Notes When Using Mics ／マイク使用時のご注意
Always be sure to switch the phantom power off except
when connecting condenser mics requiring a phantom
power supply. Supplying phantom power to dynamic
mics, audio playback equipment, and other devices that
do not use phantom power may cause damage to your
equipment.
For mic specifications, please refer to the owner’s manual
for whatever model of mic you are using.
(BR-1600CD Phantom Power: +48 V DC, 7 mA Max.)
Phantom power is supplied to the eight XLR connectors
for INPUT 1/MIC 1 through INPUT8/MIC 8
simultaneously. The phantom power cannot be switched
on or off for each connector individually.
If simultaneously using mics that require phantom
power with those that don’t, then connect any mic that
does not need phantom power to one of the standard
1/4” phone jacks. Phantom power is supplied only to the
XLR connectors, not to the standard jacks.
To connect mics to the standard jacks, use a commercially
available XLR-to-phone adapter cable or other form of
adapter.
ファンタム電源供給の必要なコンデンサー・マイクを接
続しているとき以外は、ファンタム電源を必ずオフにし
てください。ダイナミック・マイクやオーディオ再生装
置などにファンタム電源を供給すると故障の原因にな
ります。
マイクの仕様については、お使いのマイクの取扱説明書
をお読みください。
（本機のファンタム電源：DC +48 V、7 mA Max ）
ファンタム電源は、INPUT 1/MIC 1 〜 INPUT 8/MIC 8
のXLR コネクターにいっせいに供給されます。それぞ
れのコネクターごとに個別にオン／オフすることはで
きません。ファンタム電源の必要なマイクと、ファンタ
ム電源の不要なマイクを同時に使用する場合は、ファン
タム電源の不要なマイクをINPUT 1/MIC 1 〜INPUT 8/
MIC 8 の標準ジャックに接続してください。ファンタム
電源は、XLR コネクターのみに供給され、標準ジャック
には供給されません。
マイクを標準ジャックに接続するには、市販の XLR →
標準ジャック変換ケーブルなどをご使用ください。
Demo Song List ／デモ・ソング一覧
Song Name Composer
Baby Calls
Music by Jerry Barnes
Copyright © 2001 Jareese Music BMI, Licspiffy Music BMI
IF I FALL
Music by Igor Len
Copyright © 2003 Igor Len/BMI and Bouy Music/BMI
WIDE STRETCH
Music by Gregg Lee Henry
Copyright © 2003 Gregg Lee Henry
Golden
Music by Linus Bernal and Dave Watkins Lyrics by Linus Bernal, Dustin Chavis, James Jenkins, and
Rhena Santos
Copyright © 2003 Linus Bernal
Copyright © 2003 BOSS CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written permission of BOSS CORPORATION.
©2003 ボス株式会社 本書の一部、または全部を無断で複写・転載することを禁じます。

2
Insert Effect Patch List ／
インサート・エフェクト・パッチ一覧
GUITAR
No. Patch Name Algorithm
P001 CLEAN JC-120 COSM OD GUITAR AMP
P002 JAZZ TONE AM COSM OD GUITAR AMP
P003 CLASIC DIST COSM OD GUITAR AMP
P004 FAT CRNC AMB COSM OD GUITAR AMP
P005 FUZZ+MS1959 COSM OD GUITAR AMP
P006 R-FIER METAL COSM OD GUITAR AMP
P007 HiGain BG COSM OD GUITAR AMP
P008 SOLID DRIVE COSM OD GUITAR AMP
P009 VO CHORD! COSM OD GUITAR AMP
P010 METAL LD AMB COSM OD GUITAR AMP
P011 WARM DRIVE COSM OD GUITAR AMP
P012 70s US ROCK COSM OD GUITAR AMP
P013 Studio Amp M COSM COMP GUITAR AMP
P014 DIRTY FUZZ COSM OD GUITAR AMP
P015 BG CLEAN AMB COSM OD GUITAR AMP
P016 EARLY 60s UK COSM OD GUITAR AMP
P017 MATCH LEAD COSM OD GUITAR AMP
P018 MsHigain AMB COSM OD GUITAR AMP
P019 CRUNCH AMBI COSM OD GUITAR AMP
P020 PRE FLANGER COSM OD GUITAR AMP
P021 ST DETUNE CR COSM OD GUITAR AMP
P022 HEAVY!! COSM OD GUITAR AMP
P023 D-Comp Lead COSM COMP GUITAR AMP
P024 SMOOTH LEAD COSM OD GUITAR AMP
P025 SLDN STACK COSM OD GUITAR AMP
P026 R&R DRIVE COSM OD GUITAR AMP
P027 FAT DRIVE COSM OD GUITAR AMP
P028 60s UK COSM COMP GUITAR AMP
P029 HEAVY FLANGE COSM OD GUITAR AMP
P030 OCT AW LEAD COSM OD GUITAR AMP
P031 CountryCOMP COSM COMP GUITAR AMP
P032 TREMOLO TWIN COSM OD GUITAR AMP
P033 PEDAL VIBRT COSM OD GUITAR AMP
P034 LFO FILTER COSM OD GUITAR AMP
P035 MS1959 LEAD COSM OD GUITAR AMP
P036 SPACY CLEAN COSM OD GUITAR AMP
P037 BIG FUNK COSM COMP GUITAR AMP
P038 UNI-V FUZZ COSM OD GUITAR AMP
P039 HiGain Boost COSM OD GUITAR AMP
P040 VO STACK COSM OD GUITAR AMP
P041 STACK DIST COSM OD GUITAR AMP
P042 DETUNE BG COSM OD GUITAR AMP
P043 UK StudioGTR COSM COMP GUITAR AMP
P044 FAT STRAT COSM OD GUITAR AMP
P045 COMPRE-BILLY COSM COMP GUITAR AMP
P046 HEAVY RECT COSM OD GUITAR AMP
P047 COOL AC DRIV COSM OD GUITAR AMP
P048 DS+MS HiGain COSM OD GUITAR AMP
P049 Scoop'dMetal COSM OD GUITAR AMP
P050 WAH STACK COSM OD GUITAR AMP
P051 OCT FUZZ COSM OD GUITAR AMP
P052 WOMAN TONE COSM OD GUITAR AMP
P053 SCREAM TWEED
COSM OD GUITAR AMP
P054 WAH LEAD COSM OD GUITAR AMP
P055 BIG| COSM OD GUITAR AMP
P056 PEDAL OCT UP COSM OD GUITAR AMP
P057 Clean Lead COSM COMP GUITAR AMP
P058 FUNK CRY WAH COSM OD GUITAR AMP
P059 ANOTHER BRIC COSM OD GUITAR AMP
P060 COOL CRUNCH COSM OD GUITAR AMP
P061 Fat Clean COSM COMP GUITAR AMP
P062 R'BILLY CRUN COSM OD GUITAR AMP
P063 TOUCH WAH COSM OD GUITAR AMP
P064 AUSTIN BOOGI COSM OD GUITAR AMP
P065 SPACE PHASER COSM OD GUITAR AMP
P066 DELAY GATE COSM OD GUITAR AMP
P067 SLOW GEAR COSM OD GUITAR AMP
P068 FRETLESS COSM OD GUITAR AMP
P069 PEDAL OCT EC COSM OD GUITAR AMP
P070 SPACE ECHO COSM OD GUITAR AMP
P071 ACOUSTY ACOUSTIC SIM
P072 Brite Acustc ACOUSTIC SIM
P073 ACO w/PZO ACOUSTIC SIM
P074 AC Sim4Slide ACOUSTIC SIM
P075 Dream Acustc ACOUSTIC SIM
P076 Tight Bass BASS SIM
P077 Loose Bass BASS SIM
P078 BASS SIMw/Ch BASS SIM
P079 UPRT PHSD! BASS SIM
P080 GT>FRETLESS! BASS SIM
P081 Natural AG ACOUSTIC GUITAR
P082 AcousticSolo ACOUSTIC GUITAR
P083 MIC'D ACUSTC ACOUSTIC GUITAR
P084 NICE ACUSTC ACOUSTIC GUITAR
P085 WIDE ACUSTC ACOUSTIC GUITAR
P086 SLAP 'n POP BASS MULTI
P087 Phase Bass BASS MULTI
P088 FLIPTOP SOUL COSM BASS AMP
P089 SQUEEZ BASS COSM COMP BASS AMP
P090 C-StudioBASS COSM COMP BASS AMP
P091 COSMBsTUBES COSM BASS AMP
P092 PUNK BASS COSM BASS AMP
P093 SUSTAIN BASS COSM COMP BASS AMP
P094 BIG 8-STG BS BASS MULTI
P095 MIAMI FRETLS BASS MULTI
P096 STADIUM BASS COSM COMP BASS AMP
P097 OCTAVE BASS BASS MULTI
P098 NO FRET SOLO BASS MULTI
P099 DRIVIN' BASS COSM BASS AMP
P100 GRUNGE BASS COSM BASS AMP
No. Patch Name Algorithm

3
MIC
No. Patch Name Algorithm
P001 VOCAL COMP 1 COSM VOCAL COMP
P002 VOCAL COMP 2 COSM VOCAL COMP
P003 KICK COMP COSM VOCAL COMP
P004 SNARE COMP COSM VOCAL COMP
P005 BRASS COMP COSM VOCAL COMP
P006 VOCAL EFX 1 VOCAL MULTI
P007 VOCAL EFX 2 VOCAL MULTI
P008 VOCAL EFX 3 VOCAL MULTI
P009 VOCAL EFX 4 VOCAL MULTI
P010 NARRATION VOCAL MULTI
P011 VOX DOUBLER VOCAL MULTI
P012 VOX DETUNE VOCAL MULTI
P013 KARAOKE VOX VOCAL MULTI
P014 UNISON VOX VOICE TRANSFORMER
P015 STUTTER VOX VOICE TRANSFORMER
P016 D. VADER VOICE TRANSFORMER
P017 ALIEN VOX... VOICE TRANSFORMER
P018 BULL HORN VOCAL MULTI
P019 SEAGULLS? VOICE TRANSFORMER
P020 SOOO DEEP!!! VOICE TRANSFORMER
P021 BRIGHT CHOIR VOCAL MULTI
P022 RICH BRASS VOCAL MULTI
P023 CM+DARK EQ VOCAL MULTI
P024 CM+VOCAL EQ VOCAL MULTI
P025 CM+BRIGHT EQ VOCAL MULTI
P026 ENH+BASS CUT VOCAL MULTI
P027 ST.AUTOPAN VOCAL MULTI
P028 SLOW FLANGE VOCAL MULTI
P029 FAST FLANGE VOCAL MULTI
P030 SLOW CHORUS VOCAL MULTI
P031 SLAPBACK DLY VOCAL MULTI
P032 BIG EQ+S.DLY VOCAL MULTI
P033 BALLAD EFX VOCAL MULTI
P034 PTCH FIX-1/2 VOCAL MULTI
P035 PTCH FIX+1/2 VOCAL MULTI
P036 CMP+DES+ENH VOCAL MULTI
P037 CMP+ENH+EQ VOCAL MULTI
P038 CMP+DES+EQ VOCAL MULTI
P039 CMP+EQ+DBL VOCAL MULTI
P040 CMP+EQ+DTUNE
VOCAL MULTI
P041 57 to 58 MIC MODELING
P042 57 to 421 MIC MODELING
P043 57 to 451 MIC MODELING
P044 DR20 to 421 MIC MODELING
P045 DR20 to 451 MIC MODELING
P046 DR20 to 87 MIC MODELING
P047 C3KB to 57 MIC MODELING
P048 C3KB to 58 MIC MODELING
P049 C3KB to 421 MIC MODELING
P 050 C3KB to 451 MIC MODELING
STEREO
No. Patch Name Algorithm
P001 CMP+FAT EQ STEREO MULTI
P002 CMP+THIN EQ STEREO MULTI
P003 CMP+TIGHT EQ STEREO MULTI
P004 CMP+BIG EQ STEREO MULTI
P005 CMP+SMALL EQ STEREO MULTI
P006 T'WAH : UP STEREO MULTI
P007 T'WAH : DOWN STEREO MULTI
P008 RING MOD:LO STEREO MULTI
P009 RING MOD:HI STEREO MULTI
P010 TOTAL RNGMOD STEREO MULTI
P011 DEEP FLANGE STEREO MULTI
P012 LO&SLOW FLNG STEREO MULTI
P013 LO&FAST FLNG STEREO MULTI
P014 HI&SLOW FLNG STEREO MULTI
P015 HI&FAST FLNG STEREO MULTI
P016 ST CHORUS STEREO MULTI
P017 SLOW CHORUS STEREO MULTI
P018 FAST CHORUS STEREO MULTI
P019 PRE-DLY CHRS STEREO MULTI
P020 VNTG PHASER STEREO MULTI
P021 MDRN PHASER STEREO MULTI
P022 DEEP PHASE STEREO MULTI
P023 PHAT PHASE STEREO MULTI
P024 PS: DETUNE STEREO MULTI
P025 PS: -1 OCTV STEREO MULTI
P026 PS: +1 OCTV STEREO MULTI
P027 ST DOUBLER STEREO MULTI
P028 MONO>>STEREO
STEREO MULTI
P029 SLOW PANNER STEREO MULTI
P030 FAST PANNER STEREO MULTI
P031 CHORUS+DELAY
STEREO MULTI
P032 CHRS+TAP DLY STEREO MULTI
P033 PHS+SLAPBACK STEREO MULTI
P034 FLNG+TAP DLY STEREO MULTI
P035 LO COMB FLTR STEREO MULTI
P036 HI COMB FLTR STEREO MULTI
P037 120BPM R-MOD STEREO MULTI
P038 ST PAN+DELAY STEREO MULTI
P039 ST TREMOLO STEREO MULTI
P040 120BPM SLICE STEREO MULTI
P041 1920's RADIO LO-FI BOX
P042 1940's RADIO LO-FI BOX
P043 1960's RADIO LO-FI BOX
P044 EARLY EDISON LO-FI BOX
P045 VINTAGE 45's LO-FI BOX
P046 CLASSIC LP LO-FI BOX
P047 VNTG SAMPLER LO-FI BOX
P048 1985 SAMPLER LO-FI BOX
P049 R-MOD SAMPLE LO-FI BOX
P 050 2-BIT DISTOR LO-FI BOX
Insert Effect Patch List ／インサート・エフェクト・パッチ一覧

4
SIMUL
No. Patch Name Algorithm
P001 EQ + JC120 VO+GT.AMP
P002 DELAY+ JC120 VO+GT.AMP
P003 COMP +CLN TW VO+GT.AMP
P004 EQ + DRV TW VO+GT.AMP
P005 COMP +SM AMP VO+GT.AMP
P006 EQ + CRUNCH VO+GT.AMP
P007 EQ + MATCH VO+GT.AMP
P008 DELAY+ match VO+GT.AMP
P009 BRT. EQ + VO VO+GT.AMP
P010 LITE CM + vo VO+GT.AMP
P011 EQ&CMP+BLUES
VO+GT.AMP
P012 COMP&EQ + BG VO+GT.AMP
P013 EQ&DELAY +bg VO+GT.AMP
P014 EQ&DL+ML (1) VO+GT.AMP
P015 CM&DL+ml (1) VO+GT.AMP
P016 DELAY+ML 1+2 VO+GT.AMP
P017 CM&EQ+ml LD VO+GT.AMP
P018 CHRS&DL+SLDN VO+GT.AMP
P019 HVY CM+MTLms VO+GT.AMP
P020 BIG EQ+METAL VO+GT.AMP
P021 DIRECT+H-STD VO+AC.SIM
P022 BRT.EQ+S-STD VO+AC.SIM
P023 CMP&EQ+H-JUM VO+AC.SIM
P024 CMP&EQ+S-JUM VO+AC.SIM
P025 LNG DL+H-ENH VO+AC.SIM
P026 BIG CM+S-ENH VO+AC.SIM
P027 BIG EQ+H-PZO VO+AC.SIM
P028 DL EFX+S-PZO VO+AC.SIM
P029 CMP&EQ+PZO 1 VO+AC.SIM
P030 DL EFX+PZO 2 VO+AC.SIM
P031 DIRECT+SIM 1 VO+AC.SIM
P032 HVY CM+SIM 2 VO+AC.SIM
P033 HVY EQ+SIM 3 VO+AC.SIM
P034 50msDL+SIM 4 VO+AC.SIM
P035 CMP&EQ+SIM 5 VO+AC.SIM
P036 COMP +AC.MIC VO+ACOUSTIC
P037 COMP+CLS.MIC VO+ACOUSTIC
P038 COMP+DIS.MIC VO+ACOUSTIC
P039 COMP+FAR MIC VO+ACOUSTIC
P040 COMP+DYN.MIC VO+ACOUSTIC
P041 COMP+CDN.MIC VO+ACOUSTIC
P042 COMP +DIRECT VO+ACOUSTIC
P043 N.S.+VNT.CDN VO+ACOUSTIC
P044 COMP +COMP 1 VO+ACOUSTIC
P045 D.I. +COMP 2 VO+ACOUSTIC
P046 COMP +COMP 3 VO+ACOUSTIC
P047 N.SUP+COMP 4 VO+ACOUSTIC
P048 COMP +COMP 5 VO+ACOUSTIC
P049 COMP+SML.MIC VO+ACOUSTIC
P050 COMP+LRG.MIC VO+ACOUSTIC
Insert Effect Patch List ／インサート・エフェクト・パッチ一覧

5
MULTI-CHANNEL
(Algorithm: 8CH COMP EQ)
* The optinum effect is applied when the devices are connected as
above recommended connections.
* The effect changes according to the input volume level.
※ 推奨接続例のとおりに接続すると、最適な効果が得られま
す。
※ 入力する音量によって、効果は異なります。
No. Patch Name Recommended Connection
推奨接続例
P001 Rock Band
INPUT1: Guitar Amp (Mic)
INPUT2: Vocal (Mic)
INPUT3: Bass Amp (Mic)
INPUT4: Guitar Effects (Line)
INPUT5: Keyboard L (Line)
INPUT6: Keyboard R (Line)
INPUT7: Drums L (Mic)
INPUT8: Drums R (Mic)
P002 Jazz Band
INPUT1: Guitar Amp 1 (Mic)
INPUT2: Vocal (Mic)
INPUT3: Bass Amp (Mic)
INPUT4: Guitar Amp 2 (Mic)
INPUT5: Piano L (Mic)
INPUT6: Piano R (Mic)
INPUT7: Drums L (Mic)
INPUT8: Drums R (Mic)
P003 Basic Drums
INPUT1: Kick (Mic)
INPUT2: Snare (Mic)
INPUT3: Top L (Mic)
INPUT4: Top R (Mic)
INPUT5: -
INPUT6: -
INPUT7: -
INPUT8: -
P004 Multi-Drum
INPUT1: Hi Hat (Mic)
INPUT2: Kick (Mic)
INPUT3: Snare (Mic)
INPUT4: Hi Tom (Mic)
INPUT5: Lo Tom (Mic)
INPUT6: Floor Tom (Mic)
INPUT7: Top L (Mic)
INPUT8: Top R (Mic)
P005 A Cappella
INPUT1: Vocal 1 (Mic)
INPUT2: Vocal 2 (Mic)
INPUT3: Vocal 3 (Mic)
INPUT4: Vocal 4 (Mic)
INPUT5: Vocal 5 (Mic)
INPUT6: Vocal 6 (Mic)
INPUT7: Total L (Mic)
INPUT8: Total R (Mic)
P006 Doo-Wop
INPUT1: Voice Percussion (Mic)
INPUT2: Lead Vocal (Mic)
INPUT3: Bass Vocal (Mic)
INPUT4: Vocal 1 (Mic)
INPUT5: Vocal 2 (Mic)
INPUT6: Vocal 3 (Mic)
INPUT7: Total L (Mic)
INPUT8: Total R (Mic)
P007 Horn Section
INPUT1: Trumpet 1 (Mic)
INPUT2: Trumpet 2 (Mic)
INPUT3: Tronbone 1 (Mic)
INPUT4: Tronbone 2 (Mic)
INPUT5: Alt Sax 1 (Mic)
INPUT6: Alt Sax 2 (Mic)
INPUT7: Tenor Sax (Mic)
INPUT8: Baritone Sax (Mic)
P008 Mandrine Qrt
INPUT1: Mandrine (Mic)
INPUT2: Mandola (Mic)
INPUT3: Mandcello (Mic)
INPUT4: Mandbass (Mic)
INPUT5: -
INPUT6: -
INPUT7: Ambience L (Mic)
INPUT8: Ambience R (Mic)
P009 Str & Piano
INPUT1: Violin 1 (Mic)
INPUT2: Violin 2 (Mic)
INPUT3: Viola (Mic)
INPUT4: Cello (Mic)
INPUT5: Acoustic Piano L (Mic)
INPUT6: Acoustic Piano R (Mic)
INPUT7: Ambience L (Mic)
INPUT8: Ambience R (Mic)
P010 8ch Limiter
INPUT1: for any instruments
INPUT2: for any instruments
INPUT3: for any instruments
INPUT4: for any instruments
INPUT5: for any instruments
INPUT6: for any instruments
INPUT7: for any instruments
INPUT8: for any instruments
No. Patch Name Recommended Connection
推奨接続例
Insert Effect Patch List ／インサート・エフェクト・パッチ一覧
