Bowers & Wilkins 2001 User manual

2001
Stand-mount/Bookshelf loudspeaker system
Product Summary
●The baby of the bunch at just 11 inches high and with a volume of 6.8 litres, the 2001 is an
ideal monitor for the first time purchaser.
●Shelf or wall mounted with a forth-order, rear vented box, this loudspeaker will enable any
domestic hi-fi system to deliver excellent sound reproduction across all spectrums of music, without
the need to invest in a large amplifier.
Technical highlights
●As the name of the 2000 Series suggests, these loudspeakers have been designed to meet
the needs of the consumer between now and the 21st Century.
●Affordable, high performance audio/video loudspeakers with ZMF (Zero Magnetic Field)
●Contoured front baffle to overcome diffraction
●Acoustically transparent frameless grilles with specially developed low coloration drive units.
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
www.bwspeakers.com
Drive Units
Frequency Response
1 x 30mm diameter high frequency with
alloy diaphragm, 19mm dia. high
temperature voice coil and magnetic
fluid cooling.
1 x 135mm diameter bass/midrange
with acyrilic damped fibre cone, low
hysteresis rubber surround and 25mm
dia. high temperature voice coil.
85Hz – 20kHz ± 2dB
Sensitivity
Nominal Impedance
Power Handling
Dimensions
Finish
88dB spl(1 watt into 8 ohms)
4ohms
20W – 100W into 4 ohms undistorted
speech and music programme
Height: 285mm Width: 180mm
Depth: 200mm
Black ash vinyl or white vinyl
Also produced in a magnetically shielded version 2001 ZMF
