Bose T1 ToneMatch User manual

©2010 Bose Corporation Reference Number 296137-SM Rev. 01
Service Manual
T1 ToneMatch®Audio Engine
US/Canada, European, UK and Australian Versions
Electronic Copy Only

2
Contents
Safety Information.............................................................................................................................3
Warranty.............................................................................................................................................3
Specifications....................................................................................................................................4
Product Description...................................................................................................................... 4-6
Electrostatic Discharge Sensitive (ESDS) Device Handling .........................................................7
Part List Notes...................................................................................................................................7
Accessories .......................................................................................................................................7
Packaging Part List, T1 ToneMatch®Audio Engine (see Figure 1)...............................................8
Figure 1. T1 ToneMatch Audio Engine Packaging View .....................................................................8
Main Part List, T1 ToneMatch Audio Engine (see Figure 2) ..........................................................9
Figure 2. T1 ToneMatchTM Audio Engine Exploded View ................................................................10
Electrical Part Lists....................................................................................................................11-39
Input/Output PCB Assembly .....................................................................................................11-14
Digital Signal Processor (DSP) PCB Assembly...................................................................... 15-39
Display PCB Assembly ...................................................................................................................39
Disassembly Procedures ......................................................................................................... 40-41
Test Procedures ........................................................................................................................ 42-43
Appendix .................................................................................................................................... 44-65
T1 ToneMatch Test Cables .............................................................................................................44
Software Update Procedure ...........................................................................................................45
Theory of Operation.................................................................................................................. 46-51
Circuit Board Layout Diagrams ............................................................................................... 52-56
Figure 3. DSP PCB Top Component Layout and Etch......................................................................52
Figure 4. DSP PCB Top Component Layout and Power Layer Etch ................................................53
Figure 5. DSP PCB Top Component Layout and Ground Layer Etch...............................................54
Figure 6. DSP PCB Bottom Component Layout and Etch ................................................................55
Figure 7. Input / Output PCB Top Component Layout and Etch .......................................................56
Figure 8. Input / Output PCB Bottom Component Layout and Etch .................................................56
Figure 9. -15V PCB Top Component Layout and Etch .....................................................................56
Figure 10. -15V PCB Bottom Component Layout and Etch..............................................................56
Figure 11. Display PCB Top Component Layout and Etch ...............................................................56
IC Diagrams ............................................................................................................................... 57-65
Troubleshooting ........................................................................................................................ 66-69
Service Manual Revision History...................................................................................................69

3
Safety Information
1. Parts that have special safety characteristics are identified by the symbol on schematics
or by special notes on the parts list. Use only replacement parts that have critical characteristics
recommended by the manufacturer.
2. Make leakage current or resistance measurements to determine that exposed parts are
acceptably insulated from the supply circuit before returning the unit to the customer.
Use the following checks to perform these measurements:
A. Leakage Current Hot Check-With the unit completely reassembled, plug the AC line cord
directly into a 120V AC outlet. (Do not use an isolation transformer during this test.) Use a
leakage current tester or a metering system that complies with American National Standards
Institute (ANSI) C101.1 "Leakage Current for Appliances" and Underwriters Laboratories (UL)
6500 / IEC 60056 paragraph 9.1.1. With the unit AC switch first in the ON position and then in
OFF position, measure from a known earth ground (metal waterpipe, conduit, etc.) to all ex-
posed metal parts of the unit (antennas, handle bracket, metal cabinet, screwheads, metallic
overlays, control shafts, etc.), especially any exposed metal parts that offer an electrical return
path to the chassis. Any current measured must not exceed 0.5 milliamp. Reverse the unit
power cord plug in the outlet and repeat test. ANY MEASUREMENTS NOT WITHIN THE
LIMITS SPECIFIED HEREIN INDICATE A POTENTIAL SHOCK HAZARD THAT MUST BE
ELIMINATED BEFORE RETURNING THE UNIT TO THE CUSTOMER.
B. Insulation Resistance Test Cold Check-(1) Unplug the power supply and connect a jumper
wire between the two prongs of the plug. (2) Turn on the power switch of the unit. (3) Measure
the resistance with an ohmmeter between the jumpered AC plug and each exposed metallic
cabinet part on the unit. When testing 3 wire products, the resistance measured to the product
enclosure should be between 2 and infinite MOhms. Also, the resistance measured to exposed
input/output connectors should be between 4 and infinite MOhms. When testing 2 wire prod-
ucts, the resistance measured to exposed input/output connectors should be between 4 and
infinite MOhms. If it is not within the limits specified, there is the possibility of a shock hazard,
and the unit must be repaired and rechecked before it is returned to the customer.
CAUTION: The Bose®T1 ToneMatch®Audio Engine contains
no user-serviceable parts. To prevent warranty infractions,
refer servicing to warranty service stations or factory service.
PROPRIETARY INFORMATION
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF
BOSE CORPORATION WHICH IS BEING FURNISHED ONLY FOR
THE PURPOSE OF SERVICING THE IDENTIFIED BOSE PRODUCT
BYAN AUTHORIZED BOSE SERVICE CENTER OR OWNER OF
THE BOSE PRODUCT, AND SHALL NOT BE REPRODUCED OR
USED FOR ANY OTHER PURPOSE.
The Bose T1 ToneMatch Audio Engine is covered by a limited 2-year transferable warranty.
Warranty

4
Specifications
Mechanical
Dimensions: 8.22” L x 6.52” W x 2.66” H
208.9 x 165.5 x 67.6mm
Weight (unpackaged): 2.14 lb (0.97 kg)
Electrical
A/D and D/A Conversion: 24 bit
Sampling Rate: 48 kHz
USB: 1:1 protocol, Type A to Type B cable
PC Requirements: Microsoft Windows 2000, 2000 Pro, XP
The Bose®T1 ToneMatch®audio engine provides the ultimate control for performing musicians.
The T1 ToneMatch audio engine can be used with a Bose L1™ model II or model I system.
When used with the Bose L1 model II or model I system, the T1 allows you to control the sound
of your instrument as well as the output of the entire system. Using proprietary ToneMatch
presets and associated zEQ tonal adjustments, the T1 enables you to preserve the natural
sound of instruments or vocal microphones when amplified.
For convenient access, you can mount the T1 on a Cylindrical Radiator®loudspeaker or on a
microphone stand using the optional microphone stand bracket. When used with the L1 model II
system, the T1 operates on DC power received from the power stand. The optional T1
ToneMatch audio engine power supply is used to power the T1 when it is connected to an L1
model I system or a USB port on your computer.
Features and benefits
• Quick and easy-to-use interface
• One-cable connection to L1 model II loudspeaker ToneMatch port
• Mountable on a Cylindrical Radiator loudspeaker or a microphone stand
• High-quality, low-noise preamps in each channel, allowing the use of almost any instrument or
microphone
• LED display and illuminated controls for playing on dimly-lit stages
• ToneMatch presets, a proprietary technology that optimizes system equalization to preserve
the natural sound of specific instruments or microphones
• zEQ, working in conjunction with the ToneMatch technology, automatically adjusts the low,
mid, and high frequency bands for the selected preset, allowing further tonal shaping
• Built-in chromatic tuner
• Performance scenes that can be saved and recalled
• Two flexible analog outputs
• System updates and ToneMatch presets available at www.Bose.com/musicians
• USB audio interface to your computer
• Compatible with L1 model I and model II systems
Product Description

5
Front Panel Controls and Indicators
The control panel provides all the necessary controls and indicators for operation.
1. Input signal/clip LEDs (1-4/5) – Displays the input signal status in color: Green indicates the
presence of an input signal, yellow indicates a signal near clipping, and red indicates clipping.
2. Trim controls (1-4/5) – Adjusts the input sensitivity for the respective channel.
3. Phantom power switch – Applies +48V power to input channels 1-3. A red LED indicates
that phantom power is on.
4. T1 rotary selector –Allows access to both global and channel related parameters, which are
adjusted using the editing controls.
5. MASTER volume control – Adjusts the overall output level.
6. Mute buttons (1-4/5) – Silences the audio output for the respective channel.
7. Volume controls (1-4/5) – Adjusts the volume level for the respective channel.
8. FX mute buttons (1-4/5) – Bypasses the Mod, Delay, and Reverb effects on the selected
channel.
9. CH Edit buttons (1-4/5) – Selects the channel you want to modify using the T1 rotary selec-
tor and display-related editing controls.
10. Editing controls – These three rotary/push-button controls allow you to select or adjust
items/values appearing on the display.
11. Display – Provides function menus and system status information.
1
23
4
5
6
7
8
9
10
11

6
The rear panel provides all input/output connections.
1. IN – Analog input channels 1-3. Accepts XLR balanced cables for microphones, or ¼” TRS
balanced or TS unbalanced cables for high-impedance inputs such as guitars.
2. Preamp OUT – Preamp outputs for channels 1-3. Accepts ¼” TRS balanced or TS unbal-
anced cables.
3. Line IN – Analog input channels 4/5. Accepts ¼” TRS balanced or TS unbalanced cables for
line-level inputs. Can be used for stereo input signals.
4. Aux Output – User-definable analog output. Can be configured for a pre-fader, post-EQ, and
effects, or postfader output. Accepts ¼” TRS balanced or TS unbalanced cables.
5. Master Output – User-definable analog output. Can be configured for a pre- or post-Master
volume analog output. Accepts ¼” TRS balanced or TS unbalanced cables.
6. USB port – A USB interface that allows you to connect the T1 to your computer. This feature
enables you to stream audio to/from your computer, update the T1, and back up performance
scenes.
7. Power switch – Turns the T1 audio engine on or off.
8. ToneMatchTM port – A digital output used by the L1TM model II system. Also delivers power to
the T1 audio engine from the L1 model II power stand. Accepts the included ToneMatch cable.
CAUTION: Although the ToneMatch port accepts a standard RJ-45 connector, DO NOT connect
the T1 to a computer or phone network. Damage to the T1 could result.
Rear Connection Panel
2
3
6
5
7
1
4
8

7
Part List Notes
1. This part is not normally available from Customer Service. Approval from the Field Service
Manager is required before ordering.
2. The individual parts located on the PCBs are listed in the Electrical Part List.
3. This part is critical for safety purposes. Failure to use a substitute replacement with the
same safety characteristics as the recommended replacement part might create shock, fire
and/or other hazards.
4. This part is referenced for informational purposes only. It is not stocked as a repair part. Refer
to the next higher assembly for a replacement part.
Electrostatic Discharge Sensitive (ESDS)
Device Handling
This unit contains ESDS devices. We recommend the following precautions when repairing,
replacing or transporting ESDS devices:
•Perform work at an electrically grounded work station.
•Wear wrist straps that connect to the station or heel straps that connect to conductive
floor mats.
•Avoid touching the leads or contacts of ESDS devices or PC boards even if properly
grounded. Handle boards by the edges only.
•Transport or store ESDS devices in ESD protective bags, bins, or totes. Do not insert
unprotected devices into materials such as plastic, polystyrene foam, clear plastic bags,
bubble wrap or plastic trays.
Accessories
Description Bose
®
Part Number Vendor Part Number
T1 ToneMatchTM Power Supply 042533 -
Ethercon Cable Assy 042536 svc-sien11+cable
Carry Bag Accessory 042534 svc-sien11+bag
Microphone Stand Bracket 042535 -
T1 ToneMatch audio engine
power supply
ToneMatch audio engine
microphone stand bracket

8
Packaging Part List
T1 ToneMatch®Audio Engine (see Figure 1)
1234
546
7
89
10 11 12
13 14
15
Figure 1. T1 ToneMatch Audio Engine Packaging View
Item
Number
Description Bose
®
Part
Number
Vendor Part Number Qty. Note
- CARTON KIT, CONSISTS OF
ITEMS 7, 8 AND 15 BELOW 312215 - 1
1 CD ROM - 1
2 OWNER’S MANUAL 303150 4301-7273+0 1
3 QUICKSTART GUIDE 303149 4301-7299+0 1
4 POLYBAG - 1497-4122+0 2 4
5 T1 TONEMATCH AUDIO ENG REF - 1
6 NYLON CARRY BAG 042534 SVC-SIEN11+BAG 1
7 UPPER PACKING TRAY 307723 SVC-SIEN11+TRAYU 1
8 LOWER PACKING TRAY 307724 SVC-SIEN11+TRAYL 1
9 RJ-45 ETHERCON CABLE 042536 SVC-SIEN11+CABLE 1
10 L2 CARRIAGE 298750 4155-2721+0 1
11 RETENTION SCREW 298751 4155-2731+0 1
12 POLYBAG - 1497-2812+0 1 4
13 L2 MOUNTING ARM 298749 4135-7071+0 1
14 POLYBAG - 1497-7222+0 1 4
15 GIFT BOX (CARTON) 298754 1481-0701+1 1

9
Main Part List
T1 ToneMatch®Audio Engine (see Figure 2)
Item
Number Description Bose
®
Part
Number
V
endor Part
Number Qty. Note
1 PANEL, REAR, I/
O
298733 1406-3101+0 1
2 HOUSING, TOP 298730 1468-0401+1 1
3 HOUSING, BOTTOM 298731 1468-0501+1 1
- LID ASSY, CONSISTS OF ITEMS
4, 14, 24, 25, 26 AND28 BELOW 305293 SVC-SIEN11+LID 1
4 LID, PC+TPE 298746 1468-0701+1 1
5 LCD PCB ASSY 305296 SVC-SIEN11+LCDB 1
6 BOSE LOGO, ALUM 298742 2150-7221+0 1
7 KNOB, CHANNEL VOLUME 298737 2447-4401+1 4
8 KNOB, ROTARY 298739 2447-4501+1 3
9 BUTTON, PHANTOM PWR 298743 2447-4601+1 1
10 KNOB, TRIM 298741 2447-4801+1 4
11 KNOB, MASTER VOLUME 298738 2447-4901+1 2
12 SPRING, 4x10x0.35 - 2510-3971+0 2 4
13 WASHER, SPRING, M3x0.9x5.5 - 2607-3009+0553 6 4
14 WASHER, SPRING, M9x1x11, BZ 307727 2607-9010+1103 1
15 SCREW, MACH, PAN, M3x10 - 2900-3010+3000 6 4
16 SCREW, FLAT-CS, M3x5, B - 2901-3005+3000 2 4
17 SCREW, MACH, FLAT-CS - 2901-3006+3000 1 4
18 SCREW, M3x8, S29503008-3000 - 2920-3008+3000 8 4
19 B-TITE, 3x10, BLK, ZN - 2954-3010+3000 2 4
20 CONNECTOR PCB ASSEMBLY 305297 SVC-SIEN11+I/O 1
21 MOUNTING BKT, REA
R
298749 4135-7071+0 1
22 BRACKET, LCD - 4135-7081+0 1 4
23 NUT, PLASTIC, M10x4.8 - 4155-1031+0 6 4
24 RETAINER, BSPASIEN+05CS11 301567 4155-2631+0 1
25 LATCH, LID 298748 4155-2641+1 1
26 LID RELEASE 298747 4155-2651+0 1
27 PANEL, TOP, FX, PMM
A
298732 4155-2661+1 1
28 MOUNT, SWING ARM 301568 4155-2671+0 1
29 CARRIAGE, 50x100 298750 4155-2721+0 1
30 SCREW, RETENTION, 30x12 298751 4155-2731+0 1
31 SPACER, NYLON, 5x10 - 4155-2791+0 4 4
32 KEYPAD 1, FX MUTE, SILICON 298744 4157-1251+0 1
33 KEYPAD 2, FX MUTE, SILICON 298745 4157-1261+0 1
34 RUBBER FOOT, 9x18x2 331349-
001S 4157-1271+0 4 4
35 SWITCH, ROCKER, 2PIT - 5200-4910+0 1 4
36 CONN WIRE, 2P, P2.0, #28 - 7012-6919+0 1 4
37 WIRE-CONN, 4P, P2.5, #24 - 7012-9180+0 1 4
38 MODULE, LCD, HDG12864L-7 299212 8902-0020+0 1
39 MAIN PCB ASSEMBLY 298756 SVC-SIEN11+MAIN 1

10
Figure 2. T1 ToneMatch®Audio Engine Exploded View

11
Electrical Part List
Resistors
Input/Output PCB Assembly
Reference
Designator
Description Vendor Part
Number
Note
R1 100K, RMG, 0603, 1/16W, 1% 4723-104A+P 4
R2 100K, RMG, 0603, 1/16W, 1% 4723-104A+P 4
R3 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R4 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R5 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R6 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R7 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R8 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R9 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R10 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R11 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R12 100 OHM, RMG, 0603, 1/16W, 1% 4723-101A+P 4
R13 100 OHM, RMG, 0603, 1/16W, 1% 4723-101A+P 4
R14 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R37 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R38 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R57 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R58 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R59 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R60 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R61 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R62 4.99K, RMG, 0603, 1/16W, 1% 4723-4991+P 4
R63 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R64 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R65 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R66 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R67 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R68 4.99K, RMG, 0603, 1/16W, 1% 4723-4991+P 4
R69 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R70 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R71 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R72 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R73 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R74 4.99K, RMG, 0603, 1/16W, 1% 4723-4991+P 4
R75 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R76 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R77 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R78 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R79 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R80 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R81 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R82 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R83 4.99K, RMG, 0603, 1/16W, 1% 4723-4991+P 4
R84 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R85 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R86 4.99K, RMG, 0603, 1/16W, 1% 4723-4991+P 4

12
Electrical Part List
Resistors (continued)
Input/Output PCB Assembly
Capacitors
Reference
Designator
Description Vendor Part
Number
Note
R128 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R139 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R223 47K, RMG, 0603/1608, 1/16W, 5% 4723-473J+P 4
R224 47K, RMG, 0603/1608, 1/16W, 5% 4723-473J+P 4
R225 47K, RMG, 0603/1608, 1/16W, 5% 4723-473J+P 4
R226 47K, RMG, 0603/1608, 1/16W, 5% 4723-473J+P 4
R227 47K, RMG, 0603/1608, 1/16W, 5% 4723-473J+P 4
R228 47K, RMG, 0603/1608, 1/16W, 5% 4723-473J+P 4
R229 47K, RMG, 0603/1608, 1/16W, 5% 4723-473J+P 4
R230 47K, RMG, 0603/1608, 1/16W, 5% 4723-473J+P 4
R231 47K, RMG, 0603/1608, 1/16W, 5% 4723-473J+P 4
R232 47K, RMG, 0603/1608, 1/16W, 5% 4723-473J+P 4
R233 100 OHM, RMG, 0603, 1/16W, 1% 4723-101J+P 4
R234 100 OHM, RMG, 0603, 1/16W, 1% 4723-101J+P 4
R235 100 OHM, RMG, 0603, 1/16W, 1% 4723-101J+P 4
R236 100 OHM, RMG, 0603, 1/16W, 1% 4723-101J+P 4
R237 100 OHM, RMG, 0603, 1/16W, 1% 4723-101J+P 4
R239 100 OHM, RMG, 0603, 1/16W, 1% 4723-101J+P 4
R240 100 OHM, RMG, 0603, 1/16W, 1% 4723-101J+P 4
R243 100 OHM, RMG, 0603, 1/16W, 1% 4723-101J+P 4
R244 100 OHM, RMG, 0603, 1/16W, 1% 4723-101J+P 4
R246 100 OHM, RMG, 0603, 1/16W, 1% 4723-101J+P 4
R284 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R292 47K, RMG, 0603/1608, 1/16W, 5% 4723-473J+P 4
Reference
Designator
Description Vendor Part
Number
Note
C5 330pF, CC, 0603/1608, 50V, 10%, 1X2 150F-331K+P-AC 4
C6 330pF, CC, 0603/1608, 50V, 10%, 1X2 150F-331K+P-AC 4
C7 1000pF, CC, 0603/1608, 50V, 10%, 1X2 150F-102K+P-AC 4
C8 1000pF, CC, 0603/1608, 50V, 10%, 1X2 150F-102K+P-AC 4
C9 1000pF, CC, 0603/1608, 50V, 10%, 1X2 150F-102K+P-AC 4
C10 1000pF, CC, 0603/1608, 50V, 10%, 1X2 150F-102K+P-AC 4
C11 1000pF, CC, 0603/1608, 50V, 10%, 1X2 150F-102K+P-AC 4
C12 1000pF, CC, 0603/1608, 50V, 10%, 1X2 150F-102K+P-AC 4
C13 330pF, CC, 0603/1608, 50V, 10%, 1X2 150F-331K+P-AC 4
C14 330pF, CC, 0603/1608, 50V, 10%, 1X2 150F-331K+P-AC 4
C15 1000pF, CC, 0603/1608, 50V, 10%, 1X2 150F-102K+P-AC 4
C16 1000pF, CC, 0603/1608, 50V, 10%, 1X2 150F-102K+P-AC 4
C17 1000pF, CC, 0603/1608, 50V, 10%, 1X2 150F-102K+P-AC 4
C18 1000pF, CC, 0603/1608, 50V, 10%, 1X2 150F-102K+P-AC 4
C19 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C20 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C21 330pF, CC, 0603/1608, 50V, 10%, 1X2 150F-331K+P-AC 4
C22 330pF, CC, 0603/1608, 50V, 10%, 1X2 150F-331K+P-AC 4
C23 470pF, CC, 0603, 50V, 5% 150F-471J+P-AC 4

13
Electrical Part List
Input/Output PCB Assembly
Capacitors (continued)
Reference
Designator
Description Vendor Part
Number
Note
C25 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C26 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C27 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C28 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C29 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C30 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C31 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C32 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C33 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C42 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C43 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C44 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C45 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C46 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C47 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C48 1000pF, CC, 0603/1608, 50V, 10%, 1X2 150F-102K+P-AC 4
C76 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C77 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C78 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C86 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C87 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C88 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C89 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C90 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C91 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C92 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C93 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C94 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C95 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C105 470pF, CC, 0603, 50V, 5% 150F-471J+P-AC 4
C111 0.1uF, CC, 0603/1608, 50V, 10%, 1x2 150F-104K+P-AC 4
C119 0.1uF, CC, 0603/1608, 50V, 10%, 1x2 150F-104K+P-AC 4
C182 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C184 0.1uF, CC, 0603/1608, 50V, 10%, 1x2 150F-104K+P-AC 4
C186 0.1uF, CC, 0603/1608, 50V, 10%, 1x2 150F-104K+P-AC 4
C187 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C193 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C194 0.1uF, CC, 0603/1608, 50V, 10%, 1x2 150F-104K+P-AC 4
C198 0.1uF, CC, 0603/1608, 50V, 10%, 1x2 150F-104K+P-AC 4
C199 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C202 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C205 0.1uF, CC, 0603/1608, 50V, 10%, 1x2 150F-104K+P-AC 4
C206 0.1uF, CC, 0603/1608, 50V, 10%, 1x2 150F-104K+P-AC 4
C207 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C237 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C238 0.1uF, CC, 0603/1608, 50V, 10%, 1x2 150F-104K+P-AC 4

14
Electrical Part List
Input/Output PCB Assembly
Capacitors (continued)
Reference
Designator
Description Vendor Part
Number
Note
C239 0.1uF, CC, 0603/1608, 50V, 10%, 1x2 150F-104K+P-AC 4
C240 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C241 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C242 0.1uF, CC, 0603/1608, 50V, 10%, 1x2 150F-104K+P-AC 4
C243 0.1uF, CC, 0603/1608, 50V, 10%, 1x2 150F-104K+P-AC 4
C244 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C336 22uF, CE, 16V, 20%, SMD, 5X5.8 157D-226M+3-IKC 4
C337 22uF, CE, 16V, 20%, SMD, 5X5.8 157D-226M+3-IKC 4
Reference
Designator
Description Vendor Part
Number
Note
D13 BAV99, SOT23, PHILIPS 4840-8970+3 4
D14 BAV99, SOT23, PHILIPS 4840-8970+3 4
Diodes
Integrated Circuits
Reference
Designator
Description Vendor Part
Number
Note
U7 NJM2068M-#ZZZB, DUAL OP AMP 3130-6890+0 4
U8 NJM2068M-#ZZZB, DUAL OP AMP 3130-6890+0 4
U13 NJM2068M-#ZZZB, DUAL OP AMP 3130-6890+0 4
U15 NJM2068M-#ZZZB, DUAL OP AMP 3130-6890+0 4
U17 NJM2068M-#ZZZB, DUAL OP AMP 3130-6890+0 4
U18 NJM2068M-#ZZZB, DUAL OP AMP 3130-6890+0 4
Miscellaneous
Reference
Designator
Description Vendor Part
Number
Note
CN504B HOUSING, 2X8P, P2.54, STRAIGHT, F 2101-3160+0 4
J1 JACK, SOCKET, NRJ6HF, STEREO 2113-3085+0 4
J6 JACK, SOCKET, NRJ6HF, STEREO 2113-3085+0 4
J7 JACK, SOCKET, NRJ6HF, STEREO 2113-3085+0 4
J8 JACK, SOCKET, NRJ6HF, STEREO 2113-3085+0 4
J10 JACK, SOCKET, NRJ6HF, STEREO 2113-3085+0 4
J11 JACK, SOCKET, NRJ6HF, STEREO 2113-3085+0 4

15
Electrical Part List
Digital Signal Processor (DSP) PCBAssembly
Resistors
Reference
Designator
Description Vendor Part
Number
Note
R3 100K, RMG, 0603, 1/16W, 1% 4723-104A+P 4
R4 100K, RMG, 0603, 1/16W, 1% 4723-104A+P 4
R6 10M, RMG, 0603/1608, 1/16W, 5% 4723-106J+P 4
R7 100 OHM, RMG, 0603/1608, 1/16W, 5% 4723-101J+P 4
R8 100 OHM, RMG, 0603/1608, 1/16W, 5% 4723-101J+P 4
R9 100 OHM, RMG, 0603/1608, 1/16W, 5% 4723-101J+P 4
R10 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R11 100K, RMG, 0603, 1/16W, 1% 4723-104A+P 4
R13 2K, RMG, 0603/1608, 1/16W, 1% 4723-202A+P 4
R14 100 OHM, RMG, 0603, 1/16W, 1% 4723-101A+P 4
R15 100 OHM, RMG, 0603, 1/16W, 1% 4723-101A+P 4
R16 1K, RMG, 0603/1608, 1/16W, 1% 4723-102A+P 4
R17 10 OHM, RMG, 0603/1608, 1/16W, 5% 4723-100J+P 4
R18 1K, RMG, 0603/1608, 1/16W, 1% 4723-102A+P 4
R19 6.8K, RMG, 0603/1608, 1/16W, 1% 4723-682A+P 4
R20 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R21 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R22 22 OHM, RMG, 0805, 1/10W, 1% 4720-220A+J 4
R23 22 OHM, RMG, 0805, 1/10W, 1% 4720-220A+J 4
R24 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R25 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R26 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R27 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R28 1K, RMG, 0603/1608, 1/16W, 1% 4723-102A+P 4
R29 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P-R 4
R31 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R32 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R33 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R34 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R35 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R36 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R37 1K, RMG, 0603/1608, 1/16W, 1% 4723-102A+P 4
R38 3.3K, RMG, 0603, 1/16W, 5% 4723-332J+P-R 4
R39 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R40 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R41 1K, RMG, 0603/1608, 1/16W, 1% 4723-102A+P 4
R42 1M, RMG, 0805, 1/10W, 1% 4720-105A+J 4
R43 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P-R 4
R44 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R45 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R46 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R47 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R48 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R49 10M, RMG, 0603/1608, 1/16W, 5% 4723-106J+P 4
R50 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R51 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4

16
Electrical Part List
Resistors (continued)
Reference
Designator
Description Vendor Part
Number
Note
R52 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R53 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R54 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R55 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R56 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R57 3.3K, RMG, 0603, 1/16W, 5% 4723-332J+P-R 4
R58 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P-R 4
R59 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P-R 4
R60 1K, RMG, 0603/1608, 1/16W, 1% 4723-102A+P 4
R61 1K, RMG, 0603/1608, 1/16W, 1% 4723-102A+P 4
R62 1K, RMG, 0603/1608, 1/16W, 1% 4723-102A+P 4
R63 1K, RMG, 0603/1608, 1/16W, 1% 4723-102A+P 4
R64 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R65 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R66 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R67 4.7K, RMG, 0603/1608, 1/16W, 1% 4723-472A+P 4
R68 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R69 4.42K, RMG, 0603, 1/16W, 1% 4723-4421+P 4
R70 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R71 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R72 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R78 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R79 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R81 0 OHM, RMG, 1206, 1/8W, 1% 4721-000A+6 4
R82 3.3 OHM, RMG, 1206, 1/8W, 5% 4721-3R3J+6 4
R83 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R84 6.8K, RMG, 0603, 1/16W, 5% 4723-682J+P-R 4
R85 6.8K, RMG, 0603, 1/16W, 5% 4723-682J+P-R 4
R86 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R87 10K, RMG, 1206, 1/8W, 1% 4721-103A+6 4
R88 10K, RMG, 1206, 1/8W, 1% 4721-103A+6 4
R90 10M, RMG, 0603/1608, 1/16W, 5% 4723-106J+P 4
R91 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R92 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R93 1 OHM, RMG, 1206, 1/8W, 5% 4721-010J+6 4
R94 1K, RMG, 0805, 1/10W, 1% 4720-102A+J 4
R96 1K, RMG, 0603/1608, 1/16W, 1% 4723-102A+P 4
R97 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R99 1K, RMG, 0603/1608, 1/16W, 1% 4723-102A+P 4
R101 1K, RMG, 0603/1608, 1/16W, 1% 4723-102A+P 4
R103 1K, RMG, 0603/1608, 1/16W, 1% 4723-102A+P 4
R104 1K, RMG, 0603/1608, 1/16W, 1% 4723-102A+P 4
R105 22 OHM, RMG, 0805, 1/10W, 1% 4720-220A+J 4
R106 22 OHM, RMG, 0805, 1/10W, 1% 4720-220A+J 4
R107 22 OHM, RMG, 0805, 1/10W, 1% 4720-220A+J 4
R108 22 OHM, RMG, 0805, 1/10W, 1% 4720-220A+J 4
Digital Signal Processor (DSP) PCBAssembly

17
Electrical Part List
Resistors (continued)
Reference
Designator
Description Vendor Part
Number
Note
R109 1K, RMG, 0603/1608, 1/16W, 1% 4723-102A+P 4
R110 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P-R 4
R112 1K, RMG, 0603/1608, 1/16W, 1% 4723-102A+P 4
R113 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P-R 4
R115 10K, RMG, 1206, 1/8W, 1% 4721-103A+6 4
R116 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R117 RCFA, 47RX4, 0603, 1/16W, 5% 4703-470J+P-04 4
R118 10K, RMG, 1206, 1/8W, 1% 4721-103A+6 4
R119 10K, RMG, 1206, 1/8W, 1% 4721-103A+6 4
R120 10K, RMG, 1206, 1/8W, 1% 4721-103A+6 4
R121 1M, RMG, 0805, 1/10W, 1% 4720-105A+J 4
R122 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R123 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P-R 4
R124 1M, RMG, 0805, 1/10W, 1% 4720-105A+J 4
R125 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R126 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P-R 4
R127 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R128 0 OHM, RMG, 1206, 1/8W, 1% 4721-000A+6 4
R129 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R130 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R131 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R132 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R133 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R134 1K, RMG, 0805, 1/10W, 1% 4720-102A+J 4
R135 1K, RMG, 0805, 1/10W, 1% 4720-102A+J 4
R136 1K, RMG, 0603/1608, 1/16W, 1% 4723-102A+P 4
R137 2.2K, RMG, 0603/1608, 1/16W, 1% 4723-222A+P 4
R138 6.8K, RMG, 0603/1608, 1/16W, 1% 4723-682A+P 4
R140 6.8K, RMG, 0603/1608, 1/16W, 1% 4723-682A+P 4
R141 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R142 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R143 2.2K, RMG, 0603/1608, 1/16W, 1% 4723-222A+P 4
R144 4.99K, RMG, 0603, 1/16W, 1% 4723-4991+P 4
R145 4.99K, RMG, 0603, 1/16W, 1% 4723-4991+P 4
R146 75 OHM, RMG, 0603/1608, 1/16W, 5% 4723-750J+P 4
R147 2.2K, RMG, 0603/1608, 1/16W, 1% 4723-222A+P 4
R148 3.3K, RMG, 0603/1608, 1/16W, 1% 4723-332A+P 4
R149 100 OHM, RMG, 0603/1608, 1/16W, 5% 4723-101J+P 4
R150 100 OHM, RMG, 0603/1608, 1/16W, 5% 4723-101J+P 4
R151 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R152 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R153 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R154 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R155 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R156 12K, RMG, 0603, 1/16W, 1% 4723-123A+P 4
R157 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
Digital Signal Processor (DSP) PCBAssembly

18
Electrical Part List
Resistors (continued)
Reference
Designator
Description Vendor Part
Number
Note
R158 3.3K, RMG, 0603/1608, 1/16W, 1% 4723-332A+P 4
R162 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R163 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R164 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R167 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R168 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R170 RCFA, 47RX4, 0603, 1/16W, 5% 4703-470J+P-04 4
R171 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R172 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R173 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R174 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R175 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R176 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R177 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R178 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R179 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R180 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R181 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R182 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R183 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R184 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R185 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R186 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R187 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R188 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R189 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R190 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R191 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R192 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R193 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R194 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R195 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R196 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R197 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R198 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R199 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R200 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R201 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R202 91 OHM, RMG, 0603, 1/16W, 1% 4723-910A+P 4
R203 91 OHM, RMG, 0603, 1/16W, 1% 4723-910A+P 4
R204 91 OHM, RMG, 0603, 1/16W, 1% 4723-910A+P 4
R205 91 OHM, RMG, 0603, 1/16W, 1% 4723-910A+P 4
R206 91 OHM, RMG, 0603, 1/16W, 1% 4723-910A+P 4
R207 91 OHM, RMG, 0603, 1/16W, 1% 4723-910A+P 4
R208 91 OHM, RMG, 0603, 1/16W, 1% 4723-910A+P 4
R209 91 OHM, RMG, 0603, 1/16W, 1% 4723-910A+P 4
Digital Signal Processor (DSP) PCBAssembly

19
Electrical Part List
Resistors (continued)
Reference
Designator
Description Vendor Part
Number
Note
R210 634 OHM, 0603, RMG, 1/16W, 1% 4723-6340+P 4
R211 634 OHM, 0603, RMG, 1/16W, 1% 4723-6340+P 4
R212 634 OHM, 0603, RMG, 1/16W, 1% 4723-6340+P 4
R213 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R214 634 OHM, 0603, RMG, 1/16W, 1% 4723-6340+P 4
R215 634 OHM, 0603, RMG, 1/16W, 1% 4723-6340+P 4
R216 634 OHM, 0603, RMG, 1/16W, 1% 4723-6340+P 4
R217 634 OHM, 0603, RMG, 1/16W, 1% 4723-6340+P 4
R218 634 OHM, 0603, RMG, 1/16W, 1% 4723-6340+P 4
R219 634 OHM, 0603, RMG, 1/16W, 1% 4723-6340+P 4
R220 634 OHM, 0603, RMG, 1/16W, 1% 4723-6340+P 4
R221 634 OHM, 0603, RMG, 1/16W, 1% 4723-6340+P 4
R222 634 OHM, 0603, RMG, 1/16W, 1% 4723-6340+P 4
R238 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R241 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R242 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R245 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R247 RCFA, 47RX4, 0603, 1/16W, 5% 4703-470J+P-04 4
R248 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R249 4.7K, RMG, 0603/1608, 1/16W, 5% 4723-472J+P 4
R250 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R251 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R252 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R253 RCFA, 47RX4, 0603, 1/16W, 5% 4703-470J+P-04 4
R254 0 OHM, RMG, 1206, 1/8W, 1% 4721-000A+6 4
R255 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R256 30.9K, RMG, 0603/1608, 1/16W, 1% 4723-3092+P 4
R257 0 OHM, RMG, 0603, 1/16W, 5% 4723-000J+P 4
R258 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R259 9.1K, RMG, 0603/1608, 1/16W, 1% 4723-912A+P 4
R260 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R261 0 OHM, RMG, 1206, 1/8W, 1% 4721-000A+6 4
R262 1.2K, RMG, 0603, 1/16W, 1% 4723-122A+P 4
R263 470 OHM, RMG, 0603/1608, 1/16W, 1% 4723-471A+P 4
R264 14K, RMG, 0603/1608, 1/16W, 1% 4723-143A+P 4
R265 75 OHM, RMG, 0603/1608, 1/16W, 5% 4723-750J+P 4
R266 75 OHM, RMG, 0603/1608, 1/16W, 5% 4723-750J+P 4
R267 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R268 1.5K, RMG, 0603/1608, 1/16W, 1% 4723-152A+P 4
R269 1.5K, RMG, 0603/1608, 1/16W, 1% 4723-152A+P 4
R270 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R271 715 OHM, RMG, 0603, 1/16W, 1% 4723-7150+P 4
R272 715 OHM, RMG, 0603, 1/16W, 1% 4723-7150+P 4
R273 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R274 1.33K, RMG, 0603, 1/16W, 1% 4723-1331+P 4
R275 1.33K, RMG, 0603, 1/16W, 1% 4723-1331+P 4
Digital Signal Processor (DSP) PCBAssembly

20
Electrical Part List
Resistors (continued)
Reference
Designator
Description Vendor Part
Number
Note
R276 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R277 4.42K, RMG, 0603, 1/16W, 1% 4723-4421+P 4
R278 4.42K, RMG, 0603, 1/16W, 1% 4723-4421+P 4
R279 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R280 2.32K, RMG, 0603, 1/16W, 1% 4723-2321+P 4
R281 2.32K, RMG, 0603, 1/16W, 1% 4723-2321+P 4
R282 100 OHM, RMG, 0603/1608, 1/16W, 5% 4723-101J+P 4
R283 240 OHM, RMG, 0603/1608, 1/16W, 5% 4723-241J+P 4
R287 6.8K, RMG, 0603/1608, 1/16W, 1% 4723-682A+P 4
R288 75 OHM, RMG, 0603/1608, 1/16W, 5% 4723-750J+P 4
R289 6.8K, RMG, 0603/1608, 1/16W, 1% 4723-682A+P 4
R290 75 OHM, RMG, 0603/1608, 1/16W, 5% 4723-750J+P 4
R291 47K, RMG, 0603/1608, 1/16W, 5% 4723-473J+P 4
R293 10K, RMG, 0603/1608, 1/16W, 5% 4723-103J+P 4
R294 10K, RMG, 0603/1608, 1/16W, 1% 4723-103A+P 4
R295 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R296 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R297 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R298 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R299 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R300 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R301 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R302 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R303 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R304 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R305 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R306 100K, RMG, 0603/1608, 1/16W, 5% 4723-104J+P 4
R307 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R308 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R309 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R310 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R311 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R312 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R313 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R314 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R315 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R316 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R317 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R318 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R319 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R320 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R321 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R322 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R323 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R324 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
R325 1.5K, RMG, 1206, 1/8W, 5% 4721-152J+6 4
Digital Signal Processor (DSP) PCBAssembly
