2 Leg Quick Connect Desk
Assembly Instructions
a. Assembly Diagram
[e-mail]
P: 905.873.8509 Toll Free: 1.877.260.4309
http://brc.group/
Page 1of 8
2 Leg Quick Connect Desk
Assembly Instructions
a. Assembly Diagram

[e-mail]
P: 905.873.8509 Toll Free: 1.877.260.4309
http://brc.group/
Page 2of 8
b. Packing list
Base Frame Component
1. Foot
------------------------------------------------------------------ 2pcs
2. Lifting Column
------------------------------------------------------------------ 2pcs
3. Side Support
------------------------------------------------------------------ 2pcs
4. Framework-1
------------------------------------------------------------------ 1pcs
5. Extendable Tube
------------------------------------------------------------------ 2pcs
6. Framework-2
------------------------------------------------------------------1pcs
Hardware Components
7. Bolt M6x12
------------------------------------------------------------------ 8pcs
8. Rubber Bumper
----------------------------------------------------------------- 10pcs
9. Screw #12x3/4
----------------------------------------------------------------- 14pcs
10.Bolt M6x10
------------------------------------------------------------------ 8pcs
11.Leveling Glides-1”
------------------------------------------------------------------ 4pcs
12.Star Washer
------------------------------------------------------------------ 8pcs
13.Bolt M6x16
------------------------------------------------------------------ 8pcs
14.Screw #8x3/4
----------------------------------------------------------------- 7pcs
15.4mm Hex Bit
------------------------------------------------------------------ 1pcs
16.4mm Hex Wrench-
Ball Point
------------------------------------------------------------------ 1pcs
17.Cable Tie
------------------------------------------------------------------ 5pcs
Electric Components
18.Power Cord-108”
------------------------------------------------------------------ 1pcs
19.Patch Cord-59”
------------------------------------------------------------------ 2pcs
20.Control Box 2 Outlet
------------------------------------------------------------------ 1pcs
21.Handset
------------------------------------------------------------------ 1pcs
c. Base Frame Setup.
1. Take out the Framework from carton and extend the outer frame sections.
