Type 3731
Modèle 3731
Modelo 3731
3-731-157/01/VIII-05/G2
USA/CDN
Internet:
www.oralb.com
www.braun.com
English 4
Español 15
Français 25
D 25.546.4
D 25.526.4
D 25.516.4
3731157_D25NA_S2 30.07.2005 12:36 Uhr Seite 1

Oral-B
Oral-
B
aj
b
c
d
e
g
f
h
i
Oral-B
3
4
2
1
3731157_D25NA_S3 30.07.2005 12:40 Uhr Seite 3

4
Congratulations!
You have chosen the world’s most technologically
advanced rechargeable toothbrush. Oral-B®Triumph™
will provide you with the superior* oral care results you
have been striving to achieve.
Oral-B Triumph has an innovative new brushing
technology that is clinically proven to deliver cleaner
and whiter teeth. Its advanced Oral-B®FlossAction™
brushhead features MicroPulse™ bristles that gently
penetrate deep between teeth for a floss-like clean. It
provides such a superior clean, you won’t believe how
great you feel about your teeth.
Oral-B Triumph is a significant advancement in
brushing technology featuring the following:
•Smart Technology, an interactive feature that
gives you feedback to maximize your brushing
performance.
•Innovative Brushheads with new brushing
technology provide complete cleaning for your
teeth and outstanding gum care.
•Different Brushing Modes let you customize your
brushing routine to address your specific needs.
•An innovative SmartPlug™ charger makes Oral-B
Triumph convenient for traveling.
Oral-B Triumph is brought to you by Oral-B, the
worldwide leader in toothbrushes and the brand more
dentists use themselves.
If you have any questions about using the new Oral-B
Triumph toothbrush, please visit our web site at
www.oralb.com or call our toll free telephone number:
1-800-566-7252
Thank you for choosing
Oral-B Triumph.
Sincerely,
Bruce Cleverly
President, Oral-B
Smart Technology ... Brilliant Results.™
* vs. brushing with Oral-B®FlexiSoft® brushhead
Oral-B
3731157_D25NA_S4-38 01.08.2005 10:04 Uhr Seite 4

5
IMPORTANT SAFEGUARDS
Oral-B Triumph has been carefully designed to offer you and your family a new and
unique brushing experience that is both safe and effective.
However, when using electrical products, basic safety precautions should always be
followed. Please read carefully before use.
DANGER
In order to reduce the risk of electrocution:
1. Do not place or store the charger where it can fall or be pulled into a tub or sink.
2. Do not place the charger in water or other liquid.
3. Do not reach for a charger that has fallen into water. Unplug immediately.
WARNING
To reduce the risk of burns, electrocution, fire or injury:
1. Close supervision is necessary when this product is used by or near children or
invalids.
2. Use this product only for its intended use as described in this manual. Do not use
attachments not recommended by the manufacturer.
3. Keep cord away from heated surfaces.
4. Never drop the appliance or insert any object into any opening of the appliance.
5. Never operate this product if it has been dropped or damaged, if it is not working
properly, or if the SmartPlug is damaged or has been dropped into water. If any of
these occur, please contact a service center and return the product for examination
and repair.
6. This appliance is provided with a SmartPlug with integrated Safety Extra Low Voltage
power supply. Do not exchange or manipulate any part of it.
SAVE THESE INSTRUCTIONS
3731157_D25NA_S4-38 01.08.2005 10:04 Uhr Seite 5

6
Description of Oral-B T
Description of Oral-B Triumph riumph
a Oral-B FlossAction brushhead
b On/off button
c Brushing mode button
d Handle
e SmartDisplay
f SmartPlug charger (includes charging ring and SmartPlug)
g Base plate
h Base station
i Protective cover
j Oral-B®PowerPolisher™ brushhead (not with all models)
Connecting and char
Connecting and charging ging
Oral-B Triumph has a waterproof handle, is electrically safe
and is designed for use in the bathroom.
To assemble the base station (h) as a charging unit, detach
the base plate (g) first (1, page 3). Place the charging ring into
the base station and attach the base plate as shown (2and
3, page 3). Then insert the protective cover (i) on the back of
your base station (see diagram 4, page 3).
• Plug the SmartPlug into an electrical outlet and place the
toothbrush handle (d) on the charging unit. Alternatively,
Oral-B Triumph can be charged by placing the handle
directly into the charging ring while the SmartPlug is
plugged in.
• A battery symbol should appear in the SmartDisplay. The
battery symbol will fill up while the handle is being charged
and «Charging» will be displayed. When the handle is fully
charged, the SmartDisplay shows «Full Charge». A full
charge takes at least 12 hours and enables approximately
two weeks of regular brushing.
Please note: If the battery symbol is not displayed
immediately, continue charging. It will appear in 10 - 15
minutes.
• When the rechargeable battery is low, the bars of the
battery symbol will disappear and «Low» will be displayed.
Your toothbrush will slow down and then stop. It is time
to recharge Oral-B Triumph. When the battery is fully
discharged, «Empty» is displayed. It will then need a
15-minute charge before you can use it for a 2-minute
brushing.
12 h
Oral-B
Full Charge
3731157_D25NA_S4-38 01.08.2005 10:04 Uhr Seite 6

7
• For everyday use, the toothbrush handle can be stored
on the charging unit to maintain it at full power. There is
no risk of overcharging the battery.
• To maintain the maximum capacity of the rechargeable
battery, unplug the charging unit and fully discharge the
handle by regular use at least every 6 months.
Oral-B Triumph is convenient for traveling because you only
need the compact SmartPlug charger and an appropriate
travel adapter for recharging in foreign countries. The
SmartPlug automatically adapts to any voltage worldwide.
For electric specifications, see printing on the SmartPlug.
Personalizing Oral-B T
Personalizing Oral-B Triumph riumph
Before getting started, you can program your toothbrush
so that it meets your specific needs. Oral-B Triumph has
innovative Smart Technology that lets you choose the
language and the timer that works best for you.
Select your language
Oral-B Triumph comes with the English language activated. If
you wish to switch to another language, proceed as follows:
Press and hold the brushing mode button (c) until «English» is
displayed. By briefly pressing the on/off button (b) you can
scroll through 13 different languages. To confirm your desired
language, briefly press the brushing mode button again. This
will also lead you directly to the timer choice menu.
Select your timer
The «2-Minute Timer» indicates by a long stuttering sound
when the dentist recommended 2-minute brushing time has
been reached. The «Professional Timer» helps you brush all
four quadrants of your mouth equally. It signals with a short
stuttering sound at 30-second intervals that it is time to
move to the next quadrant of your mouth, followed by a long
stuttering sound when you reach the recommended two
minute mark.
Oral-B Triumph comes with the «Professional Timer»
activated. If you wish to switch to the «2-Minute Timer» after
you have confirmed the language, simply press the on/off
button to change the setting. Then press the brushing mode
button to confirm your choice.
3
0
s
e
c
3
0
s
e
c
3
0
s
e
c
3
0
s
e
c
3731157_D25NA_S4-38 01.08.2005 10:04 Uhr Seite 7

8
Using Oral-B T
Using Oral-B Triumph riumph
Attach an Oral-B brushhead to the handle. You can use any
kind of toothpaste. To avoid splashing, guide the brushhead
to your teeth before switching the appliance on.
Brushing technique
• Guide the brushhead slowly from tooth to tooth.
• Hold the brushhead in place for a few seconds before
moving on to the next tooth.
• Brush the gums as well as the teeth, first the outsides, then
the insides, finally the chewing surfaces.
• Do not press too hard or scrub, simply let the brush do all
the work.
To help you get optimum brushing results, Oral-B Triumph
has a pressure control feature to ensure that the right degree
of pressure is applied. This helps protect your gums from
excessive brushing and makes your toothbrush easy to
operate. If too much pressure is applied, the oscillating
movement of the brushhead will continue but the pulsation
will stop. In addition to feeling the change, you can also hear
a different sound.
Oral-B
Oral-B
3731157_D25NA_S4-38 01.08.2005 10:04 Uhr Seite 8

9
Brushing modes
Oral-B Triumph offers different brushing modes for varying
oral care needs:
«Clean» – Superior whole mouth cleaning.
«Soft» – Gentle, yet thorough cleaning for
sensitive areas.
«Massage» – Gentle stimulation of gums.
«Polish» (deluxe – All over polishing and whitening
model only) for occasional or everyday use.
How to switch between brushing modes:
•Oral-B Triumph automatically starts in the «Clean» mode
when pressing the on/off button.
• To shift from the «Clean» to the «Soft» mode, press the
brushing mode button once.
• If you wish to switch to the «Massage» mode, press the
brushing mode button again and let the brushhead pulse
against your gum line.
• The «Polish» mode (deluxe model only) is best used with
an Oral-B PowerPolisher brushhead. Once the Oral-B
PowerPolisher is attached, press the on/off button and
your toothbrush automatically starts in the «Polish» mode
(please see «Brushheads»).
• To return from any other mode to the «Clean» mode, press
and hold the brushing mode button.
• To turn your brush off, press the on/off button.
During brushing, the SmartDisplay shows the brushing mode
you have selected, followed by your actual brushing time.
When you finish brushing, the total brushing time will be
displayed for 30 seconds before the display switches back to
the battery charge level. To directly get to the battery charge
level display, you can clear the brushing time display by
pushing the brushing mode button.
In the first few days of using Oral-B Triumph, your gums may
bleed slightly. In general, bleeding should stop after a few
days. Should it persist after 2 weeks, please consult your
dentist or hygienist. If you have sensitive teeth and gums,
Oral-B recommends using the «Soft» mode.
Oral-B
3731157_D25NA_S4-38 01.08.2005 10:04 Uhr Seite 9

10
Brushheads
The Oral-B FlossAction and Oral-B PowerPolisher brushheads
contain a «smart chip» to communicate with the electronics
inside the Oral-B Triumph handle. The «smart chip» works
for you, automatically switching to the appropriate brushing
mode for the attached brushhead. Nevertheless, you can
select other brushing modes to customize your routine.
Oral-B FlossAction brushhead
The Oral-B FlossAction brushhead is recommended for
everyday deep cleaning. It features MicroPulse bristles that
get deep in hard-to-reach areas between your teeth, gently
removing hidden plaque. The brushhead’s outer bristles
surround each tooth, providing superior overall plaque
removal.
Oral-B PowerPolisher brushhead (not with all models)
The Oral-B PowerPolisher brushhead is for occasional or
everyday polishing. It features a dentist-inspired polishing cup
to remove stains from coffee, tea and tobacco for effective
brightening.
We do not recommend using the Oral-B PowerPolisher or
Oral-B FlossAction brushhead with braces. The Oral-B Ortho
brushhead is specifically designed to clean around braces
and wires and can be used with the Oral-B Triumph.
Oral-B Triumph has Smart Technology that helps you
remember when to replace your brushhead to get optimum
results. Dentists recommend that you change your brushhead
every three months. As soon as your Oral-B FlossAction or
Oral-B PowerPolisher brushhead has surpassed the
recommended usage, the SmartDisplay shows «Replace
Brushhead». Replace with a new brushhead to get optimum
brushing results. If you notice unusual wear before receiving
the «Replace Brushhead» message, replace your brushhead
immediately.
3731157_D25NA_S4-38 01.08.2005 10:04 Uhr Seite 10
