Bradley FLOAT Series User manual

Installation
P.O. Box 309
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
[phone]
bradleycorp.com
AD3-FLOAT_Install Rev. A
© 2021 Bradley
Page 1 of 20 12/10/2021
Euro Style Restroom Partitions
Phenolic LT – FLOAT Series
Table of Contents
Safety Information ...........................2
Supplies Required ...........................2
Marking & Installing U-Brackets.................3
Making Notches (if necessary) .................4
Installing U-Bracket on Middle Pilasters ..........6
Mounting Middle Pilaster to Partition Panel........7
Assembling the Feet .........................9
Mounting the Wall Brackets ...................10
Installing Middle Panel & Side Panel............11
Installing Headrail ..........................12
Installing Doors ............................13
Aligning the System.........................13
Pre-Drilling the System ......................14
Mounting Headrail ..........................15
Riveting Wall Connections ....................16
Mounting Door Latches ......................17
Mounting Hooks & Bumpers ..................18
Appendix A: LED Occupancy Indicator ..........20
Read the instructions in this manual before beginning installation. Save these instructions
and refer to them for inspection, maintenance, and troubleshooting information.
For questions regarding the operation, installation or maintenance of this product, visit bradleycorp.com
or call 800.BRADLEY (800.272.3539).
Product warranties and parts information may also be found under “Resources” on our website at bradleycorp.com.

2
Euro Style Restroom Partitions, Phenolic LT — FLOAT Series Installation
12/10/2021 Bradley • AD3-FLOAT_Install Rev. A
Supplies Required
• Chalk line and pencil
• 4D laser level
• Power drill or screw gun with drill bit extension
• Miter saw with aluminum saw blade
• Circular saw or jigsaw
• Cordless screwdriver
• Power rivet gun
• Metric tape measure (recommend a wood folding metric ruler)
• Standard hand tools
• Metric HSS drill bits (8 mm, 5 mm, 4.2 mm)
• Scissor jacks
• Rubber mallet
• HB45 construction adhesive
Safety Information
Warning
Before beginning installation, make sure that the wall and floor backing are adequate to support the mounting of the toilet
compartment units.
Partitions are extremely heavy and may require more than one person to position and install.
Failure to comply with these instructions may result in personal injury and/or property damage and will void the warranty.
Caution
Personal protective equipment (PPE) is required during the installation and maintenance of this product.
Notice
To prevent warping, always lay the material flat. Do not lean the material against the wall or stack unevenly.
Make sure all floors and walls are clean and smooth. Remove loose impediments, such as protruding nails and other debris which
could affect installation.
To minimize break-out, always use a support block when drilling through the material.
Carefully remove components from skid, do not drag.
Important
Review your partition layout drawings and verify the number of stalls and components before beginning installation.
Read this installation manual completely to ensure proper installation, then file it with the owner or maintenance department.
This installation manual provides instruction for the assembly of normal partition configurations and standard components.
Non-standard configurations or components including but not limited to curved or angled walls, partial walls, oversized panels, or
modified hardware are not covered in this manual. Compliance and conformity to local codes and ordinances is the responsibility
of the installer.
Separate parts from packaging and make sure all parts are accounted for before discarding packaging material. If any parts are
missing, do not begin installation until you obtain the missing parts.

3
Installation Euro Style Restroom Partitions, Phenolic LT — FLOAT Series
Bradley • AD3-FLOAT_Install Rev. A 12/10/2021
When installing the partition components, consult the
applicable Bradley Partition submittal drawing specific to this
job for compartment layout dimensions.
If the centerline dimensions are not specified, the
cubicle is divided equally according to the dimensions
for the front side.
1Marking & Installing U-Brackets
From the accompanying production drawing, use the
centerline plus overall dimensions and the dimensions
of the front wall. Transfer these measurements to the
floor and appropriate walls.
A
Be aware of your surroundings and avoid obstructions.
Number the wall U-brackets while laying out the stalls.
Use the laser level to locate the drill points for each
U-bracket. Mark and then drill the locations.
B
Using the 4D laser level, locate the centerline of each
U-bracket. Measure up from the floor 100 mm and
mark the bottom of the first U-bracket. Use the first
bracket base location as a guide to locate and mark the
remaining bracket locations using the laser level.
C
Mark the drill holes for the wall connection U-brackets.
Hold the numbered brackets at these locations, line up
the U-bracket pre-drilled holes at laser centerline, and
mark the screw hole locations on the wall. Be sure to
keep the numbered brackets straight.
E
D
Drill the marked holes using an 8 mm drill bit, and
then mount the U-brackets using 8 mm x 51 mm
plastic anchors and 5.5 mm x 60 mm countersunk
screws with 6.4 mm washers.
F
The dimensions from the floor for the remaining
U-brackets may vary depending on any slope in the
floor.

4
Euro Style Restroom Partitions, Phenolic LT — FLOAT Series Installation
12/10/2021 Bradley • AD3-FLOAT_Install Rev. A
2Making Notches (if necessary)
This step may not be necessary, depending on the layout.
Determine whether the shelf is at a right angle.
If several notches are required, align the height of the
U-brackets using a laser level.
Measure the height of the shelf on the back wall and
subtract the specified ground clearance at that location
from this dimension.
A
Shorten the mitered pre-cut U-bracket to the correct
size. Place the U-bracket with the miter end up,
making sure that it is flush with the top of the shelf.
B
Adjust the remaining piece of the long U-bracket to the
height of the system, and then attach the U-bracket,
setting it perpendicular to the wall.
C
Transfer the notch dimension with the addition of
0.20" clearance to the partition panel, and then use a
circular saw to make the notch.
E
Adjust the short miter U-bracket, and then attach it to
the shelf.
D

5
Installation Euro Style Restroom Partitions, Phenolic LT — FLOAT Series
Bradley • AD3-FLOAT_Install Rev. A 12/10/2021
Place the partition panel into the notched brackets.
Level and use jacks to support the panel and to hold the
panel in place.
F

6
Euro Style Restroom Partitions, Phenolic LT — FLOAT Series Installation
12/10/2021 Bradley • AD3-FLOAT_Install Rev. A
3Installing U-Bracket on Middle Pilasters
Verify the correct pilasters are selected by matching
the label on the pilasters with what is indicated on the
submittal drawings.
Pay close attention to the latch side versus hinge side,
in addition to the in-swing or out-swing.
Determine the centerline of the pilaster and then draw
a full-length line along the pilaster. There may be a
custom dimension indicated on the submittal drawing.
Place the U-bracket on the interior pilaster flush with
the bottom, and then mark the drill holes.
A
B
Using a 4.2 mm drill bit, drill the holes through the
surface of the first panel only, and then attach the
U-bracket using 5.5 mm x 25 mm pan head screws.
Make sure the lower hole catches part of the interior
aluminum frame at the bottom edge of the pilaster.
C

7
Installation Euro Style Restroom Partitions, Phenolic LT — FLOAT Series
Bradley • AD3-FLOAT_Install Rev. A 12/10/2021
4Mounting Middle Pilaster to Partition Panel
Position the partition panel on its rear edge.
A
Install the middle pilaster with profile in the front
groove of the partition panel.
C
Using the T-connector as a template, mark the drill
holes on the bottom edge of the middle pilaster.
D
Using a 4.2 mm drill bit, pre-drill the marked holes.
E
Secure the T-connector to the partition panel
and middle pilaster using three 4.8 mm x 50 mm
countersunk screws.
F
Put silicone on the interior of the middle pilaster.
B
Be sure to use padding to protect the edge of the
partition panel when placing it on its edge.
When securing the T-connector, be sure the middle
pilaster is at an exact 90° angle to the partition panel.

8
Euro Style Restroom Partitions, Phenolic LT — FLOAT Series Installation
12/10/2021 Bradley • AD3-FLOAT_Install Rev. A
Mark the drill holes for the top brackets. Place the
brackets flush with the lower edge of the retaining
block.
G
Using a 4.2 mm drill bit, pre-drill holes through the first
panel only.
H
Tightly secure the heavy brackets (105/60/30/8) using
4.8 x 32 mm countersunk screws.
I
Place the upper retaining heavy block against the
brackets and push onto the upper edge of the
middle panel, and then secure the block using a
4.8 mm x 70 mm countersunk screw.
J
L-bracket holes are offset so the screws do not
interfere with each other.

9
Installation Euro Style Restroom Partitions, Phenolic LT — FLOAT Series
Bradley • AD3-FLOAT_Install Rev. A 12/10/2021
5Assembling the Feet
Insert the foot through the lower heavy U-bracket.
A
Place the heavy U-bracket with foot into the foot drill
hole located in the partition panel.
B
Use a rubber mallet to tap the foot further into the drill
hole.
C
Be sure to place loose escutcheon above the flange
of the foot.

10
Euro Style Restroom Partitions, Phenolic LT — FLOAT Series Installation
12/10/2021 Bradley • AD3-FLOAT_Install Rev. A
6Mounting the Wall Brackets
Temporarily place the end pilaster into the U-bracket.
A
Mark drill holes for the wall bracket.
B
Drill the marked holes using an 8 mm drill bit.
C
Insert the 8 mm x 51 mm plastic anchors into the
pre-drilled holes for the wall brackets.
D
Tightly secure the brackets with the 5.5 mm x 60 mm
countersunk screws.
E

11
Installation Euro Style Restroom Partitions, Phenolic LT — FLOAT Series
Bradley • AD3-FLOAT_Install Rev. A 12/10/2021
Apply glue (sticks and seals) to the inner legs of the
U-brackets.
A
Place the middle panel with the middle pilaster into
the rear profile.
B
Support the front of panels and pilasters using
floor jacks.
C
Use a standard lever and 4D laser level to be sure the
panel is level and perpendicular with the floor.
D
7Installing Middle Panel & Side Panel

12
Euro Style Restroom Partitions, Phenolic LT — FLOAT Series Installation
12/10/2021 Bradley • AD3-FLOAT_Install Rev. A
8Installing Headrail
Insert the square finish flange over the front headrail.
A
Screw the mounting plate into the end thread on the
end of the headrail.
B
Insert the headrail into the upper holders and use the
set screws to attach the headrail onto the
holding blocks.
C
Use a rubber mallet to insert the end stopper into
the headrail.
D
When attaching the headrail, roughly adjust the door
clearances.

13
Installation Euro Style Restroom Partitions, Phenolic LT — FLOAT Series
Bradley • AD3-FLOAT_Install Rev. A 12/10/2021
9Installing Doors
Hang the doors on the pre-installed hinges, and then
pull the door shut to align with the system.
A
10 Aligning the System
To make any adjustments, move the two end pilasters
from side to side and/or up and down.
For information regarding the LED occupancy indicator,
refer to "Appendix A: LED Occupancy Indicator" on
page 20.
Position the front door clearance by clamping the
3 mm thick spacers or wedges between the doors and
the pilasters.
A
Verify the door gap is parallel and the door stop
is level. Also, verify the top edges of the system
components are in line with each other.
B

14
Euro Style Restroom Partitions, Phenolic LT — FLOAT Series Installation
12/10/2021 Bradley • AD3-FLOAT_Install Rev. A
11 Pre-Drilling the System
Verify the system is properly aligned before securing in place.
Pull the support leg down until it is firmly seated on the
floor. Secure the support to the floor using two 6 mm
plastic anchors and 4.8 mm x 38 mm screws. Pre-drill
into the floor through the holes in the flange.
B
Secure the wall bracket to the end pilasters using
5.5 mm x 25 mm pan head screws.
A
Slide the lower heavy U-bracket up, firmly under the
partition panel.
C
Use a 4.2 mm drill bit to drill through the heavy
U-bracket at the base, and then secure the bracket in
place using 4.8 mm x 25 mm countersunk screws.
D
Drill the upper heavy brackets in the same manner.
E
If desired, rivets can be used to secure panel to back
wall in addition to the brackets.

15
Installation Euro Style Restroom Partitions, Phenolic LT — FLOAT Series
Bradley • AD3-FLOAT_Install Rev. A 12/10/2021
12 Mounting Headrail
Hold the square headrail in the correct position against
the wall and mark the locations of the screw holes.
Drill these wall locations using a 4.2 mm drill bit.
Insert two 6 mm anchors at these locations.
Slide the square finish end flange over the headrail.
Line up headrail flange against the inserts and screw
in the two 5.6 mm x 32 mm countersunk screws.
Slide the finish flange over the screw flange using
silicone to secure.
A
When the width of the end pilaster is more than
125 mm wide, attach stabilizers to connect the end
pilasters and headrail. Stabilizers are used to reinforce
the system.
B
If indicated on the drawing, attach the stabilizer to the
top edge of the end pilaster using 4.8 mm x 50 mm
countersunk screws and to the bottom of the headrail
using 4.8 mm x 25 mm countersunk screws.
C
The stabilizers are indicated on the drawings if
necessary.

16
Euro Style Restroom Partitions, Phenolic LT — FLOAT Series Installation
12/10/2021 Bradley • AD3-FLOAT_Install Rev. A
13 Riveting Wall Connections
Rivet all parts with the U-bracket to the wall.
Use 4.8 mm x 16 mm stainless steel rivets for
all rivet locations.
Where indicated, rivet all U-brackets to panels and/or
pilasters. Measure down from top edge of U-bracket
approximately 100 mm, up from bottom edge of
U-bracket, and middle of U-bracket, and then pre-drill
using a 5 mm drill bit.
A
Manually insert rivets into the pre-drilled holes. Use a
rivet gun to tighten the rivets into the holes.
B
Glue the cover plates onto the bracket.
C

17
Installation Euro Style Restroom Partitions, Phenolic LT — FLOAT Series
Bradley • AD3-FLOAT_Install Rev. A 12/10/2021
14 Mounting Door Latches
Using a 3 mm hex Allen wrench, insert the set screw
until it is flush with the surface of the square hole.
Place the outside frame of the interior portion of the
latch onto the surface of the door.
Align the holes of the interior piece of the latch to the
outside frame of the door knob, now mounted on the
door. Bolt together using the 5 mm x 65 mm screws.
Set the red/white indicator to white with the handle in
the vertical position.
With the indicator color windows aligned to the top and
bottom positions, insert a 5 mm x 65 mm screw into
the bottom and securely tighten.
A
B
C

18
Euro Style Restroom Partitions, Phenolic LT — FLOAT Series Installation
12/10/2021 Bradley • AD3-FLOAT_Install Rev. A
15 Mounting Hooks & Bumpers
Mark the location for the hook on the inside of the
door (300 mm from the top edge in the middle of the
door).
A
Pre-drill the hook mounting holes using a 4 mm
drill bit. Only drill through the first wall of the door, not
the entire door.
B
Insert the supplied rivets (4 mm x 16 mm) into the top
pre-drilled mounting hole.
C
Use a rivet gun to attach the hook to the mounting
hole.
D
Use a level to verify the hook is level, and then drill
and rivet the second hole in the hook.
E

19
Installation Euro Style Restroom Partitions, Phenolic LT — FLOAT Series
Bradley • AD3-FLOAT_Install Rev. A 12/10/2021
Attach the door bumper to the inside pilaster using
HB45 construction adhesive.
F
Use tape to hold the door bumper in place until the
adhesive dries.
G

20
Euro Style Restroom Partitions, Phenolic LT — FLOAT Series Installation
12/10/2021 Bradley • AD3-FLOAT_Install Rev. A
Appendix A: LED Occupancy Indicator
The LED occupancy light strips, visible from the front and back of the pilasters, are pre-installed in the pilaster near the latch while
at the factory. Always place the indicators next to the door at the latch location. The activation of the LED is made with a magnetic
switch in the strike area in the edge of the pilaster. The LED indicator strips are standard 500 mm long but can be ordered in
200 mm lengths, if desired.
It is recommended that each LED indicator strip has its own power supply—multiple strips on one power supply transformer
may result in uneven light intensity.
It is recommended that each LED indicator be connected to its own low voltage transformer (not included).
Contact a Bradley representative for transformer recommendations.
Low Voltage Wire Routing Information
• The low voltage wire is included when LED indicators are ordered. Each LED indicator strip requires 12 VDC.
• Each LED indicator requires 3.6W of power.
• The LED indicator lights are on continuously. The LED is green when stall is unoccupied, and red when the stall is occupied
and the latch is locked.
• The low voltage wire routing depends on the location of the LED strips in pilasters. Interior stalls require routing the wires
along the top of the panels, running to the back wall. End stalls next to walls require routing the wires to the near wall
perpendicular to the back wall.
• Wires at back wall locations must have a minimum of 5 meters beyond back wall entrance location.
• Where the wires protrude from the fixed walls, center wires along the top of the panels so the wires run into the edge of the
panels. Verify this location is along the centerline of the panel and is approximately 10 mm from the top edge of the panel.
Example: If the bottom of the panel is 100 mm above the finished floor and the panel is the standard 1980 mm, then the
dimension from the floor to the center location of the wire placement would be 2070 mm.
• The LED is activated by a magnetic switch located in the edge opening on the pilaster at the latch location. Internal switch
activation is most prominent at the upper and lower location of this switch. The middle of this switch is not a proper activation
area. Be sure to locate the latch throw from door latch at the upper or lower area of the pilaster switch. The switch may have
to be adjusted. If the latch throw is too far separated from the switch, additional small magnets may be required.
