Botex DMX DC-1224 User manual

DMX DC-1224
DMX Controller
User Manual

Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
Internet: www.thomann.de
18.01.2024, ID: 346647 (V2)

Table of contents
1 General information.............................................................................................................. 5
1.1 Symbols and signal words........................................................................................... 5
2 Safety instructions................................................................................................................. 6
3 Features....................................................................................................................................... 7
4 Installation................................................................................................................................. 8
5 Starting up................................................................................................................................. 9
6 Connections and controls................................................................................................ 10
7 Operating................................................................................................................................. 13
7.1 Starting programming................................................................................................ 13
7.2 Editing............................................................................................................................... 15
7.3 Operation......................................................................................................................... 17
8 MIDI and DMX channel settings.................................................................................... 19
8.1 MIDI.................................................................................................................................... 19
8.2 DMX................................................................................................................................... 21
9 Quick Start Guide for the main functions................................................................. 23
9.1 Reversing scene direction.......................................................................................... 23
9.2 Setting Fade time.......................................................................................................... 23
9.3 Using TAP SYNC............................................................................................................. 23
9.4 Using MASTER fader..................................................................................................... 23
9.5 Selecting ‘Single’ mode.............................................................................................. 24
9.6 ‘Mix’ mode....................................................................................................................... 24
9.7 Dimmer Display............................................................................................................. 24
9.8 BLIND and HOME.......................................................................................................... 24
9.9 PARK................................................................................................................................... 25
9.10 ADD/KILL....................................................................................................................... 25
9.11 Double Preset.............................................................................................................. 25
10 Technical specications.................................................................................................... 26
11 Plug and pin assignments................................................................................................ 27
12 Protecting the environment........................................................................................... 28
Table of contents
DMX DC-1224 3
DMX Controller

4DMX DC-1224
DMX Controller

1 General information
This document contains important instructions for the safe operation of the product.
Read and follow the safety instructions and all other instructions. Keep the document
for future reference. Make sure that it is available to all those using the product. If you
sell the product to another user, be sure that they also receive this document.
Our products and documentation are subject to a process of continuous develop‐
ment. They are therefore subject to change. Please refer to the latest version of the
documentation, which is ready for download under www.thomann.de.
1.1 Symbols and signal words
In this section you will nd an overview of the meaning of symbols and signal words
that are used in this document.
Signal word Meaning
DANGER! This combination of symbol and signal word indicates
an immediate dangerous situation that will result in
death or serious injury if it is not avoided.
WARNING! This combination of symbol and signal word indicates
a possible dangerous situation that can result in death
or serious injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates
a possible dangerous situation that can result in mate‐
rial and environmental damage if it is not avoided.
Warning signs Type of danger
Warning – danger zone.
General information
DMX DC-1224 5
DMX Controller

2 Safety instructions
This device is used to control spotlights, dimmers, lighting eects equipment,
Moving Heads or other DMX-controlled devices. The device is designed for profes‐
sional use and is not suitable for use in households. Use the device only as described
in this user manual. Any other use or use under other operating conditions is consid‐
ered to be improper and may result in personal injury or property damage. No lia‐
bility will be assumed for damages resulting from improper use.
This device may be used only by persons with sucient physical, sensorial, and intel‐
lectual abilities and having corresponding knowledge and experience. Other persons
may use this device only if they are supervised or instructed by a person who is
responsible for their safety.
Safety
DANGER!
Risk of injury and choking hazard for children!
Children can suocate on packaging material and small parts. Children can injure themselves when handling the device. Never
allow children to play with the packaging material and the device. Always store packaging material out of the reach of babies and
small children. Always dispose of packaging material properly when it is not in use. Never allow children to use the device without
supervision. Keep small parts away from children and make sure that the device does not shed any small parts (such knobs) that
children could play with.
NOTICE!
Damage to the external power supply due to high voltages!
The device is powered by an external power supply. The external power supply can be damaged if it is operated with the incor‐
rect voltage or if high voltage peaks occur. In the worst case, excess voltages can also cause a risk of injury and res. Make sure
that the voltage specication on the external power supply matches the local power grid before plugging in the power supply.
Only operate the external power supply from professionally installed mains sockets that are protected by a residual current circuit
breaker (FI). As a precaution, disconnect the power supply from the power grid when storms are approaching or it the device will
not be used for a longer period.
NOTICE!
Risk of re due to covered vents and neighbouring heat sources!
If the vents of the device are covered or the device is operated in the immediate vicinity of other heat sources, the device can
overheat and burst into ames. Never cover the device or the vents. Do not install the device in the immediate vicinity of other
heat sources. Never operate the device in the immediate vicinity of naked ames.
NOTICE!
Damage to the device if operated in unsuitable ambient conditions!
The device can be damaged if it is operated in unsuitable ambient conditions. Only operate the device indoors within the
ambient conditions specied in the “Technical specications” chapter of this user manual. Avoid operating it in environments
with direct sunlight, heavy dirt and strong vibrations. Avoid operating it in environments with strong temperature uctuations. If
temperature uctuations cannot be avoided (for example after transport in low outside temperatures), do not switch on the
device immediately. Never subject the device to liquids or moisture. Never move the device to another location while it is in oper‐
ation. In environments with increased dirt levels (for example due to dust, smoke, nicotine or mist): Have the device cleaned by
qualied specialists at regular intervals to prevent damage due to overheating and other malfunctions.
NOTICE!
Possible staining due to plasticiser in rubber feet!
The plasticiser contained in the rubber feet of this product may react with the coating of the oor and cause permanent dark
stains after some time. If necessary, use a suitable mat or felt slide to prevent direct contact between the device’s rubber feet and
the oor.
Intended use
Safety instructions
6DMX DC-1224
DMX Controller

3 Features
Special features of the device:
n24 control channels, freely assignable to 512 DMX channels
nConnection for a fog machine
n4600 scenes
n4 banks with 48 freely programmable, directly accessible programmes
nTwelve programmable chases
n24 faders for manual control
nAssigned or reversed DMX channel preview
nSound-to-Light
n3 function layers
nBlind home function
nSpeed fade control
nBlackout master
nStand-alone mode
nManual overriding of scenes in chases
nMIDI control for banks, chases and blackout
nLCD
Features
DMX DC-1224 7
DMX Controller

4 Installation
HEATING
READY
FOG
MACHINE
15
3
2 4
If the unit is to be mounted in a 19" rack, remove the plastic panel Thereto loosen the
screws that hold the panel.
Wiring diagram for fog machines
Rack mounting
Installation
8DMX DC-1224
DMX Controller

5 Starting up
Unpack and check carefully there is no transportation damage before using the unit.
Keep the equipment packaging. To fully protect the product against vibration, dust
and moisture during transportation or storage use the original packaging or your
own packaging material suitable for transport or storage, respectively.
Create all connections while the device is o. Use the shortest possible high-quality
cables for all connections. Take care when running the cables to prevent tripping
hazards.
NOTICE!
Data transfer errors due to improper wiring!
If the DMX connections are wired incorrectly, this can cause errors
during the data transfer.
Do not connect the DMX input and output to audio devices, e.g. mixers
or ampliers.
Use special DMX cables for the wiring instead of normal microphone
cables.
Connect the DMX output of the device (C) to the DMX input of the rst DMX device
(1). Connect the output of the rst DMX device to the input of the second one, and so
on to form a daisy chain. Always ensure that the output of the last DMX device in the
daisy chain is terminated with a resistor (110 Ω, ¼W).
Connect the included 9V power supply unit to the power supply input of the device
and then plug the power cord plug into the wall outlet.
When all cable connections are made, turn on the device with the main switch on the
back. The device is immediately operational.
Connections in DMX mode
Connecting the power supply
Switching on the device
Starting up
DMX DC-1224 9
DMX Controller

6 Connections and controls
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
1 2 3 4 5 6 7 8 9 10 11 12
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
13 14 15 16 17 18 19 20 21 22 23 24
PRESET APRESET B
1 2 3 4 5 6 7 8 9 10 11 12
SCENES
REC STEP
DIMMER
SPEED TIME
FADETIME
DOWN UP DELETE INSERT EDIT
BEAT REV CHASE REV REV ONE % OR 0-255 ALL REV
PARK
SCENES
B
HOLD STEP AUDIO
DARK
MODE
PAGE KILL RECORD
24CH DMX Console
DC-1224
SELECT
REC
CLEAR
REC
EXIT
SHIFT
REC SPEED
1 2 3 4 ADD
CHNS
ADOUBLE PRESET
PRESET
SINGLE
1-24
SINGLE CHASE
MAX CHASE
10MIN5MIN
FADEMASTER SPEED AUDIO LEVEL
0
2
4
6
8
10
10
8
6
4
2
0
0
2
4
6
8
10
0
2
4
6
8
10
A B
.2s
.5s
1s
2s
5s
10s
30s
1m
2m
5m
10m
MINS
INSTANT
.2s
.5s
1s
2s
5s
10s
30s
1m
2m
5m
.2s
1s
2s
5s
10s
20s
1m
2m
5m
10m
SHOW
MINS MINS
.1sec .1sec
MODE
SHOW
MODE
BLIND HOME TAP SYNC FULL-ON BLACK OUT
HEATING
READY
FOG
MACHINE
-. /* ,+
ö
)
#
$
%
&
'
(
D
0
1
2
3
4
5
6
7
8
9 :; < = > ?
A
B
C
1[PRESET A 1-12] | Indicates the current intensity of the corresponding channels.
2[Channel faders 1-12] | These faders can be used to adjust / programme the intensity of channels 1-12.
3[FLASH 1-12] | When this button is pressed, the intensity of the respective channel 1-12 is set to 100%.
4[PRESET B 13-24] | Indicates the current intensity of the corresponding channels.
5[SCENES 1-12] | These LEDs light up when the corresponding scene is activated.
6 Channel faders [13-24] / Scene faders [1-12] | These faders can be used to adjust/programme the intensity of chan‐
nels 13-24.
7[FLASH 13-24] | When this button is pressed, the intensity of the respective channel 13-24 is set to 100%.
8[DARK] | As long as this button is held, all DMX values at the output are set to [000]
9[DOWN/BEAT REV] | [Down] can be used to change a scene in edit mode. [Beat Rev] can be used to change the
direction of the chase during a programme with constant beat.
10 [MODE SELECT/REC SPEED] | Use [Mode Select] to switch between these three modes:
nCHNS〈〉SCENES
nA DOUBLE PRESET B
n1-12 SINGLE PRESET
Use [Rec Speed] to adjust the speed of all programmes in “Mix” mode.
11 [UP/CHASE REV] | [DOWN] can be used to change a scene in edit mode. [CHASE REV] is used to change the direction
of all chases.
12 [PAGE] | Switches between the four PAGES (banks).
13 [DELETE/REV ONE] | [DELETE] can be used to delete any step in a scene. [REV ONE] is used to reverse the direction of
a chase.
14 [Display] | This display shows the current activity or programme status.
15 [INSERT/% OR 255] | [INSERT] can be used to add steps to a scene. Use [% OR 255] to choose whether to see the
value as a percentage value or as a value between 0-255.
16 [EDIT/ALL REV] | [EDIT] is used to activate edit mode. [ALL REV] is used to change the direction of all programmes.
Connections and controls
10 DMX DC-1224
DMX Controller

17 [ADD OR KILL/REC EXIT] | In [ADD], multiple scenes or ash buttons are active. In [KILL], pressing a ash button disa‐
bles any other scene or programme. Use [REC EXIT] to exit edit mode.
18 [RECORD/SHIFT] | [RECORD] is used to launch record mode or programme a step. [SHIFT] is only used in conjunction
with other buttons.
19 [MASTER] | Sets the intensity of Master A to 100% for as long as the button is pressed.
20 [PARK] | In CHNS〈〉SCENES mode you can switch between the single-chase and mix-chase modes. In single-chase
mode, the activated programmes run one after the other, while in mix-chase mode the activated programmes run
simultaneously.
21 [HOLD] | Freezes all current DMX values on the output
22 [STEP] | This button is used to move to the next step if [SPEED] is on the lowest setting or edit mode is enabled.
23 [AUDIO] | Enables audio mode.
24 [MASTER] | Master fader for channels 1-12.
25 [MASTER B] | Master fader for channels 13-24.
26 [BLIND] | This button is used to temporarily remove individual channels from a running programme.
27 [HOME] | This button is used to exit blind mode.
28 [TAP SYNC] | If you are in “Run” mode, you can use [TAP SYNC] to manually specify the speed. Pressing this button
twice sets the speed.
29 [FULL ON] | Sets all DMX values to [255].
30 [BLACK OUT] | Sets all DMX values on the output to [000].
31 [FADE] | [FADE] is used to set the fade time.
32 [SPEED] | [SPEED] is used to set the speed of a chase.
33 [AUDIO LEVEL] | [AUDIO LEVEL] is used to adjust the audio sensitivity.
34 [FOG MACHINE] | Control and display elements for a fog machine.
Connections and controls
DMX DC-1224 11
DMX Controller

POWER DC IN
–
+
PUSH
MIDI DMX OUT AUDIO REMOTE FOG MACHINE
OUT IN THRU
J KG IHE F
35 [POWER] | Turns the device on and o.
36 [DC IN] | Input for the power supply.
37 [MIDI THRU/OUT/IN] | “MIDI” connections for connecting a sequencer or a MIDI device.
38 [DMX OUT] | This connection sends DMX signals to DMX-enabled devices. Use a cable with 3-pin XLR connector to
connect the devices.
39 [AUDIO] | This input can be used to connect an audio signal with a level between 100 mV and 1 V.
40 [REMOTE] | “Black out” and “Full on” can also be activated via a remote control. Please use a 6.35-mm jack plug
(stereo) for the connection.
41 [FOG MACHINE] | A fog machine can be connected to this input.
Connections and controls
12 DMX DC-1224
DMX Controller

7 Operating
7.1 Starting programming
7.1.1 Enabling programming
1. Keep [RECORD] pressed.
2. While holding down [RECORD], press the Flash buttons 1, 6, 6 and 8 in
sequence.
When you turn on the unit for the rst time, the record code is 1, 6, 6
and 8. You can change the code to protect your programmes.
3. Release [RECORD] .
ðThe RECORD LED lights up.
Now you can start programming.
7.1.2 Protecting programmes
To protect your programmes, you can change the ‘Record’ code. To change the
Record code, proceed as follows:
1. Activate the programming (
Ä Chapter 7.1.1 ‘Enabling programming’
on page 13).
2. Keep [RECORD] and [EDIT] pressed simultaneously.
3.
The record code consists of a combination of four "Flash" buttons,
this number may not be exceeded or fallen below.
While holding down [RECORD] and [EDIT] , enter the new code using the ash
buttons.
4. Release [RECORD] and [EDIT] .
ðThe display shows ‘Cod’
5. Keep [RECORD] and [EDIT] pressed simultaneously.
6. Re-enter the new ‘Record’ code.
ðAll Channel and Scene LEDs ash three times.
The RECORD code is now changed.
If you re-enter something other than the rst time, the LEDs will
not light up. This means that changing the ‘Record’ code has
failed.
Operating
DMX DC-1224 13
DMX Controller

WARNING!
Always remember to exit ‘Record’ mode if you do not want to continue
programming. If you forget this, you lose control of the device.
7. To quite the Record mode, press [REC EXIT] while holding down [RECORD] .
8. Release both buttons.
ðThe LED of the [RECORD] button turns o. You have left the ‘Record’ mode.
Press [RECORD] and [EXIT] simultaneously.
ðThe change process is cancelled.
7.1.3 Programming a scene
1. Activate the programming
Ä Chapter 7.1.1 ‘Enabling programming’ on page 13.
Make sure the faders [Master A&B] are both set to their maximum.
([MASTER A] is set to maximum when it is at the top. [MASTER B] is set to
maximum when it is at the bottom).
2. To select the mode ‘1-24 Single’ , press [MODE SELECT]. This gives you control
over all 24 channels.
3. Create the desired scene using the channel faders 1-24. At 0 % or DMX 0, the
faders should be in position 0, at 100 % or DMX 255, the faders should be in
position 10.
4. To save the desired scene as a step, press [RECORD].
5. Repeat steps 3 and 4 until all desired steps have been stored.
You can store up to 1000 steps in memory.
6. Press [PAGE] to select a page (1-4) where you save your scenes.
7. Keep [RECORD] pressed and additionally press one of the [FLASH] buttons
between 13 and 24
ðAll record LEDs ash once.
The program is saved.
8. To exit programming mode, press [Exit] and [RECORD] simultaneously.
Programming a chase with 16 steps with channels 1-16 and storing a sequence to
[Flash 15] on Page 1.
To cancel the process of changing the
record code:
Example programme
Operating
14 DMX DC-1224
DMX Controller

1. Activate the programming
Ä Chapter 7.1.1 ‘Enabling programming’ on page 13.
Make sure the faders [Master A&B] are both set to their maximum.
[MASTER A] is set to maximum when it is at the top. [MASTER B] is set to
maximum when it is at the bottom).
2. To select the mode ‘1-24 Single’ , press [MODE SELECT]. This gives you control
over all 24 channels.
3. Slide channel fader 1 to position 10.
ðThe LED lights up fully.
4. To save the desired scene as a step, press [RECORD].
5. Repeat steps 4 and 5 until all channels 1-16 have been programmed.
6. Press [PAGE] until the LED at [PAGE 1] is lit.
7. Press [FLASH 15] while holding down [RECORD] .
ðAll record LEDs ash once.
The program is saved.
7.2 Editing
7.2.1 Programme editing
1. Activate the programming (
Ä Chapter 7.1.1 ‘Enabling programming’
on page 13).
2. Use [PAGE] to select the page where the programme to be edited is stored.
3. Press [MODE SELECT] to select [CHNS
〈 〉 SCENES] .
4. Keep [EDIT] pressed.
5. Press the respective [FLASH] button.
6. Release [EDIT] .
ðThe LED of the corresponding scene lights up, indicating that the device is
in ‘Edit’ mode.
7.2.2 Erasing programme
1. Activate the programming (
Ä Chapter 7.1.1 ‘Enabling programming’
on page 13).
2. Use [PAGE] to select the page where the programme to be erased is stored.
3. Keep [RECORD] pressed and press twice the respective [FLASH] button [13-24].
4. Release both buttons.
ðAll LEDs ash briey.
The programme is erased.
Operating
DMX DC-1224 15
DMX Controller

7.2.3 Deleting all programmes
1. Activate the programming (
Ä Chapter 7.1.1 ‘Enabling programming’
on page 13).
2. Keep [RECORD] pressed.
3. Press [FLASH 1], [FLASH 4], [FLASH 2] and [FLASH 3] successively.
ðAll LEDs light up.
All programmes are deleted.
7.2.4 Deleting scenes
1. Activate the programming
Ä Chapter 7.1.1 ‘Enabling programming’ on page 13.
2. Record one or multiple scenes.
3. If you are not satised with one or more scenes, press [REC CLEAR] while
keeping [RECORD] pressed.
ðAll LEDs light up.
All scenes in the memory are deleted.
7.2.5 Deleting a single or multiple steps
1. Activate the programming (
Ä Chapter 7.1.1 ‘Enabling programming’
on page 13).
2. Keep [EDIT] pressed and then simultaneously press the respective
[FLASH]button.
3. Press [STEP] until you have reached the step you want to delete.
4. Press [DELETE].
ðAll LEDs light up.
The step is deleted.
5. Repeat steps 2 and 3 to delete all unwanted steps.
6. Exit the mode. To do so, press [REC EXIT] while keeping [RECORD] pressed.
ðThe LED of the scene turns o.
You have left the Edit mode.
Deleting the third step in the programme on [FLASH] 15 on page 2.
1. Activate the programming (
Ä Chapter 7.1.1 ‘Enabling programming’
on page 13).
2. To select [CHNS
〈 〉 SCENES] , press [MODE SELECT].
3. Press [FLASH] while keeping [EDIT] pressed.
ðThe LED of the corresponding scene lights up.
4. To get to the third step, press [STEP].
5. To delete this step, press [DELETE].
Example for deleting a step
Operating
16 DMX DC-1224
DMX Controller

6. Exit the mode. To do so, press [REC EXIT] while keeping [RECORD] pressed.
ðThe LED of the scene turns o.
You have left the Edit mode.
7.2.6 Adding one or multiple steps
1. Programme one or more steps you want to add (
Ä Chapter 7.1.3 ‘Programming
a scene’ on page 14).
2. Make sure you are in [CHNS
〈 〉 SCENES] mode and activate the [EDIT] mode.
3. Press [STEP] press until you reach the step before which you want to insert a
step.
4. Press [INSERT] to add the step.
ðAll LEDs light up.
The step is added.
5. Exit the Edit mode. To do so, press [REC EXIT] while keeping [RECORD] pressed.
7.2.7 Changing one or multiple steps
1. Activate the Edit mode.
2. To get to the step you want to change, press [STEP].
3. Press and hold [UP] if you want to increase the intensity. Press and hold
[DOWN] if you want to decrease the intensity.
4. Press the [FLASH] button of the corresponding DMX channel of the scene to be
changed. While doing this, press and hold [UP] or [DOWN] pressed.
5. Press the respective [FLASH] until you are satised with your new scene.
6. Repeat steps 2, 3, 4 and 5 until all steps have been edited.
7. Exit the Edit mode. To do so, press [REC EXIT] while keeping [RECORD] pressed.
7.3 Operation
7.3.1 Starting a programme
1. Press [MODE SELECT] to select [CHNS
〈 〉 SCENES].
2. To call up the page where your desired programme is stored, press [PAGE].
3. Move [MASTER B] to position 10.
4. To initiate the programme, slide the corresponding channel fader (13-24) to
position 10.
The “fade time” of the programme depends on the [FADE] setting.
5. Use the channel fader to set the intensity of the corresponding programme.
Operating
DMX DC-1224 17
DMX Controller

7.3.2 Sound control
1. Use the built-in microphone or connect an external audio source via an RCA
plug.
2. Select the desired programme
Ä Chapter 7.3.1 ‘Starting a programme’
on page 17.
3. Press [AUDIO].
ðThe LED lights up.
Audio mode is activated.
4. Use [AUDIO LEVEL] to adjust the sensitivity.
5. To exit Audio mode, press [AUDIO] again.
ðThe LED turns o.
‘Audio’ mode is disabled.
7.3.3 Setting the programme speed with fader
1. Make sure that the Audio mode is disabled.
2. Select the desired programme (
Ä Chapter 7.3.1 ‘Starting a programme’
on page 17).
3. Use [FADE] to set the desired fade time.
4. Use [SPEED] to set the desired speed.
7.3.4 Setting a standard beat
‘Audio’ mode is disabled
1. To select [CHNS
〈 〉 SCENES], press [MODE SELECT].
2. Select the desired programme (
Ä Chapter 7.3.1 ‘Starting a programme’
on page 17).
3. You can adjust the speed by pressing [TAP SYNC] twice.
7.3.5 Changing the speed mode between 5 and 10 minutes
1. Activate the programming (
Ä Chapter 7.1.1 ‘Enabling programming’
on page 13).
2. Keep [RECORD] pressed and press [FLASH 5] (5 minute mode) three times or
[FLASH 10] (10 minute mode).
3. [5MIN] or [10MIN] lights up, indicating which setting has been made.
4. Exit the mode. To do so, press [REC EXIT] while keeping [RECORD] pressed.
Operating
18 DMX DC-1224
DMX Controller

8 MIDI and DMX channel settings
8.1 MIDI
8.1.1 Setting MIDI IN
1. Activate the programming (
Ä Chapter 7.1.1 ‘Enabling programming’
on page 13).
2. Press and hold [RECORD] .
3. Additionally, press [FLASH 1] three times.
ðThe display shows ‘CHI’ .
The MIDI IN channel setup is now available.
4. To assign [MIDI OUT] to a channel 1 - 16, press [FLASH 1-16].
ðThe corresponding LED lights up.
8.1.2 Exiting MIDI settings
1. Keep [RECORD] pressed.
2. To do so, press [REC EXIT].
8.1.3 Receiving MIDI le
1. Activate the programming (
Ä Chapter 7.1.1 ‘Enabling programming’
on page 13).
2. Keep [RECORD].
3. To do so, press [FLASH 3] three times.
ðThe display shows ‘IN’ .
The controller can now receive MIDI les.
During the data exchange, no other functions are available. The
functions are automatically available again as soon as the data
exchange is complete.
The data exchange is interrupted as soon as errors occur or the
device is switched o.
8.1.4 Sending MIDI le
1. Activate the programming (
Ä Chapter 7.1.1 ‘Enabling programming’
on page 13).
2. Keep [RECORD] pressed.
MIDI and DMX channel settings
DMX DC-1224 19
DMX Controller

3. Press [FLASH 4] three times.
ðThe display shows ‘OUT’ .
The controller can now send MIDI les.
During the data exchange, no other functions are available. The
functions are automatically available again as soon as the data
exchange is complete.
The data exchange is interrupted as soon as errors occur or the
device is switched o.
8.1.5 Implementation
nDuring the reception and transmission of MIDI les, all automatically running
MIDI scenes and channels are stopped for 10 minutes .
nWhile receiving and sending MIDI data, the device automatically searches for or
sends an ID of 55H(85), a le named DC1224 with the addition BIN(SPACE).
nData can be transferred to another device or to a MIDI device.
nThere are two dierent ways to transfer data.
nThe controller sends and receives Note On and Note O data via the [Flash] but‐
tons.
Note No. Touch velocity Functions
22-69 Programme master Turns programmes 1-48
on or o.
70-93 Channel intensity Activates channel 1-24.
94 Full on
95 Dark
96 Hold
MIDI and DMX channel settings
20 DMX DC-1224
DMX Controller
