Bradford White Combi2 "CDW2" Series Application guide

RESIDENTIAL GAS REPLACEMENT PARTS LIST
Effective: September 2006
ECO 6885
Specification subject to
change without notice.
NOTE: BOTH MODEL AND
SERIAL NUMBERS ARE
REQUIRED FOR ORDERING
REPLACEMENTS PARTS.
Parts Book # 238-46804-00A
Combi2TM Gas Water Heater
“CDW2” Series

CDW2504T Series
Page 2

ItemDescription Model
CDW2504T10F(BN,CX)
1Draft Hood243-33081-02-20
2Flue Reducer 243-36920-00
3Hot Water Outlet Anode Aluminum224-32999-30
4Flue Baffle 243-41037-00
5Cold Water Inlet Dip Tube Polysulfone 229-39628-19
6Plug Type Anode Aluminum224-38508-03
7T&P Relief Valve 230-40594-02
8Wire Tie 239-44328-00
9Right Side Inner Door Complete 243-43963-07
10 Screw-#8-18 x3/4 HWH 239-44195-00
11 Outer Door 243-43962-00
12 Screw-#6-20 x3/8 PHCR 239-43967-00
13Resettable ThermalSwitch 239-43676-02
14Left Side Inner Door Complete 239-43968-18
15 Screw-#10-12 x3/4 HWH 239-44113-00
16 Brass Drain Valve 265-42351-02
17 Inner Door Gasket Kit 239-44078-00
18 Piezo Igniter 239-43448-00
18A Piezo Bracket White Rodgers 239-46157-02
Piezo Bracket Robertshaw 239-46157-01
19 Nat. Gas Thermostat 265-46367-02
LP Gas Thermostat 265-46368-03
20 Kit integratedMixing Device 239-46225-01
21Inlet Tee 239-45632-00
22 Flexible Connector 239-46347-02
23 Outlet Mixing Device 239-45631-00
24 ASSEApprovedMixing Valve (Optional) 239-43740-01
*Inner door gasket kit recommended
**Ordering a complete burner assembly mayincrease deliverytime. Please order the specific component requiredfor the quickest delivery.
Page 3

CDW2504T Series
Page 4

ItemDescription Model
CDW2504T10F(BN,CX)
25Nat Gas Burner Assembly Complete** 265-43971-04-27
26 Nat. Gas BNBurner** 228-42506-00
27Nat. Gas Main Burner Orifice*234-41034-27
Nat. Gas High Altitude 2000 Ft. to 5000 Ft.*234-41034-29
Nat. Gas High Altitude 5000 Ft. to 8000 Ft.*234-41034-30
Nat. Gas High Altitude Over 8000 Ft.*234-41034-31
28 Nat. Gas Pilot Assembly* 233-46277-03
29Nat. Gas Pilot Orifice*234-46502-05
30 Thermocouple*233-46501-14
31Nat. Gas FeedLine*265-43960-04
32 Nat. Gas FeedLine Adaptor 239-60100-00
33 LP Gas Burner Assembly Complete** 265-43972-04-43
34 LP Gas Cast Iron Burner*228-37743-00
35LP Gas Pilot Assembly* 233-46278-03
36 LP Gas Pilot Orifice*234-46502-02
37Air Shutter*239-35466-00
38 Air Shutter Nut*239-18197-00
39Thermocouple*233-46501-17
40 LP Gas FeedLine*265-43961-03
41LP Gas FeedLine Adaptor 239-60099-00
42 LP Gas Main Burner Orifice*234-35928-43
LP Gas High Altitude 2000 Ft. to 5000 Ft.*234-35928-46
LP Gas High Altitude 5000 Ft. to 8000 Ft.*234-35928-47
LP Gas High Altitude Over 8000 Ft.*234-35928-47
-LP to NaturalGas Conversion Kit (NormAlt.)265-45712-25
-LP to NaturalGas Conversion Kit (High Alt.)265-45712-26
*Inner door gasket kit recommended
**Ordering a complete burner assembly mayincrease deliverytime. Please order the specific component requiredfor the quickest delivery.
Page 5

CDW275T Series
Page 6

ItemDescription Model
CDW275T10(BN,CX)
1Draft Hood239-12950-00
2Flue Baffle 243-39975-00
3Flue Reducer 243-36920-00
4Hot Water Outlet Anode Aluminum224-32999-21
5Plug Type Anode Aluminum224-38508-03
6T&P Valve 230-40594-02
7Cold Water Inlet Dip Tube 229-39628-15
8Inner Door 243-39207-00
9Outer Door 243-37177-00
10 Brass Drain Valve 227-42351-02
11 Nat Gas Thermostat 265-46365-02
LP Gas Thermostat 265-46366-02
12Kit integratedMixing Device 239-46225-01
13Inlet Tee 239-45632-00
14Flexible Connector 239-46347-02
15 Outlet Mixing Device 239-45631-00
16 ASSEApprovedMixing Valve (Optional) 239-43740-01
*Inner door gasket kit recommended
**Ordering a complete burner assembly mayincrease deliverytime. Please order the specific component requiredfor the quickest delivery.
Page 7

CDW275T Series
Page 8

ItemDescription Model
CDW275T10(BN,CX)
17 Nat Gas Burner Assembly Complete** 265-43979-03-21
18Nat. Gas BNBurner** 228-42506-00
19 Nat. Gas Main Burner Orifice 234-41034-21
Nat. Gas High Altitude 2000 Ft. to 5000 Ft. 234-41034-24
Nat. Gas High Altitude 5000 Ft. to 8000 Ft. 234-41034-29
Nat. Gas High Altitude Over 8000 Ft. 234-41034-31
20 Nat. Gas Pilot Orifice 234-46502-05
21Nat. Gas Pilot Assembly 233-40248-05
22 Thermocouple 233-46501-24
23 Nat. Gas FeedLine 233-42567-03
24 Nat. Gas FeedLine Adaptor 239-60100-00
25LP Gas Burner Assembly Complete** 265-41876-24-38
26 LP Gas Cast Iron Burner 228-14173-00
27LP Gas Pilot Assembly 233-40261-03
28 LP Gas Pilot Orifice 234-46502-02
29Air Shutter 239-35466-00
30 Air Shutter Nut 239-18197-00
31Thermocouple 233-46501-24
32 LP Gas FeedLine 233-41818-07
33 LP Gas FeedLine Adaptor 239-60099-00
34 LP Gas Main Burner Orifice 234-35928-38
LP Gas High Altitude 2000 Ft. to 5000 Ft. 234-35928-42
LP Gas High Altitude 5000 Ft. to 8000 Ft. 234-35928-43
LP Gas High Altitude Over 8000 Ft. 234-35928-43
-LP to NaturalGas Conversion Kit (NormAlt.)265-45754-07
-LP to NaturalGas Conversion Kit (High Alt.)265-45754-08
*Inner door gasket kit recommended
**Ordering a complete burner assembly mayincrease deliverytime. Please order the specific component requiredfor the quickest delivery.
