Braven 805 User manual

OWNER’S GUIDE:
BRAVEN 805, BRAVEN 1100, and BRAVEN BRV-HD

1Full manual and troubleshooting: braven.com/manuals
GET TO KNOW YOUR BRAVEN
BATTERY INDICATOR LIGHTS
POWER
BUTTON
PAIRING /
PAUSE-RESUME
MUSIC
BATTERY CHECK BUTTON
ANSWER-
END CALL
BRAVEN CHARGING PORT
VOLUME UP /
SKIP TRACK
(press and hold)
EXTERNAL USB CHARGING PORT
VOLUME DOWN /
SKIP BACK
(press and hold)
3.5 MM AUDIO-IN JACK
•20% •40% •60% •80% •100%

2
ENG
TURN ON & BLUETOOTH®PAIRING
1. Press the Power button for 2-3
seconds to turn on your BRAVEN.
Press the same button again for
2-3 seconds to turn your BRAVEN
off.
2. Activate Bluetooth® on the phone
or device to which you are pairing
(see your device’s instruction
manual for information on
activating its Bluetooth®settings).
3. Press and hold the Play button on
your BRAVEN until you hear the
BRAVEN pairing sound.
4. Go to your phone or device’s
Bluetooth®settings and select
“BRAVEN 805,” “BRAVEN 1100”
or “BRAVEN BRV-HD” from the
list.
5. If asked for a passcode enter “0000.”
Your BRAVEN will remember the last 8 devices it has
paired with.
NOTE: If your BRAVEN does not have an active
Bluetooth®connection and is left on, it will
ZO\[P[ZLSMVɈHM[LY TPU\[LZ;VYLZ[HY[`V\Y
BRAVEN you will need to press and hold the
WV^LYI\[[VUMVYZLJVUKZ

3Full manual and troubleshooting: braven.com/manuals
CHARGING YOUR BRAVEN
• Before using your BRAVEN for the first
time, charge the unit until all 5 Battery
Indicator Lights are solid (not flashing),
indicating a full charge (typically 4 to 6
hours).
• To charge your BRAVEN, plug in the wall
power adapter. Plug the connector end of
the cable into the BRAVEN charging port.
Your BRAVEN 1100 or BRV-HD speaker is designed
to charge USB devices that draw from 0.3A - 2A using
the full sized USB port, including most tablets and
cell phones. The BRAVEN 805 speaker will charge at
speeds of up to 1A. To use external charging:
1. Turn your BRAVEN on.
2. Plug the USB power cable that came with your
phone, mp3 player, or other mobile device into
the USB port on your BRAVEN.
3. Plug the other end of the cable into your mobile
device, and it will immediately begin charging.
CHARGING EXTERNAL DEVICES

4
ENG
SPEAKERPHONE WATER-RESISTANT FEATURE
(BRV-HD ONLY)
Press the Play button on your BRAVEN to answer
the call over the speaker. Press the Play button again
to end the call.
BRAVEN 8 Series speakers include a proprietary,
bass-enhancing technology from DTS Audio called
SRS WOW HD. To activate SRS WOW HD, press the
volume up and volume down buttons simultaneously
for two seconds while music is playing on the
speaker. Press the volume up and down buttons
again for two seconds to turn off SRS WOW.
• The BRV-HD is IPX3 water-resistant.
BRV-HD speakers are not intended to be
submerged in water, but are resistant to light
rainfall and light water splashing.
• IMPORTANT: To ensure your BRV-HD
speaker is prepared for use in a wet
environment, remove all cable connections
and tightly close the side water cap. If the
water cap is not properly closed, the BRV-
HD will not be water resistant.
DTS AUDIO

5Full manual and troubleshooting: braven.com/manuals
PAIR TWO 8-SERIES SPEAKERS TOGETHER FOR EVEN BIGGER SOUND
Two BRAVEN 8-series units (BRAVEN 805,
1100, BRV-HD, 850, and 855s) can be
paired together for left and right stereo using
“TrueWireless™” technology by following
these instructions precisely:
1. Disconnect all Bluetooth®connections
(if any) on your cell phone, tablet, or other
Bluetooth®source and remove any previously
paired 8-series speakers from your device.
2. Press and hold the Battery Check button
on both 8-series speakers for 5 seconds
until you hear a sonar sound from both speakers.
Within 30 seconds, a second beep will indicate a
TrueWireless™connection between the speakers.
3. Follow the regular procedure to Bluetooth ®
pair your Bluetooth®device with either one of your
8-series units.
When you turn off either of the paired speakers while
connected in TrueWireless™, both speakers will turn
off. To regain TrueWireless™, press the Power Button
on both 8-series speakers within 5 seconds of each
other. Wait approximately 15 seconds.

6
ENG
The speakers will automatically reconnect to each
other and to the previously connected device. You
will hear two beeps indicating TrueWireless™is
reestablished.
TrueWireless™Note
TrueWireless™technology only supports one active
Bluetooth®connection to your device at the same
time. If any other Bluetooth®device (other than
the paired speakers) is simultaneously connected
to your device, the BRAVEN speaker’s audio will
distort. If distortion occurs, power down all other
Bluetooth®devices in range of your device, other
than the paired 8-series speakers. Refresh the
Bluetooth®connections on your device by turning
Bluetooth®off and then back on. TrueWireless™
is now reestablished.
For troubleshooting and tutorial videos, please go
to www.youtube.com/bravenproducts

TUTORIALS: www.youtube.com/bravenproducts
PHONE: 1-877-9 BRAVEN (1-877-927-2836)
SUPPORT: www.braven.com/support
EMAIL: [email protected]
ONLINE: www.braven.com
MANUAL: www.braven.com/manuals
V7

WARNINGS. CAU TI ONS & LEGAL INFORMA T ION

WARNINGS,
CAUTIONS
& LEGAL INFORMATION
To
reduce the risk
of
fire or electric shock,
do
not
expose the BRAVEN
to
rain
or
moisture. The BRAVEN should
not
be
exposed
to
dr
ipping or
sp
lashing, and objects filled with liquids,
such as vases, should not be placed on
or
near it. Do not use near bathtubs, washbowls, kitchen sinks, laundry tubs,
in
a
wet
basement, near a swimming pool, or anywhere else
that water
is
present. As with any electronic products, use care
not
to spill liquids into any part
of
the product. Liquids can cause a failure and/ora fire hazard. The power supply must
be used indoors only. It is neither designed nor tested for charging outdoors, in recreation vehicles,
or
on boats. Make
no
modifications
to
the product or accessories. Unauthorized
alterations may compromise safety, regulatory compliance, and system performance, and will void the warranty.
Do
not
place any flame sources, such as lighted candles, on or near
the BRAVEN. The BRAVEN contains small parts that may
be
a choking hazard and
is
not suitable for
ch
il
dren under age 3. Before use, fully charge the battery using the supplied
power adapter. Do not continue charging the battery if it does not reach full charge within the specified charging time. Overcharging may cause the battery
to
become hot, rupture,
or
ignite.
If
you see any heat deformation or leakage, properly dispose ofthe battery. Do not attempt
to
charge the battery
in
temperatures outside the range
of
32°-104
of
(0°
-40°C).
If
the battery begins
to
leak,
do
not allowthe liquid
to
come in contact with your skin
or
eyes.
If
contact has been made, wash the affected area with plenty ofwater and seek medical
attention immediately.
Do
not expose the product or battery
to
excessive heat, including direct sunlight orfire and storage
or
use inside cars in hot weather, where it can
be
exposed
to
temperatures in excess of 115°F (60°C}. Doing so may cause the battery and power supply
to
generate heat, rupture, or ignite. Using the product
in
this manner also may result
in
a loss of performance and a shortened life expectancy. Extended exposure
to
direct sunlight may damage the external appearance and material qualities.
Do
not step on, throw,
or drop batteries or the power supply or device,
or
expose them
to
a strong shock. Do
not
pierce, crush, dent, or deform the batteries
or
power supply
in
any
way.
If either becomes
deformed, properly dispose
of
it. Do not short-circuit batteries. Refer all servicing
to
qualified service personnel. Servicing
is
required when the apparatus has been damaged
in
any
way: such as power supply cord or plug is damaged; liquid has been spilled
or
objects have fallen into the BRAVEN; the BRAVEN has been exposed to rain
or
moisture, does
not
operate normally, or has been dropped. Do
not
attempt
to
service the BRAVEN yourself. Opening
or
removing covers may expose you
to
dangerous voltages or other hazards and
will void the manufacturer's warranty.
To
prevent risk
of
fire
or
electric shock, avoid overloading
wa
ll
outlets, extension cords,
or
integral convenience receptacles. Do not place your
BRAVEN on high surfaces such
as
shelves. During music playback the BRAVEN mayvibrate and move which could cause the speaker
to
sh
ift and fall off
of
the edge. Your Bluetooth
device (mobile phone, music player, tablet, laptop, etc.) must support the A2DP Bluetooth profile
in
order
to
work wirelessly with your new BRAVEN
SIX
Series speaker. The A2DP
profile is supported by most recent mobile products with built-in Bluetooth capability. Please refer to your device's user manual for details and instruction regarding the Bluetooth
profiles it supports.This device complies with part 15
of
the FCC Rules. Operation is subject
to
the following
two
conditions:
(1)
This device may not cause harmful interference, and
(2
)
this device must accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to
part 15
of
the FCC Rules. These limits are designed
to
provide
reasonable protection against harmful interference
in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in
accordance with the instructions, may cause harmful interference
to
radio communications. However, there is
no
guarantee that interference will not occur
in
a particular installation.
BRRVEn
ENGLISh

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment offand on, the user is encouraged
to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment
and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV
technician for help.
CAUTION: Any changes
or modifications not expressly approved by the party responsible forcompliance could void the user's authority to operate the equipment.
FCC RADIATION EXPOSURE
STATEMENT: This device complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject
to thefollowing two conditions: (1) this device may not cause interference,
and
(2) this device must acceptany interference, including interference that may cause undesired operation of the device. Under Industry Canada regulations, this radio
transmitter mayonly operate using an antenna
of a type and maximum (or lesser) gain approved for the transmitter by IndustryCanada. To reduce potential radio interference
to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessaryforsuccessful
communication. The device meets the exemption from the routine evaluation limits in section 2.5
of RSS 102 and compliance with RSS-102 RF exposure, users can obtain
Canadian information
on RF exposure and compliance.
Uthium Battery installed is
not intended to be replaced by the USER.
CAUTION: Danger
of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
Where the MAINS plug is used as the disconnect device, the disconnect device shall remain readily operable.
~Correct Disposal of this product. This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible
harm
to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used
device, please use the return and collection systems
or contact the retailer where the product was purchased.
9 This product complies with California Energy Commission efficiency standards for consumer battery chargers.
srs@
WOWHD
For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Ucensing Umited. SRS and the Symbol together are registered trademarks
and
WOW HD is a trademark of DTS, LLC. ©DTS, Inc. All Rights Reserved.
" r ,r ' l ''
1
BRAVEn
I I ' \ ) I )

@) WWW.BRAVEN.COM/SUPPORT
