Braun 59224 Assembly instructions
Visit our website at: http://www.harborfreight.com
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 22d
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2021 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Page 2 For technical questions, please call 1-888-866-5797. Item 59224
IMPORTANT SAFETY INFORMATION
To prevent serious injury, FIRE, and EXPLOSION:
1. Only use included charging adaptors. Other
adaptors may damage tool or cause fire
2. Do not operate in explosive atmospheres, such as in
the presence of flammable liquids, gases, or dust.
3. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure.
4. Not a toy. Keep out of reach of children.
5. Contains Li-Ion battery. Battery must be
recycled or disposed of properly. Do not open,
crush, heat above 140° F or incinerate.
Specifications
Battery Li-Ion, 7.4V, 4400 mAh
Bulb Type LED
Charge Time 6.5 to 7 hours
Input Rating 5VDC, 2A
Setup - Before Use
Functions
Wrist
Strap
Stand / Hanger
(adjustable)
Lock Switch
(shown in the unlocked position)
Hand
Grip
Trigger
Belt Clip
Page 3For technical questions, please call 1-888-866-5797.Item 59224
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Charging the Battery
Note: Before using light for the first
time, fully charge the battery.
1. Open the Charge Port Cover using a suitable tool.
2. Plug one end of USB adapter into Charging
Jack. Plug other end to a 5VDC 2A source.
3. When all 4 LED charge lights turn
blue, the Battery is fully charged.
4. Disconnect the USB Cable.
5. Close the Charge Port Cover
6. To maintain waterproof seal, use
a suitable tool to tighten screw on
Charge Port Cover. Do not overtighten.
Charging Jack
LED Charge
Lights
NOTICE: Do not leave the Battery in a discharged
state. Charge the Battery every 3 months if the
Spotlight isn’t in use. This will keep the Battery
from wearing down and add to its life.
General Operating Instructions
1. Hold the Spotlight using the Hand Grip.
2. Move the Lock Switch UP to unlock it and then
turn ON the Spotlight by squeezing the Trigger.
3. Select the desired light output using the Trigger:
One press for low beam, two for medium beam,
three for high beam, four for SOS and five for
strobe. The sixth press turns the light OFF.
4. Use the Lock Switch to lock the light on or
off. When the Lock Switch is moved DOWN,
the Trigger is locked in its last setting.
Note: The Spotlight can sit on its
back and can float in water.
Note: The Spotlight’s Stand / Hanger can be adjusted,
extended and positioned as desired or hung.
Stand / Hanger
5. When finished using the Spotlight, turn it OFF
and lock Trigger to prevent accidental operation.
6. After use, wipe Spotlight with a clean soft cloth
and store indoors out of children’s reach.
Battery Removal
Note: Contains Li-ion battery. Battery must be
recycled or disposed of properly. Do not open,
crush, heat above 140° F or incinerate.
1. Remove the front lens cover by unscrewing it.
2. Remove the reflector.
3. Remove the six screws holding
the heat sink in place.
Screws
4. Gently remove the heat sink to expose the battery.
5. Cut the two wires connected to
the battery one at a time.
6. Gently pull the battery out of light housing.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Replacement parts are not available for this item. Reference UPC 193175460547
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
