3.2 AEGIS Illuminator Rear Panel
1 Photocell 5 IR Power Adjustment
2 Pressure Equalization
Vent
6 Power Input 12 VDC/24 VAC
3 Day/Night Camera
Switching
7 Photocell Sensitivity
Adjustment
4 Telemetry Input

18 en | Installation AEGIS UFLED
F.01U.123.987 | 1.0 | 2010.04 Installation Manual Bosch Security Systems
Figure 3.3 Wiring diagram
Type of Connection Cable Color
1 AC/DC Power In 4 Brown cable
2 Telemetry 5 White cable
3 Volt Free Day/Night Switching 6 Black
7 Blue
12
34
12
34
12
34
N/O
COM
N/C

AEGIS UFLED Installation | en 19
Bosch Security Systems Installation Manual F.01U.123.987 | 1.0 | 2010.04
3.2.1 Telemetry input connection
The illuminator can be activated remotely by a remote switching
device, camera signal or PIR.
The telemetry input connection is a Normally Open (NO)
contact that is switched by a volt-free contact across pins 1
(brown) and 3 (blue) of the connector cable. For this function
to work correctly, the photocell must be disabled so that the
illuminator is continuously On.
Check that the switching device contacts are closed when the
illuminator is Off and open when the illuminator is On.
3.2.2 Day/Night switching output connection
The day/night output can be used to switch a day/night camera
to its monochrome night mode if the illuminator is switched On.
To use this function, it is necessary to determine if the camera
requires an NO or an NC circuit to switch into its night mode.
Use the telemetry cables to link the brown and blue wires to
the camera switching input if a NO circuit is required to activate
the night mode. If a NC signal is required to activate the night
mode, use the brown and black wires.
3.2.3 Photocell Sensitivity
To adjust photocell sensitivity first remove the sealing cap, then
adjust the potentiometer to turn the lamp on at the desired
lighting conditions.
Disabling the photocell
Turn the photocell fully clockwise to disable the photocell. The
lamp will remain on all the time unless the telemetry input is
closed circuit.
Photocell OperationThe photocell is designed to automatically
switch the lamps ON at dusk and turn OFF at dawn. A high
degree of hysteresis is incorporated to avoid ON/OFF switching
in marginal light conditions.
NOTICE!
Replace the sealing cap after adjustment to ensure water
ingress protection.

20 en | Installation AEGIS UFLED
F.01U.123.987 | 1.0 | 2010.04 Installation Manual Bosch Security Systems
Note:
Potentiometer Factory set at mid-point 500 Lux ON and 850 Lux
OFF (approximately).
Check the photocell functions by covering with black tape and
having the telemetry link closed. The photocell operation has an
in-built delay of up to 5 seconds.
3.2.4 Power adjustment
To adjust power, first unscrew the sealing cap; the
potentiometer is set at the maximum calibration point (fully
clockwise). To decrease the power, turn the potentiometer
counter clockwise.
3.3 Remote Switching
Various switching configurations can be made using an
interface cable. Commonly used switching configurations are
explained below.
3.3.1 Camera (or other switching device) Leading
The illuminator may be activated remotely by a volt-free contact
latched across the TELEMETRY input. Use interface cable
UFLED-CI-5M.
NOTICE!
Replace the sealing cap after adjustment to ensure water
ingress protection.
1 UFLED Illuminator
2Camera
3 UFLED-CI-5M
