BOTH LIGHTING BO-TUBE192 User manual

BO-TUBE192
IP65 WIRELESS BATTERY
360° PIXEL TUBE
USERMANUAL
Please read over this manual before operating the light

1. Introduction
Unpacking: Thank you for purchasing this product, all products has been thoroughly tested and
has been shipped in perfect operating condition. Carefully check the shipping carton for damage
that may have occurred during shipping. If the carton appears to be damaged, carefully inspect
your fixture for any damage and be sure all accessories necessary to operate the unit has arrived
intact. In the case damage has been found or parts are missing, please contact the manufacturer
or your dealer for further instructions. Do not return this unit to your dealer without first contacting.
Introduction: The Light is a DMX intelligent and battery powered LED par light. This par light is
light weight and compact which makes it a great piece for mobile DJ‟s and clubs.
Warning! To prevent or reduce the risk of electrical shock or fire, do not expose this unit to rain
or moisture.
Caution! There are no user serviceable parts inside this unit. Do not attempt any repairs
yourself; doing so will void your manufactures warranty. In the unlikely event your unit
may require service please contact the manufacturer or your dealer.
PLEASE recycle the shipping carton whenever possible.
General Instructions
To optimize the performance of this product, please read these operating instructions carefully to
familiarize you with the basic operations of this unit. These instructions contain important safety
information regarding the use and maintenance of this unit. Please keep this manual with the unit,
for future reference.
Notice :please pay attention to ventilation, to prevent the battery
overheat cause burning When charging.

2. Specifications
Power input : 100-240V AC 50-60Hz
Power: 28W
Battery capacity: 9600mAh
Light Source: LED5050 192*0.2W RGBWA 5in1
Channel mode : 5/6/7/12/40/80/160CH
Control mode: wireless dmx(Guangzhou/Sweden protocol), infrared remote, Master-slave, sound, auto,
App control
Maximum running time (full light): 1 hour /2 hours /3 hours /4 hours /5 hours/ 6 hours /7 hours/8 hours /9
hours /10 hours /11 hours /12 hours mode is optional.
Maximum running time (solid light): up to 8 hours.
Stroboscopic: 1-20HZ
Dimming: 4 dimming modes
Effect: 68 preset colorful effects
Control panel: OLED display screen
IP rating: IP65
Net weight: 1.7kg
Dimensions: 53*1436*1506mm
Heat dissipation system: natural heat dissipation
Shell: aluminum alloy, semi-light oxidized fine black sand.
2.1 Features:
1. System functions: voice control/self-propelled/color temperature/color saturation
2. System upgrade: wireless DMX512 software upgrade
3. Temperature protection function
4. Battery management function
5. Infrared remote control, wireless DMX512 (Guangzhou/Sweden protocol)
6. Support mobile APP control (Android and Apple)
2.2 Charging
Most important: FIRST CHARGE THE FIXTURES FOR 6-7Hours on the First
Charge before use. Plug in Power cord. Turn off Power Switch and Turn off
other switch to charge.

3. Operation
3.1 Control Panel

3.2 Operate menu:
Address
001--512
Address 001-512
5CH
5 channel
6CH
6 channel
7CH
7 channel
12CH
12 channel
40CH
40 channel
80CH
80 channel
160CH
160 channel
DMX Fail
Hold
DMX512 data hold
Blakout
DMX512 data does not hold (black field)
Dimmer
Curve
Curve 1
linear curve
Curve 2
square curve
Curve 3
logarithmic curve
Curve 4
S-curve
Custom
Red：0-255
red manual dimming
Green：0-255
Green manual dimming
Blue：0-255
blue manual dimming
White：0-255
white manual dimming
Yellow：0-255
Yellow manual dimming
Program
Color
DIM:0-255
Color:1-27
Strobe:0-255
Lee Color
DIM:0-255
Lee
Color
L101
L102
L105
L106
L107
L110
L111
L115
L116
L118
L119
L121
L124
L126
L127
L128
L132
L135

L139
L147
L151
L152
L158
L164
L174
L179
L180
L201
L203
L204
Strobe:0-255
CCT
DIM:0-255
CCT
2700K
3000K
3200K
3500K
3800K
4100K
4400K
4700K
5000K
5300K
5600K
5900K
6200K
6500K
6800K
7100K
7400K
7700K
8000K
8300K
8600K
8900K
9200K
9500K
9800K
10000K
10500K
11000K
10500K

11000K
11500K
12000K
G/M:-1.00--1.00
HSI
DIM:0-255
HUE:0-360
STA:0-100
Auto
Auto Mode:0-60
Speed:1-16
Color:0-27
Sound
Sound Mode:0-3
SENS:0-100
Color:0-27
WIFI
LED_XXX
Master/Sl
ave
Master
Slave
Wireless
DMX
On
Off
Clear
Pairing
Run Time
1h/2h/3h/4h/5h/6h/7h/8h/9h/10h/11h/12h
Informatio
n
Version1.0
Current Time 00H35M 00S
IR
ON
OFF
Menu
Lock
ON
OFF
Back Light
Always On
10s
20s
30s
Factory
Reset
ON
YES

4. DMX Channel Functions
When using a DMX controller, use the chart below to reference each channel’s function.
CH
5CH
6CH
7CH
12CH
40CH
80CH
160CH
CH1
0-255
red
dimming
0-1 closed
light
1-255 total
dimming
0-1 closed
light
1-255 total
dimming
0-1 closed light
1-255 total dimming
R-1
R-1
R-1
CH2
0-255
green
dimming
0-10 no
strobe
11-255
strobe
0-10 no
strobe
11-255 strobe
0-10 no strobe
11-255 strobe
G-1
G-1
G-1
CH3
0-255
blue
dimming
0-4 none
5-255 RGB
color mixing
0-255 red
dimming
0-10 cycle color mixing
11-19 red
20-28 green
29-37 blue
38-46 white
47-55 yellow
56-64 red + green
65-73 green + blue
74-82 red + blue
83-91 red + green
92-100 green + blue
101-109 red + yellow
110-118 red + green
119-127 green + blue
128-136 red
137-145 blue + yellow
146-154 yellow + white
155-163 green+white
164-172 green+amber
173-181 red + blue +
white
182-190 red + yellow +
white
191-199 green + blue +
white
200-208 green + blue +
yellow
209-217 blue + yellow +
white
218-226 red + green +
blue + white
B-1
B-1
B-1

227-235 red + green +
blue + white
236-244 green + blue +
white + yellow
245-255
red+green+blue+white+
yellow
CH4
0-255
white
dimming
0-255
dimming
0-255 green
dimming
0-16 none
17-33 base color red
34-50 background color
green
51-67 background
color blue
68-84 background color
white
85-101 background
color yellow
102-118 base color red
+ green
119-135 background
color green + blue
136-152 base color red
+ blue
153-169 background
color red + green
170-186 background
color green + blue
187-203 background
color red + yellow
204-220 background
color red + green
221-237 background
color green + blue
238-254 background
color red + blue
255 base color blue +
yellow
W-1
W-1
W-1
CH5
0-255
Amber
dimming
0-4 none
5-255 color
temperature
0-255 blue
dimming
0-1 none
2-255 base light
Y-1
Y-1
Y-1
CH6
0-255 color
saturation
0-255 white
dimming
0-10 none
11-214 effects (60
types, 3 values for one
effect)
R-2
R-2
R-2

215-220 full effect
221-255 voice control
CH7
0-255 Amber
dimming
0-255 effect speed
G-2
G-2
G-2
CH8
0-255 red dimming
B-2
B-2
B-2
CH9
0-255 green dimming
W-2
W-2
W-2
CH10
0-255 blue dimming
Y-3
Y-3
Y-3
CH11
0-255 white dimming
R-3
R-3
R-3
CH12
0-255 yellow dimming
G-3
G-3
G-3
CH13
B-3
B-3
B-3
CH14
W-3
W-3
W-3
CH15
Y-3
Y-3
Y-3
CH16
R-4
R-4
R-4
CH17
G-4
G-4
G-4
CH18
B-4
B-4
B-4
CH19
W-4
W-4
W-4
CH20
Y-4
Y-4
Y-4
CH21
R-5
R-5
R-5
CH22
G-5
G-5
G-5
CH23
B-5
B-5
B-5
CH24
W-5
W-5
W-5
CH25
Y-5
Y-5
Y-5
CH26
R-6
R-6
R-6
CH27
G-6
G-6
G-6
CH28
B-6
B-6
B-6
CH29
W-6
W-6
W-6
CH30
Y-6
Y-6
Y-6
CH31
R-7
R-7
R-7
CH32
G-7
G-7
G-7
CH33
B-7
B-7
B-7
CH34
W-7
W-7
W-7
CH35
Y-7
Y-7
Y-7
CH36
R-8
R-8
R-8
CH37
G-8
G-8
G-8
CH38
B-8
B-8
B-8
CH39
W-8
W-8
W-8
CH40
Y-8
Y-8
Y-8
........
.......
.......
CH156
R-32
CH157
G-32
CH158
B-32
CH159
W-32
CH160
Y-32

5. Advanced parameter settings:（In A001 mode, press the “ENTER”key for 3
seconds to enter）
Red
000-255
Red current regulation
Green
000-255
Green current regulation
Blue
000-255
blue current regulation
White
000-255
white current regulation
Yellow
000-255
yellow current regulation
State
Single
currently bright
Whole
full light
T.Limit
060
Power reduction setting (OFF/function off, power reduction on/40-100
degrees adjustable range)
Delay
YES
Dimming delay on
NO
Dimming delay off

6. Infrared remote control functions:
1, dimming up button
2, dimming down button
3, OFF closed light pause
4, ON light running
5, R, G, B, W, A keys are 5 kinds of basic color, up and down keys to adjust the
brightness.
6, The UV key is the color temperature, up and down keys to adjust the color
temperature
7, The 0 key is A001 mode, and the up and down keys adjust the address code
8, 1-9 number keys are 9 static color mixing (AC 1...AC 9)
9, The AUTO key is the color-changing mode, and the up and down keys adjust the
speed
10, The STROBE key is the color selection strobe mode (27 types are optional), and the
up and down keys are used to adjust the speed

7. WIFI mode of operation
In the "User Settings" screen, press the MENU key to select "Program", and use the UP /
DOWN keys to select "WiFi" (WIFI mode). Press the ENTER button, there will be a WiFi name,
then you can set your phone to make the connection control. Open the phone setup function,
and find the wireless network WLAN entry, to connect the device named LED_xxx.
For IOS,Please search “Both Lighting” in app store.
For Android,Please Scan this QR code for download.
