BRAYER BR4910 User manual

Instruction manual
Инструкция по эксплуатации
Ultrasonic humidifier BR4910
Ультразвуковой увлажнитель BR4910
brayer.ru

СОДЕРЖАНИЕ
EN......................................................................................................................................3
DE....................................................................................................................................10
RU ...................................................................................................................................18
KZ ....................................................................................................................................26

3
EN
ULTRASONIC HUMIDIFIER
BR4910
High-frequency vibration of the lamp divides water
into the smallest particles of 1-5 micron in size.
Cold water «mist» mixes well with the air and
increases the relative air humidity.
Сomfortable room humidity level should be from 40%
to 60%. Insu󰀩cient room air humidity (especially during
the heating season) negatively a󰀨ects humans’ and
pets’ health as well as plants and furniture.
DESCRIPTION
1. Lid with “mist” release nozzle
2. Water tank
3. Process chamber with «sprayer»
4. Indicators of operating modes «
HUMHUM
SleepSleep
»
5. On/o󰀨/operating mode selection/relative humidity
indication button « »
6. Body
EN
1
2
3
Pic. 1 Pic. 2 Pic. 3
54
6

4
EN
SAFETY MEASURES AND OPERATION
RECOMMENDATIONS
Read the operation instructions carefully before
using the ultrasonic air humidier, after reading
keep them for future reference.
• Use the unit for its intended purpose only, as
specied in this manual.
• Mishandling the unit can lead to its breakage and
cause harm to the user or damage to the user’s
property, which is not covered by warranty.
• Make sure that the operating voltage of the unit
indicated on the label corresponds to your home
mains voltage.
• Place and use the Ultrasonic humidier on a at
dry and water-resistant surface. The distance to the
walls, other furniture and interior objects should be at
least 30 cm.
• Do not place the Ultrasonic humidier near
computers or other sensitive electronic appliances.
• Do not place the unit on carpet surfaces with high
pile.
•
• Do not use the Ultrasonic humidier outdoors.
• It is not recommended to use the unit during lightning
storms.
• Protect the unit from impacts, falling, vibrations and
other mechanical stress.
• Never leave the unit connected to the mains
unattended.
• Do not use the unit near heating appliances, heat
sources or open ame.
• Do not use the unit in places where aerosols are
used or sprayed and close to inammable liquids.
• Do not use the unit in proximity to the kitchen sink, in
bathrooms, near swimming pools or other containers
lled with water.
• If the unit is dropped into water, unplug it
immediately, and only then you can take the unit out
of water.
• Do not let the power cord touch hot surfaces and
sharp edges of furniture.
• Unplug the unit after usage or before cleaning. When
unplugging the unit, hold the power plug and carefully
remove it from the mains socket, do not pull the
power cord, as this can lead to its damage and cause
a short circuit.
• Do not touch the unit body, the power cord and the
power plug with wet hands.
• Use only the removable parts supplied with the unit.
• Use tap water cleaned with domestic water lters,
distilled or boiled water. The water temperature
should not exceed +40°С.
• Do not use sparkling or dirty water, do not add any
perfume additives into the water tank.
• Do not switch the unit on without water tank or if the
water tank is empty.

5
EN
• Switch the Ultrasonic humidier o󰀨 when the water
tank is empty.
• Unplug the unit before removing the water tank.
• Do not cover the Ultrasonic humidier during the
operation.
• Do not cover the air inlets on the unit body and avoid
getting of foreign objects inside them.
• Do not immerse the Ultrasonic humidier, the power
cord or the power plug into water or any other liquids.
• Do not move or tilt the unit during the operation, do
not remove the water tank.
• Switch the unit o󰀨 and unplug it, pour the water out of
the tank and
• the process chamber during cleaning or when you do
not use the unit.
• Unplug the unit before moving it to another place. Be
careful when carrying the unit, hold in by the body
with both hands.
• Clean the unit regularly.
• For child safety reasons do not leave polyethylene
bags used as packaging unattended.
ATTENTION!
Do not allow children to play with polyethylene bags
or packaging lm. Danger of su󰀨ocation!
• The unit is not intended for usage by children.
• Do not leave children unattended to prevent using
the unit as a toy.
• Do not allow children to touch the operating surface,
unit body, power cord or power plug during operation
of the unit.
• Close supervision is necessary when children or
disabled persons are near the operating unit.
• During the unit’s operation and breaks between
operation cycles, place the unit out of reach of
children.
• The unit is not intended for usage by physically or
mentally disabled persons (including children) or by
persons lacking experience or knowledge if they are
not under supervision of a person who is responsible
for their safety or if they are not instructed by this
person on the usage of the unit.
• Regularly check the integrity of the power cord.
• If the power cord is damaged, it should be replaced
by the manufacturer, a maintenance service or by
similar qualied personnel, to avoid danger.
• Do not repair the unit by yourself. Do not
disassemble the unit by yourself; in case of any
malfunction or if the unit is dropped, unplug it and
apply to the service center.
• To avoid damages, transport the unit in original
package only.
• Keep the unit in a dry cool place out of reach of
children and disabled persons.
THE UNIT IS INTENDED FOR HOUSEHOLD USE
ONLY, DO NOT USE THE UNIT FOR COMMERCIAL
OR LABORATORY PURPOSES.

6
EN
BEFORE THE FIRST USE
After the unit’s transportation or storage at negative
temperature, unpack it and wait for 3 hours before
using it.
• Use the humidier at the room temperature from
+10° С to +40°С and
• relative humidity less than 80%.
• Unpack the unit and remove all the packaging
materials.
• Keep the original package.
• Read the safety measures and operating
recommendations.
• Check the delivery set.
• Examine the unit for damages, in case of damage do
not plug it into the mains.
• Make sure that the indicated specications of the
power supply voltage of the unit correspond to the
specications of your mains. When using the unit in
the mains with 60 Hz frequency, the unit does not
need any additional settings.
USING THE AIR HUMIDIFIER
• Remove the lid (1) from the reservoir (2) (g. 1).
• Fill the water tank (2) with the required amount of
water.
• Notes: — if the tap water used is hard, use water
cleaned with household lters or mix tap water with
distilled water in proportion 1:1.
• Install the lid (1) on the reservoir (2) (g. 3).
• Wait till the process chamber (3) is lled with water.
• Insert the power plug into the mains socket. You’ll
hear a beep.
• Switch the air humidier on pressing the button (5)
« », the air humidier will switch on The humidier
operating modes will be displayed by the indicators
(4) «
HUMHUM
SleepSleep
».
• By repeatedly pressing the button (5) « », select
the humidication intensity level « », the
mode of maintaining the relative humidity in the room
«
HUMHUM
» or the night mode «
SleepSleep
».
• In the mode of maintaining the relative humidity «
HUMHUM
»,
the humidier will automatically set the humidication
intensity which is displayed by the indicators (4) «
» depending on the relative humidity in the
room.
• • The relative humidity in the room is indicated by the
colored illumination of the button (5) « »:
- Orange — low relative humidity;
- Green — relative humidity in the room
corresponds to the humidity installed by default;
- Blue — high relative humidity.
• By repeatedly pressing the button (5) « », select
the night mode «
SleepSleep
». The humidier will switch on to
the minimum humidication intensity in night mode,
and the indicator (4) « » will light up.
• If the water tank (2) is empty, the button (5) « »
lighting will light up red.

7
EN
• Remove the power plug from the mains socket.
• Fill the tank (2) with water, install it to its place and
switch the unit on.
• After the operation switch the air humidier o󰀨 and
unplug the power cord plug from the mains socket.
CLEANING AND MAINTENANCE
• Hard water causes the appearance of mineral scale
inside the process chamber (3), on the sprayer and
in the water tank (2); mineral scale leads to improper
operation of the humidier.
• It is recommended to clean the process chamber (3)
and the sprayer weekly, and to change water in the
water tank (2).
• If you are not going to use the Ultrasonic humidier
for a long time:
- pour the water out of the water tank (2) and the
process chamber (3)
- wash and clean the process chamber (3) and the
sprayer
- wash the water tank (2)
- dry the unit thoroughly and take it away for
storage.
WARNING!
Always switch the Ultrasonic humidier o󰀨 and unplug
it before maintenance works or cleaning.
WEEKLY CARE
• Once a week wash the water tank (2), the process
chamber (3) and the sprayer with warm water and
neutral detergent and rinse thoroughly with water.
• Add some detergent drops on the sprayer and wait
for several minutes. Remove the deposits from the
sprayer surface with a brush.
• Notes: — you can use scale removal substances for
electric kettles as a cleaning agent for the process
chamber (3) and the sprayer strictly following the
instruction.
• Clean the unit body (6) with a slightly damp cloth and
then wipe the body (6) dry.
• Do not immerse the unit body (6), the power cord and
the power plug into water or other liquids. Provide
that no liquid gets inside the unit body (6).
• Do not use solvents or abrasives to clean the surface
of the body (6) and the water tank (2).
STORAGE
• Clean the Ultrasonic humidier before taking it away
for storage, make sure that the Ultrasonic humidier
parts are dry, pack the Ultrasonic humidier in the
original package.
• Do not store the unit with remaining water in the tank
(2) and the process chamber (3).
• Keep the Ultrasonic humidier in a dry cool place out
of reach of children and disabled persons.

8
EN
TROUBLESHOOTING
Problem Possible causes Troubleshooting
The indicator
doesn’t light up, no
mist release
No supply voltage or
the mains socket is
damaged.
Connect the unit to
the mains.
Plug another, known
good appliance to
the socket to make
sure that the socket
works properly.
The indicator is
glowing red, no mist
release.
The water tank is
empty.
Fill the water tank
with water.
Released mist has
foreign smell.
First use of the unit.
Drain the water from
the water tank and
leave it open for
several hours in a
cool place.
Stale water in the
tank.
Unplug the unit,
remove the water
tank, pour out the
water, wash the tank
and ll it with clean
water.
Low mist release
intensity
Mineral scale on the
sprayer.
Unplug the unit and
clean the sprayer.
DELIVERY SET
1. Ultrasonic humidier assembled — 1 pc.
2. Manual — 1 pc.
TECHNICAL SPECIFICATIONS
• Power supply: 220-240 V, ~50-60 Hz
• Rated input power: 26 W
• Water tank capacity: 4.0 l
• Water discharge: ≥ 300 ml/h
• Humidied area: up to 30 sq.m.
RECYCLING
To prevent possible damage to the
environment or harm to the health of people
by uncontrolled waste disposal, after
expiration of the service life of the unit or the
batteries (if included), do not discard them
with usual household waste, but take the unit and the
batteries to specialized stations for further recycling.
The waste generated during the disposal of the unit
is subject to mandatory collection and consequent
disposal in the prescribed manner.

9
EN
For further information about recycling of this product
apply to a local municipal administration, a disposal
service or to the shop where you purchased this
product.
The manufacturer reserves the right to change the
appearance, design and specications not a󰀨ecting
general operation principles of the unit, without prior
notice.
3 yearsThe unit operating life is 3 years
The manufacturing date is specied in the serial
number.
In case of any malfunctions promptly apply to the
authorized service center.

10
DE
ULTRASCHALLBEFEUCHTER BR4910
DE
Hochfrequente Schwingungen des Strahlerzeugers
zerschmettern Wasser in Feinstanteile von 1 bis 5
Mikrometer groß, kalter «Wasserdampf» vermischt
sich gut mit der umgebenden Luft, indem er relative
Luftfeuchtigkeit erhöht.
Das Behaglichkeitsniveau der relativen
Raumluftfeuchtigkeit soll von 40% bis 60% betragen.
Unzureichende Raumluftfeuchtigkeit besonders in
der Heizungsperiode wirkt sich auf menschliche
Gesundheit, Haustiere, Hauspanzen und Möbelstücke
negativ aus.
BESCHREIBUNG
1. Deckel mit Dampfablassdüse
2. Wasserbehälter
3. Arbeitskammer mit Zerstäuber
4. Betriebsartanzeiger «
HUMHUM
SleepSleep
»
5. Ein-/Ausschalttaste/Betriebsartauswahltaste/
Relativfeuchtigkeitsanzeiger « »
6. Gehäuse
1
2
3
Abb. 1 Abb. 2 Abb. 3
54
6
