CONTENTS
WARNINGS.............................................................................................. 2
IMPORTANT SAFETY INSTRUCTIONS......................................................3
PACKAGE CONTENT.................................................................................7
IDENTIFICATION OF CONTROLS..............................................................8
DVD PLAYER................................................................................................................ 8
EXTRA MONITOR......................................................................................................... 10
REMOTE CONTROL.......................................................................................................12
SETTING UP YOUR PLAYER....................................................................15
CONNECTING TO AC POWER......................................................................................... 15
INSTALLING YOUR PLAYER IN A VEHICLE........................................................................... 15
CONNECTING TO A CAR CIGARETTE LIGHTER SOCKET.......................................................... 17
CONNECTING A TV OR MONITOR................................................................................... 18
CHARGING THE INCORPORATED BATTERY OF THE DVD PLAYER.......................................... 18
OPERATION........................................................................................... 19
PLAYING A DISC.......................................................................................................... 19
CONTROLLING PLAYBACK.............................................................................................. 19
ADJUSTING THE VOLUME.............................................................................................. 20
REPEAT VIEWING........................................................................................................ 20
DISPLAYING DISC INFORMATION.................................................................................... 21
SELECTING AN AUDIO LANGUAGE.................................................................................. 21
SELECTING A SUBTITLE LANGUAGE................................................................................. 21
SELECTING A VIEWING ANGEL....................................................................................... 21
USING A DVD MENU.................................................................................................. 22
USING THE TITLE FUNCTION.......................................................................................... 22
SETTING PARENTAL CONTROLS...................................................................................... 22
VIEWING PHOTOS....................................................................................................... 23
USING USB FUNCTION................................................................................................. 23
USING THE SETUP MENU.............................................................................................. 23
SPECIFICATIONS.................................................................................... 25
CLEANING AND MAINTENANCE............................................................26
TROUBLESHOOTING..............................................................................27
Downloaded from www.vandenborre.be

2
WARNINGS
This appliance is intended for domestic household use only and should
not be used for any other purpose or in any other application, such as
for non‐domestic use or in a commercial environment.
Prior to cleaning or other maintenance, the appliance must be
disconnected from the supply mains.
The ventilation should not be impeded by covering the ventilation
openings with items, such as newspapers, table‐cloths, curtains, etc.
No naked flame sources, such as lighted candles, should be placed on
the apparatus.
The apparatus shall not be exposed to dripping or splashing and that
no objects filled with liquids, such as vases, shall be placed on the
apparatus.
Ventilation
Allow at least a 10 cm gap all around the product.
This apparatus is not suitable for use in a tropical climate.
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type.
Attention should be drawn to the environmental aspects of battery
disposal.
Batteries (battery pack or batteries installed) shall not be exposed to
excessive heat such as sunshine, fire or the like.
Downloaded from www.vandenborre.be

3
Where the MAINS plug or an appliance coupler is used as the
disconnect device, the disconnect device shall remain readily operable.
IMPORTANT SAFETY INSTRUCTIONS
Do not expose the DVD player to excessive heat such as strong
sunshine, fire or the like as this strong sunshine can contribute to an
overheating of the battery and can damage the unit.
Only use attachments/accessories specified by the manufacturer.
Unplug this apparatus during lightning storms or when not in use
for long periods of time.
Symbols
This equipment is
double insulated and an
earthconnectionisnot
required.
This mark is applied to show
the equipment conforms to
European safety and
electromagnetic
compatibility standards.
Dangerous voltage
constituting a risk of
electric shock is present
inside this equipment.
There are important
operating and maintenance
instructions in the literature
accompanying this
equipment.
Downloaded from www.vandenborre.be

5
Battery handling and usage
Remote control battery:
The battery should only be replaced by adults. Do not allow children to
use the remote control unless the battery cover is attached.
The battery type used in the remote is one CR2025 3V
Lithium battery which is accessible and can be replaced.
Remove the battery holder located on the bottom of the
remote control to remove the battery.
Incorporated Battery
The battery type used in the unit is one lithium battery. The battery is
in‐cooperated and is not readily accessible.
The battery must be disposed of at your local recycling point.
Installing Remote Control Battery
Push○
1and pull○ 2to slide out the battery holder from the remote
control and insert one 3V CR2025 lithium battery in the battery holder
with the print face up, then replace the battery holder.
WARNING:
To save power: switch off mains power or pull out the AC adapter
when you are not using the apparatus.
Never operate the apparatus and try to view video while driving a
vehicle.
To prevent injury, this apparatus must be securely attached to the car
seats as in accordance with the installation instructions.
Downloaded from www.vandenborre.be

6
Class 1 laser product
This product contains a low power laser device. Invisible
laser radiation when the enclosure is opened and interlocks
are defeated.
Avoid exposure to beam.
This digital video disc player employs a laser system. Use of controls,
adjustments, or the performance of procedures other than those
specified herein may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not open the enclosure.
Never stare directly into the laser beam.
Do not install this product in a confined space such as a book case or
similar unit.
Manufactured under license from Dolby Laboratories
"Dolby" and the double‐D symbol are trademarks of Dolby
Laboratories.
Confidential Unpublished Works. Copyrights 1992‐1997 Dolby
Laboratories, All rights reserved.
Region Code
This DVD player is designed and manufactured for play ofregion
“2” encoded DVD software.
Downloaded from www.vandenborre.be

7
Notes on Discs
Handling Discs
Do not touch the play side of the disc. Hold the disc by the edges so
that fingerprints do not get on the surface. Never stick paper or tape
on the disc.
Storing Discs
After playing, store the disc in its case. Do not expose the disc to direct
sunlight or source of heat and never leave it in a parked car exposed to
direct sunlight.
Cleaning Discs
Fingerprints and dust on the disc can cause poor picture quality and
sound distortion. Before playing, clean the disc with a clean cloth.
Wipe the disc from the centre out.
Do not use strong solvents such as alcohol, benzine, thinner,
commercially available cleaners, or anti‐static spray intended for older
vinyl records.
PACKAGE CONTENT
Your box should contain:
•7” main DVD player
•7” extra monitor
•Carry bag
•Earphones (2)
Downloaded from www.vandenborre.be

8
•Remote control with battery
•Power adapter
•Car adapter
•AV/DC cable
•AV cable
•Car brackets (2)
•Instruction manual
IDENTIFICATION OF CONTROLS
DVD player
Downloaded from www.vandenborre.be

9
# Component Description
1 SETUP button Press to open or close the Setup menu.
2button Press to move up in a list or menu.
Hold this button down for over one second to
go to the previous chapter, track, or scene
during disc playback.
3button Press to move down in a list or menu.
Holding this button down for over one second
to go to the next chapter, track, or scene during
disc playback.
4button Press to move left.
Holding this button down for over one second
to decrease the volume.
5button Press to move right.
Holding this button down for over one second
to increase the volume.
6 ENTER button Press to confirm a selection.
7 SOURCE button Press to enter Disc/USB mode and then use
/to switch between disc and USB modes.
8 ON/OFF switch Slide to turn your DVD player on or off.
9USB port Connect a USB device to this port.
10
Earphone jack
Plug earphones into this jack.
11 AV OUT jack Connect the extra monitor to this jack using
AV/DC cable, or connect a TV or monitor to this
jack using the supplied AV cable.
12 DC OUT jack Connect the extra monitor to this jack using the
AV/DC cable.
13 DC IN jack Connect the power adapter or car adapter to
this jack.
Downloaded from www.vandenborre.be

10
Extra monitor
# Component Description
14 MUTE button Press to turn on or turn off sound of the extra
monitor.
15 button Press to move up in the mode menu.
16 button Press to move down in the mode menu.
17 button Press to decrease the volume.
In the mode menu, press to move left.
18 button Press to increase the volume.
In the mode menu, press to move right.
19 MODE button Press to open or close the Mode menu.
20 BACKLIGHT
button
Press to turn on or turn off the screen backlight.
21 DC IN jack Connect the DC OUT jack on your DVD player to
this jack using the AV/DC cable.
22 AV IN jack Connect the AV OUT jack on your DVD player to
this jack using the AV/DC cable.
23
Earphone jack
Plug earphones into this jack.
24 ON/OFF switch Slide to turn the extra monitor on or off.
