BRC NoLita User manual

NoLita Installation Guide
1

1
POSITION THE FRONT AND RETURN BASE AS SHOWN BELOW, SO THAT THE
CONNECTION POINTS WILL BE IN FRONT OF EACH OTHER
FRONT BASE RETURN BASE
2
REMOVE ALL TRIMS EXCEPT FOR THE FRONT (MODESTY) TRIM.
2

3
REMOVE ALL PANELS:FIRST MOVE THEM UP, AND THEN PULL THEM BACK.
4
CONNECT THE TWO FRAMES TOGETHER USING THE HARDWARE SHOWN BELOW.
MAKE SURE ALL CONNECTIONS ARE TIGHT
X 4 X 4 X 4
3

5
6
CONNECT THE LIFTING COLUMN WIRING AND POWER THEM UP.
POSITION THE LIFTING COLUMNS AT MAXIMUM HEIGHT.
4
CONNECT THE WIRE MANAGER BRACKET TO THE SPECIFIED LOCATION
WITH THE PROVIDED SELF TAPPING SCREWS.
REPLACE TRIMS AND PANELS.
X 2

7
LEVEL THE BASE USING THE LEVELERS UNDER EACH LIFTING COLUMN.
8LEVELERS
PLACE THE WORK SURFACES ON THE TOP FRAMES AND ALIGN THEM USING THE
PILOT HOLES. PILOT HOLES SHOULD BE ALIGNED WITH END BRACKET HOLES.
ALL WORK SURFACES ON ONE SIDE HAVE 3 PILOT HOLES AND ON THE OTHER SIDE
ONLY 2. THE SIDE THAT HAS 3 PILOT HOLES WILL ALWAYS SIT TOWARD THE
CONNECTION POINT OF THE WORK SURFACES AND THE SIDE THAT HAS 2 PILOT
HOLES WILL SIT ON THE ENDS.
MAKE SURE THERE IS A 3/4" GAP IN BETWEEN TWO WORK SURFACES.
X 32
5
