Braven 650 User manual

THANK YOU
Thank you for choosing the BRAVEN SIX Series, the
world's
most talented line of portable wireless speakers.
BRAVEN is the first high-fidelity wireless speaker
to
combine amazing sound quality with a multi-tasking
speakerphone and mobile phone charger.
Now you can
amplify your mobile life and enjoy your music, movies
and games the way they were meant
to be heard. And
with BRAVEN's built-in backup battery you will never
have
to worry about your phone or mp3 player running
out
of battery while you' re on-the-go.
BRAVEN puts the power
of a live performance in the
palm
of your hand.
BRAVEn
CONNECTING TO YOUR BRAVEN
Connect to your BRAVEN speaker wirelessly
through Bluetooth®.
Daisy-chain and connect wired (non-Biuetooth®)
devices
to your BRAVEN speaker with the
included 3.5mm audio cable.
CHARGING YOUR BRAVEN
Use the micro USB port on the right side of the
speaker
to charge your BRAVEN. Use the USB
port on the left side
to charge external devices.

CONTENTS
GET TO KNOW YOUR BRAVEN...............................................................................4
CHARGING ..............................................................................................................5
TURN ON &SYNC ...................................................................................................6
EXTERNAL CHARGING............................................................................................7
SPEAKERPHONE..............................................
.. .. ...................................................8
DEVICE CONTROL & DAISY-CHAINING.................................................
.. ................9
TROUBLESHOOTING .............................
.. ............................................................. .. 10
DEVICE SPECIFICATIONS........................................................................................
11
WARNINGS &CAUTIONS ........................................................................................12
LEGAL INFORMATION ............................................................................................. 13
BRAVEn

GET TO KNOW YOUR BRAVEN
BATTERY INDICATOR LIGHT
BATTERY CHECK BUTTON
3.5
MM AUDIO-OUT JACK
(daisy-ch ain)
EXTERNAL USB CHARGING
PORT
BRAVEn
LEFT S ID E
PHONEJPAIRING/PAUSE BUTTON
POWER SWITCH
POWER/SYNC STATUS LIGHT
BRAVEN CHARGING PORT
VOLUME UP/SKIP
TRACK
3.5 MM AUDIO-IN JACK
VOLUME DOWN/SKIP BACK

CHARGING
• Before using your BRAVEN speaker for the first
time, charge it until the Power/Sync Light turns off,
indicating a full charge (typically 2
to 4 hours).
• For the fastest charge, plug the included USB-
to-Micro-USB cable into the included wall
power
adapter. Plug the Micro-USB connector end into the
BRAVEN Charging Port.
• You can also charge using a powered USB port
on a computer,
but charge time will be longerthan
when charging from a wall outlet.
CHARGE INDICATOR LIGHTS:
To check your BRAVEN's battery charge level
press the Battery Check Button located on the
left side
of your speaker. The Battery Indicator
Light will illuminate indicating the current battery
charge level.
0 White light =
50 - 1 00% charge
• Blue light = 10 -
50%
• Red light= 0- 10%
BRAVEn

TURN ON & SYNC
1. Slide the power switch up to the "on"
position. You will hearthe BRAVEN
power
up sound.
2. Activate Bluetooth®on the phone
or
device you are pairing with (see your
device's instruction manual for information
on activating its Bluetooth®settings).
3. Press and hold the Pairing Button on
the BRAVEN speaker until the Sync
Status Light begins
to flash rapidly
and you hearthe BRAVEN sync
sound.
BRAVEn
4. Go to your phone or device's
Bluetooth®settings and select the
BRAVEN device from the list.
5. If asked for a passcode enter "0000"
You only need
to do this once for each device you are
syncing
to your BRAVEN speaker. Your BRAVEN speaker
will remember the last 8 devices it has paired with.
NOTE: Ifthe BRAVEN does not have an active Bluetooth®
connection and is left on, it will shut itself off after
30
minutes. To restart the BRAVEN you will need to slide
the switch
to the "off" position and then back to the "on"
position.

EXTERNAL CHARGING
BRAVEN is designed to charge USB devices that draw
from 0.3A - 1A (most cellphones &
mp3 players. Tablets and
other 2A devices cannot be charged by your BRAVEN speaker)
using the full-sized USB port on the left side of the
speaker.
To use external charging:
1. Turn the BRAVEN
power switch on.
2. Plug the USB power cable that came with your
phone,
mp3 player, or other mobile device into the
USB port on the BRAVEN speaker.
3. Plug the other end
of the cable into your mobile
device, and it will immediately begin charging.
APPROXIMATE CHARGING CAPACITY
On a full charge, without music playing, your
BRAVEN speaker can charge external devices to
the following approximate levels:
BRAVEN 650- will charge a typical smartphone
approximately 80-100% (depending
on model and
battery size)
BRAVEN 625s- will charge a typical
smartphone approximately 70-90% (depending on
model and battery size)
BRAVEN 600 -will charge a typical smartphone
approximately 50-70% (depending
on model and battery
size)
BRAVEn

SPEAKERPHONE
You can use your BRAVEN speaker as a conference
calling device if your phone supports this feature.
When the BRAVEN
is synced via Bluetooth®with your
phone and a call comes
in , the speaker will beep.
Music, if playing, will pause, and your ringtone will play
over the speaker.
ANSWERING A CALL
Press the Phone/Pairing Button on the BRAVEN
to answer the call over the speaker. The call will be
answered using the BRAVEN's microphone and
speakerphone.
BRAVEn
If you press the answer button on your phone, some
phones may answer via the mobile device and
not the
BRAVEN speaker.
You may need to manually select
the BRAVEN speaker as the audio source
to use it as
the speakerphone. (Consult yourBluetooth®device's user
manual for instructions on selecting an audio source
.)
Press the Phone/Pairing Button again to end the call.
Alternatively, you may press the end call button on your
mobile phone
to end the call.
Once the call
is ended, your music will resume playing if
your mobile phone allows this feature.

DEVICE CONTROL
While playing music and movies you can pause and
skip tracks forward and
back by using the following
buttons on the BRAVEN speaker.
@
0
8
Pause: Press the Phone/Pairing/Pause Button
for
0.5 seconds. Press again to resume playback.
Skip to nexttrack: Press the Volume Up/Skip
Track Button for 3 seconds.
Skip back: Press the Volume Down/Skip Back
Button for 3 seconds.
(To skip to the previous
track instead
of to the beginning of the current
track, press and hold the Volume Down Button
within the first few seconds
of the current song)
DAISY-CHAINING
You can daisy-chain multiple BRAVEN speakers
together for increased sound.
• Using the included 3.5mm audio cable, connect
the line-out
of your paired BRAVEN speaker to the
line-in port
of another BRAVEN speaker.
•
•
You can also connect via line-out to non-BRAVEN
or non-Biuetooth®-enabled speaker systems
(home, car, office, overhead systems, other portable
speakers,
etc .).
The paired BRAVEN speaker acts as a Bluetooth®
receiver, and audio will play on both the BRAVEN
and on the linked speaker systems. Volume can
be controlled independently on each speaker and
on the paired device.
BRAVEn

TROUBLESHOOTING
I CAN'T HEAR ANYTHING FROM
MY
SPEAKER
1. BRAVEN audio levels can
be
controlled
independently, both on the speaker and the
Bluetooth®source device. Check the volume levels
on both devices
to
ensure that they are turned
up
sufficiently.
2. If using the
3.5mm
cable, check that
the
cable is
fully inserted into both your device and the BRAVEN
speaker.
3.
Some devices experience volume loss when
connected
to
speakers through Bluetooth®.
(Please
refer to
your
device's
owner
's manual for further information.)
THE SIGNAL IS CUTTING OUT
1. A Bluetooth®signal can
be
affected
by
objects
that obstruct
the
BRAVEN from a clear path
to
the
playing device
to
which it is paired. Ensure
that
your
listening environment is conducive
to
the
33-foot
(1
0-meter) Bluetooth®range between your BRAVEN
and your playing device.
I'M
UNABLE TO PAIR WITH
MY
DEVICE
1. Check that the device you are attempting
to
pair with
is Bluetooth®compatible.
2. Follow TURN
ON
& SYNC instructions on page
6.
BRAVE
n
Mor-e
troublesllOOtJrlQ topiCS avalianle Ill the Ollilrle manual: braven
com
lllanuals

DEVICE SPECIFICATIONS
BRAVEn 650
BRAVEn 625s BRAVEn 600
PLAYTIME
20 hours* 16 hours* 12 hours*
DRIVERS 6W (3W per channel) 6W (3W per channel) 6W (3W per channel)
DECIBEL RATING 95 dB at 0.5m
95 dB at 0.5m 95 dB at 0.5m
FREQ.RESPONSE
180Hz- 13kHz +1- 3dB
180Hz- 13kHz +1- 3dB 180Hz -13kHz +I- 3dB
POWER ADAPTER Output: DC 5V 1A Output: DC 5V 1A Output: DC 5V 1A
SIZE 15.9cm x 6.4cm x 4.5cm 16cm x 6.5cm x 4.6cm 15.85cm x 6.4cm x 4.5cm
WEIGHT 12.6 oz. (360g) 11.6 oz. (330
g) 12 oz. (340g)
BLUETOOTH® RANGE 1Om/33ft. (line
of sight) 1Om/33 ft. (line of sight) 1Om/33 ft. (line
of sight)
*Approximate play time based on playing audio at medium levels overBluetootN p;. Song genre, tempo and volume will affectplay time.
BRAVEn

WARNINGS &
CAUTIONS
To reduce
the
risk
of
fire
or
electric shock,
do
not
expose
the
BRAVEN
to
rain
or
moisture. The BRAVEN should
not
be
exposed
to
dripping
or
splashing,
and
objects filled
with liquids, such as vases, should
not
be
placed on
or
nearit.
Do
not
use near bathtubs, washbowls, kitchen sinks, laundrytubs, in a
wet
basement, near a swimming
pool,
or
anywhere else that
water
is present.
As
with
any electronic products, use care
not
to
spill liquids into any part
of
the
product. Uquids can cause a failure
and/or
a fire
hazard. The
power
supply
must
be
used indoors only. It is neitherdesigned
nor
tested for charging outdoors, in recreation vehicles,
or
on
boats. Make
no
modifications
to
the
product
or
accessories. Unauthorized alterations
may
compromise safety, regulatory compliance, and system performance,
and
will void
the
warranty.
Do
not
place any
flame sources, such
as
lighted candles,
on
or
near
the
BRAVEN. The BRAVEN contains small parts that
may
be
a choking hazard
and
is
not
suitable
for
children
under
age 3.
Before use, fully charge
the
battery using
the
supplied
power
adapter.
Do
not
continue charging the battery
if
it does
not
reach full charge within the specified charging time.
Overcharging may cause
the
battery
to
become
hot, rupture,
or
ignite. Ifyou see any heat deformation
or
leakage, properly dispose
of
the
battery. Do
not
attempt
to
charge
the batteryin temperatures outside
the
range
of
32
°-
1
04
°F (0°
-40
°C}. If
the
battery begins
to
leak,
do
not
allow
the
liquid
to
come
in
contact
with your skin
or
eyes. If
contact
has been made, wash the affected area with plenty
of
water
and seek medical attention immediately.
Do
not
expose the
product
or
battery
to
excessive heat, including direct
sunlight
or
fire
and
storage
or
use inside cars in
hot
weather, where it can
be
exposed
to
temperatures in excess
of
115
°F (60°
C}
. Doing
so
may
cause
the
battery
and
power
supply
to
generate heat, rupture,
or
ignite. Using
the
product
in this manneralso may result in a loss
of
performance and a shortened life expectancy. Extended exposure
to
direct sunlight
may
damage
the
external appearance and material qualities.
Do
not
step on, throw,
or
drop
batteries
or
the
power
supply
or
device,
or
expose
them
to
a strong
shock. Do
not
pierce, crush, dent,
or
deform
the
batteries
or
power
supply in any way. Ifeither becomes deformed, properly dispose
of
it.
Do
not short-circuit batteries. Refer
all servicing
to
qualified service personnel. Servicing is required when
the
apparatus has been damaged in any way: such as
power
supply
cord
or
plug is damaged; liquid has
been spilled
or
objects have fallen into
the
BRAVEN; the BRAVEN has been exposed
to
rain
or
moisture,
does
not
operate normally,
or
has been dropped.
Do
not
attempt
to
service the BRAVEN yourself. Opening
or
removing covers
may
exposeyou
to
dangerous voltages
or
otherhazards
and
will void
the
manufacturer's warranty. To prevent risk
of
fire
or
electric shock, avoid overloading wall outlets, extension cords,
or
integral convenience receptacles.
Do
not
place your BRAVEN
on
high surfaces such
as
shelves.
During music playback
the
BRAVEN
may
vibrate
and
move
which could cause
the
speaker
to
shift and fall off
of
the
edge. Your Bluetooth device (mobile phone, music player,
tablet, laptop,
etc
.)
must
support
the
A2DP Bluetooth profile in order
to
work
wirelessly with your
new
BRAVEN SIX Series speaker. The A2DP profile is supported
by
most
recent mobile productswith built-in Bluetooth capability. Please refer
to
your device's user manual for details and instruction regarding
the
Bluetooth profiles it supports.
BRRVEn

LEGAL
INFORMATION
This device complies with part
15
of
the FCC Rules. Operation is subject
to
the following
two
conditions:
(1)
This device may
not
cause harmful interference,
and
(2)
this device must accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found
to
complywith the limits for a Class 8 digital device, pursuant
to
part
15
of
the FCC Rules. These limits
are designed
to
provide reasonable protection against harmful interference
in
a residential installation. This equipment generates, uses and can radiate radio
frequency energy
and
, if
not
installed and used
in
accordance with the instructions, may cause harmful interference
to
radio communications. However, there is
no guarantee that interference will not occur in a particular installation. Ifthis equipment does cause harmful interference
to
radio
or
television reception, which
can
be
determined
by
turning the equipment offand on, the user is encouraged
to
try
to
correct the interference
by
one
or
more
of
the following
measures:-
Reorient
or
relocate the receiving antenna.
-Increase
the separation between the equipment and receiver.
-.-connect
the equipment into an outlet
on
a circuit
different from that
to
which
the
receiver
is
connected. - Consult the dealer
or
an experienced radio/TV technician for help.
This device complies with IndustryCanada license-exempt RSS standard(s). Operation is subject
to
the following
two
conditions:
(1)
this device may
not
cause
interference, and
(2)
this device must accept any interference, including interference that may cause undesired operation
of
the device.
BRAVEn

•••••••••••••
............. :::::···········
••••••••••••••••••a:::::s:s:t
•••••••••••••••••••••••••••••
•••••••••••••••••••••••••••••
•••••••••••••••••••••••••••••
•••••••••••••••••••••••••••••
•••••••••••••••••••••••••••••
•••••••••••••••••••••••••••••
•••••••••••••••••••••••••••••
•••••••••••••••••••••••••••••
•••••••••••••••••••••••••••••
•••••••••••••••••••••••••• •• •
BRAVEn

··:··::::·:::::::i
::,:=··::!:: ••••••
::::::::::::::::::
::;:::::::::::::::
::::::::::::::::::
..... ,.....•..•.•.
·······•···••·
····
e~v~

International Adapter Instructions
To remove the current plug adapter, pull the release latch back on the
base unit.Then insert your desired adapter from
the top and slide down
intothe base until it clicks into place.
USA
Japan
Mexico
European Union
Philippines
Russia
UK
Hong Kong
Singapore
Australia
NewZealand
China
BRAVEn
Insert Adapter
Base unit
