Boss Audio Systems ELITE HARLEY-DAVIDSON BEHDX98 User manual

BEHDX98
BOSS Audio Systems
3451 Lunar Court • Oxnard, CA 93030




®| 
BLUETOOTH® 
mm
ELECTRA GLIDE®, STREET GLIDE® AND ROAD GLIDE® MODELS
  

® 

®

0923
®

- 1 -
Thank you for choosing our product!
Please read the instructions carefully so you will know how to operate your
product properly.
If there are any technical questions, please contact:
Customer care: [phone] & Live chat
Online support: www.bossaudio.com/support
IMPORTANT
Please enter below the Serial No. which is located on the exterior of the product.
Retain this information for future reference.
Model No.
Serial No.
Date of Purchase

- 2 -
Table of Contents
Introduction and Compatibility ............................................................................................................................2
Package Contents ..............................................................................................................................................3
Important ............................................................................................................................................................3
Control Panel Description...................................................................................................................................4
Wiring .................................................................................................................................................................5
Mounting.............................................................................................................................................................6
Power On/Off .....................................................................................................................................................7
Set Clock ...........................................................................................................................................................7
Adjust Volume.....................................................................................................................................................7
Adjust Screen/Button Brightness........................................................................................................................7
FM/AM Radio......................................................................................................................................................8
SiriusXM Radio...................................................................................................................................................9
Bluetooth streaming..........................................................................................................................................12
USB Playback...................................................................................................................................................13
Sound Settings .................................................................................................................................................14
System Settings................................................................................................................................................15
Audio Input .......................................................................................................................................................15
Accessory Power Control ................................................................................................................................16
Audio Output ....................................................................................................................................................16
Troubleshooting................................................................................................................................................16
Specications ...................................................................................................................................................18
FCC Notice ......................................................................................................................................................20
Introduction and Compatibility
• The unit is designed to provide a direct t to replace factory radio for 1998-2013 Harley-Davidson®models
(Electra Glide®, Street Glide®and Road Glide®).
• Connect your factory wiring harness and connectors to this unit to retain functionality including handlebar
audio controls. However, the following features are not compatible: factory amplied systems, intercom,
CB, rear volume controls, 1998-2005 Ultra rear speakers, and factory equipped satellite radio systems.

- 3 -
Package Contents
When rst unpacking this product, please check that the package contains each of the items listed below. If
something is missing, contact the store where you purchased the product.
• 1 x Multi-media receiver (with multiple cable connectors)
• User manual and warranty card
Important
Please read and understand all instructions before you use your product. Failure to follow the
instructions could result in injury and/or damage that could potentially void the warranty.
Safety Precautions
• Do not disassemble or modify this product. This can result in short circuits, res, electric shocks or other
hazards.
• Be sure to observe the following guidelines:
- Do not increase speaker volume so high that you cannot hear what is around you.
- Use caution or temporarily discontinue use in potentially hazardous situations.
• Do not make any adjustment on the product when driving or in other situations where distractions can be
hazardous. Responsible and safe driving is your primary responsibility when operating a vehicle.
• Start volume at a low setting then gradually increase the volume until you can hear it comfortably, without
sound distortion or ear discomfort.
• In the event of smoke, strange noise or odor emitted from the product or any other abnormal operational
signs appearing on the product, disconnect the product from the power supply. Discontinue use and contact
your dealer or our technical support. Using the product in this condition may result in permanent damage
to the system.
• Servicing must only be carried out by a technician. Contact our technical support for any service questions.
Installation Precautions
• WARNING: Always consult a professional installer.
• Installation must be performed by a professional. Contact our technical support for any installation questions.
• Use only installation parts provided with the product.
• Before installation, disconnect the negative terminal of the vehicle battery to prevent damage to the product,
re, and/or possible injury.
• Observe the safety and operating instructions of the devices which are connected to the product.
• This product is resistant against splashing water. Do not submerge.
Environmental Care
Do not throw away the product with normal household waste at the end of its life. Follow your local laws if/when
disposing of electronic products. By doing this, you help preserve the environment.

- 4 -
Control Panel Description
3
1
4
5
2
6 7 8 9 10 11 7
1 Dedicated mounting bracket
Use the accessory mounting bracket to secure
a dedicated external amplier, such as BOSS
model BHD3F, to the top of the unit.
BHD3F (sold separately) includes an amplifier
and two speakers.
2 /
• Press to power the unit on; Hold down to
power the unit off.
• Select a source.
3 PRESET
In FM/AM source, select a stored radio station.
In SXM source, access the preset channel list.
4
• Press to enter source-related settings.
• Press and hold to enter system settings.
5
Access external accessory power control.
6
Adjust brightness of screen and button lights:
high, medium and low.
7 /
• During USB or Bluetooth audio play, select
the previous or next audio le; hold down to
fast search.
• In FM/AM source, tune to a radio station.
• In SXM source, select a channel.
8 Function knob
• Rotate to adjust volume, or to navigate menu
options.
• Press to conrm a selection.
9
• During media playbac, start, pause or resume
play.
• In FM/AM source, mute or restore volume.
• In SXM source, replay the selected channel.
10 /
• In FM/AM source, select a radio band (FM1/
FM2/FM3/AM1/AM2).
• Return to the previous menu level, or exit
menu settings.
11 TFT Color display

- 5 -
Wiring
See the section “Installation Precautions”.
Disconnect the negative terminal of the
vehicle battery prior to wiring.
Always run signal wires away from power
cables to reduce the possibility of noise.
BT Antenna
Blue/White
USB/Charging Port
Radio Antenna
AUX-IN
SIRIUSXM INPUT
DC12V- 2
DC12V- 1
Power Antenna/Amplier Remote
Blue
Brown/White
Brown
SUB-W Out
Front Line Out
White (L)
Red (R)
Green
Rear Line Out
White (L)
Red (R)
23-Pin Male Connector
Connect to the 23-pin
Harley-Davidson®factory
wiring harness.
35-Pin Male Connector
Connect to the 35-pin
Harley-Davidson®factory
wiring harness.
Power Connection (Plug and Play)
To power the unit, simply connect your Harley-
Davidson®factory harness to the unit.
Other Connections
1: Connect to a USB ash drive for music playback;
or charge a mobile phone (1.5A).
2: Bluetooth antenna for better reception.
Never cut, short or ground this wire.
2
1
3
4
5
6
7
8
9
10
11
(Never cut)
3: Connect to a FM/AM radio antenna (not
included) for radio reception.
4: Connect to a mobile phone or MP3 player for
music playback.
5: Connect to a SiriusXM-Connect Vehicle Tuner
(not included) for SXM radio reception.
6/7: Connect to external lighting for power
supply (350mA max load).
8: Connect to an external device/amplier (not
included) for power control.
9: Connect to the subwoofer input on an external
amplier for sound output.
10 : Connect to the front audio input on an external
amplier for sound output.
11 : Connect to the rear audio input on an external
amplier for sound output.
Black
Black
Gray

- 6 -
Mounting
See the section “Installation Precautions”.
Disconnect the negative terminal of the vehicle battery prior to installation.
Install the unit where it does not interfere with your driving.
If you must modify the vehicle for the installation, make sure you do not impair the safety and
structural integrity of the vehicle.
Before you drill or cut any holes, investigate your vehicle’s layout very carefully. Take special care
when you work near the fuel tank, fuel lines, hydraulic lines and electrical wiring.
Mount the Unit
This unit is designed to replace your factory stereo, and use your existing factory wire harness to plug and play.
1. Finish wiring connection to the unit. (P.5)
2. Power on the unit. Perform a function test to ensure
correct operation.
3. Access the factory fairing stereo opening. Correctly place
the unit in the opening, Secure the unit on both sides using
four factory bolts.
Ensure the unit is rmly attached to avoid vibration while
riding.
Make sure connection cables are not pinched or damaged
by sharp objects or moving parts.
Mount a Dedicated Amplier (Optional)
This unit is equipped with a xed OEM style mounting bracket that can be used to secure a third-party
accessory such as a dedicated amplier (BOSS model BHD3F - sold separately) on top of the unit.
What You Need
• Make sure your Harley-Davidson®motorcycle
has sufcient factory stereo opening space
(minimum 4.6”/115mm height) to mount a
dedicated amplier on top of this unit.
• Purchase the product (BOSS model BHD3F)
which comes with the dedicated amplier and
two speakers.
• Mount the dedicated amplier on top of this
unit. For mounting instructions, refer to the
Installation Instructions provided with BHD3F.
4.6”
(115mm)
A dedicated
amplier (BHD3F)

- 7 -
Power On/Off
• To power the unit on, press .
- When powered on, the unit switches to the last selected source and the button lights are illuminated.
• To power the unit off, press and hold .
- When powered off, the display and the button lights are turned off.
Set Clock
1. Press and hold to display system settings.
2. Rotate the function knob to select [TIME], then press the function knob to enter time setting options.
3. Rotate the function knob to select the following time options.
• 12/24 hour
• Hour
• Minute
4. Press the function knob to conrm the selection, then rotate the function knob to set values. Press the
function knob again to conrm the setting.
5. Repeat Step 3 and 4 to complete the clock setting, then press / to exit the settings.
Adjust Volume
• To increase or decrease volume, rotate the function knob.
• To mute or restore volume, press . During media playback, pause also occurs.
To adjust subwoofer volume
• Press the function knob until “SUB-W” icon is displayed, then rotate the function knob to adjust subwoofer
volume.
To set volume balance
• To adjust left and right volume balance, press the function knob until “BALANCE” icon is displayed, then
rotate the function knob until you are pleased with the sound and a suitable balance is found.
• To adjust front and rear volume balance, press the function knob until “FADER” icon is displayed, then
rotate the function knob until the sound has a satisfying depth.
Adjust Screen/Button Brightness
Press to select a brightness level for screen and button lights: High, Medium or Low.

- 8 -
FM/AM Radio
You can listen to FM or AM radio, and preset the radio stations. The preset radio stations will be retained if the
unit is disconnected from the vehicle’s battery.
Select a Radio Band
1. Press to display source options.
2. Rotate the function knob to select [RADIO], then press the function knob to conrm the selection.
3. Press / repeatedly to select FM1, FM2, FM3, AM1 or AM2.
Tune to a Radio Station
1. Select an FM or AM radio band.
2. Press / briey. The unit will nd a station with strong reception.
- If an FM radio station with stereo signal is reached, “ST” will be displayed.
3. Repeat the steps above until your nd your desired station.
To tune to a weak station
1. Press and hold / to enter manual tuning mode. “MANUAL SEEK” is displayed briey.
2. Press / repeatedly to search by frequency step until you nd a desired station with acceptable
reception.
-Note: Manual tuning mode will automatically exit after ve seconds of button inactivity.
Store Radio Stations
Each radio band (FM1/FM2/FM3/AM1/AM2) can store six radio stations.
1. In FM/AM source, press to display radio setting menu.
2. Rotate the function knob to select [AUTO STORE], then press the function knob to start searching radio
stations.
- All FM or AM stations will be stored in FM or AM bands. The rst stored station will be automatically
broadcast.
To select a stored station
• Press repeatedly to select a stored station, then press the function knob to conrm.

- 9 -
Radio Settings
You can access the radio menu to change settings for your radio.
1. In radio source, press to display radio settings menu.
2. Rotate the function knob to select an option, then press the function knob to conrm the selection.
• [LOCAL]: Select [ON] when most FM stations are strong enough (e.g. in urban areas). Only the stations
with strong signal will be received.
Select [OFF] when most FM stations are weak (e.g. in the countrysides). Stations with both strong and weak
signals will be received.
• [AUTO STORE]: Press the function knob to search and store FM or AM radio stations.
• [TUNER REGION]: Select a country or region you are in to receive radio signal.
• [RDBS]: Enable or disable RDBS. When enabled, the unit will receive and display RDBS information (i.e.
station name, program type or other dynamic/static message) carried by FM radio signals. Not all FM radio
stations will have or display RDBS information.
3. Press / to exit the settings.
SiriusXM Radio
SiriusXM is where moments happen. It brings you ultimate entertainment.
• The widest, deepest variety of music, ad-free.
• More games, more sports, more coverage than anywhere.
• The most extensive entertainment, complete news coverage and every kind of comedy.
• Listen in your car, on your phone, online and at home.
A SiriusXM-Connect Vehicle Tuner and subscription are required. For more information, visit www.siriusxm.com.
Preparation
Step 1: Connect a SiriusXM-Connect Vehicle Tuner (not included) to the SIRIUSXM INPUT (SiriusXM-
Ready®) connector on the back of this unit. (P.5)
• After installing your SiriusXM-Connect Vehicle Tuner and antenna, power on the head unit and select
SiriusXM mode. You should be able to hear the SiriusXM preview channel on Channel 1.
• If you cannot hear the preview channel, please check the installation instructions to make sure your
SiriusXM-Connect Tuner is properly installed.
Step 2: Check your Radio ID for activation.
• The SiriusXM Radio ID is required for activation and can be found by tuning to Channel 0 as well as by
looking on the label found on the SiriusXM Vehicle Tuner and its packaging.
• The Radio ID does not include the letters I, O, Sor F.

- 10 -
Step 3: Activate the subscription.
• For users in the U.S.A., visit www.siriusxm.com/activatenow, or call SiriusXM Listener Care at
1-866-635-2349
• For users in Canada, visit www.siriusxm.ca/activate, or call SiriusXM Customer Care at 1-888-539-7474
Step 4: Conrm the activation.
• As part of the activation process, the SiriusXM satellites will send an activation message to your SiriusXM
Vehicle Tuner. When your head unit detects that the Tuner has received the activation message, your head
unit will display [Subscription Updated].
• Once subscribed, you can tune to channels in your subscription plan. Note, the activation process usually
takes 10 to 15 minutes, but may take up to an hour. Your head unit will need to be powered on and receive
the SiriusXM signal to obtain the activation message.
Access SiriusXM Radio
1. Press to display source options.
2. Rotate the function knob to select [SIRIUSXM], then press the function knob to conrm the selection.
The unit will switch to SiriusXM radio broadcast interface.
Select a Channel
You can select a channel via one of the followings.
• In SiriusXM source, press or to select the previous or next channel.
• In SiriusXM source, press to access SiriusXM settings menu.
Rotate the function knob to select [CHANNEL]or [CATEGORY] then press the function knob to access the
channel or category lists.

- 11 -
Or select [DIRECT TUNE] to display the numeric keypad. Use or to navigate between digit elds,
rotate the function knob to change digits, and press the function knob to conrm each digit selection.
Preset a Channel
1. In SiriusXM source, select a channel to play.
2. Touch and hold . The current channel will be stored as a preset.
Repeat the steps above to preset more channels.
To select a preset
1. In SiriusXM source, press to access the preset channel list.
2. Rotate the function knob to select a preset, and press the function knob to conrm.
Replay SiriusXM Content
The SiriusXM Vehicle Tuner can automatically buffer broadcast content. You can replay the last 60 minutes of
the content from the current channel.
When you select a stored/preset channel, you can replay up to 30 minutes.
• To play or pause, press .
• To skip to the previous or next track, press or .
• To search fast backward or forward, press and hold or .

- 12 -
Parental Control
This feature allows you to restrict access to any SiriusXM channels, including those with mature content. A
password is required to tune to a locked channel.
1. In SiriusXM source, press to access SiriusXM settings menu.
2. Rotate the function knob to select [PARENTAL CONTROLS], then press the function knob to conrm. A
numeric keypad is displayed.
3. Enter “0000” password to access the channel list.
4. In the channel list, select a channel to lock.
Bluetooth streaming
When you can stream music from your mobile device (e.g. a mobile phone) to the unit for the rst time, you
must pair the unit with your mobile device through Bluetooth.
1. On your mobile device, enable Bluetooth then select “Boss Audio ELITE BEHDX98” to pair the unit with
your mobile device. If prompted for password, input “0000” on your mobile device.
- When the unit connects to your mobile device, the icon at the top of the unit’s screen is displayed.
- The unit automatically connects the last paired device each time the two are powered on. To connect a
second Bluetooth device, you have to disconnect the currently connected device then repeat the steps
above to pair with a second device.
Playback control
1. Switch to Bluetooth source.
Press to display source options. Rotate the function knob to select [BT MUSIC], then press the
function knob to conrm the selection.
-Note: Bluetooth source selection is not possible if Bluetooth connection is not made on the unit.
2. Play audio les from the connected mobile device. Music will be streamed to the unit.
- For best sound performance, set the volume of your mobile device to maximum, then adjust the volume
through volume control on the unit.
-Note: If there is distortion heard, you may need to turn the volume of the mobile device down a level
or two.
3. Control playback as follows.
• To pause or resume play, press .
• To select the previous or next music le, press or .
• To search fast, press and hold or .
- If there is an incoming call during playback, music will automatically pause and resume after the call
ends.

- 13 -
USB Playback
This unit can play audio les stored on a USB ash drive.
1. Insert a USB ash drive to the USB port on the unit.
2. Switch to USB source.
Press to display source options. Rotate the function knob to select [USB], then press the function
knob to conrm the selection.
- Audio les from the USB device will play automatically.
- During playback, the display shows the following information: Artist Name - Song Title - Album Name
- Play Time.
3. Control playback as follows.
• To pause or resume play, press .
• To select the previous or next music le, press or .
• To search fast, press and hold or .
Select Play Mode
1. During USB playback, press to display USB settings menu.
2. Rotate the function knob to select [REPEAT] or [SHUFFLE], then press the function knob to conrm the
selection.
• [REPEAT]: Press the function knob to select a repeat play mode.
- : Play the current music folder repeatedly.
-ALL: Play all the audio les repeatedly.
- : Play the current track repeatedly.
-
• [SHUFFLE]: Press the function knob to select a random play mode.
- : Play the current music folder randomly.
-ALL: Play all the audio les randomly.
-OFF: Cancel random play mode.
Search by le
1. During USB playback, press to display USB settings menu.
2. Rotate the function knob to select [SEARCH], then press the function knob to conrm the selection. The
les in the current music folder are accessed and displayed.
3. Rotate the function knob to select a le. Press / to go to the folder level.
4. To play the selected le, press the function knob.

- 14 -
Sound Settings
This section helps you change the sound settings of this unit.
Sound Mode and Equalizer Setting
1. Press and hold to display system settings.
2. Navigate to [AUDIO] > [13 BAND EQ].
• To select a preset sound mode (FLAT, ROCK, CLASSIC, ACOUSTIC, DANCE, ELECTRONIC, HIP HOP),
rotate the function knob.
• To customize equalizer settings, rotate the function
knob to select [CUSTOM] then press the function knob
to access the 13-band graphic equalizer settings.
Rotate the function knob to adjust decibel output in
each frequency band and press the function knob to
conrm.
Experiment your settings until optimal result is found.
Crossover Frequency Setting
1. Press and hold to display system settings.
2. Navigate to [AUDIO] > [CROSSOVER].
3. To set crossover frequencies for front speakers, rear
speakers and subwoofer, rotate the function knob
to select [FRONT], [REAR] and [SUBWOOFER]
respectively then press the function knob to conrm.
To return to the previous option level, press /
.
• [HPF] (for front and rear speakers): Adjust High
Pass Filter (HPF) for main audio (radio and media
play). Only the frequencies above the one you set
will be received to reproduce sound.
• [SLOPE] (for front and rear speakers): Set a high pass lter slope in decibels. An HPF slope determines
the rate that attenuates the frequencies below the set one.
• [LPF] (for subwoofer): Adjust Low Pass Filter (LPF) for main audio (radio and media play). Only the
frequencies below the one you set will be received to reproduce sound.
• [SLOPE] (for subwoofer): Set a low pass lter slope in decibels. A LPF slope determines the rate that
attenuates the frequencies above the set one.

- 15 -
System Settings
This section helps you change the system settings of this unit.
1. Press and hold to display system settings.
2. Rotate the function knob to select an option, then press the function knob to conrm.
• [AUDIO]: Access the following audio settings.
• [13 BAND EQ]: Select a preset sound mode or customize equalizer settings. See the section “Sound
Settings” on page 14.
• [CROSSOVER]: Set crossover frequencies for the speakers and subwoofer. See the section “Sound
Settings” on page 14.
• [SOURCE GAIN]: Customize volume of each source independently.
• [INTERNAL AMP]: Enable or disable internal amplier output.
• [BT PAIRING]: Enable or disable Bluetooth pairing.
• [TIME]: See the section “Set Clock” on page 7.
• [LED COLOR]: Set the button illumination amber or white.
• [SOFTWARE]: Access the following options.
• [VERSION]: View the rmware information of this unit.
• [UPDATE]: The unit can be updated if needed. Connect a ash USB drive with a newer rmware to
the unit’s USB port (make sure the upgrade le is unzipped and saved in the root directory of the
USB ash drive), select USB source, and press the function knob when upgrade prompt is displayed.
• [FACTORY DEFAULT]: Select and reset [AUDIO], [SYSTEM] or [SIRIUSXM] to factory settings. The
customized settings related to audio, system or SiriusXM will be erased after resetting.
Audio Input
This unit can play audio from a mobile phone or MP3 player through 3.5 mm audio input.
1. Connect the 3.5 mm audio input (labeled AUX-IN) on the unit to the headphone jack on your mobile phone
(or MP3 player), using the following cable.
• For a mobile phone with a headphone jack, use a 3.5 mm audio cable (not included).
• For a mobile phone with a USB-C port, use a USB-C to 3.5 mm audio cable (not included).
• For an iPhone, use a lightning to 3.5 mm audio cable (not included).
2. Switch to AUX source.
Press to display source options. Rotate the function knob to select [AUX], then press the function
knob to conrm the selection.
3. Start music playback on your mobile phone. Audio will play through the unit.
- For best sound performance, set the volume of the connected device to maximum.
- Use the controls on the connected device for playback control.

- 16 -
Accessory Power Control
The unit can connect and power control the connected accessories (not included, e.g. light bars or whips). The
accessories load is rated at 350 mA.
1. Connect your external accessories to the unit through the unit’s wires marked “DC12V-1” (brown) or marked
“DC12V-2” (brown/white). See the section “Wiring” on page 5.
2. To turn on or off the connected accessories, press on the front panel to display the power button option
1and 2. Rotate the function knob to select the power button option, then press the function knob to enable
or disable the power output.
Audio Output
You can output audio from the unit to an external amplier.
1. Using RCA audio cables (not included), connect the RCA audio outputs (labeled Front Line Out L/R, Rear
Line Out L/R, SUB-W Out) on the unit to the RCA audio inputs on an amplier (not included). See the
section “Wiring” on page 5.
2. Start playback on this unit and audio will output to the connected amplier.
Troubleshooting
If you have problems using this product, check the following points before you request service. If you still have
a problem, contact our Customer Service for further assistance.
Problem Solution
Unit not responsive Restart the unit by turning the vehicle off for a few seconds, then turning the
vehicle back on.
If the problem still persists, disconnect the unit from the source battery for a
few minutes and then reconnect.
No power This unit is powered through connection to your Harley-Davidson®factory
wiring harness. Connect the factory harness to this unit for power supply.
Check that the power/ignition/ground wire of your Harley-Davidson®harness
are correctly connected.
Check that the vehicle ignition power (ACC) is switched on.
No sound Check that playback is not paused, or turn up the volume.
Incorrect source input. Press SOURCE to select the correct source.
Check that the connected speakers are not faulty.

- 17 -
Problem Solution
Bluetooth not connected /
Streaming not possible
Check that Bluetooth on your mobile device is enabled.
Make sure your mobile device is located in Bluetooth range.
This unit is connected with another Bluetooth device. Disconnect the current
Bluetooth connection.
Poor audio quality from
Bluetooth connection.
Move your mobile device closer to the unit, or remove obstacles or sources
of interference that are affecting Bluetooth reception.
USB not playable Files are not supported, or the USB device is not compatible with the unit.
Change the media les or USB device.
SiriusXM Radio
“Check Antenna” appears. Check that the antenna cable is connected to the SirirusXM-Connect Vehicle
Tuner.
Check the antenna cable for damage and kinks. Replace the antenna cable
if damaged. SiriusXM products are available at your local car audio retailer or
online at https://shop.siriusxm.com/all-parts/.
“Check Tuner” appears. Check that SiriusXM-Connect Vehicle Tuner is securely connected to the unit
(P.5), or the Tuner is damaged.
“Subscription Updated”
appears.
Your subscription is updated. Press the appropriate button to clear the
message.
“Channel Unavailable”
appears.
The selected channel is not available. For more information about SiriusXM
channel lineup, visit www.siriusxm.com.
“No Signal” appears. Verify that your vehicle is outdoors with a clear view of the sky.
Verify that the SiriusXM magnetic base antenna is mounted on a metal
surface on the outside of the vehicle.
Move the SiriusXM antenna away from any obstructions.
Checktheantennacablefordamageandkinks.Checktheantennacablefordamageandkinks.Check the antenna cable for damage and kinks.
Checktheantennacablefordamageandkinks.Consult the SiriusXM-Connect Vehicle Tuner installation manual for more
information on antenna installation.
“Channel Unsubscribed”
appears.
Theselectedchannelisnotsubscribed.fyouhavequestionsaboutyoursubscriptionpackageorwouldliketosubscribetothischannel,intheUSA,visitwww.siriusxm.comorcall1-866-635-2349;inCanada,visitwww.siriusxm.ca/activateorcall1-888-539-747The selected channel is not subscribed.
If you have questions about your subscription package or would like to
subscribe to this channel, in the USA, visit www.siriusxm.com or call
1-866-635-2349; in Canada, visit www.siriusxm.ca/activate or call
1-888-539-7474.
“Channel Locked” appears. The selected channel is locked by the Parental Control feature. Enter the
correct password to unlock.(P.12)

- 18 -
Specications
Audio
Max output power........................................ 72 W x 4 (@ 2 Ohms), 48W x 4 (@ 4 Ohms)
Amplier class ............................................. A/B (2 Ohms stable)
Speaker impedance..................................... ≥2 Ω
Frequency response.................................... 20 Hz - 20 kHz
3.5mm AUX input sensitivity........................ 1000 mV
Pre-amp outputs (RCA)............................... front left and right sockets (4V); subwoofer socket (4V)
FM Radio
Frequency range ......................................... 87.5 – 107.9 MHz (USA)
87.5 – 108 MHz (Europe)
Frequency step............................................ 200 kHz (USA)
50 kHz (Europe)
AM Radio
Frequency range ......................................... 530 – 1710 kHz (USA)
522 – 1620 kHz (Europe)
Frequency step............................................ 10 kHz (USA)
9 kHz (Europe)
Bluetooth
Bluetooth version......................................... 5.1
Bluetooth proles......................................... A2DP, AVRCP
Bluetooth frequency..................................... 2402 - 2480 MHz
Transmission power..................................... <4 dBm
Transmission distance................................. up to 33 ft /10 m (line of sight)
USB
Compatibility................................................ Type A, USB 2.0 (High-Speed)
File system .................................................. FAT32
Charging current.......................................... 5VDC, max 1.5A
Audio playback ............................................ MP3, WMA
