Bosch IXO Professional User manual

Robert Bosch GmbH
Power Tools Division
70745 Leinfelden-Echterdingen
Germany
www.bosch-pt.com
2 609 140 837 (2011.01) O / 122 ASIA
IXO Professional
en Original instructions
cn 正本使用说明书
tw 正本使用說明書
ko 사용 설명서 원본
th หนังสือคูมือการใชงานฉบับตนแบบ
id Petunjuk-Petunjuk untuk
Penggunaan Orisinal
vi BΩng hõëng dÿn nguy›n bΩn
OBJ_DOKU-24634-002.fm Page 1 Wednesday, March 2, 2011 8:23 AM

2 609 140 837 | (2.3.11) Bosch Power Tools
2|
English . . . . . . . . . . . . . . . Page 7
中文 . . . . . . . . . . . . . . . . . . . . . . . . . 页27
中文. . . . . . . . . . . . . . . . . . . . . . . . . 頁40
한국어 . . . . . . . . . . . . . . . . . . . . .면 53
ภาษาไทย. . . . . . . . . . . . . . . . . . . . . หนา 67
Bahasa Indonesia. . . . Halaman 84
Tiøng Vi·t . . . . . . . . . . . . . . Trang 104
OBJ_BUCH-1384-002.book Page 2 Wednesday, March 2, 2011 8:34 AM

| 3
Bosch Power Tools 2 609 140 837 | (2.3.11)
A
IXO
11
5
1
2
3
56
10
4
97
8
OBJ_BUCH-1384-002.book Page 3 Wednesday, March 2, 2011 8:34 AM

2 609 140 837 | (2.3.11) Bosch Power Tools
4|
C
B
1
3
2
1
OBJ_BUCH-1384-002.book Page 4 Wednesday, March 2, 2011 8:34 AM

| 5
Bosch Power Tools 2 609 140 837 | (2.3.11)
E
D
14
13
15
12
16
OBJ_BUCH-1384-002.book Page 5 Wednesday, March 2, 2011 8:34 AM

2 609 140 837 | (2.3.11) Bosch Power Tools
6|
F
3
G
11
OBJ_BUCH-1384-002.book Page 6 Wednesday, March 2, 2011 8:34 AM

English | 7
Bosch Power Tools 2 609 140 837 | (2.3.11)
en
Safety Notes
General Power Tool Safety Warnings
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or seri-
ous injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
b) Do not operate power tools in explosive atmos-
pheres, such as in the presence of flammable liq-
uids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operat-
ing a power tool. Distractions can cause you to lose
control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapt-
er plugs with earthed (grounded) power tools. Un-
modified plugs and matching outlets will reduce
risk of electric shock.
WARNING
OBJ_BUCH-1384-002.book Page 7 Wednesday, March 2, 2011 8:34 AM

2 609 140 837 | (2.3.11) Bosch Power Tools
8| English
b) Avoid body contact with earthed or grounded sur-
faces, such as pipes, radiators, ranges and refrig-
erators. There is an increased risk of electric shock
if your body is earthed or grounded.
c) Do not expose power tools to rain or wet condi-
tions. Water entering a power tool will increase the
risk of electric shock.
d) Do not abuse the cord. Never use the cord for car-
rying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges and moving
parts. Damaged or entangled cords increase the
risk of electric shock.
e) When operating a power tool outdoors, use an ex-
tension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is un-
avoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk
of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use com-
mon sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A mo-
ment of inattention while operating power tools
may result in serious personal injury.
OBJ_BUCH-1384-002.book Page 8 Wednesday, March 2, 2011 8:34 AM

English | 9
Bosch Power Tools 2 609 140 837 | (2.3.11)
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will re-
duce personal injuries.
c) Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on
the switch or energising power tools that have the
switch on invites accidents.
d) Remove any adjusting key or wrench before turn-
ing the power tool on. A wrench or a key left at-
tached to a rotating part of the power tool may re-
sult in personal injury.
e) Do not overreach. Keep proper footing and bal-
ance at all times. This enables better control of the
power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jew-
ellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust col-
lection can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct pow-
er tool for your application. The correct power tool
will do the job better and safer at the rate for which
it was designed.
OBJ_BUCH-1384-002.book Page 9 Wednesday, March 2, 2011 8:34 AM

2 609 140 837 | (2.3.11) Bosch Power Tools
10 | English
b) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must
be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool be-
fore making any adjustments, changing accesso-
ries, or storing power tools. Such preventive safe-
ty measures reduce the risk of starting the power
tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the pow-
er tool or these instructions to operate the power
tool. Power tools are dangerous in the hands of un-
trained users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly main-
tained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a haz-
ardous situation.
OBJ_BUCH-1384-002.book Page 10 Wednesday, March 2, 2011 8:34 AM

English | 11
Bosch Power Tools 2 609 140 837 | (2.3.11)
5) Battery tool use and care
a) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one
type of battery pack may create a risk of fire when
used with another battery pack.
b) Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
c) When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another. Shorting the battery terminals together
may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact acciden-
tally occurs, flush with water. If liquid contacts
eyes, additionally seek medical help. Liquid ejected
from the battery may cause irritation or burns.
6) Service
a) Have your power tool serviced by a qualified re-
pair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
Safety Warnings for Screwdriver
fHold power tool by insulated gripping surfaces, when
performing an operation where the fastener may con-
tact hidden wiring. Fasteners contacting a “live” wire
may make exposed metal parts of the power tool “live”
and could give the operator an electric shock.
OBJ_BUCH-1384-002.book Page 11 Wednesday, March 2, 2011 8:34 AM

2 609 140 837 | (2.3.11) Bosch Power Tools
12 | English
fHold the machine with a firm grip. High reaction
torque can briefly occur while driving in and loosening
screws.
fAlways wait until the machine has come to a com-
plete stop before placing it down. The tool insert can
jam and lead to loss of control over the power tool.
fBefore any work on the machine (e. g., maintenance,
tool change, etc.) as well as during transport and
storage, set the rotational direction switch to the
centre position. Unintentional actuation of the On/Off
switch can lead to injuries.
Protect the power tool against heat, e. g.,
against continuous intense sunlight, fire, wa-
ter, and moisture. Danger of explosion.
fIn case of damage and improper use of the battery,
vapours may be emitted. Provide for fresh air and
seek medical help in case of complaints. The vapours
can irritate the respiratory system.
Safety Warnings for battery chargers
Keep the battery charger away from rain or
moisture. Penetration of water in the battery
charger increases the risk of an electric shock.
fOnly charge Bosch lithium ion batteries or batteries
installed in Bosch products with the voltages listed
in the technical data. Otherwise there is danger of fire
and explosion.
fKeep the battery charger clean. Contamination can
lead to danger of an electric shock.
OBJ_BUCH-1384-002.book Page 12 Wednesday, March 2, 2011 8:34 AM

English | 13
Bosch Power Tools 2 609 140 837 | (2.3.11)
fBefore each use, check the battery charger, cable
and plug. If damage is detected, do not use the bat-
tery charger. Never open the battery charger your-
self. Have repairs performed only by a qualified tech-
nician and only using original spare parts. Damaged
battery chargers, cables and plugs increase the risk of
an electric shock.
fDo not operate the battery charger on easily inflam-
mable surfaces (e. g., paper, textiles, etc.) or sur-
roundings. The heating of the battery charger during
the charging process can pose a fire hazard.
fSupervise children. This will ensure that children do
not play with the charger.
fChildren or persons that owing to their physical, sen-
sory or mental limitations or to their lack of experi-
ence or knowledge, are not capable of securely oper-
ating the charger, may only use this charger under
supervision or after having been instructed by a re-
sponsible person. Otherwise, there is danger of oper-
ating errors and injuries.
Products sold in GB only: Your product is fitted with a
BS 1363/A approved electric plug with internal fuse (AS-
TA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should
be cut off and an appropriate plug fitted in its place by an
authorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
OBJ_BUCH-1384-002.book Page 13 Wednesday, March 2, 2011 8:34 AM

2 609 140 837 | (2.3.11) Bosch Power Tools
14 | English
Product Description and Specifica-
tions
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
Intended Use
The machine is intended for driving in and loosening
screws.
Product Features
The numbering of the product features refers to the illus-
tration of the machine on the graphics page.
1Screwdriver bit*
2Tool holder
3Rubber cap
4Indicator for right rotation
5Battery charge-control indicator
6Indicator for left rotation
7On/Off switch
8Rotational direction switch
9“PowerLight”
10 Handle (insulated gripping surface)
11 Battery charger
12 Angle driver head*
13 Torque attachment*
14 Torque presetting ring*
OBJ_BUCH-1384-002.book Page 14 Wednesday, March 2, 2011 8:34 AM

English | 15
Bosch Power Tools 2 609 140 837 | (2.3.11)
15 Torque-setting mark*
16 Release ring*
*Accessories shown or described are not part of the standard
delivery scope of the product. A complete overview of accesso-
ries can be found in our accessories program.
Technical Data
Cordless Screwdriver IXO
Professional
Article number 3 601 J60 2..
Rated voltage V= 3.6
No-load speed min-1 180
Max. torque for hard/soft screw-
driving application according to
ISO 5393 Nm 4/3
Max. screw dia. mm 5
Weight according to
EPTA-Procedure 01/2003 kg 0.3
Battery Li-Ion
Capacity Ah 1.3
Number of battery cells 1
Battery Charger
Article number 2 607 225 093
Charging time h5
Please observe the article number on the type plate of your ma-
chine. The trade names of the individual machines may vary.
OBJ_BUCH-1384-002.book Page 15 Wednesday, March 2, 2011 8:34 AM

2 609 140 837 | (2.3.11) Bosch Power Tools
16 | English
Assembly
fBefore any work on the machine (e. g., maintenance,
tool change, etc.) as well as during transport and
storage, set the rotational direction switch to the
centre position. Unintentional actuation of the On/Off
switch can lead to injuries.
Battery Charging (see figure A)
fDo not use other battery chargers. The supplied bat-
tery charger is designed for the Lithium-Ion battery in
your machine.
fObserve the mains voltage! The voltage of the power
supply must correspond with the data given on the
nameplate of the battery charger. Battery chargers
marked with 230 V can also be operated with 220 V.
Note: The battery is supplied partially charged. To ensure
full capacity of the battery, completely charge the battery
in the battery charger before using your power tool for
the first time.
The lithium-ion battery can be charged at any time with-
out reducing its service life. Interrupting the charging pro-
cedure does not damage the battery.
The Lithium-Ion battery is protected against deep dis-
charging. When the battery is discharged, the machine is
automatically switched off by a protective circuit: The in-
serted tool no longer moves and a slight whistling noise
can be heard.
Do not continue to press the On/Off
switch after the machine has been auto-
matically switched off. The battery can be damaged.
WARNING
OBJ_BUCH-1384-002.book Page 16 Wednesday, March 2, 2011 8:34 AM

English | 17
Bosch Power Tools 2 609 140 837 | (2.3.11)
When the battery charge-control indicator 5lights up red
while the On/Off switch 7is depressed half way, then the
battery has less than 30% of its capacity and should be
charged.
The charging procedure starts as soon as the main plug of
the battery charger is inserted into the socket and the
cordless screwdriver is afterwards placed on the battery
charger 11.
The battery charge-control indicator 5indicates the
charging progress. The indicator lights up green during
the charging process. When the battery charge-control in-
dicator 5is no longer lit, the battery is fully charged.
During the charging procedure, the handle of the machine
warms up. This is normal.
Disconnect the battery charger from the mains supply
when not using it for longer periods.
The power tool cannot be used during the charge proce-
dure; it is not defective when inoperative during the
charging procedure.
fProtect the battery charger against moisture!
Observe the notes for disposal.
Changing the Tool (see figure B)
fDo not use double-sided screwdriver blades that are
longer than 25 mm.
Insert the screwdriver bit 1directly into the tool holder 2.
OBJ_BUCH-1384-002.book Page 17 Wednesday, March 2, 2011 8:34 AM

2 609 140 837 | (2.3.11) Bosch Power Tools
18 | English
Torque Attachment/Angle Driver Head
(see figures C –F)
The angle driver head 12 enables screwdriving at hard to
reach locations.
With the torque presetting ring 14 on the torque attach-
ment 13, the requested torque can be preset in 10 steps.
With the correct setting, the tool bit is stopped as soon
as the screw is driven flush into the material or when the
set torque is reached.
Assembly (see figures C–D)
For assembly of the attachments, pull the rubber cap 3off
toward the front. Afterwards the attachments can be
mounted. The attachments can be mounted offset by
45°.
Dismounting (see figures E–F)
To dismount the attachments, turn the release ring 16 in
rotation direction nand pull the attachment off toward
the front. Afterwards, mount the rubber cap 3again.
Operation
Starting Operation
Reversing the Rotational Direction
The rotational direction switch 8is used to reverse the ro-
tational direction of the machine. However, this is not
possible with the On/Off switch 7actuated.
OBJ_BUCH-1384-002.book Page 18 Wednesday, March 2, 2011 8:34 AM

English | 19
Bosch Power Tools 2 609 140 837 | (2.3.11)
Right rotation: For driving in screws, push the rotational
direction switch 8left to the stop.
The indicator for right rotation 4lights up when
the On/Off switch 7is actuated and the motor is
running.
Left Rotation: For loosening or unscrewing screws, push
the rotational direction switch 8right to the stop.
The indicator for left rotation 6lights up when the
On/Off switch 7is actuated and the motor is run-
ning.
Switching On and Off
To start the machine, press the On/Off switch 7and keep
it pressed.
The power light 9lights up when the On/Off switch 7is
slightly or completely pressed, and allows the work area
to be illuminated when lighting conditions are insuffi-
cient.
To switch off the machine, release the On/Off switch 7.
Fully automatic spindle locking (Auto-lock)
The drill spindle is locked when the On/Off switch 7is not
pressed.
This enables screws to be screwed in, even when the bat-
tery is empty and allows for the machine to be used as a
screwdriver.
fWhen the drilling spindle is locked, do not press the
On/Off switch 7 for more than 15 seconds. Other-
wise the power tool can be damaged.
OBJ_BUCH-1384-002.book Page 19 Wednesday, March 2, 2011 8:34 AM

2 609 140 837 | (2.3.11) Bosch Power Tools
20 | English
Working Advice
fApply the power tool to the screw only when it is
switched off. Rotating tool inserts can slip off.
Up to 13 screwdriver bits can be stored on the side of the
battery charger 11. The fixture that holds the screwdriver
bits can be removed.
Wall-mounting the Battery Charger (see figure G)
The battery charger 11 can be mounted to a wall. For this,
hang the charger via the slots on the side onto two
screws.
Maintenance and Service
Maintenance and Cleaning
fBefore any work on the machine (e. g., maintenance,
tool change, etc.) as well as during transport and
storage, set the rotational direction switch to the
centre position. Unintentional actuation of the On/Off
switch can lead to injuries.
fFor safe and proper working, always keep the ma-
chine and ventilation slots clean.
When the battery is no longer operative, please refer to
an authorised after-sales service agent for Bosch power
tools.
If the replacement of the supply cord is necessary, this
has to be done by Bosch or an authorized Bosch service
agent in order to avoid a safety hazard.
OBJ_BUCH-1384-002.book Page 20 Wednesday, March 2, 2011 8:34 AM
