Brüel & Kjær Vibro VIBROTEST 60 Guide

Technische Dokumentation
Technical Documentation
Dokumentation Technique
VIBROTEST 60
C006389.01

All rights reserved.
No part of this publication may be reproduced, stored in a retrieval system or
transmitted, in any form, or by any means, electronic, mechanical,
photocopying, recording or otherwise without prior written permission from
Brüel & Kjær Vibro GmbH.
The right to make changes at any time without notice is reserved.
Copyright 2013 by Brüel & Kjær Vibro GmbH, D-64293 Darmstadt
Tel.: [phone] Fax: [phone]
Internet: www.bkvibro.de E-Mail: [e-mail]

VIBROTEST 60 Contents
© VTEST60E July 2013 4.46ff C102 853.002 Page 1 of 168
Contents
1Precautionary information .......................................................... 10
2Introduction ................................................................................ 12
2.1 Tasks the VIBROTEST 60 can perform........................................................12
2.1.1 The concept ............................................................................................................................12
2.1.2 Advantages of the VIBROTEST 60.........................................................................................12
2.2 Module overview ...........................................................................................14
2.3 Extent of delivery ..........................................................................................15
2.4 Mechanical construction ...............................................................................16
2.4.1 VIBROTEST 60 measuring instrument ...................................................................................17
2.4.2 AC-601 power / battery charger unit .......................................................................................18
2.5 Operation ......................................................................................................19
2.5.1 Softkeys...................................................................................................................................19
2.5.2 Cursor buttons , , , ...........................................................................................20
2.5.3 The function buttons................................................................................................................20
2.5.4 The window display .................................................................................................................21
2.5.5 Zoom function without the cursor ............................................................................................22
2.5.6 Zoom functions with activated cursor......................................................................................24
3Operational modes ..................................................................... 27
3.1 Analyser mode..............................................................................................27
3.2 Data-collector mode......................................................................................28
3.3 Field Balancing mode ...................................................................................28

Technische Dokumentation
Technical Documentation
Dokumentation Technique
VIBROTEST 60
C006389.01

Tous droits réservés.
La duplication ou la copie de cette documentation, totale ou partielle, par
quel que moyen que ce soit, est interdite sans l’autorisation écrite préalable
de Brüel & Kjær Vibro GmbH.
Nous nous réservons la possibilité de réaliser des améliorations sans
préavis.
Copyright 2012 par Brüel & Kjær Vibro GmbH (64293 Darmstadt Allemagne)
Tel.: [phone] Fax: [phone]
Internet: www.bkvibro.com E-Mail: [e-mail]

Contents VIBROTEST 60
Page 2 of 168 C102 853.002 © VTEST60E July 2013 4.46ff
4SETUP - Adjustments ................................................................ 29
4.1 System setup ................................................................................................29
4.1.1 Channels .................................................................................................................................29
4.1.2 Setup 1=2................................................................................................................................29
4.1.3 Date.........................................................................................................................................30
4.1.4 Time ........................................................................................................................................30
4.1.5 Units ........................................................................................................................................30
4.1.6 Speed ......................................................................................................................................30
4.1.7 Speed / Ref. ............................................................................................................................31
4.1.8 Language ................................................................................................................................31
4.2 The Cursor control ........................................................................................32
4.2.1 Entry of decimal points, numbers and units ............................................................................32
4.3 Vibration measurement.................................................................................34
4.3.1 Overall Vibration......................................................................................................................34
4.3.2 BCU / Bandpass......................................................................................................................37
4.3.3 RECORD Mode.......................................................................................................................40
4.4 Spectrum / Cepstrum....................................................................................42
4.4.1 Sensors ...................................................................................................................................42
4.4.2 Unit / Signal detection .............................................................................................................43
4.4.3 Filter ........................................................................................................................................43
4.4.4 No. of Lines .............................................................................................................................43
4.4.5 Window ...................................................................................................................................43
4.4.6 Averaging mode ......................................................................................................................44
4.4.7 No. of Averages.......................................................................................................................44

VIBROTEST 60 Contents
_________________________________________________________________________________
© VTEST60E July 2013 V4.46ff C102 853.002 Page 3 of 168
4.5 Envelope Analysis / BCS ..............................................................................45
4.5.1 Envelope analysis - BCS mode (Bearing Condition Signature) ..............................................45
4.5.2 Envelope analysis - SED mode (Selective Envelope Detection).............................................46
4.5.3 Frequency analysis parameters ..............................................................................................48
4.5.4 No. of Lines .............................................................................................................................48
4.5.5 Window ...................................................................................................................................48
4.5.6 Averaging mode ......................................................................................................................49
4.5.7 No. of Averages.......................................................................................................................49
4.6 CPB-spectrum ..............................................................................................50
4.6.1 Sensors ...................................................................................................................................50
4.6.2 Unit / Signal detection .............................................................................................................51
4.6.3 Bandwidth................................................................................................................................51
4.6.4 Filter ........................................................................................................................................51
4.6.5 Averaging time ........................................................................................................................51
4.7 Process Values.............................................................................................52
4.7.1 Sensor sensitivity ....................................................................................................................52
4.7.2 Off-set .....................................................................................................................................52
4.8 Tracking Analysis..........................................................................................53
4.8.1 Sensors ...................................................................................................................................53
4.8.2 Unit ..........................................................................................................................................54
4.8.3 Additional Order ......................................................................................................................54
4.8.4 RECORD.................................................................................................................................54

Contents VIBROTEST 60
Page 4 of 168 C102 853.002 © VTEST60E July 2013 4.46ff
4.9 Balancing ......................................................................................................56
4.9.1 Sensors ...................................................................................................................................56
4.9.2 Unit ..........................................................................................................................................57
4.9.3 No. of planes ...........................................................................................................................57
4.9.4 Correction type ........................................................................................................................57
4.9.5 Adaptive Mode ........................................................................................................................58
4.9.6 Mass Units...............................................................................................................................58
4.10 Service functions ..........................................................................................59
4.10.1 Buttons test .............................................................................................................................59
4.10.2 Display test..............................................................................................................................59
4.10.3 Memory test.............................................................................................................................59
4.10.4 Calibration info ........................................................................................................................61
4.10.5 Error reports ............................................................................................................................61
4.10.6 Upgrade...................................................................................................................................61
4.10.7 Formatting the PC Card ..........................................................................................................61
5Acquiring and displaying measurements .................................... 62
5.1 »Overall Vibration / BCU measurement«......................................................64
5.1.1 Listing function ........................................................................................................................65
5.1.2 Recording measurements in a specific speed range or time interval ....................................68
5.2 »Spectrum / Cepstrum«................................................................................74
5.2.1 Executing the measurement ...................................................................................................74
5.2.2 Averaging functions.................................................................................................................77
5.2.3 Display of low frequencies.......................................................................................................79

VIBROTEST 60 Contents
_________________________________________________________________________________
© VTEST60E July 2013 V4.46ff C102 853.002 Page 5 of 168
5.3 »Envelope Analysis / BCS« ..........................................................................80
5.4 »CPB Spectra« .............................................................................................82
5.4.1 Executing a measurement ......................................................................................................82
5.5 »Process-value« measurement ....................................................................84
5.5.1 Listing function ........................................................................................................................85
5.6 »Tracking Analysis« measurement...............................................................86
5.6.1 Free-running measurement.....................................................................................................87
5.6.2 Measurement vs. Speed .........................................................................................................88
5.6.3 Measurement vs. time.............................................................................................................92
5.7 »Keyboard Input« .........................................................................................96
6Data-collector mode ................................................................... 97
6.1 Selecting the Route ......................................................................................97
6.2 Selecting the measurement Points ...............................................................98
6.3 Measurement acquisition ............................................................................100
6.4 Allocation of Comments..............................................................................103
7Field Balancing......................................................................... 104
7.1 Balancing overview .....................................................................................104
7.2 Balancing user-interface .............................................................................108
7.2.1 Main Balancing menu............................................................................................................108
7.2.2 Main menu with all measuring runs:......................................................................................108
7.2.3 Softkeys.................................................................................................................................109

Contents VIBROTEST 60
Page 6 of 168 C102 853.002 © VTEST60E July 2013 4.46ff
7.3 Storage of the balancing procedure............................................................110
7.4 Selecting Balancing / Executing the Setup .................................................111
7.5 Single-plane balancing steps with polar correction example .....................113
7.6 Single-plane, repeat balancing steps with polar correct-ion example .........120
7.7 Two-plane Balancing steps with component correction example ...............122
7.8 Single and 2-plane Balancing with prognosis and polar correction example129
8Storing and displaying measurements (Reports) on the PC-card131
8.1 Storing Reports on the PC-card..................................................................131
8.2 Displaying Reports......................................................................................133
8.3 Memory requirement and management......................................................137
8.3.1 In Analyser mode ..................................................................................................................137
8.3.2 In Data-collector mode ..........................................................................................................137
8.3.3 Storage capacity of each (4 MB) PC-card.............................................................................137
9Commissioning......................................................................... 138
9.1 Selecting the language ...............................................................................139
9.2 Basic settings for the System Setup ...........................................................140
9.3 System-error messages..............................................................................141
10 PC-cards - Handling and action................................................ 142

VIBROTEST 60 Contents
_________________________________________________________________________________
© VTEST60E July 2013 V4.46ff C102 853.002 Page 7 of 168
11 Battery sets: Handling and Disposal......................................... 145
11.1 General .......................................................................................................145
11.1.1 Battery set voltage monitoring...............................................................................................145
11.1.2 Exchanging battery sets ........................................................................................................146
11.1.3 Charging................................................................................................................................146
11.1.4 LED Charge monitoring.........................................................................................................147
11.1.5 Battery maintenance with a VIBROTEST 60 in storage........................................................148
11.1.6 Disposal.................................................................................................................................148
11.1.7 Battery replacement ..............................................................................................................148
12 Technical Data ......................................................................... 149
12.1 Safety conformance....................................................................................149
12.2 Technical Data............................................................................................150
12.2.1 VIBROTEST 60.....................................................................................................................150
12.2.2 Power / charger unit AC-601 .................................................................................................151
12.2.3 Measurement acquisition ......................................................................................................152
12.2.4 PC-Cards...............................................................................................................................154
12.2.5 Battery set AC-602 ................................................................................................................154
12.3 Sensor connections ....................................................................................154
12.4 Acceleration Sensor, AS-065......................................................................156
12.4.1 Application.............................................................................................................................156
12.4.2 Measuring Principle...............................................................................................................156
12.4.3 Technical Data ......................................................................................................................157
12.4.4 Mounting................................................................................................................................159

Contents VIBROTEST 60
Page 8 of 168 C102 853.002 © VTEST60E July 2013 4.46ff
12.5 Optical reference pickup P - 95 ..................................................................161
12.5.1 Application.............................................................................................................................161
12.5.2 Operating Principle................................................................................................................161
12.5.3 Technical Data ......................................................................................................................162
12.5.4 Reference mark.....................................................................................................................163
12.5.5 Mounting / Adjustment ..........................................................................................................164
12.5.6 Problems with the reference signal ? ....................................................................................164
13 Appending EG-conformance statements.................................. 167

VIBROTEST 60 Contents
_________________________________________________________________________________
© VTEST60E July 2013 V4.46ff C102 853.002 Page 9 of 168

Precautionary information VIBROTEST 60
Page 10 of 168 C102 853.002 © VTEST60E July 2013 4.46ff
1 Precautionary information
Application
The VIBROTEST 60 is specifically conceived for the purpose of
overall vibration, spectrum, process-value and tracking analysis
measurements.
Use of the instrument for any purpose other than these is
therefore outside of the design purpose.
The VIBROTEST 60 is of the latest technological design and is
operationally secure.
Unrelated and unpredictable events may occur if the
VIBROTEST 60 is used by untrained persons for any indiscri-
minate purpose. Any person given the task of using the
VIBROTEST 60 should have first read and understood the
operating instructions and in particular the precautionary
information it contains.
Indiscriminate usage
in the operating instructions is emphasized by the following:
Note:
Non-observance of the precautionary information may result in
the possibility of damage (in particular component damage) to
the instrument.
Service work
Service work to the instrument may only be carried out by Brüel
& Kjær Vibro service personnel or Brüel & Kjær Vibro
authorised service personnel.
Note:
Please check the power in your region and compare it with the
power range capability of the battery charger unit of the
instrument before commissioning.
The battery set of the VIBROTEST 60 must not remain in the
instrument during transportation!
The connections of the battery set must not be short-circuited!

VIBROTEST 60 Precautionary information
_________________________________________________________________________________
© VTEST60E July 2013 V4.46ff C102 853.002 Page 11 of 168
Note:
•VIBROTEST 60 should only be operated with its covers on.
•Do not touch the charging contacts under the instrument.
This could result in faulty operation of the functions due to
electro-static discharge.
•The use of mobile telephones within a distance of 5 m could
lead to malfunction.

Introduction VIBROTEST 60
Page 12 of 168 C102 853.002 © VTEST60E July 2013 4.46ff
2 Introduction
2.1 Tasks the VIBROTEST 60 can perform
VIBROTEST 60 offers extensive measuring functions in a
modular concept as a
•Vibration analyser
•Field Balancing instrument
•Data-collector.
VIBROTEST 60 is the realisation of a measuring instrument
technically designed for evaluation of machine condition,
accurate diagnosis of damage and faults and achievement of
the most modern standard for „condition-based„ maintenance
strategy.
2.1.1 The concept
The modular concept of the VIBROTEST 60 permits individual
combinations of measurement functions and therefore opens
up a number of applications.
Functional modules of the instrument can be expanded at any
time and therefore future development of the measurement
functions can be easily supplemented.
2.1.2 Advantages of the VIBROTEST 60
•Unique FFT-analyser, Field Balancer, Data-collector in one
handy instrument
•Easily-understood operator dialogue, selectable in the
following languages:
−German,
−English,
−French,
−Italian,
−Dutch,
−Portuguese,
−Spanish,
−Czech,
−Hungarian,
−Polish

VIBROTEST 60 Introduction
_________________________________________________________________________________
© VTEST60E July 2013 V4.46ff C102 853.002 Page 13 of 168
•Real 2-channel measurement plus speed
•Small, light-weight (900 g), single-hand operated instrument
•Latest quality in Data-collector technology with
−extreme speed of measurement and simultaneous
processing of up to 5 different measurement types
−multiple Routes and random Point processing in
measurement Routes
−random switching between analyser, field balancing,
and Data-collector modes
•High-tech signal processing with true Digital Signal
Processor (DSP)
•Guaranteed long product life-cycle through modular expan-
dable measurement functions for future developments
•High accuracy and dynamic resolution with 16-Bit ADC
•Excellent FFT resolution with up to 12,800 lines
•Commercially-available accelerometers, velocity and displa-
cement sensors can be used
•Brilliant, high-contrast graphic display with back-light
•Extreme storage capacity and high measurement data
security through use of PC-cards

Introduction VIBROTEST 60
Page 14 of 168 C102 853.002 © VTEST60E July 2013 4.46ff
2.2 Module overview
The following documentation describes all available modules of
the VIBROTEST 60. In any individual case those modules
which correspond to the order acknow-ledgement are released.
Module Functions
Module 1.1: Basic Module
Overall values for machine
evaluation
•Absolute bearing vibration
•Relative shaft vibration
•BCU / Bandpass (BP)
•Process values
•Manual entry
•Listing function
•Speed measurement
Module 1.2 : Extension
Module
Overall values for machine
evaluation
•Measurement vs. speed (f(n))
•Measurement vs. time (f(t))
Module 2.1: Basic Module
Machine diagnosis
•FFT-Spectrum
Module 2.2: Extension
Module
Machine diagnosis
•Envelope analysis (BCS / SED)
•Cepstrum
Module 3
Tracking analysis
•Free-running measurement
•Measurement vs. speed f(n) and time f(t)
(Run-up, Coast-down)
Module 5
Two-channel function
•Two-channel function
Module 6
Data-collector
single-channel measurement
Measurement module not
included
Following optional modules can be used in
Data-collector operation.
•Module 1.1 Basic Module
Overall values for machine evaluation
•Module 2.1 and 2.2
Machine diagnosis
•Module 8
CPB-Spectrum
Module 7
Field balancing
•1-plane balancing
•2-plane balancing
•1-/2-plane balancing with Prognosis
•Polar-, component and unit mass correction
•On- / Off Adaptive mode
Module 8
CPB-spectrum
•CPB-spectrum

VIBROTEST 60 Introduction
_________________________________________________________________________________
© VTEST60E July 2013 V4.46ff C102 853.002 Page 15 of 168
2.3 Extent of delivery
The extent of delivery of the basic VIBROTEST 60 instrument
consists of the following components:
1 x VIBROTEST 60 measuring instrument
incl. Basic Module 1.1:
„Overalls for machine evaluation“
1 x Power / charger unit AC-601
2 x Battery set AC-602
1 x PC-card AC-603
1 x Vibration acceleration pickup AS-065
with cable AC-437
Mounting magnet AC-172
Probe AC-272
Threaded stud AC-350
1 x Case AC-605
for transport of instrument and accessories
1 x Technical documentation

Introduction VIBROTEST 60
Page 16 of 168 C102 853.002 © VTEST60E July 2013 4.46ff
2.4 Mechanical construction
Sensors connections
1 Pickup channel 1
2 Pickup channel 2
REF Ref.- / speed pickup
Display unit
LED: GREEN
Instrument On
RED
Residual battery life < 2 Min.
(LED is „RED“ only when VIBROTEST 60
has been on for more than 10 min.)
Softkeys
Cursor control buttons
The back-light is switched On by pushing any
button. The function of the respective button is
also executed.
Function buttons
ON / OFF
After removal of the lower housing cover
the compartment for the battery set and
PC-card is accessible.
Battery set
PC-Card
PC-Card ejector
Exchanging the PC-Card:
•Switch the VIBROTEST 60 Off (ON button)
•Push card ejector
•Remove the PC-Card
When inserting a PC-card take care that the label of the
card faces up and the card is inserted in the direction of
the arrow on the card. Never use excessive force to
remove or insert the card !
