Bosch LTC 0610/11 User manual

Video | LTC 0610 Series DinionXF Color Cameras
LTC 0610 Series DinionXF Color Cameras
www.boschsecurity.com
u15-bit DSP technology
uXF-Dynamic
uBilinx communication
uNightSense
uDefault shutter
The LTC 0610 Series of High Performance 1/2-inch
Digital CCD Color Cameras create the best possible
image, even under the most difficult light and scene
conditions. Based on unique 15-bit digital video
processing technology and employing XF-Dynamic,
these cameras provide the ultimate sensitivity with
extended dynamic range. By employing the best 1/2-
inch CCD available, advanced front end processing,
combined with the outstanding Dinion DSP, the
cameras achieve an astonishing sensitivity, providing
better color images in low light situations and sharper
daytime images.
Intelligent White balance algorithms, supported by a
White Balance Hold function and even full manual
white balance, ensure the most accurate color
reproduction possible. All Dinion cameras are supplied
ready to operate. Simply attach and focus the lens,
and connect power to provide optimal pictures under
virtually all scene conditions. No tools are required for
back focus and power connection.
For extra challenging situations where fine tuning or
special settings are required, the camera parameters
can be individually set using the control buttons on the
side of the camera and On-screen Display (OSD). Also,
to aid installation, the camera automatically detects
the lens type, and using the Lens Wizard ensures
accurate (back) focusing for perfectly sharp pictures
at all times.
Functions
XF-Dynamic
Extended dynamic range is brought to a new level on
the LTC 0610 Series Camera by XF-Dynamic
technology. XF-Dynamic automatically processes the
highly accurate 15-bit digital signal to optimally
capture the detail in both the highlight and lowlight
areas of the scene simultaneously, to maximize the
information visible in the picture.
Bilinx Technology
The LTC 0610 Series cameras incorporate Bilinx. Bilinx
is a bidirectional communication capability embedded
in the video signal of all Bosch Dinion cameras. With
Bilinx technicians can check status, change camera
settings and even update firmware from virtually
anywhere along the video cable. Bilinx reduces service
and installation time, provides for more accurate setup
and adjustment, and improves overall performance. In
addition, Bilinx uses the standard video cable to
transmit alarm and status messages, providing
superior performance without additional installation
steps.
Video Motion Detection
The built-in video motion detector allows you to select
up to four fully programmable areas with individual
thresholds. The global scene change detector

minimizes false alarms caused by sudden lighting
condition changes, such as switching on or off the
indoor or security lighting. When motion is detected
alarms may be displayed in the video signal, the output
relay can be closed in addition to alarm message
transmission on Bilinx.
Auto Black
The automatic black level feature, enhances contrast
by removing veiling glare from the picture or when
contrast is reduced by fog or mist.
Default Shutter
When viewing moving objects a fast shutter speed is
required. When using a fast shutter speed the lens
opening or gain control needs to be increased to
maintain the video signal. The camera sensitivity is
limited by the fast shutter speed. The default shutter
setting of the LTC 0610 offers the best of all worlds,
fast shutter speed as long as there is sufficient light,
however as the light level falls, when other
adjustments have been exhausted, the shutter reverts
to the standard setting maintaining the cameras
excellent sensitivity.
Back Light Compensation (BLC)
Offering a fully programmable BLC area of interest,
and a variable BLC level, the camera can be easily set
up for even the most challenging entrance
applications.
Lens Wizard
The LTC 0610 Series automatically detects the type of
lens installed. The Lens Wizard will focus the lens at
the maximum lens opening, to ensure that focus is
maintained throughout the entire 24-hour day/night
cycle. No special tools or filters are required.
Programmable Modes
The camera supports three independent operating
modes. The 3 modes are preprogrammed for typical
applications, but are fully programmable for individual
situations. Switching between modes is easy via Bilinx
or the external alarm input.
NightSense
The LTC 0610 cameras feature NightSense. With
NightSense the sensitivity is increased by 9 dB in
monochrome mode. NightSense can be automatically
activated in low light situations, or remotely using
Bilinx.
SensUp
By increasing the integration time on the CCD up to 10
times, the effective sensitivity is dramatically
enhanced, especially useful where there is no artificial
lighting and you rely on the moon, stars and scattered
radiation.
Certifications and approvals
Electro Magnetic Compatibility
Emission EN55022 class B, FCC class B part 15
Immunity EN50130-4 Alarm Systems, Part 4
Vibration Camera with 500 gr (1.1 lbs) lens according to
IEC60068-2-27
Safety
LTC 0610/11 and LTC 0610/51: EN60065
LTC 0610/21 and LTC 0610/61: UL6500, cUL CAN/CSA E60065-00
Region Certification
Europe CE
CE Declaration of Conformity
USA FCC Declaration of Conformity
Installation/configuration notes
Dimensions in mm (inches)
Parts included
Quantity Components
1LTC 0610 Series DinionXF Color Camera
1 Spare male 4–pin lens connector
Lens not included
Technical specifications
Electrical
Model No. RatedVoltage
LTC 0610/11 12–28 VAC 45–65 Hz
11–39 VDC
LTC 0610/21 12–28 VAC 45–65 Hz
11–39 VDC
2 | LTC 0610 Series DinionXF Color Cameras

LTC 0610/51 85–265 VAC 45–65 Hz
LTC 0610/61 85–265 VAC 45–65 Hz
Power Consumption 4 W
Imager Interline CCD type, ½-in. image format
Active Pixels
PAL Models 752 H x 582 V
NTSC Models 768 H x 492 V
Sensitivity (3200 k)
Sensitivity (full
video)1)
1.4 lx (0.14 fc)
Sensitivity 50 IRE1) 0.35 lux / 0.14 lux (NightSense)
(0.035 fc / 0.014 fc (NightSense))
Minimum
Illumination1)
0.18 lux / 0.08 lux (NightSense)
(0.018 fc / 0.008 fc (NightSense))
Minimum
Illumination with
SensUp
0.018 lux / 0.008 lux (NightSense)
(0.0018 fc / 0.0008 fc (NightSense))
Horizontal
Resolution
540 TVL
Signal-to-Noise-
Ratio
> 50dB
Video Output 1Vpp, 75 Ohm
Y/C Output Y: 1 Vpp / C: 0.3 Vpp
Synchronization Internal, Line Lock, HV-lock and Genlock (Burst
lock) selectable
Shutter Auto (1/60 (1/50) to 1/500000), fixed,
flickerless, default
Night Sense Auto, forced, off
Sensitivity up Off, automatic continuous up to 10x
Auto Black On, off selectable
Dynamic Range 32x dynamic range enhancement
Dynamic Noise
Reduction
Auto, off selectable
Contour Sharpness enhancement level selectable
BLC Off, area and level selectable
Gain Auto (maximum level selectable to 28 dB) or
fixed level selectable
Lens Mount C and CS
White Balance ATW (2500–10000 K), AWB hold, manual WB
selectable
VMD 4 area, sensitivity selectable
Alarm Output VMD or Bilinx
Alarm Input (TTL) Profile switching, +5 V nominal, +40 VDC max.
Alarm Output Relay Max. 30 VAC or +40 VDC, max. 0.5 A
continuous, 10 VA
External Synchronal
Input
75 Ohm or High Impedance selectable
Cable
Compensation
Up to 1000 m (3000 ft) coax without external
amplifiers (automatic setup in combination
with coaxial communication)
Camera ID 16 character editable string, position
selectable
Lens Types Manual, DC- and Video-iris auto-detect with
override DC-iris drive: max 50mA continuous
Video-iris: 11.5 ± 0.5 VDC, max. 50 mA
continuous
Remote Control Bi-directional coaxial communication
1) F/1.2, 89% reflection, SensUp off
Mechanical
Dimensions
(H x W x L)
59 x 67 x 122 mm (2.28 x 2.6 x 4.8 in.)
without lens
Weight 450 g (0.99 lbs) without lens
Tripod Mount Bottom (isolated) and top 1/4-inch 20 UNC
Controls OSD with softkey operation
Environmental
Operating Temperature -20 °C to +50 °C (-4 °F to +122 °F)
Storage Temperature -25 °C to +70 °C (-13 °F to +158 °F)
Operating Humidity 20% to 93% Relative humidity
Storage Humidity up to 98% Relative humidity
Ordering information
LTC 0610/11 DinionXF Color Camera
1/2-inch, high performance, 540 TVL, PAL, DSP, 12 –
28 VAC/11 – 39 VDC, 50 Hz
Order number LTC0610/11
LTC 0610/21 DinionXF Color Camera
1/2-inch, high performance, 540 TVL, NTSC, DSP, 12 –
28 VAC/11 – 39 VDC, 60 Hz
Order number LTC0610/21
LTC 0610/51 DinionXF Color Camera
1/2-inch, high performance, 540 TVL, PAL, DSP, 85 –
265 VAC, 50 Hz
Order number LTC0610/51
LTC 0610/61 DinionXF Color Camera
1/2-inch, high performance, 540 TVL, NTSC, DSP, 85 –
265 VAC, 60 Hz
Order number LTC0610/61
