Bosch NPD-6001A User manual

High PoE Midspans
NPD-6001A │ NPD-9501A
en Installation Manual

Table of contents
1Safety 4
1.1 About this Manual 4
1.2 Legal Information 4
1.3 Safety Precautions 4
1.4 Important Safety Instructions 5
1.5 Customer Support and Service 8
2Unpacking 10
2.1 Parts List 10
2.2 Additional Parts Required 10
2.3 Tools Required 11
2.4 Additional Parts Recommended But Not Required 11
3System overview 12
4Installation 14
5Connection 16
6Troubleshooting 18
High PoE Midspans Table of Contents | en 3
Bosch Security Systems 2015.06 | 3.1 | F.01U.304.912

Safety
About this Manual
This manual has been compiled with great care and the
information it contains has been thoroughly verified. The text
was complete and correct at the time of printing. Because of the
ongoing development of products, the content of the manual
may change without notice. Bosch Security Systems accepts no
liability for damage resulting directly or indirectly from faults,
incompleteness, or discrepancies between the manual and the
product described.
Legal Information
Copyright
This manual is the intellectual property of Bosch Security
Systems, Inc. and is protected by copyright. All rights reserved.
Trademarks
All hardware and software product names used in this document
are likely to be registered trademarks and must be treated
accordingly.
Safety Precautions
In this manual, the following symbols and notations are used to
draw attention to special situations:
Danger!
High risk: This symbol indicates an imminently hazardous
situation such as “Dangerous Voltage” inside the product. If not
avoided, this will result in an electrical shock, serious bodily
injury, or death.
1
1.1
1.2
1.3
4en | Safety High PoE Midspans
2015.06 | 3.1 | F.01U.304.912 Bosch Security Systems

!
Caution!
Medium risk: Indicates a potentially hazardous situation. If not
avoided, this may result in minor or moderate injury. Alerts the
user to important instructions accompanying the unit.
!
Caution!
Low risk: Indicates a potentially hazardous situation. If not
avoided, this may result in property damage or risk of damage
to the unit.
Notice!
This symbol indicates information or a company policy that
relates directly or indirectly to the safety of personnel or
protection of property.
Important Safety Instructions
Read, follow, and retain for future reference all of the following
safety instructions. Heed all warnings on the unit and in the
operating instructions before operating the unit.
– FOR INDOOR USE ONLY
– The unit is intended only for installation in a Restricted
Access Location.
– Installation and removal of the midspan must be carried out
by qualified personnel only.
– Follow basic electricity safety measures whenever
connecting the midspan to its power source.
–AC Power Cord Set: Although the High PoE Midspan 60W,
Single port ships with one (1) 120 V power cord and one
(1) 230 V power cord, please note the following as it
applies to your region:
– The power cord must have regulatory agency approval
for the specific country in which it is being used (i.e.,
UL, CSA, VDE, etc.).
1.4
High PoE Midspans Safety | en 5
Bosch Security Systems 2015.06 | 3.1 | F.01U.304.912

– The power cord must be a three-conductor type (two
current carrying conductors; one ground conductor)
terminated on one end by an IEC 60320 appliance
coupler (for connection to the midspan), and on the
other end by a plug containing a ground (earthing)
contact.
– The power cord must be rated for a minimum of 250
VAC RMS operation, with a minimum rated current
capacity of 5 Amps (or a minimum wire gauge of 18
AWG (0.75mm2).
– Midspans installed in Australia require power cords
with a minimum wire gauge of 16 AWG (1.0 mm2).
– A voltage mismatch can cause equipment damage and may
pose a fire hazard. If the voltage indicated on the label is
different from the power outlet voltage, do not connect the
midspan to this power outlet.
– The AC wall socket-outlet must be near the midspan and
easily accessible. You can remove AC power from the
midspan by disconnecting the AC power cord from either
the wall socket-outlet or the midspan appliance coupler.
– The PoE injector "Data In" and "Data & Power Out" ports
are shielded RJ45 data sockets. They cannot be used as
Plain Old Telephone Service (POTS) telephone sockets.
Only RJ45 data connectors can be connected to these
sockets.
– The Data In and Data & Power Out interfaces are qualified
as SELV (Safety Extra-Low Voltage) circuits according to
IEC 60950-1. These interfaces can only be connected to
SELV interfaces on other equipment.
Recycling and Disposal:
6en | Safety High PoE Midspans
2015.06 | 3.1 | F.01U.304.912 Bosch Security Systems

Your Bosch product was developed and manufactured with high-
quality material and components that can be recycled and
reused. This symbol means that electronic and electrical
appliances, which have reached the end of their working life,
must be collected and disposed of separately from household
waste material. Separate collecting systems are usually in place
for disused electronic and electrical products. In the United
States, please dispose of these units at your local communal
waste collection point or at a recycling center. In the EU, please
dispose of these units at an environmentally compatible
recycling facility, per European Directive 2002/96/EC.
High PoE Midspans Safety | en 7
Bosch Security Systems 2015.06 | 3.1 | F.01U.304.912

Customer Support and Service
If this unit needs service, contact the nearest Bosch Security
Systems Service Center for authorization to return and shipping
instructions.
Service Centers
USA
Telephone: [phone] or 585-340-4162
Fax: [phone]
Email: [email protected]
Customer Service
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
Telephone: [phone]
Fax: [phone] or 717-735-6560
Email: [email protected]
Repair Center
Telephone: [phone]
Fax: [phone] or 717-735-6561
Email: [email protected]
Canada
Telephone: [phone]
Fax: [phone]
Europe, Middle East & Africa Region
Please contact your local distributor or Bosch sales office. Use
this link:
http://www.boschsecurity.com/startpage/html/europe.htm
Asia Pacific Region
Please contact your local distributor or Bosch sales office. Use
this link:
http://www.boschsecurity.com/startpage/html/asia_pacific.htm
1.5
8en | Safety High PoE Midspans
2015.06 | 3.1 | F.01U.304.912 Bosch Security Systems

More Information
For more information please contact the nearest Bosch Security
Systems location or visit www.boschsecurity.com
High PoE Midspans Safety | en 9
Bosch Security Systems 2015.06 | 3.1 | F.01U.304.912

Unpacking
Parts List
The package containing the midspan should include the
following items:
Quantity Part
1 Midspan:
High PoE Midspan 60W, Single port, AC in
or
High PoE Midspan 95W
1 120 V power cord
1 230 V power cord
1 Installation Manual (this document)
Additional Parts Required
The following table lists additional parts (not supplied by
Bosch) required to install the midspan:
2
2.1
2.2
10 en | Unpacking High PoE Midspans
2015.06 | 3.1 | F.01U.304.912 Bosch Security Systems

Quantity Part Size Notes
2 Mounting
screws;
Select either
size
(but not both).
Head diameter:
5.8 mm
(0.23 in.)
1.5 mm (0.059 in.)
clearance from mounting
surface
Head diameter:
7 mm
(0.27 in.)
Head height:
2 mm
(0.08 in.)
2.5 mm (0.098 in.)
clearance from mounting
surface
2 CAT5 cables Not to exceed
100 m (333 ft)
each
1 cable to connect to the
“Data & Power
Out“ port.
1 cable to connect to the
“Data In” port.
Tools Required
Screwdriver
Additional Parts Recommended But Not
Required
The following table lists additional parts (not supplied by
Bosch) recommended to install the midspan:
Quantity Part
1 Surge suppressor
1 Splitter
1 Universal Power Supply (UPS)
2.3
2.4
High PoE Midspans Unpacking | en 11
Bosch Security Systems 2015.06 | 3.1 | F.01U.304.912

System overview
Bosch sells two (2) models of midspans (a 60 W model and a 95
W model) that enable remote power over an IP network
connection for specific Bosch IP cameras. Rated for indoor
installation only, the midspans can be installed indoors and
wired to a camera installed outdoors.
Each midspan has a single port and is designed to carry data
and power over a standard CAT5e (or better) cable, delivered
through all 4 pairs.
60 W Midspan
The 60 W midspan (NPD-6001A) enables remote High Power
over Ethernet (High PoE) for various Bosch IP/HD PTZ cameras.
Generating a maximum of 60 W, it complies to both the IEEE
802.3af and the IEEE 802.3at standards, while doubling the
available power.
This model of midspan is necessary to supply power to the
heater for an outdoor AUTODOME 7000 camera.
It can also supply power to a standard model of MIC7000
without an illuminator accessory.
95 W Midspan
The 95 W midspan (NPD-9501A) is a high-power PoH (Power
Over HDBase T) device that provides data and power between
an Ethernet (remote network) switch and a MIC7000 camera. It
supports the proposed standard for a 95 W output device, and
is backwards compatible to both the IEEE 802.3af and the IEEE
802.3at standards (15.4 W and 25.5 W).
This model of midspan can supply power to all models of
MIC7000.
Notes
Note: Do NOT use cross-over cable between the Data & Power
Out port and the camera!
Note: The midspan is not a repeater and does not amplify the
Ethernet data signal.
3
12 en | System overview High PoE Midspans
2015.06 | 3.1 | F.01U.304.912 Bosch Security Systems

Note: The total length of Cat5e/Cat6 cable must be less than
100 m (328 ft) between the camera and the head-end system.
High PoE Midspans System overview | en 13
Bosch Security Systems 2015.06 | 3.1 | F.01U.304.912

Installation
!
Caution!
Installation must be made by qualified personnel and conform
to ANSI/NFPA 70 (the National Electrical Code® (NEC)),
Canadian Electrical Code, Part I (also called CE Code or CSA
C22.1), and all applicable local codes. Bosch Security Systems,
Inc. accepts no liability for any damages or losses caused by
incorrect or improper installation.
!
Warning!
FOR INDOOR USE ONLY
Place the midspan on a desktop, or mount it to a wall, a bench,
or a shelf using the mounting holes in the bottom of the device.
Before mounting the midspan to a fixed location, note the
following:
– Do not cover the midspan or block the airflow to the PoE
with any foreign objects.
– Keep the midspan away from excessive heat and humidity
and free from vibration and dust.
– Ensure that the cable length from the Ethernet network
source to the terminal does not exceed 100 meters (333
feet). The midspan is not a repeater and does not amplify
the Ethernet data signal.
– No “on-off” switch exists; simply plug the midspan into an
AC power source.
Mount the Unit Directly to a Flat Surface
1. Select the mounting location and surface. Ensure that the
selected surface will be able to support the weight of the
unit (400 g / 0.88 lb). Note that this unit is intended only
for installation in a Restricted Access Location.
4
14 en | Installation High PoE Midspans
2015.06 | 3.1 | F.01U.304.912 Bosch Security Systems

2. Install two mounting screws (user-supplied) in the selected
mounting surface, at a distance of 9.17 cm / 91.7 mm (3.61
in.) apart from the center of each screw.
3. Align the mounting holes on the bottom of the unit to the
screws. Slide the unit into place.
Stack One Unit on Top or on the Side of Another Unit
Slide the rail on the right side (when facing the ports) of one
unit to the left side (when facing the ports) of a second unit.
High PoE Midspans Installation | en 15
Bosch Security Systems 2015.06 | 3.1 | F.01U.304.912

Connection
Notice!
The PoE ports “Data In“ and “Data & Power Out“ are shielded
RJ45 data sockets. They cannot be used as “Plain Old
Telephone Service” (POTS) telephone sockets. Connect only
RJ45 data connectors (EIA 568A and 568B) to these ports.
The “Data In” and “Data & Power Out” interfaces are qualified
as “Safety Extra Low Voltage” (SELV) circuits according to IEC
60950-1. These interfaces can be connected only to SELV
interfaces on other equipment.
1. Connect the midspan to an AC power outlet (100 – 240
VAC), using one of the two power cords supplied, or one
that has the appropriate ratings and specifications (see the
Safety chapter).
Note: The voltage of the power outlet must match the
voltage indicated on the midspan label.
2. Connect the Data In (input) port to the remote Ethernet
network switch.
3. Connect the Data & Power Out (output) port to the
Ethernet port on the AutoDome camera.
Note: Do NOT use cross-over cable!
5
16 en | Connection High PoE Midspans
2015.06 | 3.1 | F.01U.304.912 Bosch Security Systems

Figure 5.1: Midspan_DataIn_DataOut_Connections
1AC input connectivity indicator
2 Port connectivity indicator
3 CAT5 cable
4 Connection to camera
5 Connection to Ethernet switch
High PoE Midspans Connection | en 17
Bosch Security Systems 2015.06 | 3.1 | F.01U.304.912

Troubleshooting
The following tables identify the LED indicators on the top of
the midspan.
AC (Main) LED Indicator (60 W and 95 W)
AC (Main)
LED
OFF Green
Green Power off indicator Power on indicator
(power is active)
Port LED Indicator (60 W)
Port LED Behavior
– OFF – No detection or disconnected or no
load is connected.
– Yellow ON – Power is supplied over the data pair
or over the spare pair.
– Green ON – Power is supplied over the data and
spare pairs together.
– Blinking yellow
at 1 Hz rate
– Over current or short circuit
condition at one of the 2 pairs (the
other pair is OFF) - data or spare,
(PD or cable fault)
– Blinking yellow
and green
at 1 Hz rate
– Over current or short circuit
condition at one or both pairs - data
or/and spare, (PD or cable fault)
– Blinking yellow
or green at 4
Hz rate
– Internal fault condition
6
18 en | Troubleshooting High PoE Midspans
2015.06 | 3.1 | F.01U.304.912 Bosch Security Systems

Port LED Indicator (95 W)
Port LED Behavior
– OFF – Nothing is connected to the port.
– Yellow ON – Power is supplied over the data pair
or over the spare pair.
– Green ON – Power is supplied over the data and
spare pairs together.
– Blinking green
at 0.5 Hz rate
– Port was powered at four pairs, then
a short circuit condition or an over
voltage limit (OVL) event occurred.
After AC voltage is supplied, the green LED will blink, and then
the yellow LED will blink, each for one second.
High PoE Midspans Troubleshooting | en 19
Bosch Security Systems 2015.06 | 3.1 | F.01U.304.912

Troubleshooting Steps
Symptom Corrective Steps
– The
midspan
does not
power up.
1. Verify that a reliable power cord is used.
2. Verify that the voltage at the power inlet
is between 100 and 240 VAC.
3. Remove and re-apply power to the device
and then check the indicators during power
up sequence.
– The
midspan
does not
operate, but
no port
indicator is
lit.
1. Verify that the midspan detects the
camera.
2. Verify that you are using a standard
Category 5/5e/6, straight-wired cable, with
four pairs.
3. If an external power splitter is used,
replace it with a splitter known to operate.
4. Verify that the input Ethernet cable is
connected to the Data In port.
5. Verify that the camera is connected to the
Data & Power Out port.
6. Try to reconnect the camera to a different
midspan. If the camera works, then there is
probably a faulty port or RJ45 connection
on the midspan.
7. Verify that there is not a short over any of
the twisted pair cables or over the RJ45
connectors.
20 en | Troubleshooting High PoE Midspans
2015.06 | 3.1 | F.01U.304.912 Bosch Security Systems
