Bosch BCC100 User manual

1
BoschHeatingAndCooling.com
Bosch Connected Control
BCC100 Wi-Fi Thermostat User Guide

1
Contents
WARNING: Failure
to follow and read
all instructions
before installing or
operating this device
may cause personal
injury and/or
property damage.
IN THE BOX:
▶BCC100 Wi-Fi Thermostat
▶Screws (2) and Anchors (2)
▶Flathead Screwdriver
▶Wire Labels
▶Jumper Wire
▶User Guide
▶Customer Support Card
Some features require an
internet connection and a
user account. Features,
specifications, and
appearance are subject to
change without notice.
A C-wire (common wire) is
required to power the unit.
Two wire systems are not
supported. If a C-wire is not
available, please contact
your local Contractor for
support.
CHECK COMPATIBILITY FIRST
For conventional (gas/oil/electric) ▶Heat Only, Cool Only,
and Combined Heat & Cool
For heat-pump systems ▶Up To 4-Heat & 2-Cool
Not compatible with other Bosch Boiler controls, such as the Logamatic
Getting Started.......................2
Main Screen............................9
Icons.....................................10
Initialization..........................12
Wi-Fi Setup...........................16
App Setup.............................19
Starting Your System............21
Temporary Scheduling..........23
Programming Schedules.......24
Additional Features ............... 26
Advanced Features...............30
Warranty ............................... 33
Connected Solution for 24VAC Thermostat Systems

2
Getting Started
The BCC100 thermostat is designed to work on most 24VAC
low voltage heating and cooling systems such as gas and oil
furnaces, heat pumps, and single or dual-stage systems.
Professional installation recommended for:
▶Humidifiers and dehumidifiers
Before removing the wires from the old thermostat, take a
picture of the wiring configuration for reference, and then
label each wire according to the terminal codes using the
wire labels provided.
Remove the Old Thermostat
1
NOTE: After labeling the wires, secure them to an
object such as a pen or clip to prevent them from
falling back into the wall.
WARNING: Turn Off Power
Failure to turn off power may result in
electrical shock and/or system damage.
Disconnect the wires from the old thermostat one by
one. Do not let wires fall back into the wall.
Turn Off Power
Please turn off the unit’s main power at the circuit panel
before beginning the installation process.

3
Feed all wires vertically into the hole or slit in the center
of the backplate. Referencing the photo of the previous
wiring configuration or the wire labels currently on the
wires, insert the wires one-by-one into the matching
terminals, and use the supplied flathead screwdriver to
close each terminal. After you have finished fastening the
wires, pull each wire gently to ensure they are secure.
Repeat this process for each wire to be installed.
Connect the New Wall Plate
3
CAUTION: To prevent possible shorts to adjacent
terminals, use care when securing and routing
your thermostat wires.
Mount the New Wall Plate
Use the enclosed screws and anchors to
mount the new wall plate. In most cases,
you can utilize the same mounting position of your old
thermostat. Be sure to check the alignment of your wall
plate before installation to ensure all holes are covered.
2
Note: The color of your wires may not be the same as shown in this User Guide
(1)Emergency heat activated at W1, (2)Auxiliary heat activated at W2,
(3)Only to be used with Bosch WSHP)
BCC100 Terminal Key
Data
Alarm Input3
C
Common
W/E (W1)
1st Stage Heating1
Y (Y1)
1st Stage Compressor
RH
Heating Appliance Power
RC (R)
Cooling Appliance Power
----
Not Used
G
Fan
W2
(W2) 2nd Stage Heating2
Y2
2nd Stage Compressor
O/B
Reversing Valve
H/DH
Humidifier/Dehumidifier
Jumper

4
Conventional Systems
Conventional systems include furnaces, boilers, and
dedicated, non-window air conditioning units.
NOTE: The following wiring diagrams describe some
common configurations that are compatible with the
BCC100. Not all compatible configurations are depicted
below. If you are unsure of how to connect your
thermostat, please contact customer support using the
number on the card provided in the box.
Single Stage Heat – Boiler
Ensure the system has a C-wire
Ensure the pre-installed jumper
wire remains between RH and RC
Connect the R, C and W1 wires
from the boiler to RH, C and W/E
terminals on the wall plate,
respectively
Jumper
----
G
W2
Y2
O/B
H/DH
Data
C
W/E
Y
RH
RC
Single Stage Heat – Furnace
Ensure the system has a C-wire
Ensure the pre-installed jumper
wire remains between RH and RC
Connect the R, C, W1 and G
wires from the Furnace to RH, C,
Y and G terminals on the wall
plate, respectively
Jumper
----
G
W2
Y2
O/B
H/DH
Data
C
W/E
Y
RH
RC

5
Two Stage Heat – Furnance
Ensure the system has a C-wire
Ensure the pre-installed jumper
wire remains between RH and RC
Connect the R, C, W1, W2 and G
wires from the Furnace to RH, C,
W/E, W2 and G terminals on the
wall plate, respectively
Jumper
----
G
W2
Y2
O/B
H/DH
Data
C
W/E
Y
RH
RC
Combined Single Stage Heat and Cool
Furnace and Air Conditioner ONLY
Note: combined boiler and air conditioner
systems are not currently supported.
Ensure the system has a C-wire
Remove the pre-installed jumper
wire from between RH and RC
Connect the R, C, W1 and G wires
from the Furnace to RH, C, W/E
and G terminals on the wall plate,
respectively
Connect the R, C, Y1 and G wires
from the Air Conditioner to RC, C,
Y and G terminals on the wall plate,
respectively
----
G
W2
Y2
O/B
H/DH
Data
C
W/E
Y
RH
RC
Single Stage Cool – Air Conditioner
Ensure the system has a C-wire
Ensure the pre-installed jumper
wire remains between RH and RC
Connect the R, C, Y1 and G wires
from the Air Conditioner to RC,
C, Y and G terminals on the wall
plate, respectively
Jumper
----
G
W2
Y2
O/B
H/DH
Data
C
W/E
Y
RH
RC

6
Single Stage Heat Pump
Ensure the system has a C-wire
Ensure the pre-installed jumper
wire remains between RH and RC
Connect the R, C, Y1, O/B and G
wires from the heat pump to RC,
C, Y, O/B and G terminals on the
wall plate, respectively
Jumper
----
G
W2
Y2
O/B
H/DH
Data
C
W/E
Y
RH
RC
Heat Pump Systems
Heat pump systems are specialty designed to be able to
provide heating and cooling using a single compressor, a
reversing valve, and a fan
Single Stage Heat Pump with
Emergency Heat and Auxiliary Heat
Note: W/E controls the Emergency Heat
output and W2 controls the Auxiliary Heat
output. Therefore, a jumper is required when
using the same heating source for both
Emergency Heat and Auxiliary Heat.
Ensure the system has a C-wire
Ensure the pre-installed jumper
wire remains between RH and RC
Connect the R, C, W1, Y1, O/B and
G wires from the heat pump to RC,
C, W/E, Y, O/B and G terminals on
the wall plate, respectively
Connect the supplied jumper
wire between the W/E and W2
terminals of the wall plate
Jumper
----
G
W2
Y2
O/B
H/DH
Data
C
W/E
Y
RH
RC
Two Stage Heat Pump with
One Stage Emergency Heat
Ensure the system has a C-wire
Ensure the pre-installed jumper
wire remains between RH and RC
Connect the R, C, W1, Y1, Y2,
O/B and G wires from the heat
pump to RC, C, W/E, Y, Y2, O/B
and G terminals on the wall plate,
respectively
Jumper
----
G
W2
Y2
O/B
H/DH
Data
C
W/E
Y
RH
RC

7
Humidifier or Dehumidifier
Accessory with a Combined Single
Stage Heat and Cool Conventional
System
Note: The wiring configuration for
humidifiers and dehumidifiers is the same
for all type of Conventional Systems.
Ensure that the accessory is
externally powered
Ensure the Conventional System
is wired correctly
Connect the control wire of the
accessory to the H/DH terminal
of the wall plate
----
G
W2
Y2
O/B
H/DH
Data
C
W/E
Y
RH
RC
Humidifier and Dehumidifier Accessory
A single Humidifier or Dehumidifier Accessory can be
controlled using the BCC100. The thermostat only
supports Humidifiers in heating operation, Dehumidifiers
in cooling operation, and only one accessory per
thermostat.
Humidifier or Dehumidifier
Accessory with a Single Stage
Heat Pump
Note: The wiring configuration for
humidifiers and dehumidifiers is the same
for all type of Heat Pump Systems
Ensure that the accessory is
externally powered
Ensure the Heat Pump System is
wired correctly
Connect the control wire of the
accessory to the H/DH terminal
of the wall plate
Jumper
----
G
W2
Y2
O/B
H/DH
Data
C
W/E
Y
RH
RC

8
Attach BCC100 to the Wall Plate
Align the two clips on
the back of the
BCC100 into the
corresponding slots
on the top of the
wall plate.
4
Firmly press forward
until you hear a click to
secure the thermostat
into position.
1
2
PUSH
CLIPS
Switch on the power to the heating/cooling system at the
main switch box. If the thermostat does not power on,
remove the BCC100 from the wall and ensure the RH/RC
wire(s) and C-wire are correctly connected to both the
appliance and the thermostat.

9
When your thermostat powers on, it prompts you to
start the setup. If you are having trouble powering the
thermostat, please refer to the Customer Support
Card in the box for additional support information.
Thank you for choosing the BCC100. Enjoy the savings
and comfort of owning a Bosch connected thermostat!
Main Screen
System
Mode
Main Menu Fan
Status Wifi / Cloud Access
Indicator
Current
Room
Humidity Current Room
Temperature
Current
Schedule
Adjust
Temperature
Set-Points
Enjoy the experience
of the product!
5

10
Icons
Menu
Exit / Save Settings
Back
Weather
Schedule
Device Settings
System Settings
Advanced Settings
Heat Mode
Cool Mode
Auto Mode
Emergency Heat Mode
Off
Gas/Oil/
Propane
Heat Pump
Electric
Auto
On
Circulation
Humidifier
Dehumidifier
System Modes
Basic Icons Heating Types
Fan Modes
Humidity
10

11
Icons
11
Schedule on Device
Schedule on Cloud
Wi-Fi Connection Established
Wi-Fi Connection Not Established
Internet is Not Available
Retry Internet Connection
System Connectivity
Unit Operation
1 2
12
1 2
1 2
4
Heat Mode
Heating on (1st stage) & (2nd stage)
Cool Mode
Cooling on (1st stage) & (2nd stage)
Auto Mode
Heating on (1st stage) & (2nd stage)
Auto Mode
Cooling on (1st stage) & (2nd stage)
Fan on/running - Fan Auto Mode
Emergency heat on
Auxiliary heat on - 2nd Aux Stage of a
4-stage heating system
Auxiliary
Heating
Emergency
Heating

12
For a quick and easy way to begin using your new smart
thermostat, the device will automatically direct you to the
Initial Setup screen after you have turned it on for the first
time.
Initialization
Heat Pump System
Configure the reversing valve for O (energized in cool) or B
(energized in heat) and enable/disable Emergency Heat and/or
Auxiliary Heat.
1. Unit Configuration
Select your home’s heating type, stage configuration for
heating and cooling, and type of accessory (humidifier or
dehumidifier) if available.
NOTE: If you do not know which operation to choose,
check your heating/cooling system manual or consult
a professional HVAC technician.
Humidifier & Dehumidifier Unit Configuration
When selecting a dehumidifier, you have the ability to enable or
disable Cool to Dehumidify. When selecting a humidifier, you have
the ability to choose between either a steam or evaporative type.
Enabling this feature will allow the thermostat to control an external
dehumidifier accessory, while disabling this feature will allow the
thermostat to control specific appliances, such as Bosch Water
Source Heat Pumps equipped with Hot Gas Reheat coils and/or
ECM motors, with just an H/DH call.

13
2. Date & Time
ON DEVICE: Enter your location’s current date and time;
after the device is registered or linked to a user account,
the date and time on the device will automatically update
to the current time associated
with the user account.
APP: The date and time for the device, as well as the user
account, will automatically update by selecting the time
zone for the device.
3. Wi-Fi Setup
The BCC100 requires a reliable Wi-Fi connetion in order
to access smart features such as remote access, weather
forecast and more. To complete the Wi-Fi setup, follow
the on-screen instructions. Additional instructions are
also available on page 16 in the Wi-Fi Setup section of this
User Guide.
After a successful connection, the thermostat displays the
Registration screen. Follow the instructions on the screen
to complete the setup. After completing the setup,
download the Bosch Connected Control (BCC100) app
from the App Store or Google Play. Create an account
within the app and then add a device by following the
on-screen instructions.

14
4. Schedule
During offline operations, only 2 schedules (Home and
Vacation) are available. However, when a Wi-Fi connection
is established, the list can be expanded up to 4 schedules.
HOME: You can use this schedule to set your heating/
cooling equipment to predefined set points. The device
initially comes with a factory default schedule, which can
be adjusted as necessary.
VACATION: This schedule will be used to set your
heating/cooling equipment to 2 periods with set points (1
heating and 1 cooling) that can be manually adjusted.
However, you will not be able to add additional or remove
current periods. The schedule can be used for vacation or
permanently setting a heating/cooling set point.

15
5. Review
In the final step, the BCC100 provides a review of all
information that you have entered into the thermostat.
You will be able to go back to different parts of the Initial
Setup guide by pressing the different sections on the left
pane. If you have completed the review, please press the
Complete button to start utilizing your BCC100!

16
Wi-Fi Connection
SCAN: To start Wi-Fi setup, tap the Wi-Fi icon in the top
right hand corner of the main screen. Then click the Scan
icon to view available Wi-Fi networks. Follow the
on-screen instructions to complete the Wi-Fi setup.
Hidden Wi-Fi Connection
MANUAL ENTRY: If you are trying to connect to a hidden
network, press the SSID button to bring up the SSID
screen. Enter your SSID into the text box, then follow the
on-screen instruction to complete the Wi-Fi setup.
Wi-Fi Setup

17
NOTE: If this is a first time installation, follow the
instructions in the App Setup section of this User
Guide to register your thermostat to your smart device.
The following may cause a failed connection
to the device:
▶Wi-Fi signal is too weak
▶5 GHz Wi-Fi network is not supported
▶SSID contains space or non-ASCII characters
▶Incorrect password
▶Wi-Fi is okay but your internet is unavailable
▶Additional web authentication is not supported
After you have successfully established a connection, your
network name appears. If your thermostat is already
registered to your account on your smart device, your
User ID name appears.
NOTE: For all smart devices that require access to the
same thermostat, you must use the same account.

18
For an unregistered device, click the green Registration
button to register your account. If you want to register a
different account to your device, you can also click the
Registration button and follow the steps outlined in the
App Setup section of this User Guide.
Auto Reconnect
If your device loses connection with your wireless
network, it will automatically attempt to reconnect after
5 minutes. If that fails, it will make a new attempt every
15 minutes for the next 24 hours. Any manual network
reconfiguration of the thermostat will stop automatic
reconnection attempts.

19
BOSCH CONNECTED CONTROL COMPATIBLE DEVICES
Apple® devices running iOS 7.1 & higher
Android™ devices running 4.0.3 & higher
There are three ways to download the
BCC100 App for your smart device:
▶ In the App Store or Google Play, search “Bosch
Connected Control” or “BCC100” and then
download the app.
▶ Use your smart device to scan the QR code below or
on the packaging to be directed to the Bosch website
for easy download.
▶ On your smart device, navigate to the website:
www.bosch-climate.us/bcc100
and click the links for the app
in the Download the App
section to download.
App
Setup
Congratulations! You are now connected
to the thermostat. Now set up your App to
enjoy additional exciting features.
Step 1: Download
