Bosch PVA-1KS User manual

Communications Systems - PVA-1KS Call station key switch
PVA-1KS Call station key switch
PAVIRO
uKey switch for call station
uEN 54-16 system certification
The PVA-1KS Call station key switch is an optional key
switch that can be installed in the PVA-15CST Call
station. The feed lines of the key switch are monitored
for short-circuits and interruptions. For more
information, refer to the call station manual.
Certifications and approvals
Emergency standard certifications
Europe EN54‑16
Emergency standard compliance
UK BS 5839-8
Austria ÖNORMF3033
Environmental directive compliance
Safety EN62368-1
Immunity EN 50130-4
Emissions EN 61000-6-3
ICES-003
FCC-47 part 15B class A
Environment EN 50581
Maritime EN 60945
Conformity
Europe CE/CPR
Conformity
Australia RCM
Environment RoHS
Installation/configuration notes
Assembly in call station
1. Disconnect the call station from all connectors.
2. Unscrew the call station baseplate.
3. Unplug the connection cable from the CN1 plug
connector.
4. Prepare the installation location. Use a sharp ob-
ject (knife, scriber, or similar) to carefully punch
through and cut out the pre-cut circle on the back
housing. Perform any follow-up work that may be
required to the installation location (e.g. filing,
trimming).
5. Bore through the pre-cut side opening for the
holding pin of the key switch cover.
6. Align the switch and screw tightly in place with
the supplied knurled screw.
7. The supplied 4-pin cable and the resistors must be
connected as shown in the following figures, de-
pending on the intended purpose of the key
switch.

Communications Systems - PVA-1KS Call station key switch 2 | 3
i
Notice
Connect the key switch as shown in the follow-
ing figure (normally closed contact, NCC) to
lock the call station via the key switch!
8. Note the connection sequence of the ribbon
cable. The two external cables 1 (red) and 4
(green) must be cut as close to the cut-off point
as possible and isolated. The two internal cables 2
(green) and 3 (green) must be soldered to switch
connections 3 and 4. The polarity is not important.
9. Depending on whether the right/middle/left in-
stallation location will be used, plug the ribbon
cable into plug connector CN201/CN202/CN203
on the circuit board.
10. Plug the connecting cable into CN1 again.
11. Re-attach the call station baseplate.
12. Attach the connections.
13. Configure the key switch in IRIS-Net.
R2
10k
1 rt
2 gr
3 gr
4 gr
CN1-4
CN1-3
CN1-2
CN1-1
1
2R1
10k
3
4
Fig.1: Connecting the key switch as normally closed
contact (NCC) for key lock function
R2
10k
1 rt
2 gr
3 gr
4 gr
CN1-4
CN1-3
CN1-2
CN1-1
1
2R1
10k
3
4
Fig.2: Connecting the key switch as normally open
contact (NOC) for special purposes
Parts included
Quantity Component
1Key switch
1Preconfigured 4-pin connecting cable
2Resistor 10 kΩ
1Installation note
Technical specifications
Mechanical
Product dimensions (Height x Width
x Depth)
45mm x 19mm x 24mm
Net weight 0.03kg
Shipping weight 0.04kg
Environmental
Operating temperature -5°C to +45°C (+23°F to +113°F)
Storage and transport temperature -25°C to +70°C (-13°F to +158°F)
Humidity (non-condensing) 5% to 90%
Altitude Up to 2000 m
Ordering information
PVA-1KS Call station key switch
Optional key switch that can be installed in the
PVA-15CST Call station.
Order number PVA-1KS | F.01U.397.468 F.01U.312.984
Services
EWE-PAIOCS-IW 12 mths wrty ext. Plena all-in-1 cal
12 months warranty extension
Order number EWE-PAIOCS-IW | F.01U.360.713

Communications Systems - PVA-1KS Call station key switch 3 | 3
