B+K precision PVS60085 User manual

Model: PVS10005, PVS60085, PVS60085MR
High Power Programmable DC
Power Supply
USER MANUAL

i
Safety Summary
The following safety precautions apply to both operating and
maintenance personnel and must be followed during all phases of
operation, service, and repair of this instrument.
Before applying power to this instrument:
Read and understand the safety and operational information in
this manual.
Apply all the listed safety precautions.
Verify that the voltage selector at the line power cord input is
set to the correct line voltage. Operating the instrument at an
incorrect line voltage will void the warranty.
Make all connections to the instrument before applying power.
Do not operate the instrument in ways not specified by this
manual or by B&K Precision.
Failure to comply with these precautions or with warnings elsewhere in
this manual violates the safety standards of design, manufacture, and
intended use of the instrument. B&K Precision assumes no liability for a
customer’s failure to comply with these requirements.
Category rating
The IEC 61010 standard defines safety category ratings that specify the
amount of electrical energy available and the voltage impulses that may
occur on electrical conductors associated with these category ratings.
The category rating is a Roman numeral of I, II, III, or IV. This rating is
also accompanied by a maximum voltage of the circuit to be tested,
which defines the voltage impulses expected and required insulation
clearances. These categories are:

ii
Category I (CAT I): Measurement instruments whose measurement
inputs are not intended to be connected to the mains supply. The
voltages in the environment are typically derived from a limited-energy
transformer or a battery.
Category II (CAT II): Measurement instruments whose measurement
inputs are meant to be connected to the mains supply at a standard wall
outlet or similar sources. Example measurement environments are
portable tools and household appliances.
Category III (CAT III): Measurement instruments whose measurement
inputs are meant to be connected to the mains installation of a building.
Examples are measurements inside a building's circuit breaker panel or
the wiring of permanently-installed motors.
Category IV (CAT IV): Measurement instruments whose measurement
inputs are meant to be connected to the primary power entering a
building or other outdoor wiring.
Do not use this instrument in an electrical environment with a higher
category rating than what is specified in this manual for this instrument.
You must ensure that each accessory you use with this instrument has a
category rating equal to or higher than the instrument's category rating
to maintain the instrument's category rating. Failure to do so will lower
the category rating of the measuring system.
Electrical Power
This instrument is intended to be powered from a CATEGORY II mains
power environment. The mains power should be 120 V RMS or 240 V
RMS. Use only the power cord supplied with the instrument and

iii
ensure it is appropriate for your country of use.
Ground the Instrument
To minimize shock hazard, the instrument chassis and cabinet must be
connected to an electrical safety ground. This instrument is grounded
through the ground conductor of the supplied, three-conductor AC line
power cable. The power cable must be plugged into an approved three-
conductor electrical outlet. The power jack and mating plug of the
power cable meet IEC safety standards.
Do not alter or defeat the ground connection. Without the safety
ground connection, all accessible conductive parts (including control
knobs) may provide an electric shock. Failure to use a properly-
grounded approved outlet and the recommended three-conductor AC
line power cable may result in injury or death.
Unless otherwise stated, a ground connection on the instrument's front
or rear panel is for a reference of potential only and is not to be used as
a safety ground.
Do not operate in an explosive or flammable atmosphere
Do not operate the instrument in the presence of flammable gases or
vapors, fumes, or finely-divided particulates.
The instrument is designed to be used in office-type indoor
environments. Do not operate the instrument

iv
In the presence of noxious, corrosive, or flammable fumes,
gases, vapors, chemicals, or finely-divided particulates.
In relative humidity conditions outside the instrument's
specifications.
In environments where there is a danger of any liquid being
spilled on the instrument or where any liquid can condense on
the instrument.
In air temperatures exceeding the specified operating
temperatures.
In atmospheric pressures outside the specified altitude limits or
where the surrounding gas is not air.
In environments with restricted cooling air flow, even if the air
temperatures are within specifications.
In direct sunlight.
This instrument is intended to be used in an indoor pollution degree 2
environment. The operating temperature range is 0 °C to 40 °C and the
operating humidity 90% relative humidity with no condensation
allowed.
Measurements made by this instrument may be outside specifications if
the instrument is used in non-office-type environments. Such
environments may include rapid temperature or humidity changes,
sunlight, vibration and/or mechanical shocks, acoustic noise, electrical
noise, strong electric fields, or strong magnetic fields.
Do not operate instrument if damaged
If the instrument is damaged, appears to be
damaged, or if any liquid, chemical, or other material gets on or inside
the instrument, remove the instrument's power cord, remove the

v
instrument from service, label it as not to be operated, and return the
instrument to B&K Precision for repair. Notify B&K Precision of the
nature of any contamination of the instrument.
Clean the instrument only as instructed
Do not clean the instrument, its switches, or its terminals with contact
cleaners, abrasives, lubricants, solvents, acids/bases, or other such
chemicals. Clean the instrument only with a clean dry lint-free cloth or
as instructed in this manual.
Not for critical applications
This instrument is not authorized for use in contact with the human
body or for use as a component in a life-support device or system.
Do not touch live circuits
Instrument covers must not be removed by operating personnel.
Component replacement and internal adjustments must be made by
qualified service-trained maintenance personnel who are aware of the
hazards involved when the instrument's covers and shields are
removed. Under certain conditions, even with the power cord removed,
dangerous voltages may exist when the covers are removed. To avoid
injuries, always disconnect the power cord from the instrument,
disconnect all other connections (for example, test leads, computer
interface cables, etc.), discharge all circuits, and verify there are no
hazardous voltages present on any conductors by measurements with a
properly-operating voltage-sensing device before touching any internal
parts. Verify the voltage-sensing device is working properly before and

vi
after making the measurements by testing with known-operating
voltage sources and test for both DC and AC voltages. Do not attempt
any service or adjustment unless another person capable of rendering
first aid and resuscitation is present.
Do not insert any object into an instrument's ventilation openings or
other openings.
Hazardous voltages may be present in unexpected locations in circuitry
being tested when a fault condition in the circuit exists.
Fuse replacement
Fuse replacement must be done by qualified service-trained
maintenance personnel who are aware of the instrument's fuse
requirements and safe replacement procedures. Disconnect the
instrument from the power line before replacing fuses. Replace fuses
only with new fuses of the fuse types, voltage ratings, and current
ratings specified in this manual or on the back of the instrument. Failure
to do so may damage the instrument, lead to a safety hazard, or cause a
fire. Failure to use the specified fuses will void the warranty.
Servicing
Do not substitute parts that are not approved by B&K Precision or
modify this instrument. Return the instrument to B&K Precision for
service and repair to ensure that safety and performance features are
maintained.
Cooling fans

vii
This instrument contains one or more cooling fans. For continued safe
operation of the instrument, the air inlet and exhaust openings for
these fans must not be blocked nor must accumulated dust or other
debris be allowed to reduce air flow. Maintain at least 25 mm clearance
around the sides of the instrument that contain air inlet and exhaust
ports. If mounted in a rack, position power devices in the rack above the
instrument to minimize instrument heating while rack mounted. Do not
continue to operate the instrument if you cannot verify the fan is
operating (note some fans may have intermittent duty cycles). Do not
insert any object into the fan's inlet or outlet.
Use correctly sized wires
To connect a load to the power supply, use a wire diameter large
enough to handle the maximum continuous output short-circuit current
of the power supply without the wire overheating.
For continued safe use of the instrument
Do not place heavy objects on the instrument.
Do not obstruct cooling air flow to the instrument.
Do not place a hot soldering iron on the instrument.
Do not pull the instrument with the power cord, connected
probe, or connected test lead.
Do not move the instrument when a probe is connected to a
circuit being tested.

viii
Compliance Statements
Disposal of Old Electrical & Electronic Equipment (Applicable in the
European
Union and other European countries with separate collection systems)
This product is subject to Directive 2002/96/EC
of the European Parliament and the Council of
the European Union on waste electrical and
electronic equipment (WEEE), and in
jurisdictions adopting that Directive, is marked
as being put on the market after August 13,
2005, and should not be disposed of as
unsorted municipal waste. Please utilize your
local WEEE collection facilities in the
disposition of this product and otherwise
observe all applicable requirements.

ix
CE Declaration of Conformity
This instrument meets the requirements of 2006/95/EC Low Voltage
Directive and 2004/108/EC Electromagnetic Compatibility Directive with
the following standards.
Low Voltage Directive
-EN61010-1: 2001
EMC Directive
-EN 61000-3-2: 2006
-EN 61000-3-3: 1995+A1: 2001+A2: 2005
-EN 61000-4-2 / -3 / -4 / -5 / -6 / -11
-EN 61326-1: 2006

x
Safety Symbols
Refer to the user manual for warning information
to avoid hazard or personal injury and prevent
damage to instrument.
Electric Shock hazard
On (Supply). This is the AC mains
connect/disconnect switch on the front of the
instrument.
Off (Supply). This is the AC mains
connect/disconnect switch on the front of the
instrument.
Direct current
Alternating current
Fuse Symbol
Chassis (earth ground) symbol
Ground terminal
Protective earth ground

xi
CAUTION indicates a hazardous situation which, if
not avoided, will result in minor or moderate injury
WARNING indicates a hazardous situation which, if
not avoided, could result in death or serious injury
DANGER indicates a hazardous situation which, if
not avoided, will result in death or serious injury.

xii
Table of Contents
Safety Summary................................................................... i
Compliance Statements......................................................................viii
Safety Symbols.......................................................................................x
1General Information ..................................................... 1
1.1 Product Overview....................................................................... 1
1.2 Package Contents....................................................................... 2
1.3 Product Dimensions................................................................... 3
1.4 Front Panel Overview................................................................. 4
Front Panel Description..................................................................... 4
1.5 Keypad Overview ....................................................................... 5
Keypad Description ........................................................................... 5
1.6 Rear Panel Overview .................................................................. 7
Rear Panel Description...................................................................... 7
1.7 Display Overview........................................................................ 8
Display Description ........................................................................... 8
2Getting Started ............................................................. 9
2.1 Input Power and Fuse Requirements......................................... 9
Input Power....................................................................................... 9
Fuse Replacement ........................................................................... 12
2.2 Rackmount Installation ............................................................ 12
2.3 Output Connections................................................................. 13

xiii
2.4 Preliminary Check .................................................................... 15
Warm-up Time ................................................................................ 15
Output Check .................................................................................. 16
Check Model and Firmware Version ............................................... 17
3Front Panel Operation ................................................ 19
3.1 Menu Options .......................................................................... 19
How to Access the Menu................................................................. 20
3.2 Configure Voltage/Current Output .......................................... 21
Setting Voltage................................................................................ 21
Setting Current................................................................................ 22
Remote Sense.................................................................................. 23
3.3 Voltage/Current Measurement................................................ 25
3.4 System Messages ..................................................................... 25
3.5 SYSTEM Menu .......................................................................... 27
Remote Communication Configuration .......................................... 27
Save/Recall Instrument Settings ..................................................... 27
Enable/Disable Key Sound .............................................................. 29
Restore Factory Default Settings..................................................... 30
Configure Power-On State .............................................................. 32
3.6 CONFIG Menu .......................................................................... 33
Output Limit Settings...................................................................... 33
Protection Settings.......................................................................... 35
External Analog Control.................................................................. 40
Parallel Operation........................................................................... 53

xiv
3.7 PV Simulation ........................................................................... 58
3.8 Program Function..................................................................... 61
Overview ......................................................................................... 61
Configure Program Parameters...................................................... 62
3.9 Timer Function ......................................................................... 65
3.10 Slew Rate Setting ..................................................................... 66
4Remote Operation ...................................................... 68
4.1 Interface Configuration ............................................................ 68
4.2 Parameter Definition................................................................ 79
4.3 Error/Event List ........................................................................ 79
4.4 SCPI Common Commands........................................................ 80
4.5 SCPI Common Subsystem......................................................... 81
4.6 Non-SCPI Remote Commands.................................................. 88
4.7 Multi-Unit Programming Commands....................................... 89
System control commands.............................................................. 89
Output control commands.............................................................. 89
Synchronous control commands..................................................... 90
Error List.......................................................................................... 91
Status Define................................................................................... 92
5Calibration.................................................................. 93
5.1 Voltage Calibration................................................................... 94
5.2 Current Calibration................................................................... 95
5.3 OVP Calibration ........................................................................ 97
5.4 OCP Calibration ........................................................................ 98

xv
5.5 External Voltage Programming Calibration.............................. 99
5.6 External Current Programming Calibration............................ 100
5.7 CC Calibration of External Voltage ......................................... 101
5.8 CC Calibration of External Current ......................................... 102
6Troubleshooting Guide ............................................. 104
General ......................................................................................... 104
Remote Control ............................................................................. 105
7Specifications............................................................ 106
SERVICE INFORMATION................................................... 109

1
1General Information
1.1 Product Overview
B&K Precision models PVS60085, PVS60085MR, and PVS10005 are high
voltage programmable DC power supplies with single outputs that offer
the maximum power output up to 5100 watts (0 - 600 V / 8.5 A or 0 -
1000 V / 5 A). By connecting up to *50 power supplies in parallel, a
maximum output power can reach up to 250 kW. These power supplies
are fully programmable and controllable through analog programming,
USB, RS232, RS485, GPIB and Ethernet interface. The front numerical
keypad and rotary knob provide a convenient interface for adjusting
voltage, current, operating functions and enabling/disabling the output.
The PVS series power supplies also provide over voltage protection
(OVP) and over current protection (OCP) features used to keep the
output voltage and current within a specified safety level and
preventing damage to the UUT (Unit Under Test).
Features:
High power output of up to 5100 watts (0-600V/8.5A) (0-
1000V/5A)
USB(virtual COM)/RS232/RS485/Analog/GPIB and Ethernet
interfaces
Parallel connectivity for up to *50 units
Adjustable voltage and current slope
9 user defined programs with up to 100 steps each
OVP, OCP, OPP, CV to CC, and CC to CV protection
Store/recall up to 100 sets of voltage/current settings

2
*Parallel connectivity and operations can be configured in several
different modes, however speed and performance will decrease as
each additional units are paralleled together. Refer to section 3.6
Parallel Operation and 4.1 RS-485 for more details regarding the
configuration, setup, and limitations.
If you wish to connect more than 10 units in parallel, we advise to
contact us at www.bkprecision.com for further assistance.
1.2 Package Contents
Please inspect the instrument mechanically and electrically upon
receiving it. Unpack all items from the shipping carton, and check for
any obvious signs of physical damage that may have occurred during
transportation. Report any damage to the shipping agent immediately.
Save the original packing carton for possible future reshipment. Every
power supply is shipped with the following contents:
1 x PVS10005, PVS60085, or PVS60085MR Power Supply
1 x AC Power Cord
1 x Certificate of Calibration
1 x Test Report
Verify that all items above are included in the shipping container. If
anything is missing, please contact B&K Precision.

3
1.3 Product Dimensions
The PVS10005, PVS60085, and PVS60085MR power supply’s dimensions
are approximately: 420mm (16.54in) x 88mm (3.46in) x 532mm
(20.95in) (WxHxD). These 2U supplies are designed to fit in a standard
19-inch rackmount.
Note: All dimensions in the figures below are measured in millimeters (mm).
Figure 1.1 – Front Panel Dimensions
Figure 1.2 – Side Panel Dimensions

4
1.4 Front Panel Overview
Figure 1.3 – Front Panel Overview
Front Panel Description
Power On/Off switch
Vacuum Fluorescent Display
OVP, OCP, OPP indicators
Keypad lock indicator
Function keys
Numeric keys
Rotary Knob
Left, Right cursor keys
1
2
3
4
5
6
7
8
7
8
2
3
4
5
1
6
