Bosch VSS7390/01T User manual

VSS7390/01T Switcher
Manual de Instalação
Comutador
PT
Installationsvejledning
Omskifter
DA
Asennusohje
Valitsin
FI
Installationshandbok
Switcher
SV
Βιβλίο οδηγιών
Μεταγωγέας
EL
Installeringsh ndbok
Switcher
NO
Installation Instructions
Switcher
EN
Manuel d’installation
Système de commutation
FR
Installationshandbuch
Schaltsystem
DE
Installatiehandleiding
Switcher
NL
Manuale di istruzioni
Switcher
IT
Manual de instalación
Conmutador
ES

osch Security Systems | 2003-06
VSS7390/01T Switcher | Installation Manual | Table of Contents EN | 1
1. SAFETY PRECAUTIONS .........................................................................................................................................................2
1.1 IMPORTANT SAFEGUARDS .......................................................................................................................2
1.1.1 FCC Information ..................................................................................................................................3
2. HARDWARE INSTALLATION ................................................................................................................................................4
2.1 SYSTEM CA LE .............................................................................................................................................4
2.2 SYSTEM CONNECTION ..............................................................................................................................4
2.2.1 Camera inputs (1 to 4) ......................................................................................................................4
2.2.2 Slave output .........................................................................................................................................4
2.2.3 Aux. output/input .................................................................................................................................4
2.2.4 Video Recorder in/output ..................................................................................................................5
2.2.5 Alarm output contact (N.O./N.C.) ...................................................................................................5
2.2.6 RS232 ...................................................................................................................................................5
2.2.7 Mains Power Connector ...................................................................................................................5
2.3 WIZARD INSTALLATION ..............................................................................................................................5
2.4 SYSTEM SETTINGS ......................................................................................................................................6
2.4.1 Main Menu ............................................................................................................................................6
2.4.2 System Settings Menu .......................................................................................................................6
2.4.3 Sequence ..............................................................................................................................................6
2.4.4 Alarms ....................................................................................................................................................6
2.4.5 Aux output .............................................................................................................................................8
2.4.6 Recorder ...............................................................................................................................................8
2.4.7 Installation .............................................................................................................................................8
2.4.8 Motion Sensitivity ............................................................................................................................. 10
2.4.9 Service ................................................................................................................................................ 10
2.4.10 Disable System Setting Option .................................................................................................... 10
3. TECHNICAL SPECIFICATIONS ........................................................................................................................................ 12
APPROVALS ................................................................................................................................................. 12
Safety .................................................................................................................................................. 12
Electro Magnetic Compatibility (EMC) ....................................................................................... 12
ELECTRICAL ................................................................................................................................................. 12
Alarm output screwblock ............................................................................................................... 12
AUX/VCR ........................................................................................................................................... 12
System cable .................................................................................................................................... 12
MECHANICAL ............................................................................................................................................... 12

osch Security Systems | 2003-06
VSS7390/01T Switcher | Installation Manual | Chapter 1 EN | 2
1SAFETY PRECAUTIONS
1.1 IMPORTANT SAFEGUARDS
1 Read these instructions.
2 Keep these instructions.
3 Comply with all warnings.
4 Follow all instructions.
5 Do not use this equipment near water.
Clean only with dry cloth.
7 Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8 Do not install near any heat sources such as radia-
tors, heat registers, stoves, or other equipment
(including amplifiers) that produce heat.
9 Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two
blades with one wider than the other. Agrounding
type plug has two blades and a third grounding
prong. Both the wide blade and the third prong are
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10 Protect the power cord from being walked on or
pinched particularly at plugs, convenience recepta-
cles, and the point where they exit from the equip-
ment.
11 Only use attachments/accessories specified by the
manufacturer.
12 Unplug this equipment during lightning storms or
when unused for long periods of time.
13 Refer all servicing to qualified service personnel.
Servicing is required when the equipment has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the equipment, the equipment has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
14
15 The equipment shall not be exposed to dripping or
splashing and that no objects filled with liquids, such
as vases, shall be placed on the equipment.
1 The back of the monitor should only be removed by
qualified maintenance and service personnel.
Ventilation
17 Keep ventilation openings free to avoid the monitor
for overheating.
18 Do not place the monitor in the immediate vicinity
of a heating source.
19 Do not install this equipment in a confined space
such as a bookcase or similar unit.
Cleaning
20 You can clean the monitor with a moist fluff-free
cloth or shammy leather cloth.
Disposal
21 This monitor contains batteries. Do not dispose of
these batteries with other solid waste. The batteries
type AA (standard penlights) are located in the bat-
tery compartment at the bottom of your monitor.
Danger
The lightning flash with arrowhead symbol,
within a triangle, is intended to alert the user to
the presence of uninstalled “dangerous voltage”
within the product's enclosure; that may be of
sufficient magnitude to constitute a risk of elec-
tric shock to persons.
Warning
The exclamation mark within a triangle is
intended to alert the user to the presence of
important operating and maintenance (servic-
ing) instructions in the literature accompanying
the appliance.
Caution
To reduce the risk of electricschock, do not
remove cover (or back). No user - serviceable
parts inside. Refer servicing to qualified service
personnel
Warning
To reduce the risk of fire or electric shock, do
not expose this equipment to rain or moisture.

osch Security Systems | 2003-06
VSS7390/01T Switcher | Installation Manual | Chapter 1 EN | 3
Remark
Bosch has a strong commitment towards the environ-
ment. This monitor has been designed to respect the
environment as much as possible.
1.1.1 FCC Information
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interfer-
ence in a residential installation. This equipment gener-
ates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instruc-
tions, may cause harmful interference to radio commu-
nications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is con-
nected.
• Consult the dealer or an experienced radio/ TV
technician for help.
Note
Any change or modification not expressly approved by
Bosch of the equipment authorization could void the
user's authority to operate the equipment.
For additional information or to speak to a representa-
tive, please contact the Bosch Security Systems location
nearest you or visit our web site at www.boschsecurit-
ysystems.com (See: Your Guide To Observation)
Caution
Danger of explosion if batteries are incorrectly
replaced. Replace only with the same or equiva-
lent type.
Warning
This device is intended for use in public areas
only. Surreptitious recording of oral communica-
tions is strictly prohibited by U.S. Federal law

osch Security Systems | 2003-06
VSS7390/01T Switcher | Installation Manual | Chapter 2 EN | 4
2 Hardware Installation
This chapter describes the installation of the system
hardware. For details of operation, see the supplied
Operation Instructions.
Note
Ensure that you read all safety precautions.
2.1 SYSTEM CABLE
For the interconnection between the monitor and
camera a 15m/45ft system cable is supplied with the
camera. For an optimum picture and sound quality you
should always use 4-wire dual twisted-pair cable when
extending the connection. The maximum allowed cable
length is 200m/ 00ft. Pay attention that the connectors
are fixed to the cable corresponding to the figure below.
(Figure 3.1) If the length of the system cable is over
200m/ 00ft (up to 300m/900ft), an interface box should
be used to feed the accessory or camera (see optional
accessories in the Operation Instructions).
2.2 SYSTEM CONNECTION
2.2.1 Camera inputs (1 to 4)
The cameras are connected to inputs 1 through to 4,
depending on the number of cameras used.
2.2.2 Slave output
An output for a slave monitor (optional accessory) is
available.
2.2.3 Aux. output/input
You can configure an auxiliary output configuration via
the menu option (see System settings). The auxiliary
output provides loop-through from one of the 4 camera
inputs or presentation mode where you can connect
another video source to aux-in. It is possible to switch
between this video source and one of the camera
pictures.
Note
The supplied A/V cable can be used for Aux. output/
input connection. However, if you are using two Video
Recorders you will need to order a second A/V cable
(see your local supplier).
• Connect the Mini Din plug to the Aux. connector of
the system monitor.
• Connect the BNC connectors to the video in and
video output of the Video Recorder or CVBS moni-
tor.
Caution
The plugs used for the observation system have
the same dimensions as standard telephone
plugs. (RJ-11) Never connect telephone equip-
ment or cable to the observation system.
VIDEO
OUT
AUDIO
OUT
AUDIO
IN
VIDEO
IN
VIDEO
OUT
AUDIO
OUT
AUDIO
IN
VIDEO
IN
Time Lapse VCR
VIDEO OUT
VIDEO IN
NOT USED
AUDIO OUT
AUDIO IN
TO SLAVE
VIDEO OUT
AUDIO OUT
TV / MONITOR
VCR (PLAYBACK ONLY)
VIDEO IN
AUDIO IN
CAMERA 1..4
Not used
1234
ALARM
Figure 3.1: System Connection

osch Security Systems | 2003-06
VSS7390/01T Switcher | Installation Manual | Chapter 2 EN | 5
• Connect the RCA plugs to the Audio in and Audio
out of your Video Recorder or CVBS monitor.
2.2.4 Video ecorder in/output
The Video Recorder in/output allows you to connect a
Video Recorder to record camera images.
• Connect the Mini Din plug to the Video Recorder
connector of the system monitor.
• Connect the BNC connectors to the video in and
video output of the Video Recorder.
Attention
The ‘Video In plug’ of the A/V cable must be connected to the
‘Video out’ of the Video Recorder. The ‘Video Out plug’ of the
A/V cable must be connected to the ‘Video In’ of the Video
Recorder.
• Connect the RCA connectors to the Audio in and
Audio out of your Video Recorder.
Attention
The ‘Audio In plug’ of the A/V cable must be connected to the
‘Audio out’ of the Video Recorder. The ‘Audio Out plug’ of the
A/V cable must be connected to the ‘Audio In’ of the Video
Recorder.
2.2.5 Alarm output contact (N.O./N.C.)
In case of an alarm or doorbell a potential free relay
contact (Normally Open/Normally Closed; 24V/2A
max.) can activate a Video Recorder, siren or telephone
selector. If the ‘alarm output’ is connected to the ‘alarm
input’ of a video recorder, the recording speed will
switch from time-lapse to full speed in case of an alarm.
This will result in the recording of more pictures per
second. If the alarm is acknowledged by the user or
automatically the Video Recorder switches back to
time-lapse mode.
2.2.6 S232
For service purposes to connect a PC/Laptop to save
and load the system settings.
2.2.7 Mains Power Connector
Ensure that you observe all safety precautions when
connecting the mains power cable and switching on the
power.
Attention
When the configuration is changed, the s stem must be scanned
again. Therefore alwa s switch off the s stem before a camera or
accessor is added or removed. After power up the s stem moni-
tor will recognize the item that was added or removed.
2.3 WIZARD INSTALLATION
When the system is powered up the FIRST time, the
WIZARD setup option is displayed. The Installation
Wizard will guide you through the most important
settings of the system. Follow the screen options and
select using the ROTARY wheel.
Note
When an additional camera or accessory is connected to
the system, the WIZARD function is automatically
enabled and you are guided through the appropriate
menus at power up.
During startup the following screen is displayed:
The following menu is displayed after a number of
seconds:
Turn the ROTARY wheel until the required language is
highlighted.
• Select your preferred language by pressing the
ROTARY wheel.
The following menu is displayed:
• Select YES to start the wizard setup. The wizard
setup enables you to configure the system to your
own settings and guides you through the process
automatically.
• Select NO to enable the system to automatically con-
figure itself to the factory default settings.
OSCH
O SERVATION SYSTEM
VERSION
X.X
LANGUAGE
ENGLISH
FRANCAIS
DEUTSCH
ITALIANO
PORTUGUES
ESPAGNOL
NEDERLANDS
CONFIGURATION
START INSTALLATION WIZARD ?
YES NO

osch Security Systems | 2003-06
VSS7390/01T Switcher | Installation Manual | Chapter 2 EN | 6
Note
For detailed information on the on screen menus refer
to the System Settings Part.
When completed the following screen will appear:
2.4 SYSTEM SETTINGS
The system settings can be configured to your own
requirements. The system is setup via on-screen menus.
To access the menu options:
• Press the MENU button. Toggle to switch on/off.
The ROTARY wheel controls the menu navigation as
described in the Operation Instructions.
At the end of this chapter you will find the complete
menu structure in a diagram.
2.4.1 Main Menu
After pressing the menu button the following menu will
be displayed:
Note
HISTORY, SWITCH TO PLAYBACK VIEW,
VIEW SETTINGS and TIME/DATE functions are
described in detail in the Operation Instructions.
Remark
After entering the system settings, alarms are disabled.
2.4.2 System Settings Menu
With the System settings menu you can configure the
system according to your own requirements.
Configurations that can be changed are:
Select system settings from the main menu and the
following menu will appear:
2.4.3 Sequence
You can change the sequence dwell time from 01 sec to
30 secs. Sequence/dwell time is the length of time an
image is displayed before the next image in the
sequence is shown.
2.4.4 Alarms
The Alarm Profiles can be accessed from the Alarm
menu.
CONFIGURATION
WIZARD COMPLETED
MAINMENU
HISTORY
SWITCH TO PLAY ACK VIEW
VIEW SETTINGS
TIME / DATE
SYSTEM SETTINGS
MAIN MENU
SYSTEM SETTINGS
SEQUENCE
ALARMS
AUX-OUTPUT
RECORDER
INSTALLATION
SERVICE
MAIN MENU
SYSTEM SETTINGS
SEQUENCE
DWELL TIME 05 SEC
MAIN MENU
SYSTEM SETTINGS
ALARMS
ALARM DURATION 05 SEC
AUTO ACKNOWLEDGE OFF
ALARM PROFILE DAY
ALARM PROFILE NIGHT
DAY / NIGHT SWITCH NONE
ALARM
DURATION
This defines the period of time (5
sec. to 15 min.) that the alarm
beeper and the alarm relay are acti-
vated, unless the operator acknow-
ledges the alarm.
AUTO
ACKNOWLEDGE
ON/OFF When there is an alarm,
the system automatically acknow-
ledges the alarm and replays the
event (if event replay is activated)
after the programmed alarm duration
has expired (can be set from 5 sec.
to 15 min).

osch Security Systems | 2003-06
VSS7390/01T Switcher | Installation Manual | Chapter 2 EN | 7
Note
If the display is in sequence mode during an alarm, it
automatically returns to sequence mode, starting with
the next image after the alarm image.
Alarm Profile Day
Alarm Profile Night
The other options are the same as for the ALARM
PROFILE DAY.
Note
When the day/night switch function is activated the
day/night switch on the monitor and on the remote
control is deactivated.
MAIN MENU
SYSTEM SETTINGS
ALARMS
ALARM PROFILE DAY
EXIT DELAY 0 SEC
TITLE MOTION ALARM- OX DOOR ELL
1OFF OFF OFF
2OFF OFF ON
3OFF OFF OFF
4OFF OFF OFF
EXIT DELAY Alarm Exit Delay (0 sec. to 4
min.) is the amount of time
before the alarm profile night will
be activated. (For example, time
for a person to exit a room
before the night alarm profile is
activated after switching over
from day to night).
MOTION ON/OFF The camera detects
motion within the defined motion
area.
ALARM BOX ON/OFF An alarm box is an
optional accessory that enables
you to activate an alarm input
(e.g. PIR detector).
DOORBELL ON/OFF/REMOTE A doorbell
(Intercom ox) is an optional
accessory that enables you to
react to persons who enter by
pressing the respective door-
bell. Pressing the doorbell will
sound the system buzzer and
register an event. If ‘remote’
option is selected, the doorbell
also triggers the alarm output
contact of the monitor.
MAIN MENU
SYSTEM SETTINGS
ALARMS
ALARM PROFILE NIGHT
EXIT DELAY 0 SEC
DISPLAY ON
TITLE MOTION ALARM OX DOOR ELL
1OFF OFF OFF
2OFF OFF ON
3OFF OFF OFF
4OFF OFF OFF
ENTRY DELAY An alarm generated in night
mode will be processed by the
system after the entry delay time
has expired (programmable
between 0 sec. and 4 min.). If
the system is switched over
from night to day during the
entry delay time the alarm will
not be processed. Exceptions
are special alarms, like tamper
and system alarm, which will
always be processed.
DISPLAY ON/OFF/ON AT ALARM In
night mode, the monitor screen
display can be switched ON or
OFF. Selecting ‘ON AT ALARM’
switches the monitor screen on
if an alarm is activated and dis-
plays the image of the camera
that has been activated.
If there is no user activity, the
system will automatically switch
back to night mode display OFF
within 15 minutes. If there is
user activity, the user must
switch the display off by
pressng the Day/Night Switch.
DAY / NIGHT
SWITCH
None/Select camera line with
Alarm/Action box. When
selected, the day and night pro-
files can be activated from an
Alarm/Action box.

osch Security Systems | 2003-06
VSS7390/01T Switcher | Installation Manual | Chapter 2 EN | 8
2.4.5 Aux output
From the system settings menu you can configure the
system aux-output.
2.4.6 ecorder
You can set up the Video Recorder from the system
menu:
2.4.7 Installation
The Installation group contains all installation-related
items, such as language, system beep and camera
setting.
MAIN MENU
SYSTEM SETTINGS
AUX-OUTPUT
PRESENTATION MODE ON
AUX-OUT 1
SLAVE DISPLAY FOLLOW
SEQUENCE ON
SEQUENCE WITH 2
DWELL TIME 03 SEC
AUDIO SOURCE AUX-IN
PRESENTATION
MODE
An advanced feature of this sys-
tem is the ‘presentation mode’.
OFF - The auxiliary output pro-
vides loop-through from one of
the 4 camera inputs, depending
on the AUX-OUT camera
number setting.
ON - The auxiliary input allows
you to view images from an
additional Video Recorder.
These images can consist of a
promotional video sequenced
with live camera images.
AUX-OUT When presentation mode is
OFF, one of the eight camera
outputs can be displayed on the
AUXoutput.
When presentation mode is ON,
the AUX-OUT menu option is
disabled.
SLAVE DISPLAY FOLLOW/1-4
Slave display lets you display
the images from the main moni-
tor (Follow) or from any camera
on the slave monitor (1-4).
SEQUENCE The presentation is sequenced
with a live camera image when
selected to ON.
SEQUENCE
WITH
Presentation is sequenced with
the selected live camera image
(in this case with camera
number 2).
DWELL TIME Change the image sequence
dwell time (programmable
between 02 and 30 secs).
AUDIO SOURCE Selected Audio source is auto-
matically displayed.
MAIN MENU
SYSTEMSETTINGS
RECORDER
PLAY ACK DETECTION ON
PLAYBACK
DETECTION
y connecting the input and
output from the same Video
Recorder you can have an auto-
matic playback detection.
ON This allows you to switch on
the Video Recorder playback
and the system will automatically
detect the Video Recorder has
been switched on for playback.
OFF The playback detection is
disabled. You can select the
Video Recorder playback by
accessing the main menu and
selecting “SWITCH TO PLAY-
ACK VIEW”
MAIN MENU
SYSTEM SETTINGS
INSTALLATION
LANGUAGE ENGLISH
EEP VOLUME OFF
EXTERNAL CONTROL
SETUP CAMERA 1
SETUP CAMERA 2
SETUP CAMERA 3
SETUP CAMERA 4

osch Security Systems | 2003-06
VSS7390/01T Switcher | Installation Manual | Chapter 2 EN | 9
External Control
LANGUAGE You can choose from English,
French, German, Spanish,
Dutch, Italian and Portuguese.
The menus are then displayed
in the selected language.
BEEP VOLUME Allows you to select the sys-
tem audio beep high, medium,
low or off.
EXERNAL
CONTROL
Allows you to control the sys-
tem via slave or IR Remote
Control.
MAIN MENU
SYSTEM SETTINGS
INSTALLATION
EXTERNAL CONTROL
REMOTE CONTROL OFF
SYSTEM ADDRESS 1
CONTROL AT SLAVE OFF
REMOTE
CONTROL
Can be selected ON or OFF
to allow control of the system
from the IR Remote Control
accessory.
SYSTEM
ADDRESS
Can be selected from an
address of 1 to 8 to avoid mul-
tiple system switching with
one IR Remote Control.
CONTROL AT
SLAVE
Can be selected ON or OFF
to allow control of the system
from the Slave Monitor acces-
sory.
SETUP CAMERA
For every connected camera a camera configuration
menu can be selected (activated).
MAIN MENU
SYSTEM SETTINGS
INSTALLATION
SETUP CAMERA 1
TITLE 1
COVERT DISPLAY OFF
ACKLIGHT COMPENSATION OFF
FLICKERLESS OFF
WHITE ALANCE AUTO
FIELD OF VIEW 1
MICROPHONE ON
MOTION AREA
MOTION SENSITIVITY
DISPLAY MOTION OFF
TITLE Allows you to enter a camera title
(max. 8 characters).
COVERT
DISPLAY
This feature is only available in the
multiplexer, therefore it is disabled
in the switcher.
BACKLIGHT
COMPENSATION
(BLC)
acklight compensation:
LC OFF - The camera Automatic
Light Control (ALC) responds to
the average content of the entire
video picture.
LC ON - The camera ALC
responds pre-dominantly to the
center of the picture, shown by the
diagram. If an object of interest falls
inside the LC area, its visibility will
remain relatively constant even if
the background illumination varies.
FLICKERLESS This option is available with certain
camera versions. It reduces the
flicker produced by artificial lights.
WHITE
BALANCE
White balance is used only for color
cameras. The camera automatically
matches the video color to the
white (reference) area of the image.
The different options are:
FIXED - keep the white balance
settings which are currently used.
AUTO - White balance is automati-
cally set.
RECALCULATE - Set the white
balance to automatic for 5 seconds
and then back to fixed.
Note
Recalculate is only available when
current setting is FIXED.
This function is disabled when a
black and white camera is used.

osch Security Systems | 2003-06
VSS7390/01T Switcher | Installation Manual | Chapter 2 EN | 10
2.4.8 Motion Sensitivity
Set motion alarm as follows:
1 Reset indicator.
2 Set level on minimum.
3 Walk through motion area (motion indicator indi-
cates level of motion).
4 Set level just below the level of motion indication.
2.4.9 Service
The SERVICE menu contains all items relevant for
servicing your observation system: resetting the system
to factory defaults and the internal diagnose.
2.4.10 Disable System Setting Option
You can disable the system setting option, ensuring
operators do not make inadvertent system changes.
To menu lock the system settings option:
• Switch the complete system off.
• Switch the system on while keeping the PIP and PIP
Swap buttons pressed at the same time. Continue to
keep the buttons pressed until the start-up screen
appears.
System settings are removed from the main menu.
Note
Follow the same procedure to unlock the system settings
menu.
FIELD OF
VIEW
(Range 1: 1.33: 1.66 : 2: default is
1). Adjust the field of view using
digital zoom in the camera to
ensure complete coverage of the
object within the viewing angle of
the camera lens.
MICROPHONE Select the microphone ON/OFF.
This function will be disabled when
cameras are connected without a
microphone (e.g. covert cameras).
MOTION
AREA
Allows you to define the area size
for motion detection.
MOTION
SENSITIVITY
Allows you to define the sensitivity
of motion detection.
This enables you to detect objects
like a person running across the
motion area but will not raise an
alarm if there is a small movement
(detect humans but no birds).
DISPLAY
MOTION
This allows you to view where the
motion has been detected by dis-
playing a series of movement indi-
cators on the monitor screen.
MAIN MENU
SYSTEM SETTINGS
INSTALLATION
SETUP CAMERA 1
MOTION SENSITIVITY 1
LEVEL
MOTION INDICATOR
RESET INDICATOR
LEVEL Sets the level (the amount) of
motion detection.
MOTION
INDICATOR
Displays the set level of motion
detection.
RESET
INDICATOR
Resets the motion detection indica-
tor to the current setting.
MAIN MENU
SYSTEM SETTINGS
SERVICE
SYSTEM DIAGNOSE
FACTORY DEFAULTS
SYSTEM
DIAGNOSE
With this option you can obtain an
overview of the internal diagnose
settings. (Consult the service man-
ual for more information).
FACTORY
DEFAULTS
With this option you can set the
complete system to the factory
defaults. All current settings will be
lost, (this will take a few seconds).
Language selector and Wizard
setup will be activated again.
MAIN MENU
SYSTEM SETTINGS
SEVICE
FACTORY DEFAULTS
CURRENT SETTINGS
WILL E LOST
CONTINUE?
NO YE S

osch Security Systems | 2003-06
VSS7390/01T Switcher | Installation Manual | Chapter 2 EN | 11
History Switch to playback view View Settings Time and Date System Settings
Main Menu
History list History View Settings
PIP Position Hide Titles Hide Time/Date Brightness Contrast Color Sharpness Hue (NTSC only) Cancel
Time and Date
Time Date Format Date
System Settings
Sequence Alarms Aux - Output Recorder Installation Service Hour Format
Dwell Time
Sequence
Auto Acknowledge Alarm Profile Day Alarm Profile Night Alarm Duration
Alarms
Aux - Output Presentation Mode Aux - out Slave Display Sequence Sequence with Dwell Time Audio Source Day/Night Switch
Aux Output
Playback Detection
Recorder
Beep Volume External Control Setup Camera 1 Language
Installation
Setup Camera 4 Factory Defaults System Diagnose
Service
-------------------
Camera 1 Exit Delay
Alarm Profile Day
Camera 4 Camera 2
Alarm Profile Night
Display Camera 1 Entry Delay Camera 4 Camera 2 Title Covert Display Backlight Compensation Flickerless White Balance Field of View Microphone Motion Area Motion Sensivity Display Motion
External Control
System Address Control at Slave Remote Control
Setup Camera System Diagnose
Diagnose Screen
Factory Defaults
Confirmation Screen
Motion Area
Set Motion Area
Motion Indicator Reset Indicator Sensitivity
Motion Sensitivity
Menu Structure
Camera 3
Camera 3

osch Security Systems | 2003-06
VSS7390/01T Switcher | Installation Manual | Chapter 3 EN | 12
3 TECHNICAL SPECIFICATIONS
APPROVALS
Safety
Europe EN60065
USA UL6500 UL & cUL listed
Australia C-Tick
Electro Magnetic Compatibility (EMC)
Europe EN55022 Class , EN50130-4
USA FCC part 15, class
Australia AS/NZS 3548
ELECTRICAL
Picture tube 14” (viewable picture area
13”), 90° deflection, 0.65 mm
pitch TV grade
Resolution PAL: 320 TVL;
NTSC: 290 TVL
TV standard PAL: 625 lines, 50 Hz, 2:1;
NTSC: 525 lines, 60 Hz, 2:1
Mains supply voltage Universal input, 100 -
240 VAC +/-10%, 50/60 Hz
Power consumption <75 W max. (without
cameras)
Camera power supply 24 to 32 VDC, short-circuit
protected
System synchronizationMonitor locks to the mains
Cameras lock to H and V of
the monitor
Camera inputs 4 (system interface)
Slave monitor output 1 (system interface)
Microphone Sensitivity 46d SPL @ 1kHz
Audio speaker 500 mW rated, 1000 mW
max.
Frequency range 300 - 3kHz
Alarm output screwblock
4-pole screw-block N.O./N.C. contact + system
ground
Contact rating 24VAC or DC, 2 A (resistive
load)
AUX/VCR
Video input NC (1 Vpp, input
impedance 75 Ohm)
Audio input RCA (0.5 Vpp, input
impedance 10 kOhm)
Video output NC (1 Vpp, output
impedance 75 Ohm)
Audio output RCA (0.5 Vpp, output
impedance 1 kOhm)
System cable
4-wire dual twisted pair cable
1 twist/inch, loop resistances
max 16 ohm at 100 meter
MECHANICAL
Weight approx. 9.5 kg/21 lbs
Dimensions (hxwxd) 325 x 364 x 368 mm
12.8 x 14.3 x 14.5 inches
Ambient temperature
Operating +5°C…+45°C
+41...+113 F
Storage -25°C…+70°C
-13...+158 F
Ambient humidity 5% to 95% RH
Specifications may change without notice.
If you have any problems, contact your dealer.

osch Sicherheitssysteme GmbH
Ludwig- ölkow-Allee
85521 Ottobrunn
Germany
www.bosch-sicherheitssysteme.de
osch Security Systems .V.
P.O. ox 80002
5600 J Eindhoven
The Netherlands
www.boschsecuritysystems.com
3122 165 22352 03-30
© 2003 osch Security Systems .V.
Subject to change Printed in Portugal
