Projector
MP-57i / MP-58i
User's Manual - Operating Guide
Thank you for purchasing this projector!
1.800.762.5757
www.boxlight.com
©2004, BOXLIGHT Corporation. All rights reserved.This manual may not be copied in any media or form without the written consent of the manufacturer.

TRADEMARK ACKNOWLEDGMENT
• VGA and XGA are registered trademarks of the International Business Machines Corporation.
• Apple and Mac are registered trademarks of Apple Computer, Inc.
• VESA and SVGA are trademarks of the Video Electronics Standard Association.
• Windows is a registered trademark of Microsoft Corporation.
• Internet Explorer is a trademark of the Microsoft Corporation.
All other trademarks are the property of their respective owners.
NOTE: The information in this manual is subject to change without notice.
The manufacturer assumes no responsibility for any errors that may appear in this manual.
The reproduction, transmission or use of this document or contents is not permitted
without express written authority.
WARNING!
Before using, read the “User’s Manual - Safety Guide” and
these manuals to ensure correct usage through understanding. After reading,
store them in a safe place for future reference
Projector
MP-57i / MP-58i
User's Manual - Operating Guide
Thank you for purchasing this projector!

2
Projector Features
Projector Features
Preparation
Preparation
●
Ultra High Brightness
Crisp, ultra-bright presentations is achieved by using a UHB (ultra high brightness) lamp and a highly
efficient optical system.
●
Whisper Mode Equipped
Special mode is available for reducing projector noise to achieve quieter operation.
●
User Memory Function
This projector can memorize 4 settings by MY MEMORY function.
●
Partial Magnification Function
Interesting parts of images can be magnified for closer viewing.
●
Keystone Distortion Correction
Quick correction of distorted images electrically.
●
Optical Lens Shift
The lens of this projector can be shifted vertically. When you want to finely adjust the picture position,
use the LENS SHIFT buttons.
This multimedia projector is used to project various computer signals as well as
NTSC/PAL/SECAM video signals onto a screen. Little space is required for
installation and large images can easily be realized.
Please see the “Contents Of Package” of the “User’s Manual – Quick Guide”.
Your projector should come with the items shown there. Contact your dealer
anything is missing.
• Keep the original packing material for future reshipment. For moving the projector, be
sure to use the original packing material. Use special caution for the lens part.
NOTE
01CP-X1200-ENG-OG-三校03.12.51:10PMページ2

3
Contents
Contents
Projector Features ……………………………………2
Preparation ……………………………………………………2
Part Names ……………………………………………………4
Projector ……………………………4
Control Buttons ……………………5
Remote control ……………………5
Setting Up …………………………………………………………6
Arrangement ………………………6
Adjusting The Projector’s
Elevator ……………………………7
Using The Lens shift Buttons ……7
Connecting Your Devices…………8
Connecting The Power Supply …11
Remote Control …………………………………………12
About The Laser Pointer ………12
Putting Batteries …………………12
Operating The
Remote Control …………………13
Using The Remote
ID Feature…………………………13
Using The Mouse/Keyboard
Control Function …………………14
Power ON/OFF …………………………………………15
Turning On The Power …………15
Turning Off The Power …………15
Operating ……………………………………………………16
Selecting An Input Signal ………16
Selecting The Aspect Ratio ……17
Using The Automatic
Adjustment Feature………………17
Adjusting The Picture Position …18
Correcting The Keystone
Distortion …………………………18
Adjusting The Volume …………19
Muting The Sound ………………19
Temporarily Blanking
The Screen ………………………19
Freezing The Screen ……………20
Using The Magnify Feature ……20
Displaying The Child Window …21
Selecting An Audio Input ………21
Multifunctional Settings ……………………22
Using The Menu Functions ……22
MAIN Menu ………………………23
PICTURE-1 Menu ………………24
PICTURE-2 Menu ………………26
INPUT Menu ……………………27
AUTO Menu ………………………29
SCREEN Menu …………………31
OPTION Menu ……………………33
NETWORK Menu ………………35
Network Setting Up ………………………………36
Lamp ………………………………………………………………37
Replacing The Lamp ……………38
Air Filter …………………………………………………………39
Caring For The Air Filter…………39
Other Care ……………………………………………………40
Caring For The Inside Of
The Projector ……………………40
Caring For The Lens ……………40
Caring For The Cabinet And
Remote Control …………………40
Troubleshooting ……………………………………41
Related Messages ………………41
Regarding The Indicator
Lamps ……………………………43
Phenomena That May Easily Be
Mistaken For Machine Defects …45
Warranty And After-Service …………47
Specifications …………………………………………47
TECHNICAL
01CP-X1200-ENG-OG-三校03.12.51:10PMページ3

4
Part Names
Part Names
Projector
1Elevator button
2Elevator foot
3Remote sensor
4Lens cap
5Lens
The picture is projected from
here.
6Filter cover
An air filter is inside.
ARGB port
BM1-D port
CBNC port
DAUDIO IN 1 port
EAUDIO IN 2 port
FCONTROL port
GNETWORK port
HAUDIO IN R/L port
IVIDEO IN port
JS-VIDEO port
KCOMPONENT port
LRGB OUT port
MAUDIO OUT port
7REMOTE CONTROL port
8DC OUT port
9AC Inlet
0Power switch
-Control buttons
See the following page.
Projector (Front/Right)
Projector (Rear/Left)
INTER
INPUT
M1-D
RGB
BNG
S-VIDEO
STANDBY/ON
TEMP
VIDEO
COMPONENT
LAMP
KEYSTONE
SEARCH
RESET
MENU
FOCUS
LENSSHIFTZOOM
1
2
3
5
4
6
INTER
INPUT
M1-D
RGB
BNG
S-VIDEO
STANDBY/ON
TEMP
VIDEO
COMPONENT
LAMP
KEYSTONE
SEARCH
RESET
MENU
FOCUS
LENS SHIFTZOOM
VIDEO
R-AUDIO IN-L S-VIDEO
BNC
RGB
AUDI O IN1
AUDI O IN2 RGB OUT
AUDI O OUT
REMOTE CONTROL
R/C
R
/P
R
G/Y B/C
B
/P
B
HV
Y
CONTROL NETWORK
CR/PR Ca/Pa
7
8-
LF
A
D
E
CM
HIJ
K
G3
09
B
01CP-X1200-ENG-OG-三校03.12.51:10PMページ4

INTER
INPUT
M1-D
RGB
BNG
S-VIDEO
STANDBY/ON
TEMP
VIDEO
COMPONENT
LAMP
KEYSTONE
SEARCH
RESET
MENU
FOCUS
LENSSHIFTZOOM
STANDBY/ON VIDEO
LASER INDICATOR
ESC MENU
POSITION RESET AUTO
KEYSTONE
1 2 3
ID CHANGE
SEARCH
ON
OFF
FREEZE MUTE
MAGNFY PinP VOLUME
RGB
BLANK
PREVIOUS NEXT
ASPECT
ENTER
LASER
LENS SHIFT
+
–––
++
FOCUS ZOOM
1
4
w
u
r
s
f
h
j
k
e
q
io
p
[
\
]
d
t
g
l
;
6
a
'
5
Part Names (continued)
Part Names (continued)
Remote Control
Control Buttons
ENTER
INPUT
M1-D
RGB
BNC
S-VIDEO
STANDBY/ON
TEMP
VIDEO
COMPONENT
LAMP
KEYSTONE
SEARCH
RESET
MENU
FOCUS
LENS SHIFT ZOOM
1
e
w q
4
7
8
9
0
-
=2
5
6
t
y
u
3
r
1STANDBY/ON button
and STANDBY/ON indicator
2TEMP indicator
3LAMP indicator
4LENS SHIFT buttons
5INPUT dial
6SEARCH button
7M1-D indicator
8RGB indicator
9BNC indicator
0COMPONENT indicator
-S-VIDEO indicator
=VIDEO indicator
qZOOM buttons
wFOCUS buttons
eKEYSTONE button
rMENU button
tRESET button
yENTER button
uCursor buttons / / /
Control Panel
on the Projector
Remote Control
iLASER INDICATOR
oVIDEO button
pRGB button
[BLANK button
]ASPECT button
\LASER button
aCursor buttons / / /
(Mouse move pointer)
sESC button
(Keyboard ESC key)
d(Mouse right button)
fPOSITION button
gAUTO button
hPinP button
jMAGNIFY buttons
kFREEZE button
lVOLUME button
;MUTE button
'ID CHANGE switch
1STANDBY/ON button
4LENS SHIFT buttons
6SEARCH button
qZOOM buttons
wFOCUS buttons
eKEYSTONE button
rMENU button
tRESET button
yENTER button
(Mouse left button)
uCursor buttons
///
(Keyboard
Arrow keys / / / )
y
(Rear)
01CP-X1200-ENG-OG-三校03.12.51:10PMページ5

6
Setting Up
Setting Up
Arrangement
WARNING • Before installation, make sure that the projector is turned off and the
power code is disconnected.
• Do not set up and move the projector, while it is hot.
• Install the projector in a suitable environment according to instructions of the “User’s
Manual – Safety Guide” and this manual.
• The power outlet should be close to the projector and easily accessible.
Refer to the illustrations and tables below to determine the screen size and projection
distance. The values shown in the table are calculated for a full size screen. (±10%)
Reference for
the 4:3 aspect ratio
Reference for
the 16:9 aspect ratio
Screen Size
[inch (m)] a[inch (m)] b[inch (cm)]
Min. Max. m:n=1:1 m:n=10:0
40 (1.0) 46(1.2) 71(1.8) 12(30) 24(61)
60 (1.5) 71(1.8) 107(2.7) 18(46) 36(91)
70 (1.8) 83(2.1) 126(3.2) 21(53) 42(107)
80 (2.0) 95(2.4) 144(3.7) 24(61) 48(122)
100 (2.5) 120(3.0) 181(4.6) 30(76) 60(152)
120 (3.0) 144(3.7) 217(5.5) 36(91) 72(183)
150 (3.8) 181(4.6) 272(6.9) 45(114) 90(229)
200 (5.1) 243(6.2) 364(9.2) 60(152) 120(305)
250 (6.4) 304(7.7) 455(11.6) 75(191) 150(381)
300 (7.6) 366(9.3) 547(13.9) 90(229) 180(457)
350 (8.9) 427(10.9) 638(16.2) 105(267)210(533)
400 (10.2) 489(12.4) 730(18.5) 120(305)240(610)
500 (12.7) 612(15.5) 913(23.2) 150(381)300(762)
Screen Size
[inch (m)] a[inch (m)] b[inch (cm)]
Min. Max. m:n=1:1 m:n=10:0
40 (1.0) 50(1.3) 77(2.0) 10(25) 23(58)
60 (1.5) 77(2.0) 117(3.0) 15(37) 34(87)
70 (1.8) 91(2.3) 137(3.5) 17(44) 40(102)
80 (2.0) 104(2.6) 157(4.0) 20(50) 46(116)
100 (2.5) 131(3.3) 197(5.0) 25(62) 57(145)
120 (3.0) 158(4.0) 237(6.0) 29(75) 69(174)
150 (3.8) 198(5.0) 297(7.5) 37(93) 86(218)
200 (5.1) 265(6.7) 396(10.1) 49(125) 114(291)
250 (6.4) 332(8.4) 496(12.6) 61(156) 143(363)
300 (7.6) 399(10.1) 596(15.1) 74(187) 172(436)
350 (8.9) 466(11.8) 696(17.7) 86(218) 200(508)
400 (10.2) 533(13.5) 795(20.2) 98(249) 229(581)
450 (11.4) 600(15.2) 895(22.7) 110(280)257(654)
bm
a
n
Lens center
Screen
Side View
bm
a
n
Lens center
Screen
Side View
01CP-X1200-ENG-OG-三校03.12.51:10PMページ6

INTER
INPUT
M1-D
RGB
BNG
S-VIDEO
STANDBY/ON
TEMP
VIDEO
COMPONENT
LAMP
KEYSTONE
SEARCH
RESET
MENU
FOCUS
LENSSHIFT ZOOM
7
Setting Up (continued)
Setting Up (continued)
Adjusting The Projector's Elevator
Using The Lens Shift Buttons
• Generally, better quality of a picture is available when the lens shift is set
to the center.
NOTE
You can use the elevator feet to make adjustments if the surface on which you need to set
the projector is uneven or if you otherwise need to adjust the angle of projection. The
adjustment range of the elevator feet is 0 to 9 degrees.
WARNING • Do not touch about the lens and ventilation openings during use or
immediately after use to prevent a burn.
CAUTION • To prevent damaging the projector and injuring yourself, always
hold the projector whenever using the elevator buttons to adjust the elevator feet.
Press and hold in the elevator buttons.
Raise or lower the projector to the desired height and
then release the elevator buttons.
When you release the elevator buttons, the elevator
feet will lock into position.
As necessary, you can also finely adjust the height of
the projector by twisting the elevator feet by hand.
Elevator buttons
Elevator feet
The lens of this projector can be shifted
vertically. When you want to finely adjust the
picture position, use the LENS SHIFT buttons
of the projector.
10:0
1:1
1
2
3
STANDBY/ON VIDEO
LASER INDICATOR
RGB
BLANK ASPECT LASER
LENS SHIFT
+
–––
++
FOCUS ZOOM
Projector
LENS SHIFT buttons
Remote control
LENS SHIFT
01CP-X1200-ENG-OG-三校03.12.51:10PMページ7

8
Setting Up (continued)
Setting Up (continued)
Connecting Your Devices
WARNING • Whenever attempting to connect other devices to the projector, read
thoroughly the "User's Manual - Safety Guide", this manual and the manual of each
device to be connected. Incorrect connecting could result in fire or electrical shock.
CAUTION • TURN OFF ALL DEVICES prior to connecting them to the projector.
Attempting to connect a live device to the projector may generate extremely loud
noises or other abnormalities that may result in malfunction and/or damage to the
device and/or projector.
ATTENTION • Make sure that you connect devices to the correct port. Incorrect
connection may result in malfunction and/or damage to the device and/or projector.
Refer to the section “Technical” of this manual for the pin assignment of connectors and
RS-232C communication data.
• Some cables have to be used with core set. Use the accessory cable or a
designated-type cable for the connection. For cables that have a core only at one
end, connect the core to the projector.
• Secure the screws on the connectors and tighten.
• Whenever attempting to connect a laptop computer to the projector, be sure to
activate the laptop’s RGB external image output (set the laptop to CRT display or to
simultaneous LCD and CRT display). For details on how this is done, please refer to
the instruction manual of the corresponding laptop computer.
• Some computers may have multiple display screen modes. Use of some of
these modes may not be compatible with this projector.
• For some RGB input modes, the optional Mac adapter is necessary.
• When the image resolution is changed on a computer, depending on an input,
automatic adjust function may take some time and may not be completed. In this
case, you may not be able to see a check box to select “Yes/No” for the new
resolution on Windows. Then the resolution will go back to the original. It might be
recommended to use other CRT or TFT monitors to change the resolution.
NOTE
Plug-and-Play Capability
• Plug-and-Play is a system incorporated in the computer, its operating system and
peripheral equipment (i.e. display devices).
• This projector is compatible with VESA DDC 1/2B. Plug-and-Play can be achieved by
connecting this projector to computers that are VESA DDC (display data channel)
compatible.
• Please take advantage of this function by connecting the accessory RGB cable to the
RGB port (DDC 1/2B compatible). Plug-and-Play may not work properly if any other
type of connection is attempted.
• Please use the standard drivers in your computer as this projector is a Plug-and-Play
monitor.
NOTE
01CP-X1200-ENG-OG-三校03.12.51:10PMページ8

9
Setting Up (continued)
Setting Up (continued)
Please refer to the following (for example) for connecting your devices. See the rear of the projector.
You can see the ports.
INTER
INPUT
M1-D
RGB
BNG
S-VIDEO
STANDBY/ON
TEMP
VIDEO
COMPONENT
LAMP
KEYSTONE
SEARCH
RESET
MENU
FOCUS
LENSSHIFTZOOM
VIDEO
R-AUDIOIN-LS-VIDEO
BNC
RGB
AUDIOIN1
AUDIOIN2 RGB OUT
AUDIOOUT
REMOTECONTROL
R/C
R
/P
R
G/Y B/C
B
/P
B
HV
Y
CONTROL NETWORK
CR/PR Ca/Pa
R/CR/PRG/Y B/CB/PBH V
Examples of connection with a computer
VIDEOR-AUDIO IN-L S-VIDEO
BNC
RGB
AUDIO IN1
AUDIO IN2 RGB OUT
AUDIO OUT
REMOTE CONTROL
R/CR/PRG/Y B/CB/PBHV
Y
CONTROL NETWORK
CR/PR Ca/Pa
A
E
F G
REMOTE CONTROL
VIDEOR-AUDIO IN-L S-VIDEO
BNC
RGB
AUDIO IN1
AUDIO IN2 RGB OUT
AUDIO OUT
G/Y H V
Y
CONTROL NETWORK
CR/PR Ca/Pa
R/CR/PRB/CB/PB
B
D
REMOTE CONTROL
VIDEOR-AUDIO IN-L S-VIDEO
BNC
RGB
AUDIO IN1
AUDIO IN2 RGB OUT
AUDIO OUT
R/CR/PRG/Y B/CB/PBHV
Y
CONTROL NETWORK
CR/PR Ca/Pa
C
D
Computer Projector
RGB out RGB cable RGB
Audio out Stereo Mini cable AUDIO IN 2
RS-232C port RS-232C cable CONTROL
Network port CAT-5 cable NETWORK
■If using a M1-D input (to mouse control)
■If using a BNC input
DVI port M1-D
USB port M1-D cable
Audio out Stereo Mini cable AUDIO IN 1
BNC cable
RGB out
R/CR/PR
G/Y
B/CB/PB
H
V
C
D
B
G
F
E
A
D
Audio out Stereo Mini cable AUDIO IN 1
01CP-X1200-ENG-OG-三校03.12.51:10PMページ9

10
Setting Up (continued)
Setting Up (continued)
VIDEOR-AUDIO IN-L S-VIDEO
BNC
RGB
AUDIO IN1
AUDIO IN2 RGB OUT
AUDIO OUT
R/CR/PRG/Y B/CB/PBHV
Y
CONTROL NETWORK
CR/PR Ca/Pa
REMOTE CONTROL
H I
REMOTE CONTROL
VIDEOR-AUDIO IN-L S-VIDEO
BNC
RGB
AUDIO IN1
AUDIO IN2 RGB OUT
AUDIO OUT
R/CR/PRG/Y B/CB/PBHV
Y
CONTROL NETWORK
CR/PR Ca/Pa
H J
REMOTE CONTROL
VIDEOR-AUDIO IN-L S-VIDEO
BNC
RGB
AUDIO IN1
AUDIO IN2 RGB OUT
AUDIO OUT
R/CR/PRG/Y B/CB/PBHV
Y
CONTROL NETWORK
CR/PR Ca/Pa
H
K
VCR/DVD Player Projector
■If using a s-video signal
■If using a component signal
R-AUDIO IN-L VIDEO
R-AUDIO IN-L VIDEO
COMPONENT
S-video out S-video cable S -VIDEO
J
CR/PR
CB/PB
Y
CR/PRout
CB/PBout
Y out
R-AUDIO IN-L VIDEO
R-AUDIO IN
AUDIO IN-L
Audio out (R)
Audio out (L)
Audio out (R)
Audio out (L)
R-AUDIO IN
AUDIO IN-L
R-AUDIO IN
AUDIO IN-L
VIDEO IN
Audio out (R)
Audio out (L)
Video out
H
H
K
H
REMOTE CONTROL
VIDEOR-AUDIO IN-L S-VIDEO
BNC
RGB
AUDIO IN1
AUDIO IN2 RGB OUT
AUDIO OUT
R/CR/PRG/Y B/CB/PBHV
Y
CONTROL NETWORK
CR/PR Ca/Pa
HI
K
■If using a SCART RGB input
COMPONENT
R-AUDIO IN-L VIDEO
R (CR/PR)
B (CB/PB)
G (Y)
R-AUDIO IN
AUDIO IN-L
VIDEO IN
SCART
RGB out
SCART
adapter
K
I
H
I
Examples of connection with a VCR/DVD Player
01CP-X1200-ENG-OG-三校03.12.51:10PMページ10

INTER
INPUT
M1-D
RGB
BNG
S-VIDEO
STANDBY/ON
TEMP
VIDEO
COMPONENT
LAMP
KEYSTONE
SEARCH
RESET
MENU
FOCUS
LENS SHIFTZOOM
VIDEO
R-AUDIOIN-L S-VIDEO
BNC
RGB
AUDIOIN1
AUDIOIN2 RGB OUT
AUDIOOUT
REMOTECONTROL
R/C
R
/P
R
G/Y B/C
B
/P
B
HV
Y
CONTROL NETWORK
CR/PR Ca/Pa
11
Setting Up (continued)
Setting Up (continued)
REMOTE CONTROL
VIDEOR-AUDIO IN-L S-VIDEO
BNC
RGB
AUDIO IN1
AUDIO IN2 RGB OUT
AUDIO OUT
R/CR/PRG/Y B/CB/PBHV
Y
CONTROL NETWORK
CR/PR Ca/Pa
L
REMOTE CONTROL
VIDEOR-AUDIO IN-L S-VIDEO
BNC
RGB
AUDIO IN1
AUDIO IN2 RGB OUT
AUDIO OUT
R/CR/PRG/Y B/CB/PBHV
Y
CONTROL NETWORK
CR/PR Ca/Pa
M
Monitor Projector
RGB in RGB cable RGB OUT
Connecting to a monitor
Speaker Projector
Connecting to a speaker (with amplifier)
Audio in Stereo Mini cable AUDIO OUT
M
L
WARNING • Use extra caution when connecting the power cord as incorrect or faulty
connections may result in fire and/or electrical shock. Please adhere to the “User’s manual –
Safety Guide” and the following.
• Only plug the power cord into outlets rated for use with the power cord’s specified voltage range.
• Only use the power cord that came with the projector. If it is damaged, contact your dealer to
newly get correct one.
• Never modify the power cord. Never attempt to defeat the ground connection of the three-pronged plug.
•
Make sure that you firmly connect the power cord to the projector and wall outlet.
1Connect the connector of the power cord to
the AC inlet of the projector.
2Firmly plug the power cord’s plug into the
outlet. AC Inlet
Connector Plug
Outlet
Connecting The Power Supply
01CP-X1200-ENG-OG-三校03.12.51:10PMページ11

12
Remote Control
Remote Control
About The Laser Pointer
Putting Batteries
WARNING • The laser pointer of the remote control is used in place of a finger or
rod. Never look directly into the laser beam outlet or point the laser beam at other
people. The laser beam can cause vision problems.
CAUTION •Use of controls or adjustments or performance of procedures other
than those specified herein may result in hazardous radiation exposure.
STANDBY/ON
VIDEO
LASER INDICATOR
ESC MENU
POSITION
RESET AUTO
KEYSTONE
1 2 3
ID CHANGE
SEARCH
ON
OFF
FREEZE MUTE
MAGNFY
PinP
VOLUME
RGB
BLANK
PREVIOUS
NEXT
ASPECT
ENTER
LASER
LENS SHIFT
+
–––
++
FOCUS ZOOM
JQA
MADE IN CHINA
P S
C
レーザー光をのぞき込まないこと。
レーザー光を人に向けないこと。
子供に使わせないこと。
製造者：INTERLINK ELECTRONICS
This remote control has a laser pointer in place of a finger or rod. The laser beam works and the
LASER INDICATOR lights while the LASER button is pressed.
CAUTION • About the battery
• Keep a battery away from children and pets.
• Use only the battery specified: two AA batteries.
• Do not mix new battery with used one.
• Make sure the plus and minus terminals are correctly aligned when loading the
battery (as indicated in the remote control).
• Dispose of batteries in accord with environmental laws.
1Remove the battery
cover.
Slide back and
remove the battery
cover in the direction
of the arrow.
Insert the batteries.
Align and insert the
two AA batteries
according to their plus
minus terminals (as
indicated in the remote
control).
Close the battery
cover.
Replace the battery
cover in the direction
of the arrow and snap
it back into place.
23
AVOID EXPOSURE-LASER
RADIATION IS EMITTED
FROM THIS APERTURE
CAUTION
WAVE LENGTH: 640-660nm
MAX OUTPUT: 1mW
CLASS 2 LASER PRODUCT
Comples with 21 CFR, 1040.10 AND 1040.11
IEO60825-1:1993+A1:1997+A2:2001
LASER-STRAHLING
NICHT IN DEN STRAHL BLICKEN
LASER KLASSE 2
WAVE LENGTH:640-660nm MAX OUTPUT:1mW
レーザー光
ビームをのぞきこまないこと
クラス2レーザー製品 JISC6802（1998）
最大出力：1.0mW 波長：640−660nm
MODEL:H-IRC4
LASER RADIATION
DO NOT STARE INTO BEAM
MANUFACTURER: B
MANUFACTURED
JANUARY,2003
INTERLINK K.K.
1-10-7 HIGASHIKANDA CHIYODA-KU,TOKYO,JAPAN
101-0031 MADE IN CHINA
01CP-X1200-ENG-OG-三校03.12.51:10PMページ12

STANDBY/ON VIDEO
LASER INDICATOR
ESC MENU
POSITION RESET AUTO
KEYSTONE
1 2 3
ID CHANGE
SEARCH
ON
OFF
FREEZE MUTE
MAGNFY PinP VOLUME
RGB
BLANK
PREVIOUS NEXT
ASPECT
ENTER
LASER
LENS SHIFT
+
–––
++
FOCUS ZOOM
13
Remote Control (continued)
Remote Control (continued)
Operating The Remote Control
CAUTION • Do not disassemble the remote control.
• Do not place the remote control near the projector’s lens, fan, or vents.
• Do not drop or otherwise expose the remote control to physical impact.
•
Do not get the remote control wet or place it on wet objects on it. Doing so may result in malfunction.
• Remove the batteries from the remote control and store them in a safe place if you
won't be using the remote control for an extended period.
• Replace the batteries whenever the remote control starts to malfunction.
•
When strong light, such as direct sunlight or light from an extremely close range (such as from an
inverter fluorescent lamp), hits the projector's remote sensor, the remote control may cease to function.
Adjust the direction of the projector to keep light from directly hitting the projector's remote sensor.
NOTE
• The remote control works with the
projector’s remote sensor.
• Front remote sensor is 3 meters with a 60
degree range (30 degrees to the left and
right of a remote sensor).
Rear remote sensor is 3 meters with a 40
degree range (20 degrees to the left and
right of a remote sensor).
• Also a remote signal reflected in the screen etc.
may be available. If it is difficult to send a remote signal to the sensor directly, please try.
• Since the remote control uses infrared light to send signals to the projector (Class1 LED), be sure to use the
remote control in an area free from obstacles that could block the remote control’s output signal to the projector.
memo You can use the remote control as a wired remote control, by connecting the REMOTE CONTROL
ports of the main unit and remote control via an audio cable (3.5 dia. stereo mini cable with plugs).
Set the ID number to the projector beforehand,
referring to the item “IR REMOTE ID” of the section
“OPTION Menu”.
memo When the ALL is selected to the item “IR
REMOTE ID” of the OPTION menu, the projector is
controlled by a remote control irrespective of the
position of the ID CHAGE switch.
Slide the knob of the switch into the position of the
ID number of the projector you want to control.
Using The Remote ID Feature
This is the function to properly use when you use two or
three same type projectors at the same time. This function
should be used combining a setup of a projector.
ID CHANGE
switch
INTER
INPUT
M1-D
RGB
BNG
S-VIDEO
STANDBY/ON
TEMP
VIDEO
COMPONENT
LAMP
KEYSTONE
SEARCH
RESET
MENU
FOCUS
LENSSHIFTZOOM
INTER
INPUT
M1-D
RGB
BNG
S-VIDEO
STANDBY/ON
TEMP
VIDEO
COMPONENT
LAMP
KEYSTONE
SEARCH
RESET
MENU
FOCUS
LENSSHIFTZOOM
VIDEO
R-AUDIOIN-L S-VIDEO
BNC
RGB
AUDIOIN1
AUDIOIN2RGBOUT
AUDIOOUT
REMOTECONTROL
R/C
R
/P
R
G/Y B/C
B
/P
B
HV
Y
CONTROLNETWORK
CR/PRCa/Pa
approximately
3 meters
30 degrees
30 degrees
approximately
3 meters
20 degrees
20 degrees
1
2
01CP-X1200-ENG-OG-三校03.12.51:10PMページ13

STANDBY/ON VIDEO
LASER INDICATOR
ESC MENU
POSITION RESET AUTO
KEYSTONE
1 2 3
ID CHANGE
SEARCH
ON
OFF
FREEZE MUTE
MAGNFY PinP VOLUME
RGB
BLANK
PREVIOUS NEXT
ASPECT
ENTER
LASER
LENS SHIFT
+
–––
++
FOCUS ZOOM
14
Remote Control (continued)
Remote Control (continued)
Using The Mouse/Keyboard Control Function
CAUTION • Before connecting, read the manuals of the device you will connect.
Mistaken use of the mouse/keyboard control could damage your equipment.
• Only connect to a PC.
• Do not unplug the connector cables while the computer is operating.
Using the USB control feature, you can use the remote control as a simplified mouse or
keyboard of the computer.
Connect the M1-D port of the projector to the computer via the M1-D cable. Then
functions illustrated below will be enabled.
memo The USB control can be used with
Windows 95 OSR 2.1 or higher. It may not be
possible to use the remote control, depending
on the computer’s configurations and mouse
drivers.
memo The function can be used only for the
functions illustrated on the right.
memo The projector would be enumerated as a
mouse and a keyboard of HID (Human
Interface Device) class devices, after
connecting cable.
Mouse move pointer
Keyboard
Arrow keys / / /
Mouse right button
Keyboard ESC key
(Front) (Rear)
Mouse left button
01CP-X1200-ENG-OG-三校03.12.51:10PMページ14

STANDBY/ON VIDEO
LASER INDICATOR
RGB
SC S
LENS SHIFT
+
–––
++
FOCUS ZOOM
INTER
INPUT
M1-D
RGB
BNG
S-VIDEO
STANDBY/ON
TEMP
VIDEO
COMPONENT
LAMP
KEYSTONE
SEARCH
RESET
MENU
FOCUS
LENSSHIFT ZOOM
VIDEO
R-AUDIOIN-LS-VIDEO
BNC
RGB
AUDIOIN1
AUDIOIN2RGBOUT
AUDIOOUT
REMOTECONTROL
R/C
R
/P
R
G/Y B/C
B
/P
B
HV
Y
CONTROL NETWORK
CR/PR Ca/Pa
INTER
INPUT
M1-D
RGB
BNG
S-VIDEO
STANDBY/ON
TEMP
VIDEO
COMPONENT
LAMP
KEYSTONE
SEARCH
RESET
MENU
FOCUS
LENSSHIFTZOOM
VIDEO
R-AUDIOIN-LS-VIDEO
BNC
RGB
AUDIOIN1
AUDIOIN2 RGB OUT
AUDIOOUT
REMOTECONTROL
R/C
R
/P
R
G/Y B/C
B
/P
B
HV
Y
CONTROL NETWORK
CR/PR Ca/Pa
STANDBY/ON VIDEO
LASER INDICATOR
RGB
BLANK ASPECT LASER
LENS SHIFT
+
–––
++
FOCUS ZOOM
INTER
INPUT
M1-D
RGB
BNG
S-VIDEO
STANDBY/ON
TEMP
VIDEO
COMPONENT
LAMP
KEYSTONE
SEARCH
RESET
MENU
FOCUS
LENSSHIFTZOOM
VIDEO
R-AUDIOIN-LS-VIDEO
BNC
RGB
AUDIOIN1
AUDIOIN2RGBOUT
AUDIOOUT
REMOTECONTROL
R/C
R
/P
R
G/YB/C
B
/P
B
HV
Y
CONTROL NETWORK
CR/PRCa/Pa
15
Tur ning On The Power
WARNING • When the power is ON, a strong light is emitted. Do not look
into the lens or vents of the projector.
• Turn the power on/off in right order. Please power on the projector before
the connected devices. Power off the projector after the connected devices.
NOTE
Power ON/OFF
Power ON/OFF
Remove the lens cap.
2
Set the power switch to [ | ] (ON).
The STANDBY/ON indicator will light to solid orange.
STANDBY/ON
STANDBY/ON button / indicator
LENS SHIFT
buttons
Power switch (ON position)
STANDBY/ON
button
STANDBY/ON
3Press the STANDBY/ON button.
The projector lamp will light up and the
STANDBY/ON indicator will begin blinking green.
When the power is completely on, the indicator
will stop blinking and light green.
4Use the LENS SHIFT buttons to shift the
picture upward or downward.
5Select an input signal according to the
section “Selecting An Input Signal” of the
following page.
LENS SHIFT
Power switch (OFF position)
1
Press the STANDBY/ON button.
The message “Power off?” will appear on
the screen for approximately 5 seconds.
Attached the lens cap.
2
Press the STANDBY/ON button again while
“Power off?” the message is visible.
The projector lamp will go off, and the
STANDBY/ON indicator will begin blanking orange.
Then the STANDBY/ON indicator will stop blinking
and light to solid orange when the lamp cooling is
complete.
3Switch the power switch to [O] (OFF).
The STANDBY/ON indicator will go off.
STANDBY/ON
button
STANDBY/ON
STANDBY/ON
STANDBY/ON button / indicator
Tur ning Off The Power
STANDBY/ON VIDEO
LASER INDICATOR
RGB
BLANK ASPECT LASER
LENS SHIFT
+
–––
++
FOCUS ZOOM
1
4
01CP-X1200-ENG-OG-三校03.12.51:10PMページ15

INTER
INPUT
M1-D
RGB
BNG
S-VIDEO
STANDBY/ON
TEMP
VIDEO
COMPONENT
LAMP
KEYSTONE
SEARCH
RESET
MENU
FOCUS
LENSSHIFTZOOM
VIDEO
R-AUDIOIN-LS-VIDEO
BNC
RGB
AUDIOIN1
AUDIOIN2RGBOUT
AUDIOOUT
REMOTECONTROL
R/C
R
/P
R
G/Y B/C
B
/P
B
HV
Y
CONTROL NETWORK
CR/PR Ca/Pa
STANDBY/ON VIDEO
LASER INDICATOR
ESC MENU
POSITION RESET AUTO
KEYSTONE
1 2 3
ID CHANGE
SEARCH
ON
OFF
FREEZE MUTE
MAGNFY PinP VOLUME
RGB
BLANK
PREVIOUS NEXT
ASPECT
ENTER
LASER
LENS SHIFT
+
–––
++
FOCUS ZOOM
16
Operating
Operating
Selecting An Input Signal
Select an input signal.
Turn the INPUT dial of the projector.
Turning the dial cycles through the input ports as
shown below. Select the signal you wish to project.
M1-D RGB BNC
S-VIDEO COMPONEN
T
VIDEO
M1-D RGB BNC
S-VIDEO COMPONEN
T
VIDEO
INTER
INPUT
M1-D
RGB
BNG
S-VIDEO
STANDBY/ON
TEMP
VIDEO
COMPONENT
LAMP
KEYSTONE
SEARCH
RESET
MENU
FOCUS
LENSSHIFT ZOOM
VIDEO
R-AUDIOIN-LS-VIDEO
BNC
RGB
AUDIOIN1
AUDIOIN2RGBOUT
AUDIOOUT
REMOTECONTROL
R/C
R
/P
R
G/Y B/C
B
/P
B
HV
Y
CONTROL NETWORK
CR/PRCa/Pa
ENTER
INPUT
M1-D
RGB
BNC
S-VIDEO
VIDEO
COMPONENT
SEARCH
RESET
MENU
■Using the INPUT dial
Press the SEARCH button of the projector or the
remote control.
Pressing the button automatically cycles through input
ports and displays the picture of retrieved signal.
memo If no signal is found or the projector is unstable to
find an input signal at any of its ports, it will turn to the state
it was in prior to the search.
■Using SEARCH button
Press the RGB button of the remote control.
Pressing the button toggles between the RGB ports
as shown below Select the signal you wish to project.
Press the VIDEO button of the remote control.
Pressing the button toggles between the VIDEO ports
as shown below Select the signal you wish to project.
M1-D RGB BN
C
S-VIDEO VIDEOCOMPONENT
INPUT dial
SEARCH button
VIDEO button
RGB button
SEARCH button
ZOOM
buttons FOCUS buttons
ZOOM
FOCUS
Use the FOCUS buttons to adjust the focus.
Use the ZOOM buttons to adjust the screen size.
■Using RGB button
■Using VIDEO button
2
3
1
01CP-X1200-ENG-OG-三校03.12.51:10PMページ16

STANDBY/ON VIDEO
LASER INDICATOR
ESC MENU
POSITION RESET AUTO
KEYSTONE
1 2 3
ID CHANGE
SEARCH
ON
OFF
FREEZE MUTE
MAGNFY PinP VOLUME
RGB
BLANK
PREVIOUS NEXT
ASPECT
ENTER
LASER
LENS SHIFT
+
–––
++
FOCUS ZOOM
STANDBY/ON VIDEO
LASER INDICATOR
ESC MENU
POSITION RESET AUTO
KEYSTONE
1 2 3
ID CHANGE
SEARCH
ON
OFF
FREEZE MUTE
MAGNFY PinP VOLUME
RGB
BLANK
PREVIOUS NEXT
ASPECT
ENTER
LASER
LENS SHIFT
+
–––
++
FOCUS ZOOM
17
Operating (continued)
Operating (continued)
The Vertical position (V POSITION), the horizontal
position (H POSITION), the clock phase (H PHASE)
and horizontal size (H SIZE) will be automatically
adjusted.
memo Make sure that the application window is set to
its maximum size prior to attempting to use this feature.
Dark pictures may still be incorrectly adjusted. Use a
bright screen when adjusting.
The signal type mode best suited for the respective
input signal will be selected automatically.
memo This function is available only when the AUTO is
selected to the item VIDEO of the INPUT menu. For a
component video signal, the signal type is identified
automatically independently of this function.
Selecting The Aspect Ratio
Press the Aspect button to toggle between the
modes for aspect ratio.
ASPECT button
AUTO button
4:3 16:9 NORMAL
Using The Automatic Adjustment Feature
Press the AUTO button.
memo NORMAL keeps the original aspect ratio of the
input signal.
memo At a HDTV signal of 1125i or 750p, only 16:9 can
be selected.
memo The automatic adjustment operation requires approximately 10 seconds. Also,
please note that it may not function correctly with some input.
4:3 16:
9
4:3 16:9 SMALL
■At a M1-D signal
■At a RGB signal (not M1-D)
■At a video signal
■At a RGB signal
■At a video signal
1
1
01CP-X1200-ENG-OG-三校03.12.51:10PMページ17

STANDBY/ON VIDEO
LASER INDICATOR
ESC MENU
POSITION RESET AUTO
KEYSTONE
1 2 3
ID CHANGE
SEARCH
ON
OFF
FREEZE MUTE
MAGNFY PinP VOLUME
RGB
BLANK
PREVIOUS NEXT
ASPECT
ENTER
LASER
LENS SHIFT
+
–––
++
FOCUS ZOOM
STANDBY/ON VIDEO
LASER INDICATOR
ESC MENU
POSITION RESET AUTO
KEYSTONE
1 2 3
ID CHANGE
SEARCH
ON
OFF
FREEZE MUTE
MAGNFY PinP VOLUME
RGB
BLANK
PREVIOUS NEXT
ASPECT
ENTER
LASER
LENS SHIFT
+
–––
++
FOCUS ZOOM
18
Operating (continued)
Operating (continued)
Adjusting The Picture Position
Press the POSITION button.
As illustrated on the right, a
dialog will appear on the
screen to aid you in adjusting
the position.
POSITION
POSITION
button
Cursor
buttons
RESET
button
KEYSTONE
button
2
1
Use the cursor buttons / / / to adjust the
position.
memo When you want to initialize the position, press
the RESET button during adjustment.
3
1
Press the POSITION button again to close the
dialog and complete this operation.
memo Even if you don't do anything, the dialog will
automatically disappear after a few seconds.
2Use the cursor buttons / to
select the direction of distortion to
correct ( or ).
4Press the KEYSTONE button again to close the
dialog and complete this operation.
memo Even if you don't do anything, the dialog will
automatically disappear after a few seconds.
memo When this adjustment is excessive, certain
degradation may appear on the picture. Also,
please note that it may not function correctly with
some input.
3Use the cursor buttons / to correct the
distortion.
Correcting The Keystone Distortion
Press the KEYSTONE button.
As illustrated on the right, a dialog
will appear on the screen to aid you
in correcting the keystone
distortion.
0
KEYSTONE
+0 +
memo This function is available only for RGB signals.
Cursor
buttons
01CP-X1200-ENG-OG-三校03.12.51:10PMページ18

STANDBY/ON VIDEO
LASER INDICATOR
ESC MENU
POSITION RESET AUTO
KEYSTONE
1 2 3
ID CHANGE
SEARCH
ON
OFF
FREEZE MUTE
MAGNFY PinP VOLUME
RGB
BLANK
PREVIOUS NEXT
ASPECT
ENTER
LASER
LENS SHIFT
+
–––
++
FOCUS ZOOM
STANDBY/ON VIDEO
LASER INDICATOR
ESC MENU
POSITION RESET AUTO
KEYSTONE
1 2 3
ID CHANGE
SEARCH
ON
OFF
FREEZE MUTE
MAGNFY PinP VOLUME
RGB
BLANK
PREVIOUS NEXT
ASPECT
ENTER
LASER
LENS SHIFT
+
–––
++
FOCUS ZOOM
STANDBY/ON VIDEO
LASER INDICATOR
ESC MENU
POSITION RESET AUTO
KEYSTONE
1 2 3
ID CHANGE
SEARCH
ON
OFF
FREEZE MUTE
MAGNFY PinP VOLUME
RGB
BLANK
PREVIOUS NEXT
ASPECT
ENTER
LASER
LENS SHIFT
+
–––
++
FOCUS ZOOM
19
Operating (continued)
Operating (continued)
Adjusting The Volume
Muting The Sound
Temporarily Blanking The Screen
Press the VOLUME button.
As illustrated on the right, a dialog
will appear on the screen to aid you
in adjusting the volume.
Use the cursor buttons / to
adjust the volume.
Press the VOLUME button again to close the
dialog and complete this operation.
memo Even if you don't do anything, the dialog will
automatically disappear after a few seconds.
Press the MUTE button.
As illustrated on the right, a dialog
will appear on the screen indicating
that you have muted the sound.
Press the MUTE or VOLUME
button to restore the sound.
memo Even if you don't do anything,
the dialog will automatically
disappear after a few seconds.
Press the BLANK button.
The input signal screen will shut off, and a BLANK
screen will appear.
memo You can set the BLANK screen using the
menu. Please refer to the item “BLANK” of the
table of the section “SCREEN Menu”.
Press the BLANK button again to remove the
blank screen, and return to the input signal screen.
16
VOLUME
16
VOLUME
Cursor
buttons
VOLUME
button
MUTE
button
BLANK
button
1
2
3
1
2
1
2
01CP-X1200-ENG-OG-三校03.12.51:10PMページ19
