1 Welcome
Thank you for buying a PicoScope 5000 Series Flexible Resolution Oscilloscope
from PicoTechnology!
The PicoScope 5000 A and B Series of Flexible
Resolution Oscilloscopes from PicoTechnology are a
range of high-specification real-time measuring
instruments that connect to the USB port of your
computer. With the PicoScope software you can use
these devices as oscilloscopes and spectrum analyzers.
With various options of portability, resolution, deep
memory, fast sampling rates and high bandwidth,
these highly versatile oscilloscopes suit a wide range of
applications.
B
5V
A
Ext G
PicoScope
www.picotech.com
PicoScope 5000 Series
BCD
5V
A
Ext G
PicoScope
www.picotech.com
PicoScope 5000 Series
The A models are high-speed portable oscilloscopes with a function generator:
PicoScope 5242A
PicoScope 5243A
PicoScope 5244A
PicoScope 5442A
PicoScope 5443A
PicoScope 5444A
The B models are as the A models, but feature an arbitrary waveform generator and
deeper memory:
PicoScope 5242B
PicoScope 5243B
PicoScope 5244B
PicoScope 5442B
PicoScope 5443B
PicoScope 5444B
Here are some of the benefits provided by the PicoScope 5000 A and B Series
oscilloscopes:
Flexibility: Whether you want 8, 12, 14, 15 or 16-bit resolution, the PicoScope
5000 Series oscilloscopes will suit your needs.
Portability: Take the unit with you and plug it in to any Windows PC.
Performance: Up to 1 GS/s sampling, 200 MHz bandwidth and 512 MS buffer.
Programmability: The PicoScope 5000A SDK lets you write your own programs, in
your chosen programming language, to control all the features of the scope. Using
the API functions, you can develop your own programs to collect and analyze data
from the oscilloscope. Refer to the PicoScope 5000 Series (A API) Programmer's
Guide for more information.
Long-term support: Software upgrades are available to download from our
website. You can also call our technical specialists for support. You can continue to
use both of these services free of charge for the lifetime of the product.
Value for money: You don't have to pay twice for all the features that you already
have in your PC, as the PicoScope 5000 Series oscilloscope contains the special
hardware you need and nothing more.
Convenience: The software makes full use of the full-sized display, disk storage,
user interface and networking built in to your PC.
Five-year warranty: Your oscilloscope is covered for five years from the day of
purchase against manufacturing faults. We don't charge a penny extra for this
benefit.
For further information on the PicoScope 5000 A and B Series oscilloscopes, see the
comparison table in this manual, and the specifications tables in the PicoScope 5000
Series data sheets available on our website.
北京海洋兴业科技股份有限公司（证券代码：839145）
www.hyxyyq.com

Introduction2
Copyright © 2013–2016 Pico Technology Limited. All rights reserved.ps5000ab.en r4
2 Introduction
2.1 Safety information
This product has been designed and tested in accordance with the European standard
publication EN 61010-1: 2010, and left the factory in a safe condition.
The following safety descriptions are found throughout this guide:
A WARNING identifies conditions or practices that could result in injury or death.
A CAUTION identifies conditions or practices that could result in damage to the
product or equipment to which it is connected.
Each of these safety instructions applies to all of the PicoScope 5000 Series
oscilloscopes covered by this User's Guide, unless otherwise specified.
北京海洋兴业科技股份有限公司（证券代码：839145）
www.hyxyyq.com

PicoScope 5000 A and B Series PC Oscilloscopes User's Guide 3
Copyright © 2013–2016 Pico Technology Limited. All rights reserved. ps5000ab.en r4
2.1.1 Safety symbols
These safety and electrical symbols may appear on the product and throughout this
guide.
Symbol
Description
Direct current.
Alternating current.
Functional earth terminal.
This terminal is connected to
chassis ground, and allows you to
connect the oscilloscope to an
external ground reference. This
terminal is not intended to
provide a protective (safety)
ground.
Chassis ground terminal.
The ground terminals of
connectors marked with this
symbol are all connected
together, and connected to the
host PC via the screen of the USB
cable. This symbol is used in
place of the equipotential symbol
which may appear on older
products.
Equipment protected throughout by
double insulation or reinforced
insulation.
Possibility of electric shock.
Caution.
Indicates a potential HAZARD:
consult the product
documentation every time you
see this symbol, in order to
identify the hazard and any
actions needed to avoid it.
Static awareness. Static discharge can
damage part(s).
IEC 61010 overvoltage category.
Do not dispose of this product as
unsorted municipal waste.
北京海洋兴业科技股份有限公司（证券代码：839145）
www.hyxyyq.com

Introduction4
Copyright © 2013–2016 Pico Technology Limited. All rights reserved.ps5000ab.en r4
2.1.2 Product usage
WARNING
To prevent injury or death, use the product only as instructed and use only
accessories supplied or recommended. Protection provided by the product
may be impaired if used in a manner not specified by the manufacturer.
WARNING
To prevent possible electrical shock, fire, personal injury, or damage to the
product, carefully read this safety information before attempting to install or
use the product. In addition, follow all generally accepted safety practices and
procedures for working with and around electricity.
2.1.3 Maximum input ranges
Observe all terminal ratings and warnings marked on the product.
The table below indicates the full scale measurement range and overload protection
range for each oscilloscope model. The full scale measurement ranges are the
maximum voltages that can be accurately measured by each instrument. The overload
protection ranges are the maximum voltages that can be applied without damaging
the oscilloscope.
WARNING
To prevent electric shock, do not attempt to measure voltages outside the
specified full scale measurement range below.
Model
Full scale
measurement
range
Overload protection
Input channels
/ EXT trigger
Signal generator
All PicoScope 5000 A
and B Series
oscilloscopes
±20V
±100 V pk max.
±20 V pk max.
WARNING
Signals exceeding the voltage limits in the table below are defined as
"hazardous live" by EN 61010. To prevent electric shock, take all necessary
safety precautions when working on equipment where hazardous live voltages
may be present.
Signal voltage limits of EN 61010
±70V DC
33 V AC RMS
±46.7V pk max.
WARNING
The PicoScope 5000 Series oscilloscopes are not designed to measure
hazardous live signals as defined by EN 61010. To prevent electric shock, do
not attempt to measure voltages outside of the limits shown in the table
above or the specified full scale measurement range, whichever is lower.
WARNING
To prevent injury or death, the oscilloscope must not be directly connected to
the mains (line power). To measure mains voltages, use a differential isolating
北京海洋兴业科技股份有限公司（证券代码：839145）
www.hyxyyq.com

PicoScope 5000 A and B Series PC Oscilloscopes User's Guide 5
Copyright © 2013–2016 Pico Technology Limited. All rights reserved. ps5000ab.en r4
probe specifically rated for mains use, such as the TA041 listed on the Pico
website.
CAUTION
Exceeding the overload protection range on any connector can cause
permanent damage to the oscilloscope and other connected equipment.
2.1.4 Grounding
WARNING
The oscilloscope's ground connection through the USB cable is for
measurement purposes only. The oscilloscope does not have a protective
safety ground.
WARNING
Never connect the ground input (chassis) to any electrical power source. To
prevent personal injury or death, use a voltmeter to check that there is no
significant AC or DC voltage between the oscilloscope ground and the point to
which you intend to connect it.
CAUTION
Applying a voltage to the ground input is likely to cause permanent damage to
the oscilloscope, the attached computer, and other equipment.
CAUTION
To prevent measurement errors caused by poor grounding, always use the
high-quality USB cable supplied with the oscilloscope.
2.1.5 Environment
WARNING
To prevent injury or death, do not use in wet or damp conditions, or around
explosive gas or vapor.
CAUTION
To prevent damage, always use and store your oscilloscope in appropriate
environments.
Storage
Operating
Temperature
–20°C to +60°C
0°C to +40°C
(+20°C to +30°C for quoted
accuracy)
Humidity
5% to 95% RH
(non-condensing)
5% to 80% RH
(non-condensing)
北京海洋兴业科技股份有限公司（证券代码：839145）
www.hyxyyq.com

Introduction6
Copyright © 2013–2016 Pico Technology Limited. All rights reserved.ps5000ab.en r4
2.1.6 Care of the instrument
The oscilloscope and its accessories contain no user-serviceable parts. Repair and
servicing require specialized test equipment and must only be performed by Pico
Technology or an approved service provider. There may be a charge for these services
unless covered by the Pico five year warranty.
WARNING
To prevent injury or death, do not use the instrument if it appears to be
damaged in any way, and stop use immediately if you are concerned by any
abnormal operations.
WARNING
When cleaning the oscilloscope, use a soft cloth and a solution of mild soap or
detergent in water. To prevent electric shock, do not allow liquids to enter the
casing, as this will cause damage to the electronics or insulation inside.
CAUTION
Do not tamper with or disassemble the oscilloscope, connectors or
accessories. Internal damage will affect performance.
2.2 Conformance
2.2.1 FCC notice
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 Subpart B of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his or her own
expense.
For safety and maintenance information see the safety information.
2.2.2 CE notice
The PicoScope 5000 A and B Series oscilloscopes meet the intent of the EMC directive
89/336/EEC and have been tested to EN 61326-1:2013 Class A Emissions and
Immunity standard.
The product also meets the intent of the Low Voltage Directive and has been
designed to meet BS EN 61010-1:2010 Safety requirements for electrical
equipment for measurement, control, and laboratory use standard.
2.3 Software license conditions
The software supplied with this product is licensed, not sold. Pico Technology Limited
grants a license to the person who installs this software, subject to the conditions
listed below:
Access. The licensee agrees to allow access to this software only to persons who have
been informed of these conditions and agree to abide by them.
Usage. The software in this release is for use only with Pico Technology products or
with data collected using Pico Technology products.
北京海洋兴业科技股份有限公司（证券代码：839145）
www.hyxyyq.com

PicoScope 5000 A and B Series PC Oscilloscopes User's Guide 7
Copyright © 2013–2016 Pico Technology Limited. All rights reserved. ps5000ab.en r4
Copyright. Pico Technology Limited claims the copyright of, and retains the rights to,
all material (software, documents etc.) contained in this release. You may copy and
distribute the entire release in its original state, but must not copy individual items
within the release other than for backup purposes.
Liability. Pico Technology and its agents shall not be liable for any loss, damage or
injury, howsoever caused, related to the use of Pico Technology equipment or
software, unless excluded by statute.
Fitness for purpose. Because no two applications are the same, Pico Technology
cannot guarantee that its equipment or software is suitable for a given application. It
is your responsibility, therefore, to ensure that the product is suitable for your
application.
Mission-critical applications. This software is intended for use on a computer that
may be running other software products. For this reason, one of the conditions of the
license is that it excludes usage in mission-critical applications; for example, life-
support systems.
Viruses. This software was continuously monitored for viruses during production, but
you are responsible for virus-checking the software once it is installed.
Support. If you are dissatisfied with the performance of this software, please contact
our technical support staff, who will try to fix the problem within a reasonable time. If
you are still dissatisfied, please return the product and software to your supplier within
14 days of purchase for a full refund.
Upgrades. We provide upgrades, free of charge, from our website at
www.picotech.com. We reserve the right to charge for updates or replacements sent
out on physical media.
2.4 Trademarks
Windows is a registered trademark of Microsoft Corporation in the USA and other
countries.
Pico Technology Limited and PicoScope are trademarks of Pico Technology Limited
registered in the United Kingdom and other countries.
2.5 Warranty
Pico Technology warrants upon delivery, and for a period of 5 years unless otherwise
stated from the date of delivery, that the Goods will be free from defects in material
and workmanship.
Pico Technology shall not be liable for a breach of the warranty if the defect has been
caused by fair wear and tear, willful damage, negligence, abnormal working conditions
or failure to follow Pico Technology's spoken or written advice on the storage,
installation, commissioning, use or maintenance of the Goods or (if no advice has been
given) good trade practice; or if the Customer alters or repairs such Goods without the
written consent of Pico Technology.
北京海洋兴业科技股份有限公司（证券代码：839145）
www.hyxyyq.com

Introduction8
Copyright © 2013–2016 Pico Technology Limited. All rights reserved.ps5000ab.en r4
2.6 Minimum system requirements
To ensure that your PicoScope 5000 Series oscilloscope operates correctly, you must
have a computer with at least the minimum system requirements as shown in the
following table. The performance of the oscilloscope will be better with a more
powerful PC, and will benefit from a multi-core processor.
Item
Specification
Operating system
Windows 7, Windows 8, Windows 10*. 32 bit and 64 bit
versions.
Beta software is also available for Linux and OS X operating
systems.
Processor
As required by the operating system
Memory
Free disk space
Ports
USB 3.0 or USB 2.0 port(s)
*PicoScope version 6.11 and SDKs are compatible with Windows XP SP3 and
Vista SP2 in addition to the Windows versions listed above. For best
performance we recommend Windows 7 or later.
3Pack contents
A PicoScope 5000 A or B Series oscilloscope is supplied with the following items:
Standard USB cable (4-channel scopes only)
Double-headed USB cable
AC adaptor (4-channel scopes only)
Software and Reference CD
Installation Guide
2 or 4 x Probes (see Model Comparison table for probe details)
北京海洋兴业科技股份有限公司（证券代码：839145）
www.hyxyyq.com

Installation10
Copyright © 2013–2016 Pico Technology Limited. All rights reserved.ps5000ab.en r4
4 Installation
Please note the various power supply options below. Consult the appropriate section
relating to the intended use of the oscilloscope and the instructions in the Installation
Guide and the leaflet included with your product package.
Powering 2-channel scopes
Connect your PicoScope 5000 Series 2-channel oscilloscope to two free, powered USB
ports on the PC or USB hub using the double-headed USB cable supplied (see image 1
below).
Powering 4-channel scopes
When using one or two channels of the 4-channel PicoScope 5000 Series oscilloscopes,
you have two options for power.
1. If your computer or USB hub does not have two free, powered USB ports, connect
your PicoScope 5000 Series oscilloscope to the PC or hub using the single-headed
USB cable supplied. Plug the power adaptor into the mains and connect the DC
cable to the DC power socket on the rear of the oscilloscope (see image 2 below).
2. If your computer or USB hub has two free, powered USB ports, connect your
PicoScope 5000 Series oscilloscope to two ports on the PC or hub using the double-
headed USB cable supplied (see image 1 below).
When using three or four channels on the 4-channel PicoScope 5000 Series
oscilloscopes, connect your oscilloscope to the PC or hub using the single-headed USB
cable supplied. Plug the power adaptor into the mains and connect the DC cable to
the DC power socket on the rear of the oscilloscope (see image 2 below).
Note: If you connect or disconnect the AC adaptor while the oscilloscope is in
operation it will restart automatically and any unsaved data will be lost.
Checking the installation
Once you have installed the software and connected the oscilloscope to the PC, start
the PicoScope software. The software should now display any signal connected to the
scope inputs. If you have a probe connected to your oscilloscope, you should see a
small 50or 60 hertz signal in the oscilloscope window when you touch the probe tip
with your finger.
北京海洋兴业科技股份有限公司（证券代码：839145）
www.hyxyyq.com

PicoScope 5000 A and B Series PC Oscilloscopes User's Guide 11
Copyright © 2013–2016 Pico Technology Limited. All rights reserved. ps5000ab.en r4
5Product information
Standard oscilloscope connectors
The PicoScope 5000 A and B Series Flexible Resolution Oscilloscopes have input
channels with standard BNC connectors and standard input impedance. They are
therefore compatible with most oscilloscope probes including x10 and switched x1/x10
types.
The probes supplied with the PicoScope 5000 A and B Series oscilloscopes have been
trimmed specifically for use with the scopes they are supplied with. For optimum
performance, please use the probes supplied. Although other oscilloscope probes can
be used, the specified performance cannot be guaranteed. Replacement probes
matched to your PicoScope 5000 can be ordered from Pico Technology.
Signal generator (Gen) output
The Gen connector is the output of the oscilloscope's built-in signal generator, which
can generate a number of built-in waveforms as well as user-defined arbitrary
waveforms (B Models only).
If you are using the PicoScope 6 program, refer to the PicoScope 6 User's Guide for
information on how to configure the signal generator.
If you are writing your own software, refer to the PicoScope 5000 Series (A API)
Programmer's Guide.
External trigger (Ext) input
The Ext input can be used as a trigger source. It is selected using the trigger drop-
down menu in the PicoScope software, or using a function call if you are writing your
own software.
The Ext input uses dedicated circuitry with a software-configurable threshold to detect
a trigger signal. This has the advantage of freeing the analog channels for viewing
signals. The Ext input has the same characteristics as a scope channel so that a
supplied probe can be trimmed on one of the channels and then used with the Ext
input to give best vertical accuracy. If trigger timing accuracy is critical, we
recommend using one of the main input channels as the trigger source. These
channels use digital triggering (accurate to one sample period) and have a vertical
resolution of 1 LSB.
北京海洋兴业科技股份有限公司（证券代码：839145）
www.hyxyyq.com

Product information12
Copyright © 2013–2016 Pico Technology Limited. All rights reserved.ps5000ab.en r4
5.1 Model comparison table
For full specifications and further information, refer to the PicoScope 5000 Series page
on our website or to the PicoScope 5000 Series data sheets available on our website
and on your Software and Reference CD.
PicoScope 2-channel models overview
Model
Maximum
Bandwidth
Memory
Waveform Output
Probes
Supplied
8-bit
≥12-bit
5242A
60 MHz
16 MS
8 MS
Func. Gen.
2 x 60 MHz
5242B
60 MHz
32 MS
16 MS
Func. Gen. and AWG
2 x 60 MHz
5243A
100 MHz
64 MS
32 MS
Func. Gen.
2 x 150 MHz
5243B
100 MHz
128 MS
64 MS
Func. Gen. and AWG
2 x 150 MHz
5244A
200 MHz
256 MS
128 MS
Func. Gen.
2 x 250 MHz
5244B
200 MHz
512 MS
256 MS
Func. Gen. and AWG
2 x 250 MHz
PicoScope 4-channel models overview
Model
Maximum
Bandwidth
Memory
Waveform Output
Probes
Supplied
8-bit
≥12-bit
5442A
60 MHz
16 MS
8 MS
Func. Gen.
4 x 60 MHz
5442B
60 MHz
32 MS
16 MS
Func. Gen. and AWG
4 x 60 MHz
5443A
100 MHz
64 MS
32 MS
Func. Gen.
4 x 150 MHz
5443B
100 MHz
128 MS
64 MS
Func. Gen. and AWG
4 x 150 MHz
5444A
200 MHz
256 MS
128 MS
Func. Gen.
4 x 250 MHz
5444B
200 MHz
512 MS
256 MS
Func. Gen. and AWG
4 x 250 MHz
Resolution vs sampling rate
Resolution
Sampling rate vs. number of channels in use
Any 1 channel
Any 2 channels
Any 3 channels
All channels
8-bit
12-bit
14-bit
15-bit
16-bit
1 GS/s
500 MS/s
125 MS/s
125 MS/s
62.5 MS/s
500 MS/s
250 MS/s
125 MS/s
125 MS/s
-
250 MS/s
125 MS/s
125 MS/s
-
-
250 MS/s
125 MS/s
125 MS/s
-
-
北京海洋兴业科技股份有限公司（证券代码：839145）
www.hyxyyq.com

PicoScope 5000 A and B Series PC Oscilloscopes User's Guide 13
Copyright © 2013–2016 Pico Technology Limited. All rights reserved. ps5000ab.en r4
5.2 Connector diagrams
PicoScope 5000 A and B Series oscilloscopes
B
5V
A
ExtG
PicoScope
www.picotech.com
PicoScope5000 Series
A
B
34
1
2
PicoScope
www.picotech.com
PicoScope5000 Series
5VDC
5
6
7
BCD
5V
A
ExtG
PicoScope
www.picotech.com
PicoScope5000 Series
A
B
C
D
34
1
2
A. Input channel A
B. Input channel B
C. Input channel C
D. Input channel D
1. Probe compensation output
2. LED: red when scope is connected but not operating. Flashes green when the
oscilloscope is capturing data.
3. External trigger input
4. Signal generator output
5. DC power socket: for use with the AC adaptor supplied. See Installation for details.
6. USB 2.0 port: connects to your PC using the Hi-Speed USB cable supplied. See
Installation for powering options.
7. Earth terminal: Some laptop power supplies can produce electrical noise which may
interfere with your measurements. If this occurs, the earth terminal can be
connected to an external ground point (for example, on the system you are testing)
to provide a ground reference for the scope. This can help to avoid external noise
interfering with your measurements. Alternatively you can run the laptop using
battery power.
北京海洋兴业科技股份有限公司（证券代码：839145）
www.hyxyyq.com

Product information14
Copyright © 2013–2016 Pico Technology Limited. All rights reserved.ps5000ab.en r4
5.3 Moving to another USB port
The process is automatic. When you move the device from one port to another,
Windows displays an "Installing device driver software" message and then a
"PicoScope 5000 Series PC Oscilloscope" message. The oscilloscope is then ready for
use.
5.4 Compensating probes
We recommend that you compensate each oscilloscope probe before using it with your
PicoScope. Compensation instructions specific to the probe are included in the leaflet
supplied with the probe.
Connecting a probe for compensation
1. Plug the probe's BNC connector into the appropriate input channel on the scope.
2. Fit the spring hook (supplied with the probe) on the probe tip.
3. Attach the spring hook to the probe compensation output located on the front panel.
4. Attach the ground lead (supplied) to the probe and connect the crocodile clip to the
ground shell of one of the scope's BNC inputs.
5. Run the PicoScope software. Set the input coupling to AC and then click Auto Setup,
which ensures that the correct range and timebase are selected.
6. Follow the compensation (or 'trimming') instructions in the probe leaflet.
Note: if the probe is moved to a different scope channel, the compensation procedure
must be repeated.
北京海洋兴业科技股份有限公司（证券代码：839145）
www.hyxyyq.com

PicoScope 5000 A and B Series PC Oscilloscopes User's Guide 15
Copyright © 2013–2016 Pico Technology Limited. All rights reserved. ps5000ab.en r4
6 Glossary
API. Application Programming Interface. A set of function calls that give
programmers access to the PicoScope 5000 A and B Series driver.
Bandwidth. The range of input frequencies over which the measured signal amplitude
is no more than 3 decibels below its true value.
Buffer size. The size of the oscilloscope buffer memory, measured in samples. In
block mode, the buffer memory is used by the oscilloscope to store data temporarily.
This allows the oscilloscope to sample data independently of the speed at which it can
transfer data to the computer.
Driver. A program that controls a piece of hardware. The driver for the PicoScope
5000 A and B Series oscilloscopes is supplied in the form of a 32-bit Windows DLL,
ps5000a.dll. This is used by the PicoScope software, and by user-designed
applications, to control the oscilloscopes.
External trigger. This is the BNC connector marked Ext on the PicoScope 5000 A and
B Series oscilloscopes. It can be used as a trigger source but not as a waveform input.
Flexible Resolution Oscilloscope. The instrument formed by connecting a PicoScope
5000 A and B Series oscilloscope to a computer running the PicoScope software
application.
Maximum sampling rate. A figure indicating the maximum number of samples the
oscilloscope can acquire per second. Maximum sample rates are usually given in MS/s
(megasamples per second) or GS/s (gigasamples per second.) The higher the
sampling rate of the oscilloscope, the more accurate the representation of the high-
frequency details in a fast signal.
MS/s. Megasamples per second. Used to quantify the sampling rate of an
oscilloscope.
PicoScope software. This is a software product that accompanies all our
oscilloscopes. It turns your PC into an oscilloscope, spectrum analyzer, and meter
display.
Signal generator. A built-in circuit that generates signals suitable for driving an
external device under test. Its output is on the BNC connector marked Gen on the
oscilloscope. If you connect a BNC cable between this and one of the channel inputs,
you can send a signal into the channel.
Timebase. A timer that controls the speed at which the scope device captures data.
At slow timebases this process is visible as PicoScope draws the trace across the scope
view from left to right, but at fast timebases PicoScope draws the whole trace in a
single operation. The timebase is measured in units of time (such as seconds) per
division. There are ten divisions across the scope view, so the total time across the
width of the view is ten times the "per division" setting.
USB 1.1. USB (Universal Serial Bus) is a standard port that enables you to connect
external devices to PCs. A typical USB 1.1 port supports a data transfer rate of 12
Mbps (12 megabits per second), much faster than an RS232 port.
USB 2.0. A typical USB 2.0 port supports a data transfer rate that is 40 times faster
than USB 1.1. USB 2.0 is backwards-compatible with USB 1.1.
USB 3.0. A USB 3.0 port uses signaling speeds of up to 5 gigabits per second and is
backwards-compatible with USB 2.0 and USB 1.1.
Vertical resolution. A value, in bits, indicating the precision with which the
oscilloscope converts input voltages to digital values. The resolution enhancement
function in PicoScope can improve the effective vertical resolution.
Voltage range.The range of input voltages that the oscilloscope can measure. For
example, a voltage range of ±20 V means that the oscilloscope can measure voltages
between —20 V and +20 V. Input voltages outside this range will not be measured
correctly, but will not damage the instrument as long as they remain within the
protection limits stated in the specifications.
北京海洋兴业科技股份有限公司（证券代码：839145）
www.hyxyyq.com

PicoScope 5000 A and B Series PC Oscilloscopes User's Guide 17
Copyright © 2013–2016 Pico Technology Limited. All rights reserved. ps5000ab.en r4
Index
A
AC adaptor 9, 10, 13
Arbitrary waveform generator 11
B
Bandwidth 12
Buffer size 12
C
Compliance 6
Connections
Arbitrary waveform generator 13
Compensation output 13
Earth terminal 13
Ext connector 13
External trigger 13
Function generator 13
Gen connector 13
USB port 13, 14
E
Earth terminal 11
Ext connector 11
External trigger 11
F
Function generator 11
G
Gen connector 11
L
LED 13
License conditions 6
M
Maximum sampling rate 12
Memory 12
Model comparison 12
O
Oscilloscope probe 10, 11, 13
compensating 14
P
Pack contents
AC adaptor 9
Installation Guide 9
Probes 9
Software and Reference CD 9
USB cable (double-headed) 9
USB cable (single-headed) 9
PicoScope 5000 Series 8, 11
PicoScope software 10, 11
Probes 12
S
Safety
symbols 3
warning 6
Signal generator 12
output 11
Specifications 12
System requirements 8
T
Trademarks 7
U
USB 8
USB cable (double-headed) 10
USB cable (single-headed) 10
W
Warranty 7
北京海洋兴业科技股份有限公司（证券代码：839145）
www.hyxyyq.com

UK headquarters
Pico Technology
James House
Colmworth Business Park
St. Neots
Cambridgeshire
PE19 8YP
United Kingdom
Tel: [phone]
Fax: [phone]
[e-mail]
[e-mail]
www.picotech.com
Copyright © 2013–2016 Pico Technology Limited. All rights reserved.
ps5000ab.en r4 2016-05-12
USA headquarters
Pico Technology
320 N Glenwood Blvd
Tyler
Texas 75702
United States
Tel: [phone]
Fax: [phone]
