Bosch VDC-230 User manual

Video | Indoor Dome Color Camera
Indoor Dome Color Camera
www.boschsecurity.com
The VDC-230 camera is a compact, stylish surveil-
lance dome that offers excellent resolution in vari-
able lighting conditions. The high performance
1/3‑inch CCD camera is available with a 3.8 mm
fixed lens.
The camera is easy to install and can be adjusted
around 3 axes. Privacy zones and motion detection
functions can be set up in the handy camera menu
system.
Features
uExcellent resolution (570 TVL sensor resolution)
uClean images under variable light
uEasy install

Technical specifications
Technical specifications
System PAL
Effective pixels (H x V) 752 x 582 (PAL)
Image Sensor 1/3-inch High sensitivity CCD
Video Output Composite: 1 Vpp, 75 Ohm
Sync. System Internal sync., Line-lock
S/N Ratio
(sharpness, AGC off)
50 dB min.
Horizontal resolution 570 TVL sensor resolution
Minimum Illumination
(F2.0, 30IRE, AGC
max.)
0.15 lx (color)
ESC 1/50 – 1/120,000
Manual Shutter 1/50(60), 1/100(120), 1/250, 1/500, 1/700,
1/1k, 1/1.6K, 1/2.5K, 1/5K, 1/7K, 1/10K,1/30K,
1/60K, 1/120K
DNR Off, Low, Middle, High
White Balance ATW, Manual, Push
SBLC Off, Low, Middle, High
AGC On, Off
Day/Night Auto, Color, B/W, Ext.
Burst On, Off
Motion detection On, Off (4 programmable zones)
Privacy On, Off (4 programmable zones)
Mirror On (horizontal), Off
Sharpness 1 ‑ 20
Gamma 0.35, 0.45, 0.6, 0.75
OSD language English, Chinese
Lens type Manual lens
Supply Voltage 12 VDC (±10%)
Power Consumption 3.6 W max. / 0.3 A
Operating Temperature -10 °C to +50 °C
(14 ºF to +122 ºF)
Operating Humidity 30% to 80% RH
Storage Temperature -20 °C to +60 °C
(-4 ºF to +140 ºF)
Storage Humidity 20% to 90% RH
Certifications and approvals
Region Certification
Europe CE
Standards
EN 55022:2006/A1:2010
EN 60950-1:2006/
A11:2009+A1:2010+A12:2011+AC:2011
Installation/configuration notes
46.75
11.3
H=95
Ø123
mm
39
39
45
Ø92
Ordering information
Indoor Dome Camera, 3.8 mm fixed lens VDC-230F04-10
